Peg-Perego Primo Viaggio User manual

CA
Instructions for use EN
FICA2203I348
WARNING: Do not install or use this child restraint until you read and understand all
instructions in this manual. To avoid serious injuries to your child, follow the instructions carefully and
be sure to buckle your child at all times.
Weight limits in
rear-facing mode
with vehicle belt:
2.3 - 18 kg (5 - 40 pounds)
Weight limits in rear-facing
mode with UAS:
2.3 - 16 kg (5 - 35 pounds)
maximum height:
119 cm (47 inches)
Weight limits in
forward-facing mode
with vehicle belt:
10 - 29.5 kg (22 - 65 pounds)
Weight limits in
forward-facing mode
with UAS:
10 - 18 kg (22 - 40 pounds)
maximum height:
125 cm (49 inches)
Weight limits in
booster mode :
18 - 54 kg (40 - 120 pounds)

- 2 -
Table of Contents
Introduction page 4
Weight and dimension range page 6
Safe practices page 8
Warning page 9
Registration form and recall page 12
A car seat that grows with the child page 13
When is a child ready to ride without a booster seat page 15
Product Function
• Turning the seat from forward to rear facing orientation page 16
• Integrated ARB spacer page 17
• Latch strap page 18
• Top tether page 21
• Seat reclining page 22
• Headrest adjustment page 24
• Harness system page 25
• Tri-stage cushion page 27
• Kinetic pods page 28
• Booster mode conversion page 29
• Cup holder page 32
Vehicle compatibility page 33
UAS system - what is it and where is it in the vehicle page 35
Seat belts - which ones are safe to use with this car seat page 38
Installing the car seat in a vehicle

- 3 -
© 2022 Peg Perego. All rights reserved.
Table of Contents
• rear facing mode preparation page 43
• rear facing installation using UAS system (LUAS) page 44
• rear facing installation using vehicle belts page 45
• forward facing mode preparation page 48
• forward facing installation using UAS system page 49
• forward facing installation using vehicle belts page 51
Installing your child restraint in an aircraft page 54
Securing your child into the child restraint
• Harness use and adjustment page 55
• Use and adjustment in booster mode page 58
Securing the child in the booster seat page 59
Cleaning and maintenance page 61
How to tell if the seat has been in a crash page 66
Replacement parts page 67
Declaration of conformity page 68

- 4 -
Introduction
Thank you for choosing Peg Perego Primo Viaggio All In One child restraint system.
As with all Peg- Perego products, your Primo Viaggio All In One has been designed and
certied by a dedicated team of engineers inside Peg Perego's Research and Development
Department. lt has been manufactured and assembled in a Peg Perego plant in Italy under
certied quality procedures using high quality materials from certied suppliers.
As with all child restraints, Primo Viaggio All In One is designed to be used by a child in a
vehicle.
Always check the product prior to use. In case of missing or malfunctioning parts, please
contact Peg Perego Canada Customer Service 1-800-661-5050 or send an e-mail to
[e-mail].
The product is composed of:
headrest with belt guides (a), shell (b), base (c) with integrated anti rebound bar (ARB) (d),
shell integrated LATCH strap (e) stored under the seat, shell integrated Top Tether Strap
(f) stored behind the backrest, integral 5 point harness (g) with chest clip (h), upholstered
seat and headrest covers (i) , Kinetic pods (j), cup holder (k), Three Stage Cushion (l) and
shoulder belt and crotch pads (m).

- 5 -
Introduction
a
k
l
c
m
m
i
h
g
b
f
d
c
j
a
b
e

- 6 -
Primo Viaggio All In One is suitable from birth
up to a recomended age of 10 years.
It can be used in three modes:
1_REAR FACING MODE WITH INTEGRAL
BELTS: 2.3 - 20.4 kg (5 - 45 pounds)
for children weighing in the range 2.3 - 18 kg (5
- 40 pounds) when installed with vehicle belts.
Maximum height: 119 cm (47 inches). Use
rear facing if head is at least one inch below
headrest edge.
LUAS System: do not install by this
method for a child weighing more
than 16 kg (35 pounds).
2_FORWARD FACING MODE WITH
INTEGRAL BELTS :
for children weighing in the range 10-29.5 kg
(22 - 65 pounds) when installed with vehicle
belts. Maximum height: 125 cm (49 inches).
Use forward facing if head is no more than
one inch above headrest edge.
UAS System: do not install
by this method for a child
weighing more than 18 kg (40
pounds).
REAR FACING
FORWARD FACING
Weight And Dimension Range

- 7 -
3_BOOSTER MODE :
For children weighing in the range 18-54 kg
(40-120 pounds) using 3-point vehicle belt
(LUAS optional).
Height limit 99-160 cm (39-63 inches).
FORWARD FACING
Weight And Dimension Range

- 8 -
Safe Practices
• Everyone buckles up, including adults in the
back seat. Make no exceptions. If someone
unbuckles, stop the vehicle. Be rm and
consistent from the start so children know
the rules. An unrestrained person increases
the risk of death for everyone else as they can
y into and injure other passengers.
• Never take a child out of a car seat for any
reason while the vehicle is moving.
• Do not leave loose objects, bags or luggage
in the passenger area. In a crash they will be
much heavier than usual and can y around
and hurt the people in the car.
• Do not leave your child unattended in the
vehicle, even for a minute. Your child can get
tangled in the seat belt and strangle. Also,
temperature inside the vehicle can change
very fast (the vehicle cockpit can become
very hot in summer and very cold in winter)
and be dangerous for your child’s health
(heatstroke can cause death in children left in
an hot vehicle, even for a short time).
• It is recomended to secure this car seat all
the time, even when the child is not in it. This
car seat is a heavy object that can severely
hurt others in a crash if it were to y around
the car. There are two ways you can secure
this car seat when the child is not in it to
prevent it from becoming a deadly projectile.
You only need to use one of these ways.
1. Use LATCH strap (see pages 18, 19, 20)
2. Use the vehicle’s seat belt to buckle in
the empty car seat .
• DO NOT give children lollipops or ice
cream on a stick while in the car. These
sticks can injure a child if the car hits a
bump or swerves.
• Do not leave the car seat under direct
sunlight for a prolonged time. The seat
may become very hot and burn your
child’s skin.
• Store the car seat in a cool, dry area if not
used for long periods. Use the travel bag
to keep it away from dust and moisture
(sold as accessory).
• Do not try to remove or add parts
unless where explained in this manual;
do not try to repair this product without
direct Peg Perego assistance . In case
of damaged or defective parts, call
Peg Perego Canada Customer Service
1-800-661-5050 or send an e-mail to
[e-mail].

- 9 -
Warning
• Do not install or use this child restraint until
you read and understand all the instructions
in this manual and the labels on the product.
To avoid serious injuries to your child,
follow the instructions carefully. Keep the
instruction manual in the dedicated pocket
for future reference.
• This car seat meets or exceeds all applicable
Canada Motor Vehicle Safety Standard 213,
213.1 requirements for use in motor vehicles
and aircraft and 213.2 for use in motor vehicles.
• When using this child restraint in rear
facing mode, never place it in vehicle seats
equipped with an active air bag. Death or
serious injuries can occur if an air bag hits the
unit. Check your vehicle owner's manual for
child restraint and vehicle seat compatibility.
• This child restraint is designed to be used
in passenger vehicles. According to accident
statistics, children are safer when properly
restrained in the rear seating positions. It is
not designed for use on three-wheel vehicles
or motor bikes.
• In case of a crash: if this car seat is involved
in a minor crash, you may continue to use it.
Otherwise, it must be replaced. If you have
questions, call Peg Perego Canada Customer
Service1-800-661-5050orsendane-mailto
[e-mail].
Refer to section at page 66 for additional
information.
• This child restraint is designed to be
installed on front facing vehicle seats only.
Never use on seats looking sideways or
rearward facing.
• This child restraint can be secured to your
vehicle by means of lap/shoulder belts in
conjunction with a top tether available in
your vehicle. However, not all available
models of seat belts are approved for use
with this product. Refer to the dedicated
section in this manual for further details.
• This child restraint can be secured to
your vehicle by means of lower universal
anchorage system (UAS in conjunction
with a top tether), both provided with this
product. Refer to the dedicated section
in this manual for installation details and
check your vehicle owner’s manual for
further details.
• Do not use in cars with door-mounted
or motorized shoulder belts. Read your
vehicle owner’s manual for additional
information.

- 10 -
• Do not use in cars equipped with inatable
vehicle belts.
• When the child restraint is installed on the
vehicle seat, check that vehicle belts or UAS
and top tether straps are snugly tted around
the child restraint structure and that there is no
slack. An incorrectly fastened child restraint may
result in an additional excursion or deceleration
on your child in case of an accident.
• Use this child restraint in rear facing mode
with vehicle belt with children weighing 2.3 –
18 kg (5 – 40 lbs) and with UAS with children
weighing 2.3-16 kg (5-35 lbs) and having a
maximum height of 119 cm (47 inches); in
forward facing mode with vehicle belt with
children weighing in the range 10 – 29.5
kg (22 – 65 lbs) and with UAS with children
weighing 10-18 kg (22-40 lbs) and having a
maximum height of 125 cm (49 inches).
• Keep your child in rearward facing mode as
long as possible: NEVER use Primo Viaggio All
In One in forward facing mode if baby weighs
less than 10 kg (22 lbs). The adjustable Anti
Rebound Bar (ARB) featured in this product is
designed to allow more leg room space when
the car seat is used rear facing.
• According to theAmerican Academyof Pediatrics
(AAP) parents should keep their children in
rear facing child restraints until the age of two
(2) or until they reach the maximum weight or
height for which the restraint is designed.
• When used in Infant Restraint and Child
Restraint mode, always restrain your child with
the 5-point integral harness provided with the
product. Be sure that the buckle is correctly
latched. Snugly adjust the belt around the
child's body making sure that the belt lies at
with no slack. Use the chest clip to be sure that
the belts are in the correct position.
• Be sure the child restraint is properly
levelled. If the seat reclines too much, your
child can be injured or ejected from the
seat. If the seat is too upright, it can cause
your child to have breathing problems,
which could lead to injury or death.
• WARNING! When restraining the child
in booster seat mode, DO NOT use
other meaning than the vehicle's lap
and shoulder belt system.
Additionally, UAS system can be used to
stabilize the seat in the vehicle or when the
seat is empty and the vehicle is moving.
• All fabric covers and pads that come with
this car seat are part of the product and the
Warning

- 11 -
certication program. The use of non approved
covers orother accessories arenot recommended
and can put your child at risk in a crash.
• The energy absorbing white foam (EPP
and EPS) located under the fabric covers is
a safety feature of this car seat and should
never be removed or damaged.
• When used in booster mode, this car seat is
not certied for aircraft use because aircraft
seats DO NOT have shoulder belts
• Bulky jackets should be removed and placed
on backwards over the child after the harness
is tted.
• Keep ngers away from moving parts.
• Do not lift this child restraint by harnesses
to avoid unnecessary wear or stress on the
webbing. Lift it by the hard structure.
• Donot placethis childrestrainton countertops,
tables or soft surfaces, elevated surfaces.
• When not in use, store the product, away
from light, moisture, excessive heat or cold.
• Expiration: do not use this car seat if it is
more than 12 years old from the date of
production labeled on the seat.
Model number, model name, date of
manufacturing, etc. are indelebly printed on
a label located in the picture shown here.
Harness serial number is also indelebly
printed on the buckle and the webbing
and could provide useful information in
case of accident or defects.
Important! Second hand: Peg Perego
does not recommend purchasing used
seats for which there is no known history.
Hidden parts of the seat may be damaged
or not working properly, thus making the
restraint dangerous or inecent in the
event of a crash.
Warning

- 12 -
Registration form and recall
Complete and send in the registration form provided with this product right away.
In case of an accident: if this car seat is involved in a car accident, it may be no longer
safe for use. You may need to get a new unit.
Call customer service @ 1-800-661-5050 or send an e-mail to
[e-mail] for help.
Important! Child restraints could be recalled for safety reasons. You must register this
restraint to be reached in a recall. Send your name, address and the restraint's model
number and manufacturing date to:
Peg Perego Canada, Inc.
585 Granite Court
Pickering Ontario Canada L1W3K1
Or call 1-800-661-5050 (toll free)
Or register online at
www.carseat-registration.pegperegocanada.com
For recall information, call Transport Canada’s Road Safety Information Centre at 1-800-
333-0371.
The registration form is attached to the product cover. Detach the form, ll in and mail to
Peg Perego. No stamp is needed. We have already paid for it. Should the registration form be
missing, please call Peg Perego Canada Customer Service 1-800-661-5050.

- 13 -
A Car Seat That Grows With The Child
Primo Viaggio All in One is designed to be
used with children weighing between 2,3
and 54 kg (5 - 120 lbs).
Many parents confuse the words “car
seat” and “booster seat”. It is important to
understand the dierence between a car
seat and a booster seat.
A car seat is a seat the child sits in and uses a
5-point harness as their restraint; it means that
the car seat is equipped with an integral harness.
A booster seat is a seat the child sits on and
uses the vehicle's seat belt as their restraint.
Along the growth of your child, Primo
Viaggio All in One will be used in 3 modes.
1. REAR FACING : from 2,3 kg (5 lbs) up to a
weight of 18 kg (40 lbs), Primo Viaggio All in
One must be used rear facing. When riding
rear facing, a child is more comfortable and
much safer than in forward facing, because
his/her back and head are fully supported
and protected by the big and deep shell
of the seat. Its integral harness guarantees
that the child is rmly attached to the seat.
An integral belt system made of a ve point
harness comprising crotch, lap and shoulder
belts, is the most eective way of protecting
a child in a frontal collision.
When rear facing, the car seat can be
adjusted in dierent reclining positions and
dierent headrest height adjustments and
thanks to the integrated leg spacer has the
possibility of staying safe and comfortable
rear facing longer.
2. FORWARD FACING : at the minimum
child’s weight of 10 kg (22lbs), the car
seat can be turned forward facing. Up to a
maximum child’s weight between 18 and
29,5 kg (40 and 65 lbs), this car seat must
be used with its integral harness. Integral
harness guarantees that crash loads are
distributed evenly on the body and the
crotch strap protects from submarining.
When used in forward facing, Primo Viaggio
All in One can be used in dierent recling
positions, for added comfort in long journeys.
3. BOOSTER: when the child structure and
stature allows, and at a minimum weight
of 18 kg (40 lbs), Primo Viaggio All in One
can be used in booster mode. Integral
harness must be removed and stored in

- 14 -
the dedicated compartment under the seat,
as the protection of the child is oered by
the vehicle belt directly. LATCH connectors
should be used in booster mode in order
to keep the car seat rm and stable on the
vehicle seat.
Booster seats are for kids who are too big for
their car seat and too small to t properly
in a seat belt. Booster seats help the child’s
body t properly on the vehicle seat. Booster
seats make the seat belt start and stay on the
correct bony parts of the child's body.
It isn't a coincidence that boosters make kids
taller. By raising the child up, boosters help
the shoulder belt t properly between the
shoulder and the neck. By raising the child up
and giving the child a shorter seat pan, the
child's knees can now bend at the edge of
the booster. This makes kids much less likely
to slouch. Slouching is dangerous as it puts
the lap belt on the soft belly which injures the
abdominal organs and spinal cord.
Before transiting from a car seat to a
booster seat, a child must meet ALL of these
requirements:
• at least 4 years old
• at least 40 pounds
• at least 39 inches tall
• able to sit properly in this booster seat
during the entire car ride - no slouching, no
playing with the seat belt, no putting the
seat belt under the arm or behind the back,
no leaning over, etc.
Most children can not sit properly in a
booster seat until at least age 5. Sitting
properly is what makes sure the seat belt ts
snugly and rests on the proper bony parts of
the body. If the child is not mature enough
for a booster, they need to ride in a car seat.
The car seat's 5-point-harness will keep them
safe and won’t let them slouch or lean over.
Does your child meet all of the requirements
above to use this booster, but also still ts
in their old car seat? Many parents can be
unsure about which seat to use. If you use
their forward-facing car seat, make sure you
always use the tether strap on that forward-
facing car seat. If you have a vehicle that
does not have a tether anchor, a booster
seat may provide better head and neck
protection than a forward-facing car seat
that isn’t tethered.
A Car Seat That Grows With The Child

- 15 -
When Is A Child Ready To Ride Without A Booster Seat
Children need a booster seat until their body ts properly on the vehicle seat AND the seat
belt ts properly on their body without the help of a booster.
Fitting properly means that you can say yes to all 5 questions below:
1. The child can sit with their back against the back of the vehicle seat.
2. The child’s knees can bend naturally at the edge of the vehicle seat without slouching.
3. The lap belt is on the lap, not on the belly.The lap belt should rest on the top of the thighs.
4. The shoulder belt is comfortable between the neck and the shoulder.
5. The child can sit like this for the entire trip.
Studies show that half of all 10 year olds need a booster seat to ride safely. By age 12 most
kids can ride safely without a booster.

- 16 -
Product Function
TURNING THE SEAT FROM FORWARD TO REAR FACING ORIENTATION
Primo Viaggio All in One is delivered with the seat oriented forward facing. In order to
change the orientation to rear facing, squeeze the handle (a) located in the back of the seat
and pull out the rebound bar (b). Keeping the handle squeezed, turn the seat (c) until you
reach the opposite direction (180°).
Pull the rebound bar back in place (d) and check that the seat is positively locked (click).
b
ac
d

- 17 -
Product Function
INTEGRATED ARB SPACER
When the seat is adjusted in rear facing mode, the anti-rebound bar can be adjusted in two
positions.
Squeeze the handle (a) and pull the rebound bar out (b). Release the handle and make sure
that it is locked in position (click).
Picture A: rebound bar fully retracted; the seat is compact when reclined.
Picture B: rebound bar fully exposed; this position allows more space for toddler legs,
especially when the seat backrest is upright.
b
b
b
a
A B

- 18 -
Product Function
LATCH STRAP
Latch strap is a part of the connecting system and it is stored in a compartment located
under the seat and covered by a lid. To access the latch strap, remove the cushions, move
the headrest up, undo the cover button and move the upholstery forward (a) as shown in
the picture.
Unsnap the lid from the compartment side (b) and open it (c).
a
c
b

- 19 -
Product Function
Pull on the red cords (a) to free the connectors.
Display the connector as shown in the picture (b) and make sure that the lid is closed.
For rear facing installation, thread the connector strap into the blue guides (c) and into the
openings in the shell, as shown in the picture.
aa
c
b

- 20 -
Product Function
Picture A shows Primo Viaggio All in One ready for installation in rear facing mode with
latch connectors.
For forward facing installation, thread the connector strap into the red guides (a) and into
the openings in the shell, as shown in the picture .
Picture B shows Primo Viaggio All in One ready for installation in forward facing mode with
latch connectors.
a
AB
