Peg-Perego PRIMO VIAGGIO SIP ES 30.30 User manual

Do not install or use this child restraint
until you read and understand all
instructions in this manual. To avoid
serious injuries to your baby, follow the
instructions carefully and be sure to
buckle your baby using the
5-point harness.
WARNING: Child Requirements:
Weight:
From 2,3 kg (5 pounds)
up to 13,5 Kg 30 pounds)
Maximum height: 76 cm (30 inches)
FICA1301I154
OWNER’S MANUAL
CANADA
Instructions for use EN
(LF)
Side Impact Protection
PRIMO VIAGGIO SIP 30.30

2
3 Before You Start
4 Customer Service
4 Registration Form
5 Safety
7 Safety Rules
8 Your Car Seat
9 Your Car Seat Base
10 Travel System
11 Serial Numbers
12 Installation Instructions
13 Installing the Base
14 How to Install the Base Using the
LUAS SYSTEM
17 How to install the Base Using your
VEHICLE SEAT BELT
19 Installing the Base with Different
Types of Seat Belts
21 How to Install the Locking Clip
22 Vehicle and Vehicle Seat Belts
compatibility
23 Installing the Car Seat on the Base
25
Installing the Car Seat without the Base
27 Installing the Seat with Different
Types of Seat Belts
28 How to Buckle Your Baby into the
Car Seat
33 How to Raise or Lower the Shoulder
Straps
35 Using the Car Seat Outside the
Vehicle
38 How to Use the Car Seat on Aircraft
without the Base
39 How to Use the Car Seat on Aircraft
with the Base
41 Cleaning and Maintenance
42 How to Wash the Chair Padding-
Cover removal
44 How to Wash the Chair Padding-
Refitting
46 Replacement Parts
© 2013 Peg Perego. All rights reserved.
Table of Contents

3
1 Please read this manual carefully. Keep this manual in the plastic pocket on
the base of the child car seat.
2 Review car seat parts and read through instructions. Also read the labels.
Read and understand all instructions before using this car seat.
3 Fill in and return the registration card (see page 4).
4 All assembly must be performed by an adult.
5 Do not use the car seat if damaged or parts are missing.
6 Use only the parts or accessories that come with the unit. Do not modify or
repair any part.
7 Remember: this car seat is to be installed rear facing only.
8 Peg Perego has the right to make changes to the product at any time
without notice.
Before You Start

4
Call Peg Perego CANADA customer
service at 1-800-661-5050 (toll free)
for information about repairs or spare
parts. If any part is missing or damaged,
replace with Peg Perego parts only. See
page 46 for a list of replacement parts.
If you want more than one base, you
can purchase it from your local dealer,
or you can call 1-800-661-5050
(toll free), or you can go to
www.pegperego.com.
Important! Child restraints could be
recalled for safety reasons. You must
register this restraint to be reached
in a recall. Send your Name, address,
model name, model number, date of
manufacture and date of purchase to:
Peg Perego CANADA, Inc.
585 Granite Court
Pickering Ontario Canada L1W3K1
Or call 1-800-661-5050 (toll free)
Or register online at
www.carseat-registration.pegperegocanada.com
For recall information, call Transport
Canada’s Road Safety Information
Centre at 1-800-333-0371.
Customer Service Registration Form

5
Warning
• This car seat meets or exceeds all
applicable Canada Motor Vehicle
Safety Standard 213 , 213.1
requirements for use in motor
vehicles and aircraft.
• Your child could be seriously injured
if you do not follow instructions and
warnings correctly.
• Use this car seat rear facing only.
This seat is not designed to face
forward. Serious injury or death can
occur in an accident if you install the
seat facing forward.
• Never use in a vehicle seat with an
active air bag. Read your vehicle
manual for instructions on how to
turn off the air bag.
• If your vehicle has air bags, do not
install this car seat on a seat with
an active air bags. Death or serious
injuries can occur if an air bag hits the
unit (read your vehicle owner’s manual
for instructions on where to install an
child car seat in your vehicle).
• This car seat is certified for use with
or without base. Use of the base is
highly recommended for ease of
proper installation. Install this car
seat without the base only if needed.
• Never install the car seat in the front
vehicle seat unless instructed by
Safety

6
your vehicle manual. According to
accident statistics, children are safer
when properly restrained in the rear
seating positions than in the front
seating positions.
• Install this car seat on front facing
vehicle seats only. Do not use on
rear facing or side facing seats or in
seating positions equipped with door-
mounted or motorized shoulder belts.
• If you use a lap belt or lap/shoulder
belt to install the base, you must use a
seat belt that locks in place. If it does
not lock in place, use the locking clip.
The seat belt must lock into place for
the car seat to be properly secured.
• Be sure the car seat or car seat
base are properly secured using
a vehicle seat belt or the lower
universal anchorage system (LUAS)
hereinafter referred to as LUAS (Lower
Anchorages and Tether for children).
• Always buckle your baby into the
car seat with the harness. Be sure to
latch buckles correctly.
• When lifting the seat out of the base,
be sure you first secure the handle
into the carrying position.
•
Keep fingers away from moving parts.
• Use only approved parts. Use of
unapproved parts can affect the
safety of the car seat and cause
serious injury or death in an accident.
• Complete and send in the
registration form right away.
• Always store the manual with car seat.
Keep it in the pocket on front of base.
• In case of accident: if this car seat is
involved in a car accident, it may be
no longer safe to use. You may need
to get a new unit. Call customer
service at 1-800-661-5050 (toll free)
for more information.
• Do not use Primo Viaggio SIP 30•30
with bases manufactured before
November 2011.

7
• Use only with children who weigh
between 2,3 and 13,5 kg (5 and 30
pounds) and whose height is 76 cm
(30 inches) or less. If your baby was
born with low birth weight, ask your
doctor for special instructions on
using an child car seat.
• Use this car seat in vehicles with
standard lap or lap/shoulder belts or
universal lower universal anchorage.
If your vehicle has lower anchors, use
those to secure the car seat instead
of the standard seat belt. Read your
vehicle manual to locate the lower
anchors.
• Be sure the car seat is properly
leveled. If the seat reclines too
much, your baby can be injured or
ejected from the seat. If the seat is
too upright, it can cause your baby
to have breathing problems, which
could lead to injury or death.
• Do not place car seat on countertop,
table, or soft surfaces.
• Never leave your baby alone in the
car seat. He/she could get tangled in
the straps and be seriously injured or
could move or tip the seat.
• Do not leave the car seat or base
unsecured in the vehicle, even if not
occupied. A loose car seat can injure
other passengers in a crash.
• Do not use this unit after seven (7)
years from the date of manufacture
labeled on the seat.
• Do not hang toys on handle of seat.
Safety Rules

8
HOOD
BACK
Slide adjuster
Harness strap
Anchor buckles
Release lever
FRONT
Seat handle
Seat pad for child
Side Impact
Head protection
Harness adjuster button
Harness adjuster strap
Chest harness clip
Harness buckle
Harness latch plate
5-POINT
HARNESS SYSTEM
Your Car Seat

9
Belt slots with
anti-slip rubber pads
FRONT
Level knob
Locking clip
Anchor
latches
Lower connector
system hereinafter
referred to as
LUAS strap
Level indicator
SIDE LOCKING CLIP
STORAGE
BACK
Instruction
Manual
book pocket
Your Car Seat Base

Travel System
Duette SW
Triplette SW
Aria Twin 6040
Si
Pliko Mini
Vela easy drive
Pliko Four
Switch Four
Uno
GT3
Skate
Book
Book Plus
Base
Seat
10

The following information can be
found under the front of the seat of the
Primo Viaggio Sip 30•30: product name,
production date and serial number.
Buckle production date.
Harness production date.
In the event of problems with the
product, these details will be of use to
customers.
11
Serial Numbers

12
Installation Instructions
Peg Perego Primo Viaggio Sip 30•30
is certified for use with or without
the base. Use of the base is highly
recommended because it makes
installation easier and therefore safer.
It is also certified for use on aircraft with
or without the base.

13
I USING THE LUAS
SYSTEM. If your car
has “lower universal
anchorage systems
(LUAS)”, you can install
the child car seat using the
LUAS system instructions on page
14. The anchor is a bar located where
the seat back meets the seat bottom
(slide your hand down between the
seat back and seat bottom to locate
this bar).
Important! Also read your vehicle
manual for locating lower anchors
and instructions on using the LUAS
system.
II USING THE STANDARD LAP BELT/
SHOULDER STRAP. If your car does
not have universal lower anchors,
install the child car seat using the
instructions for lap/shoulder belt
straps on page 17.
When using Primo Viaggio Sip 30•30 with its base, first you install the base,
and then you install the car seat on the base.
Important! Read your vehicle manual for instructions on where to best install an
child car seat in your vehicle.
There are two ways to install the base:
Installing the Base

14
Install the base with your vehicle parked
on level ground.
1• Take the car seat off the base by
moving the handle to the upright
position. Place your hand on the top
of the seat back and pull up on the
handle with your fingers.
Note: Pulling near the center of the
handle provides the easiest release.
2• Position the base rear facing in the
back seat of your vehicle. Check the
level indicator on the side of the
base to make sure that the pointer
is in the green area. If it is not, turn
the knob left or right until it is in the
correct position.
I - How to Install the Base Using the LUAS SYSTEM

15
A
PUSH
B
A
PUSH
B
3• Remove the two LUAS latches from
their storage housings. The latches
are on the sides of the base. First
loosen the LUAS strap by pressing on
the gray button and pulling the strap
as shown. Then press the red button
on top of the latch and pull the latch
out of its housing. Repeat on other
side.
4• Push each latch onto the anchor bar
located between your vehicle seat
back and seat bottom. Press until
you hear the click.

16
5• Make sure that the LUAS strap is
threaded flat against the base.
6• Tighten the base against the seat
by pulling the free end of the LUAS
strap. Press down on the base with
your body weight and tighten
further. Check the level indicator. If
the pointer has moved outside of the
green area, turn the knob until the
pointer is back within the green area.
You may need to loosen the strap
slightly to do this. Push and pull on
the base. If you can move it more
than 2,5 cm (1 inch), tighten the belt
further.
• Now that you have installed the
base, go to page 23.

17
Important! Not all seat belts work
the same way. To make sure that the
child car seat is properly installed
using your seat belts, read your vehicle
owner’s manual. It will suggest proper
placement of an child car seat in your
particular vehicle.
Park your vehicle on level ground.
1• Take the car seat off the base by
moving the handle to the upright
position. Place your hand on the top
of the seat back and pull up on the
handle with your fingers.
Note: Pulling near the center of the
handle provides the easiest release.
2• Position the base rear facing in the
back seat of your vehicle. Check the
level indicator on the side of the
base to make sure that the pointer
is in the green area. If it is not, turn
the knob left or right until it is in the
correct position.
II - How to Install the Base Using Your VEHICLE SEAT BELT

18
3• Thread the lap belt through the slots
on the base and lock the latch plate
into the buckle as shown.
4• Pull the strap to tighten the seat
belt. Press down on the base with
your body weight and pull the strap
tighter. Then push and pull on the
base. If you can move the base more
than 2,5 cm (1 inch), tighten the belt
further. Once the base is tight, check
the level indicator. If the pointer has
moved outside of the green area,
turn the knob until the pointer is
back within the green area. You may
need to loosen the strap slightly to
do this.
Warning! If you cannot get the belt
tight enough, refer to your vehicle
manual for instructions on how to
secure the base using the type of seat
belt in your vehicle. Your baby is not
safe riding in a loose car seat.

19
Installing the Base with Different Types of Seat Belts
Primo Viaggio Sip 30•30 is designed for
use with lap or lap/shoulder seat belts.
Four of the most common types are
listed below. Please read your vehicle
manual for instructions on installing an
child car seat using your vehicle seat
belts.
I Lap/Shoulder belt with
Switchable Locking Retractor
If your vehicle has Switchable
Locking Retractor lap/shoulder belts,
pull the shoulder strap all the way
out, let it retract several inches, then
pull it out again. It should lock in
place to properly secure the base.
II Lap/Shoulder belt with
Emergency Locking Retractor
(ELR) and free sliding latch plate
This type of seat belt will only lock
in an emergency, so you must use

20
the locking clip (stored on child seat
base) to properly secure this type of
seat belt (see page 21).
III Lap/shoulder belt with a locking
latch plate
If you have a lap/shoulder belt with
a locking latch plate and the belt
comes loose after buckling, unbuckle
it, flip it over, and re-buckle. This will
usually keep the seat belt locked
in place. If not, read your vehicle
manual for specific instructions.
IV Different Types of Lap Belts
Lap belts with Emergency Locking
Retractors (ELR), Automatic Locking
Retractors (ALR), and Switching
Locking Retractors (SLR) look as
shown. Consult your vehicle owner's
manual to determine which style you
have. Lap belts with locking latch
plates look as shown.
V Lap belt only with an Emergency
Locking Retractor
If you have a lap belt (without
shoulder strap) that locks only in an
emergency (ELR), do not use it to
secure the Primo Viaggio Sip 30•30
car seat. Please consult a certified
child Passenger Safety Technician for
other installation options.
