peerless-AV ESA763PU Guide

ISSUED: 01-05-11 SHEET #: 061-9062-7 03-22-12
Models: ESA763PU
Installation and Assembly:
Corrosion Resistant Articulating Mount for Indoor or Outdoor
37"- 63"Flat Panel Displays
2300 White Oak Circle • Aurora, Il 60502 • [phone] • Fax: [phone] • www.peerless-av.com
Max UL Load Capacity: 200 lb (90.7 kg)

2 of 50 ISSUED: 01-05-11 SHEET #: 061-9062-7 03-22-12
Note: Read entire instruction sheet before you start installation and assembly.
Table of Contents
Parts List.............................................................................................................................................................................3, 4
Wall installation...................................................................................................................................................................6, 7
Installing Adapter Brackets to Display...............................................................................................................................8-13
Mounting Flat Panel Display.................................................................................................................................................14
Cable Management..............................................................................................................................................................16
Tools Needed for Assembly
• stud finder ("edge to edge" stud finder is recommended)
• phillips screwdriver
• drill
• 3/16" (5mm) drill bits for wood studs, 13/32" (10mm) drill bits for concrete
• level
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US
customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact
your local distributor.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Due to outdoor environmental conditions such as heavy snow, hail, rain, etc. the environmental mount and
hardware must be inspected at least once a year. This product should not be exposed to high winds.Aqualified
installer or inspector must check for signs of rust, loose fasteners, bent metal, etc. If evidence of excessive wear,
deterioration or any unsafe condition is observed, this product must be taken out of service immediately. Direct all
inquiries to customer care if you have any questions.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
• Never exceed the Maximum UL Load Capacity. See page one.
• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of
an "edge to edge" stud finder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws firmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding
power.
• This product was designed to be installed on the following wall construction only;
WALL CONSTRUCTION HARDWARE REQUIRED
• Wood Stud Included
•Wood Beam Included
•Solid Concrete Included
•Cinder Block Included
•Metal Stud Contact Qualified Professional (not evaluated by UL)
•Brick Contact Qualified Professional (not evaluated by UL)
•Other or unsure? Contact Qualified Professional
WARNING

3 of 50 ISSUED: 01-05-11 SHEET #: 061-9062-7 03-22-12
ESA763PU
Description Qty. Part #
A
wall arm assembly 1 095-T1994
Buniversal adapter bracket 1 095-T1635-2
C3" wood screw 3 520-D1243
D10mm concrete anchor 4 590-0321
EM10 x 15mm socket head screw 2520-D1262
Fwall plate cover 2590-1325
Gcable ties 16 590-1168
H6mm allen wrench 1 560-9716
I5mm allen wrench 1 560-9640
Jrear cable cover 4 590-P1326
K
front cable cover 4 590-P1327
L5/32" allen wrench 1 560-9646
M2.5" security wood screw 1 520-D1668
Parts List
BCD
EG
M
H
J
L
F
K
I
A
Parts may appear slightly different than illustrated.
Before you begin, make sure all parts shown are included with your product.

4 of 50 ISSUED: 01-05-11 SHEET #: 061-9062-7 03-22-12
Adapter Bracket Fasteners
M4 x 12 mm (6)
(510-D1079)
M4 x 25 mm (4)
(510-D1082)
M5 x 12 mm (4)
(520-D1064) M5 x 25 mm (4)
(520-D1122)
M8 x 12 mm (6)
(520-D1068)
M8 x 40 mm (4)
(520-D1152)
M8 x 25 mm (4)
(520-D1101)
I.D. .34" (4)
(540-1059)
I.D. .22" (4)
(540-1057)
M6 x 30 mm (4)
(520-D1067)
M6 x 12 mm (4)
(520-D1050)
M6 x 25 mm (4)
(520-D1211)
M6 x 20 mm (4)
(520-D1554)
multi-washer (6)
(580-D1036)

5 of 50 ISSUED: 01-05-11 SHEET #: 061-9062-7 03-22-12
1/4-20 X 17 MM SCREWS WALL PLATE
WALLARM
SLIDE PLATE
WALL PLATE RAIL
NOTE: If mounting wall arm (A) to wood stud walls, slots on wall plate must align to wood studs.
Determine desired location of display center detailed in step 2.
Measure the distance from the center of wall arm (A) to desired display center. Loosen four 1/4-20 x 17mm screws
using 5mm allen wrench (I). Slide wall arm assembly 4-1/2" to the left or right as shown in figure 1.1. NOTE: Align
bevels (dots) of slide plate with bevels (dots) of wall plate rails as shown in detail 1 then retighten 1/4-20 x 17mm
screws.
Do not adjust arm while display is attached.
Skip to page 6 for Wood Stud Installation.
Skip to page 7 for Concrete and Cinder Block Installation.
1
Optional Horizontal Adjustment of Wall Arm on Wall Plate
fig. 1.1
DETAIL 1

6 of 50 ISSUED: 01-05-11 SHEET #: 061-9062-7 03-22-12
9"
(229 mm)
Use a stud finder to locate the edges of the studs and draw a vertical line down the center of each stud. Determine
and mark the desired display center on the wall. Place wall plate template (wall arm) on wall with top mounting slots
9" (229mm) above desired display center as shown in figure 2.1. Level wall plate template (wall arm) on wall and
mark center of four mounting holes making sure that the mounting holes are on the stud centerlines. Drill four 3/16"
(5mm) dia. pilot holes to a depth of 3" (76mm). Attach wall arm (A) to wall using three wood screws (C) and one
security wood screw (M) as shown in fig. 2.2.
Level wall plate then tighten all fasteners.
Installation to Double-Stud Wall
2
• Installer must verify that the supporting surface will safely support the combined load of the equipment and all
attached hardware and components.
• Tighten wood screws so that wall plate is firmly attached, but do not overtighten. Overtightening can damage the
screws, greatly reducing their holding power.
• Never tighten in excess of 80 in. • lb (9 N.M.).
• Make sure that mounting screws are anchored into the center of the stud. The use of an "edge to edge" stud finder
is highly recommended.
• Hardware provided is for attachment of mount through standard thickness drywall or plaster into wood studs.
Installers are responsible to provide hardware for other types of mounting situations (not evaluated by UL).
WARNING
A
WOOD STUD
WOOD STUD
fig. 2.2
CS = CENTER OF DISPLAY
fig. 2.1
CS
M
C
#14 SECURITY
SCREW
5/16" WOOD
SCREW

7 of 50 ISSUED: 01-05-11 SHEET #: 061-9062-7 03-22-12
Installation to Solid Concrete or Cinder Block
Determine and mark the desired display center on the
wall. Place wall plate template (wall arm) on wall with
top mounting slots 9" (229mm) above desired display
center as shown in figure 2.1 on page 6. Level wall
plate template (wall arm) on wall and mark center of
four mounting holes. Drill four 13/32" (10mm) dia. pilot
holes to a depth of 3" (76mm). Insert anchors (D) into
four holes flush with wall as shown (right). Place wall
arm (A) over anchors and secure using three wood
screws (C) and one security wood screw (M). Level,
then tighten all fasteners.
D
2
2
A
fig. 2.3
M
C
• When installing Peerless wall mounts on cinder block, verify that you have a minimum of 1-3/8" (35mm) of actual
concrete thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount
in a solid part of the block, generally 1" (25mm) minimum from the side of the block. Cinder block must meet ASTM
C-90 specifications. It is suggested that a standard electric drill on slow setting is used to drill the hole instead of a
hammer drill to avoid breaking out the back of the hole when entering a void or cavity.
• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
WARNING
• Tighten screws so that wall plate is firmly attached,
but do not overtighten. Overtightening can damage
screws, greatly reducing their holding power.
• Never tighten in excess of 80 in. • lb (9 N.M.).
• Always attach concrete expansion anchors directly
to load-bearing concrete.
• Never attach concrete expansion anchors to
concrete covered with plaster, drywall, or other
finishing material. If mounting to concrete surfaces
covered with a finishing surface is unavoidable (not
evaluated by UL), the finishing surface must be
counterbored as shown below. Be sure concrete
anchors do not pull away from concrete when
tightening screws. If plaster/drywall is thicker than
5/8" (16mm), custom fasteners must be supplied by
installer (not evaluated by UL).
WARNING
SOLID CONCRETE
CINDER BLOCK
CUTAWAY VIEW
INCORRECT CORRECT
wall
plate wall
plate
plaster/
drywall plaster/
drywall
concrete concrete
1
3
2
D
Drill holes and insert anchors (D).
Place plate (A) over anchors (D) and secure with screws (C,M).
Tighten all fasteners.
A
D
C,M
concrete
surface
#14 SECURITY
SCREW
5/16" WOOD
SCREW

8 of 50 ISSUED: 01-05-11 SHEET #: 061-9062-7 03-22-12
NOTE: If display has a VESA 400 horizontal
mounting pattern, skip to step 3-3 or 3-4 on page
10.
NOTE: For VESA 200x200 or VESA 200x100
mount hole patterns, skip to step 4 on page 11.
NOTE: For dedicated PLP plate installation skip to
step 5 on page 13.
Remove four 1/4-20 x .6" screws using 5 mm allen
wrench (I) and loosen two 1/4-20 x 1.25" screws
1/2 turn to allow for display bracket adjustment.
1/4-20 x .6" SCREWS
1/4-20 x 1.25" SCREWS
3
To prevent scratching the display, set a cloth on a flat, level surface that will support the weight of the display.
Place display face side down and refer to display manufacturers instructions for removing obstructions from the
back of the display.Adjust display brackets to align with display mounting holes.
Measure horizontal mounting hole pattern and choose fixed stop-position from chart below.
3-1
FIXED STOP-POSTION #2
FIXED STOP-POSTION #1
FIXED STOP-POSTION #3
horizontal mounting hole pattern fixed stop-position
10-3/4" - 16-1/16" (273 - 408 mm) #1
15-1/16" - 21-9/16" (383 - 548 mm) #2
20-7/16" - 27-9/16" (519 - 700 mm) #3
Installing Adapter Brackets to Display

9 of 50 ISSUED: 01-05-11 SHEET #: 061-9062-7 03-22-12
Select the screws from the baffled fastener pack that best fit your display and secure to display following step 3-3
or 3-4 on page 10.
NOTE: Top and bottom mounting holes must be used for attaching display brackets. Middle holes should also be
used where the fasteners and displays allow.
Verify that all holes are properly aligned, then tighten screws using a phillips screwdriver.
CENTER DISPLAY BRACKETS VERTICALLY AND
HORIZONTALLY ON BACK OF DISPLAY
DISPLAY
DISPLAY BRACKETS
NOTE: "X" dimensions should be equal.
"Y" dimensions should be equal.
• Tighten screws so display brackets are firmly attached to display. Do not tighten with excessive force.
Overtightening can cause stress damage to screws, greatly reducing their holding power and possibly causing
screw heads to become detached. Tighten to 40 in. • lb (4.5 N.M.) maximum torque.
• If screws don't get three complete turns in the display inserts or if screws bottom out and bracket is still not tightly
secured, damage may occur to display or product may fail.
WARNING
YY
X
X
Installing Adapter Brackets to Display
3-2

10 of 50 ISSUED: 01-05-11 SHEET #: 061-9062-7 03-22-12
Begin with the shortest length screw, hand thread
screw through multi-washer and display brackets
(B) into display as shown below. Screw must make
at least three full turns into the mounting hole and
fit snug into place. Do not over tighten. If screw
cannot make three full turns into the display, select
a longer length screw from the baffled fastener
pack. Repeat for remaining mounting holes, level
display brackets and tighten screws.
NOTE: Spacers may not be used, depending upon
the type of display.
Skip to step 3-5.
Begin with the longest length screw, hand thread
screw through multi-washer, display brackets (B)
and spacer in that order into display as shown
below. Screw must make at least three full turns
into the mounting hole and fit snug into place.
Do not over tighten. If screw cannot make three
full turns into the display, select a shorter length
screw from the baffled fastener pack. Repeat for
remaining mounting holes, level display brackets
and tighten screws.
For Flat Back Display
For Bump-out or Recessed Back Display
3-3
3-4
DISPLAY MULTI-WASHER
SCREW
B
DISPLAY MULTI-WASHER
SPACER
B
SCREW
Center display brackets horizontally and vertically
on back of display. Tighten two 1/4-20 x 1.25"
screws. Reinstall four 1/4-20 x .6" screws using
5 mm allen wrench (I) into appropriate fixed-stop
position from chart on page 8.
3-5 1/4-20 x 1.25" SCREWS
1/4-20 x .6" SCREWS
