Pelgrim OVS826RVS User manual

Instructions for use
Steam oven
OVS826RVS
OVS826MAT
www.gorenje.com

We thank you for your
trust in purchasing our appliance.
This detailed instruction manual is
supplied to allow you to learn about
your new appliance as quickly as
possible.
Make sure you have received an
undamaged appliance.
Should you notice any transport
damage, please notify your dealer
or regional warehouse where your
appliance was supplied from.
The telephone number can be found
on the invoice or on the delivery
note.
Instructions for installation and
connection are supplied separately.
Important information
Tip, note
IMPORTANT SAFETY
INSTRUCTIONS
Instructions for safety are supplied separately.
CAREFULLY READ THE INSTRUCTIONS AND SAVE THEM
FOR FUTURE REFERENCE.

3
CONTENTS
782904
WARNINGS
INITIAL
PREPARATION
OF THE
APPLIANCE
SETTINGS AND
BAKING
CLEANING AND
MAINTENANCE
PROBLEM
SOLVING
4 BEFORE CONNECTING THE APPLIANCE
4 Safe and correct use of the steam oven
5 COMBINED STEAM OVEN
8 Control unit
10 Information on the appliance - data plate (depending on the model)
11 BEFORE THE FIRST USE
11 Steam cooking
12 Filling the water tank
13 FIRST USE
14 Testing water hardness
15 SELECTING THE MAIN MENUS FOR BAKING AND STEAMING
19 A) Baking by selecting the type of food (Auto)
21 B) baking by selecting an oven system (Pro mode)
25 C) Steam cooking (Steam – quick access to steam programs)
27 D) Storing your own program (My mode)
28 START OF BAKING
28 END OF BAKING AND OVEN SHUT-OFF
29 SELECTING ADDITIONAL FEATURES
31 SELECTING GENERAL SETTINGS
34 MAINTENANCE & CLEANING
35 Conventional oven cleaning
36 Steam cleaning program (Steam clean)
37 Cleaning the steam system
38 Cleaning the filter foam
39 Removing and cleaning wire and telescopic extendible guides
40 Removing and inserting the oven door
42 Removing and inserting the oven door glass pane
43 Replacing the bulb
44 TROUBLESHOOTING TABLE
45 DISPOSAL
INTRODUCTION

4
Safe and correct use of the steam oven
Leave the appliance at room temperature for
some time before connecting it to the power
mains to allow all components to adapt to
room temperature. If the oven is stored at a
temperature near or below freezing point,
there is a danger for some components,
especially the pumps.
The appliance should not operate in an
environment with a temperature below 5
°C. Below this temperature, the appliance
may not operate correctly. If the appliance
is switched on in such conditions, the pump
could be damaged.
If the appliance does not work correctly,
disconnect it from the power mains.
Do not store items in the oven, which could
cause danger when the oven is switched on.
Do not use distilled water that is not suitable
for ingestion (e.g. distilled water for batteries,
to which acid is added).
After the steam cooking is completed, there
is some residual steam in the oven. Open
the oven door carefully, as there is danger of
scalding with steam. Clean the oven once it
has cooled down to room temperature.
After the cooking process, the remaining
water in the steam system is pumped back
into the water tank. Therefore, the water
there could be hot. Be careful when emptying
the water tank.
To prevent the build-up of limescale, leave
the oven door open after cooking to allow
the oven cavity to cool down to room
temperature.
It is inadvisable to open the door during
the steam cycle, as this will increase power
consumption and formation of water
condensate.
782904
BEFORE CONNECTING THE APPLIANCE
Carefully read the instructions for use before connecting the
appliance. Repair or any warranty claim resulting from incorrect
connection or use of the appliance shall not be covered by the
warranty.

5
COMBINED STEAM OVEN
(DESCRIPTION OF THE OVEN AND ACCESSORIES – DEPENDING ON
THE MODEL)
Guides
- Cooking levels
4
3
2
1
5
Water tank door
782904
The figure represents one of the built-in appliance models. Since the appliances for which
these instructions were drawn up may have different equipment, some functions or
equipment may be described in the manual that may not be present in your appliances.
WIRE GUIDES
The wire guides allow preparation of the food on 5 levels (please note that the levels/
guides are counted from the bottom up).
Guides 4 and 5 are intended for grilling.
TELESCOPIC PULL-OUT GUIDES
Telescopic pull-out guides can be installed on the 2nd, 3rd and 4th level. Pull-out guides
can be partially or completely extractable.
OVEN DOOR SWITCH
If you open the oven door during operation, the oven heaters, fan, and steam generator
will be switched off. When the door is closed again, the switches turn the heaters and
steam injection back on.
Control unit
Oven door
Oven handle

6
782904
COOLING FAN
The appliance is fitted with a cooling fan that cools the housing and the appliance control
panel.
EXTENDED OPERATION OF THE COOLING FAN
After the oven is switched off, the cooling fan continues to operate for a short while in
order to cool the oven. (Extended cooling fan operation depends on the temperature in
the center of the oven).
ACCESSORIES (depending on the model)
GLASS BAKING DISH is used for cooking
with all oven systems. It can also be used
as a serving tray. NOT suitable for pyrolysis
cleaning.
The GRID is used for grilling or as support
for a pan, baking tray or baking dish with
the food.
There is a safety latch on the grid.
Therefore, lift the grid slightly at the front
when pulling it out from the oven.
The SHALLOW BAKING TRAY is used for
baking pastry and cakes.
The DEEP BAKING TRAY is used for roasting
meat and baking moist pastry. It can also be
used as a drip tray.
Never place the deep baking tray in the
first guide during the cooking process, except
when grilling and you are only using the deep
tray as a drip tray.
STEAM SET (INOX) is used for steam
cooking. Place the perforated steam dish
in the middle of the oven and the non
perforated steam dish one level below the
perforated steam dish.

7
782904
The grid or the tray should always be
inserted into the groove between the two
wire profiles.
With telescopic extendible guides, first pull
out the guides of one level and place the
grid or the baking tray onto them. Then,
push them in with your hand as far as they
will go.
Close the oven door when the
telescopic guides are retracted all the way
into the oven.
BAKING TRAY HOLDER makes it easier
to remove hot baking trays from the oven
after baking.
Meat temperature probe
DESCALING AGENT or steam system
cleaning.
TEST PAPER STRIP for testing water
hardness.
2
3
4
The appliance and some of the accessible parts tend to heat up
during cooking. Use oven mitts.

8
CONTROL UNIT
(depending on the model)
1ON/OFF KEY 2OVEN LIGHTING ON/
OFF KEY 3BACK KEY
Touch briefly to
return to previous
menu.
Touch and hold to
return to main menu.
4KNOB for SELECTION and
CONFIRMATION
Select the setting by
rotating the knob.
Confirm your
selection by pressing
the knob.
782904

9
5KITCHEN TIMER 6CHILD LOCK KEY 7START/STOP KEY
Touch: START
Touch during
operation: PAUSE/
STOP
8DISPLAY
NOTE:
The keys will respond better if you touch them with a larger area of your fingertip. Each
time you touch a key, this will be acknowledged by a short acoustic signal.
782904

10
782904
INFORMATION ON THE APPLIANCE - DATA
PLATE (DEPENDING ON THE MODEL)
The rating plate indicating the basic
information about the appliance is located
at the edge of the oven and it is visible
when the oven door is opened.
ASerial number
BCode
CType
DBrand
EModel
FTechnical data
GCompliance symbols

11
782904
BEFORE THE FIRST USE
Before the first use, remove all components, including any transport equipment, from the
oven. Clean all accessories and utensils with warm water and regular detergent. Do not
use any abrasive cleaners.
Before using the oven the first time, heat it without any food, in the system “Bottom and
top heat”, at the temperature of 200 °C for approximately one hour. The characteristic
smell of a “new appliance” will be emitted. Ventilate the room thoroughly during the first
use.
STEAM COOKING
Healthy and natural; steam cooking preserves the full flavour of foods. This cooking
method releases no odours.
Following are the advantages of steam cooking:
• Cooking (braising, roasting) starts before the temperature inside the oven reaches
100°C. Slow cooking (braising, roasting) is also possible at lower temperatures.
• It is healthy: vitamins and minerals are well preserved because only a small share of
them is dissolved in the condensation water that touches the food.
• There is no need to add any fat during the cooking process. The steam maintains
the taste of food. It does not add odours, nor the taste of the grill or the pan.
Furthermore, it takes nothing away because the food is not diluted in the water.
• Steam does not spread the flavour or smell; therefore, meat or fish can be cooked
together with vegetables.
• Steam is also suitable for blanching, defrosting and reheating or keeping the food
warm.

12
782904
FILLING THE WATER TANK
The WATER TANK allows for independent water supply to the steam oven. The tank volume
amounts to approx. 1.3 litres (maximum water level – see marking). This amount of water
suffices for approximately 3 hours of cooking time with the longest steam cycle (hot air with
steam on "high" system).
Clean the water tank before the first use.
Always fill the water tank with clean and cool water from the
pipeline, bottled water without additives, or distilled water suitable
for use in cooking. Water poured into the water tank should be at a
temperature of 20°C(+/– 10°C).
1Press (on the spot with the sticker) to open the tank door.
The sticker can be removed later.
2Remove the water tank from the housing by pulling by the recessed part.
3Open the lid. Wash the tank with water. Re-assemble the tank. Before use, add
fresh water up to the MAX marking on the
tank.
4Push the water tank back into the housing to the final position (until you
hear a short click). Then, press the tank
door to close it.
After the cooking process, the
remaining water in the steam system is
pumped back into the water tank. The lid
and the water tank can be washed with
standard non-abrasive liquid cleaners or in
a dishwasher.

13
782904
FIRST USE
LANGUAGE SELECTION
Upon the first connection of the appliance to the power supply or after a prolonged period of
being disconnected, please set the desired language. The default language is English.
Confirm each setting by pressing the KNOB.
By pressing the
KNOB and turning
the knob, set the
DAY, MONTH and
YEAR. Turn the
knob and confirm
your selection with a
check mark.
Turn the KNOB and
set the CLOCK.
Confirm your
selection with a
check mark.
The oven also operates if you do not set the time of day, but in this case it is not
possible to set the timer features (see chapter SELECTING TIMER FEATURES).
After a few minutes of inactivity, the appliance goes into Standby mode.
CHANGING CLOCK SETTINGS
You can change the time of day when no timer function is activated (see chapter
SELECTING GENERAL SETTINGS).
Turn the KNOB and
select the desired
language. Confirm
your selection.
SETTING THE DATE
SETTING THE CLOCK

14
782904
Incorrect water hardness level setting could affect appliance
operation and useful life.
TESTING WATER HARDNESS
Water hardness test should be carried out before first use.
A strip will appear on the display with the sign "Very hard water".
Maximum water hardness is set as a factory default.
Soak the test paper
strip (supplied
with the appliance)
in water for one
(1) second. Wait
one minute and
observe the number
of stripes on the
paper. Enter the
information on the
number of stripes
into the appliance.
Rotate the KNOB
and confirm.
4 green stripes Very soft water
1 red stripe Soft water
2 red stripes Medium hard water
3 red stripes Hard water
4 red stripes Very hard water
CHANGING THE WATER HARDNESS SETTING
Water hardness can also be set by selecting: Settings/Cooking settings/Steam.

15
782904
SELECTING THE MAIN MENUS
FOR BAKING AND STEAMING
Turn the KNOB and
select the name of
the menu. Confirm
the selection by
pressing the KNOB.
The NAME of the
selected menu
appears above.
A) Auto
In this mode, first select the type of dish and then the selected
food with automatic setting of the quantity, level of doneness and
end of operation.
The program offers a variety of pre-set recipes, tested by chefs
and nutrition experts.
B) Pro
This mode offers a selection of functions with factory pre-set
values, which you can modify.
C) Steam
This is a natural way of cooking that retains a full flavour of the
food.
D) My mode
This mode allows you to prepare dishes according to your wishes,
each time using the same steps and settings. You can save your
settings in the oven's memory and recall them the next time you
want to use them.
Confirm each setting by pressing the KNOB.

16
782904
A) BAKING BY SELECTING THE TYPE OF
FOOD (Auto)
Confirm each setting by pressing the KNOB.
Turn the KNOB
and select the
Auto. Confirm your
selection by pressing
the KNOB.
Select the type
of dish and the
selected food.
Confirm your
selection.
The pre-set values
are shown.
You can change
the quantity, level
of doneness and
delayed start (end of
baking).
1234 56
1 Quantity
2 Level of doneness
3 Delayed start
4 Duration of baking
5 Baking system and recommended level
6 Professional (Pro) mode
If in the Auto mode the symbol is selected, the program switches to Pro mode
(see chapter BAKING BY SELECTING THE MODE).
Touch the START/STOP key to start the baking process.
The display shows all the selected settings.

17
782904
PREHEATING
Cooking procedures for some dishes in the Auto mode also include the preheat function
. When you select the food, the following notification will appear: "Selected program
includes preheat function." (Confirm your selection with the KNOB.) "Preheating
started." Do not insert the food yet. Actual and set temperature will alternate on the
display.
When the selected temperature is reached, the preheating process stops and an acoustic
signal is emitted. The following notification will appear on the display: "Preheating
complete." Open the door and insert the food. The program then resumes the cooking
process with selected settings.
When the preheat function is set, delayed start function cannot be used.

18
782904
BASIC SETTINGS
1 Pre-heating
2 System (see table OVEN SYSTEMS)
3 Temperature in the oven
ADDITIONAL SETTINGS
4 Duration of baking (see chapter TIMER FUNCTIONS)
5 Multiphase cooking (see chapter Multiphase cooking)
6 Steam injection (see chapter STEAM INJECTION)
PREHEATING
Use the preheat function if you wish to heat the oven to the desired temperature as
quickly as possible. When this symbol is selected, the preheat function will be
activated and a notification will appear: "Preheating started." Do not insert the food yet.
Actual and set temperature will alternate on the display.
When the selected temperature is reached, the preheating process stops and an acoustic
signal is emitted.
The following notification will appear on the display: "Preheating complete." Open the
door and insert the food. The program then resumes the cooking process with selected
settings.
When the preheat function is set, delayed start function cannot be used.
Turn the KNOB and
select Pro. Confirm
your selection.
Select your own
basic settings.
1234 5
B) BAKING BY SELECTING AN OVEN SYSTEM
(Pro mode)
Confirm each setting by pressing the KNOB.

19
782904
OVEN SYSTEMS (depending on the model)
DESCRIPTION OVEN SYSTEMS PRESET
TEMPERATURE
(°C)
MIN – MAX
TEMPERATURE
(°C)
TOP + BOTTOM HEAT
The heaters in the bottom and in the ceiling of the oven
cavity will radiate heat evenly into the oven interior.
Pastry or meat can only be baked/roasted at a single
height level.
200 30–230
TOP HEAT
Only the heater on the oven cavity ceiling will radiate
heat. Use this heater to brown the upper side of the
dish.
150 30–230
BOTTOM HEAT
Only the heater on the bottom of the oven cavity will
radiate heat. Use this heater to brown the lower side of
the dish.
160 30–230
SMALL GRILL
Only grill heater, a part of the large grill set, will operate.
Use this heater to grill a few open sandwiches or beer
sausages, or for toasting bread.
230 30–230
LARGE GRILL
The upper heater and the grill heater will operate. The
heat is radiated directly by the grill heater installed in
the oven ceiling. To boost the heating effect, the upper
heater is activated as well. This system is used for
grilling a smaller amount of open sandwiches or beer
sausages, and for toasting bread.
230 30–230
LARGE GRILL + FAN
Grill heater and the fan will operate. This combination is
used to grill meat and to roast larger chunks of meat or
poultry at a single height level. It is also appropriate for
dishes au gratin and for browning to a crispy crust.
170 30–230
HOT AIR + BOTTOM HEAT
Bottom heater, round heater, and the fan will operate.
This is used to bake pizza, moist pastry, fruitcakes,
leavened dough and shortcrust on several levels
simultaneously.
200 30–230
HOT AIR
Round heater and the fan will operate. The fan installed
in the back wall of the oven cavity makes sure the hot
air constantly circulates around the roast or pastry. This
mode is used for roasting meat and baking pastry at
several levels simultaneously.
180 30–230
ECO HOT AIR 1)
In this mode, power consumption during the cooking
process is optimized.
This mode is used for roasting meat and baking pastry.
180 120- 230

20
782904
DESCRIPTION OVEN SYSTEMS PRESET
TEMPERATURE
(°C)
MIN – MAX
TEMPERATURE
(°C)
BOTTOM HEAT + FAN
This is used for baking leavened but low-rising pastry
and for preserving fruit and vegetables.
180 30–230
ROASTING
In the Auto Roast mode/system, the upper heater will
operate in combination with the grill heater and the
round heater. It is used for roasting all types of meat.
180 30–230
1) It is used for determining the energy efficiency class pursuant to the EN 60350-1
standard.
DESCRIPTION STEAM AND COMBI SYSTEMS PRESET TEMPE-
RATURE (°C)
MIN – MAX
TEMPERATURE
(°C)
HOT AIR WITH STEAM
This system is used for cooking and defrosting. It allows
quick and efficient cooking without changing the
colour or shape of the food. Three options are available:
160
HIGH: cooking escalopes, steaks, and smaller chunks
of meat 30–230
MEDIUM: reheating cool/frozen meals, cooking fish
fillets and vegetables au gratin 30–230
LOW: cooking large chunks of meat (roast, whole
chicken), baking risen dough (bread and rolls), cooking
lasagne etc.
30–230
STEAM
Use this for all types of meat, stews, vegetables, pies,
cakes, bread, and dishes au gratin (i.e. food that require
longer cooking time).
100 –
SOUS VIDE is a slow cooking procedure with food
vacuum sealed and cooked at a specific temperature
that is accurately maintained. The sous vide method
is suitable for cooking meat, fish, and all types of fruit
and vegetables. Food cooked in this way is juicy and it
develops a fuller flavour.
50 30-95
Touch the START/STOP key to start the baking process.
The display shows all the selected settings.
The symbol °C flashes on the display until the set temperature is reached. A sound
signal beeps.
