F262 Series Airflow Switch Installation Guide
Applications
Important: Use this F262 Series Airflow Switch only
as an operating control. Where failure or malfunction
of the F262 switch could lead to personal injury
or property damage to the controlled equipment
or other property, additional precautions must be
designed into the control system. Incorporate and
maintain other devices, such as supervisory or alarm
systems or safety or limit controls, intended to warn
of or protect against failure or malfunction of the
F262 switch.
Important: Utiliser ce F262 Series Airflow Switch
uniquement en tant que dispositif de régulation.
Lorsqu'une défaillance ou un dysfonctionnement
du F262 switch risque de provoquer des blessures
ou d'endommager l'équipement contrôlé ou un
autre équipement, la conception du système de
contrôle doit intégrer des dispositifs de protection
supplémentaires. Veiller dans ce cas à intégrer de
façon permanente d'autres dispositifs, tels que
des systèmes de supervision ou d'alarme, ou des
dispositifs de sécurité ou de limitation, ayant une
fonction d'avertissement ou de protection en cas de
défaillance ou de dysfonctionnement du F262 switch.
The F262 Series Airflow Switch detects airflow or the
absence of airflow only in response to the velocity of air
movement within a duct. You can wire the switch to open
one circuit and close a second circuit, single-pole, double-
throw (SPDT), for either signaling or interlock purposes.
Airflow failure during the normal operation of air handling
systems may cause overheating, coil icing, or other
conditions that may be detrimental to the equipment.
Typical applications include:
• Make-up air systems
• Air cooling or heating processes
• Exhaust systems
The switch has a Type 3R/IP43 enclosure with an integral
mounting plate. A mounting plate gasket is supplied with
each control.
The enclosed SPDT Penn switch has color-coded
terminals for ease of wiring. The control is factory set
at approximately the minimum flow rate. See Table 1.
You must not set the control any lower than the factory
setting because the control may fail to return to a no-flow
condition. If you require a higher flow rate setting, turn
the range adjusting screw clockwise.
Mount the F262 switch on the top, side, or bottom of a
duct in a horizontal position whenever possible. If vertical
duct mounting is required and the flow is downward, you
must readjust the control. If the flow is upward, refer to
Table 1 for minimum flow required to actuate the control.
The switch is not designed for use where it is exposed to
outside weather.
Part No. 24-7664-2977 Rev. E
2021-04-20
F262AA

Installation
Dimensions
Figure 1: F262 Airflow Switch with Type 3R/IP43 enclosure dimensions, in. [mm]
Installation procedure
Before you begin:
Select the proper location. See Mounting.
1. Use the mounting plate gasket as a template and
mark the hole positions.
2. Drill or punch the screw holes.
3. Cut the center hole large enough for the paddle to
pass through.
4. Trim the paddle, if necessary. See Figure 2.
- The standard paddle fits into ducts of 3 in. × 8
in. (76 mm × 203 mm) minimum.
- You can trim the paddle for installation in
ducts as small as 3 in. × 6 in. (76 mm × 152
mm).
Figure 2: Trimming the paddle, dimensions, in. [mm]
F262 Series Airflow Switch Installation Guide2

Mounting
Important: Mount the switch so that the housing is
level horizontally, or plumb vertically. Use a shim, if
necessary.
You can mount the F262AA switch on the top, side, or
bottom of a duct.
• Mount the switch in a horizontal duct whenever
possible. In a horizontal duct, make sure that the switch
housing is level and the paddle is at approximately a
right angle to the air flow.
Figure 3: Mounting the F262 Switch in a horizontal duct
• When you mount the switch in a horizontal duct that
is not horizontally true, check with a level and place a
shim under the switch mounting plate. Do not mount
the switch without a shim. See the following figure.
Figure 4: Mounting the F262 Switch in an angled duct
• When you mount the switch in a vertical duct where
the airflow is upward as shown in the following figure,
see Table 1 for the minimum flow required to actuate
the switch. The maximum air velocity must not exceed
2,000 fpm (10.16 m/s).
Figure 5: Mounting the F262 control in a vertical duct
• When you mount the switch in a vertical duct where the
airflow is downward as shown in the previous figure,
adjust the switch:
a. Turn the adjustment screw clockwise until the
switch closes the circuit between the red and
blue terminals when there is no air flow. See the
following figure.
b. Turn the adjustment screw one additional turn
clockwise.
Figure 6: F262 Switch action
Location considerations
Important: Mount the switch so that the housing is
level horizontally or plumb vertically. Use a shim, if
necessary.
Do not use this switch where exposure to outdoor
weather occurs. Use the switch only for indoor situations.
Avoid locations close to elbows, dampers, fans, duct
openings, or other areas where excessive turbulence
occurs.
Mount the switch away from such areas at least five times
the distance of the smallest duct dimension as shown in
the following figure.
Example: On a 3 in. × 8 in. duct, mount the F261 at least
15 in. (381 mm) from the nearest bend.
Figure 7: Required duct distance
F262 Series Airflow Switch Installation Guide 3

Wiring
WARNING
Risk of electric shock
Disconnect the power supply before making electrical
connections. The printed circuit board and its
components are at AC line voltage. Contact with
components carrying hazardous voltage can cause
electric shock and may result in personal injury or
death.
AVERTISSEMENT
Risque de décharge électrique.
Débrancher l'alimentation avant de réaliser tout
raccordement électrique. Le circuit imprimé et
ses composants présentent une tension CA. Tout
contact avec des composants porteurs de tensions
dangereuses risque d'entraîner une décharge
électrique et de provoquer des blessures graves, voire
mortelles.
Important:
• Use the M4 x 8 crosshead terminal screws
provided. Substitution of other screws voids the
warranty and agency approvals.
• Use copper conductors only. Make all wiring
connections in accordance with local, national,
and regional regulations. Do not exceed the
device’s electrical ratings.
The terminals are color coded. Red is common. See the
following figure for switch action.
Figure 8: F262 control switch action
On an installed switch, the circuit between the red and
yellow terminals closes when the required airflow velocity
is present within the duct.
When you connect an indicator light or signal to the blue
terminal, the light or signal activates when the airflow
decreases or ceases.
Setup and adjustments
Before you begin:
CAUTION
Risk of property damage.
Do not set the switch lower than the factory setting.
The switch is factory set at approximately the
minimum flow rate. A lower setting may result in the
switch failing to return to a no-flow position which may
result in damage to the controlled equipment or other
property.
ATTENTION
Risque de dégâts matériels.
Ne pas régler le commutateur sur une valeur
inférieure au paramètre d'usine. Le commutateur
est réglé en usine sur une valeur correspondant
environ au débit minimum. Un réglage sur une valeur
inférieure risque d'empêcher le commutateur de
revenir sur une position « aucun-débit », ce qui risque
d'endommager l'équipement contrôlé ou de provoquer
d'autres dégâts matériels.
CAUTION
Risk of property damage.
Do not attempt to change sealed settings (screws
marked with black paint). Attempted adjustment may
damage the switch or cause loss of calibration or
other property damage.
ATTENTION
Risque de dégâts matériels.
Ne pas essayer de modifier la position des éléments
de réglage bloqués (vis identifiées par de la
peinture noire). Toute tentative de réglage risque
d'endommager le dispositif de contrôle ou de
provoquer la perte des valeurs d'étalonnage ou
d'autres dégâts matériels.
F262 Series Airflow Switch Installation Guide4

About this task:
The following table shows airflow velocities in fpm required to activate the switch for any given duct size, with horizontal
or vertical upward flow. The flow rate table is based on a standard air density of 0.075 lb/ft3 (1.2 kg/m3).
Table 1: Flow rate table, fpm (m/s)
Minimum air velocity required to activate control
Horizontal flow Vertical flow
Paddle
width
Switch actuation on
flow
50 in.2 (323 cm2) or
larger duct area
Less than 50 in.2
(323 cm2) duct area
50 in.2 (323 cm2) or
larger duct area
Less than 50 in.2
(323 cm2) duct area
Increase
R to Y closes
625 (3.2) 575 (2.9) 950 (4.8) 750 (3.8)2-1/8 in.
Decrease
R to B closes
325 (1.7) 220 (1.1) 850 (4.3) 575 (2.9)
Increase
R to Y closes
500 (2.5) 350 (1.8) 750 (3.8) 500 (2.5)3-1/8 in.
Decrease
R to B closes
250 (1.3) 100 (0.5) 650 (3.3) 350 (1.8)
To adjust the setting of the flow switch, complete the following steps:
1. Disconnect the power supply before you make any
electrical connections.
2. Remove the enclosure cover.
3. Adjust the switch’s flow rate. For more information,
see the following figure.
- Turn the adjustment screw counterclockwise
to lower the flow rate required to activate the
switch.
- Turn the adjustment screw clockwise to raise
the flow rate required to activate the switch.
Figure 9: Flow rate adjustment
Note: Do not lower the flow rate required to
activate the switch unless it is set above the
factory set flow rate.
4. Replace the enclosure cover and tighten the cover
screws with 12 in•lb of torque.
Checkout procedure
The circuit between the red and yellow terminals closes
when air flows through the duct where the switch is
located at the required velocity. When you connect to
the red and blue terminals, the warning light or signal
activates when the air flow decreases or ceases.
Before leaving the installation, observe at least three
complete operating cycles to make sure that all
components function correctly.
Ordering information
Table 2: Replacement paddle kits for F262 Switch
Product code Description
PLT112-1R 2-1/8 in. wide x 6-7/8 in. long (54 mm x
175 mm) paddle
PLT112-2R 3-1/8 in. wide x 6-7/8 in. long (79 mm x
175 mm) paddle
Repair information
Do not make field repairs, except for replacement of the
flow paddle. For a replacement control or paddle kit,
contact the nearest Johnson Controls®/Penn distributor.
F262 Airflow Switch technical
specifications
Table 3: F262 Series Airflow Switch electrical ratings
UL 60730/UL 1059 EN 60730Volts 50/60 Hz
24 120 208 240 24 230
Horsepower – 1 1 1 – –
Full load amperes – 16 10 10 – 8
Locked rotor
amperes
– 96 60 60 – 48
Resistive
amperes
16 16 10 10 16 16
Pilot duty VA 125 720 720 720 77 720
F262 Series Airflow Switch Installation Guide 5

Table 4: UL conformity declaration information
Information Description
Purpose of
control
F262 Airflow Switch
Construction
of control
Electronic independently mounted control
Number of
cycles
100,000 cycles
Method of
mounting
control
Mounting to sensed media vessel and
orientation
Type 1 or
Type 2 action
Type 1.C (Micro-interruption)
External
pollution
situation
Pollution degree 4
Internal
pollution
situation
Pollution degree 2
Rated
impulse
voltage
4,000 VAC
Ball pressure
temperature
Enclosure: 266°F (130°C )
Switch component: 252°F (122°C)
Control
adjustment
instruction
-
Field wiring
rating
Wire/cord temperature ratings:
• 140°F (60°C) only permitted when
ambient air and media are less than
113°F (45°C)
• 167°F (75°C) only permitted when
ambient air and media are less than
140°F (60°C)
• 194°F (90°C) only permitted when
ambient air is less than 140°F (60°C)
and media is less than 167°F (75°C)
• 302°F (150°C) permitted when ambient
air is less than 140°F (60°C) and media
is less than 176°F (80°C)
Table 5: F262 Airflow Switch technical specifications
Specification Description
Switch SPDT
Enclosure UL: Type 3R
CE: IP43
Wiring
connections
Three color-coded screw terminals and
one ground terminal
Conduit
connection
One 7/8 in. (22 mm) hole for 1/2 in.
trade size (or PG16) conduit
Paddle
material
0.006 in. (0.15 mm) stainless spring
steel
Table 5: F262 Airflow Switch technical specifications
Specification Description
Maximum air
velocity
2,000 fpm (10.16 m/sec)
Maximum
duct air
temperature
176°F (80°C)
Ambient
conditions
32°F to 131°F (0°C to 55°C)
Compliance North America: cULus Listed; UL 60730,
File E6688; FCC Compliant to CFR47, Part
15, Subpart B, Class B
Plenum rated; UL 2043, suitable for
use in other environmental spaces,
plenums, in accordance with section
300.22.(c) of the National Electrical Code
Industry Canada (IC) Compliant to
Canadian ICES-003, Class B limits
Europe: CE Mark – Johnson Controls
declares that this product is in
compliance with the essential
requirements and other relevant
provisions of the EMC Directive and the
Low Voltage Directive.
Australia/New Zealand: Mark: RCM
Compliant
The performance specifications are nominal and conform
to acceptable industry standards. For application at
conditions beyond these specifications, consult Johnson
Controls or PENN Refrigeration Application Engineering at
1-800-275-5676. Johnson Controls shall not be liable for
damages resulting from misapplication or misuse of its
products.
North American emissions
compliance
United States
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in
a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
F262 Series Airflow Switch Installation Guide6

• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Warning (Part 15.21)
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
Canada
This Class (B) digital apparatus meets all the requirements
of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la Classe (B) respecte toutes
les exigences du Règlement sur le matériel brouilleur du
Canada.
Industry Canada Statement(s)
This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two
conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including
interference that may cause undesired operation of
the device.
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions
suivantes :
1. L'appareil ne doit pas produire de brouillage, et
2. L'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le
fonctionnement.
Product warranty
This product is covered by a limited warranty, details
of which can be found at www.johnsoncontrols.com/
buildingswarranty.
Single point of contact
APAC Europe NA/SA
JOHNSON CONTROLS
C/O CONTROLS PRODUCT
MANAGEMENT
NO. 32 CHANGJIJANG RD NEW
DISTRICT
WUXI JIANGSU PROVINCE 214028
CHINA
JOHNSON CONTROLS
WESTENDHOF 3
45143 ESSEN
GERMANY
JOHNSON CONTROLS
507 E MICHIGAN ST
MILWAUKEE WI 53202
USA
Contact information
Contact your local branch office:
www.johnsoncontrols.com/locations
Contact Johnson Controls: www.johnsoncontrols.com/
contact-us
F262 Series Airflow Switch Installation Guide 7

© 2021 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision and
are subject to change without notice.
www.penncontrols.com
