Pentair E-Box SOLEO Connect Operating instructions

INSTALLATION AND OPERATION GUIDE
Version E-Box SOLEO Connect
IMPORTANT SAFETY INSTRUCTIONS
Read and follow all the instructions
Keep these instructions WWW.PENTAIRPOOLEUROPE.COM

Installation and Operation Guide Version E-Box SOLEO Connect - Table of Contents
2 / 64 Ref. SB-CU-IMP-069EB / A - 12.05.2023
Table of Contents
1 General............................................................................................ 4
1.1 Scope of this document............................................................................... 4
1.2 Version Management .................................................................................. 4
1.3 Manufacturer identification (ID), product ................................................... 4
1.4 Technical assistance procedure................................................................. 4
1.5 Copyright and Trademarks ......................................................................... 5
1.6 Limitation of Liability .................................................................................. 5
1.7 Declaration of conformity ........................................................................... 6
1.8 Pentair Scan Application............................................................................. 7
1.9 Home automation control application ........................................................ 7
1.10 Website and notices additional to the installation ..................................... 7
2 Security ........................................................................................... 8
2.1 Definition of safety pictograms................................................................... 8
2.2 Series label locations.................................................................................. 8
2.3 Risks............................................................................................................ 9
2.3.1 Personnel ............................................................................................................ 9
2.3.2 Hardware............................................................................................................. 11
3 Description ...................................................................................... 13
3.1 Technical specifications.............................................................................. 13
3.2 Congestion diagram.................................................................................... 14
3.3 Product Description .................................................................................... 16
3.3.1 General operation ............................................................................................... 16
3.3.2 The E-Box............................................................................................................ 17
3.3.3 The Speedeo Connect box................................................................................... 18
3.3.4 Soleo.................................................................................................................... 18
3.3.5 Internet Gateway Relay (Option) ......................................................................... 19
4 Installation ...................................................................................... 20
4.1 Warnings ..................................................................................................... 20
4.2 Package contents........................................................................................ 21
4.3 Accessories provided depending on the options chosen ........................... 22
4.3.1 Analysis chamber................................................................................................ 22
4.3.2 Pool water treatment liquid solution injection metering pump......................... 23
4.3.3 Salt electrolysis cell for chlorine production 13 or 27 g/h (optional) ................ 24
4.4 Principle of control through WiFi or LoRa radio ........................................ 25
4.5 E-Box........................................................................................................... 28
4.5.1 Wall mounting ..................................................................................................... 28
4.5.2 Connections......................................................................................................... 30

Installation and Operation Guide Version E-Box SOLEO Connect - Table of Contents
Ref. SB-CU-IMP-069EB / A - 12.05.2023 3 / 64
4.5.3 Connection of the "PENTAIR VSF" filter pump................................................. 35
4.5.4 Connection of the heat pump power supply (if installed)................................... 35
4.5.5 Connection of the pool automatic shutter power supply (if equipped) .............. 36
4.6 Soleo and Speedeo Connect ....................................................................... 37
4.6.1 Wall mounting ..................................................................................................... 37
4.6.2 Hydraulic and electrical installation................................................................... 38
4.6.3 Installation of probes .......................................................................................... 39
4.6.4 Connections......................................................................................................... 42
4.7 Control of variable speed pumps................................................................ 46
4.7.1 PENTAIR IntelliFlo VSF and IntelliFlo 3.............................................................. 46
4.7.2 PENTAIR VS2 and VS2m...................................................................................... 47
4.7.3 Other variable speed pumps............................................................................... 47
4.7.4 Single speed pump.............................................................................................. 48
5 Programming .................................................................................. 49
5.1 Presentation of menus on Soleo ................................................................ 49
5.2 Presentation of menus on Speedeo Connect ............................................. 51
6 Maintenance .................................................................................... 55
6.1 Maintenance................................................................................................ 55
6.2 Overwintering of Soleo Connect (Water temperature < +3.0°C)................ 55
6.3 pH and RedOx probes ................................................................................. 55
6.4 Cleaning the pH or RedOx probe ................................................................ 56
7 Spare part........................................................................................ 58
8 Disposal........................................................................................... 59
9 Annexes........................................................................................... 60

Installation and Operation Guide Version E-Box SOLEO Connect - General
4 / 64 Ref. SB-CU-IMP-069EB / A - 12.05.2023
1 General
1.1 Scope of this document
This document contains the information necessary for proper use of the product. It informs the
user in order to guarantee the proper execution of the installation, use and maintenance
procedures.
The content of this document is based on information available at the time of publication.
The original version of this document was written in French.
For reasons of safety and environmental protection, the safety instructions contained in this
document must be strictly adhered to.
This document is provided for reference only and does not include all possible installation
situations. The person responsible for installing this equipment must have:
• Followed adequate training for the installation of swimming pools.
• A good knowledge of the pool equipment as well as their settings.
This document is available in other languages on the page www.pentairpooleurope.com
1.2 Version Management
Review Date Authors Description
A 12.05.2023 STF/YML First edition.
1.3 Manufacturer identification (ID), product
Manufacturer: Pentair International LLC
Avenue de Sevelin 20
1004 Lausanne
Suisse
Product: SOLEO Connect
1.4 Technical assistance procedure
Procedure to follow for any request for technical assistance:
1. Collect the information that is necessary for a technical assistance request.
ðProduct identification (see Series label locations [→Page8]).
ðDescription of the problem that the device has.
2. Contact your supplier.

Installation and Operation Guide Version E-Box SOLEO Connect - General
Ref. SB-CU-IMP-069EB / A - 12.05.2023 5 / 64
1.5 Copyright and Trademarks
All trademarks and logos Pentair are the property of Pentair. The brands, trademarks and logos of
third parties are the property of their respective owners.
© 2023 Pentair. All rights reserved.
1.6 Limitation of Liability
As part of the quality system Pentair, the products benefit, under certain conditions, from a
manufacturer's guarantee, which the direct customers of Pentair can access. Users must contact
the reseller of this product for the applicable conditions and in the event of a possible warranty
claim.
With the exception of probes and consumables, the warranty is 2 years.
Any warranty provided by Pentair regarding the product will be annulled in the following cases:
• Installation carried out by a person not specialised in the installation of swimming pool;
• Non-compliant installation, programming, use, operation and/or maintenance causing any
damage to the product;
• Non-compliant or unauthorised work on components;
• Incorrect, inappropriate or incorrect connection/assembly of systems or products in
connection with this product and vice versa;
• Use of a lubricant, grease or chemical of any type not compatible with the product and not
listed as compatible with the product by the manufacturer;
• Failure due to incorrect configuration and/or measurements.
Pentair declines all liability for equipment installed by the user contrary to the instructions given
for the products Pentair, as well as for any production procedure or process, installed and
connected around the installation, indeed related to this. All direct or indirect malfunction or
failure and any damage caused by such equipment or process are also excluded from the
guarantee. Pentair does not accept any liability for any loss or any prejudice as regards profits,
revenue, usage, production or contracts, or for any indirect, special or consecutive loss or
damage, whatever the nature may be.

Installation and Operation Guide Version E-Box SOLEO Connect - General
6 / 64 Ref. SB-CU-IMP-069EB / A - 12.05.2023
1.7 Declaration of conformity
Guidelines – Harmonised standards
Pentair International LLC- Avenue de Sevelin 20 - 1004 Lausanne - Suisse
We declare that the product meets the guidelines and take responsibility for it:
RED
• 2014/53/EU.
SAFETY
• EN 62368-1:2014;
• EN 62311: 2008.
EMC
• EN 301 489-1 V2.2.0;
• EN 301 489-3 V2.1.1;
• EN 55024: 2010/ A1: 2015.
RADIO
• EN 300 220-2 V3.1.1.
SOLEO CONNECT (+ PARTS)
• SB-PF-ENS-005E.
PART NUMBERS
• SB-SE-SOL-003C;
• SB-SE-TEC-003C;
• INTP-5220;
• INTP-5210;
• SB-PD-PRO-004B;
• INTP-HOLD-2.
Other normative documents
• 2002/95/EC (RoHS)
• 2002/96/EC (WEEE)

Installation and Operation Guide Version E-Box SOLEO Connect - General
Ref. SB-CU-IMP-069EB / A - 12.05.2023 7 / 64
1.8 Pentair Scan Application
The mobile application Pentair Scan is an ideal tool for the daily work of the maintenance
technician. The simple reading of the identification label present on the product, with a smart
phone, gives instant access to all its information.
1. Download the Pentair Scan application from or on a smart phone.
2. Open the Pentair Scan application.
3. Scan the label affixed to the product.
4. Navigate through the information.
1.9 Home automation control application
The Intellipool is a necessary application for controlling your installation remotely. It is not limiting
and can be installed on several media (phone and tablet) with the same identifiers.
The use of an internal connection via a computer is necessary to configure the E-Box.
It is free, no subscription necessary, you just need to:
1. Download the Pentair Home from or on a smart phone or a table (not
supplied).
2. Open the Pentair Home application.
3. Fill in your Login and your password.
4. Navigate within the application to pair your devices and control your installation.
1.10 Website and notices additional to the installation
We advise you to read and download the instructions for the various equipment available on the
website: www.pentairpooleurope.com
Access is free, no subscription required.
As a professional a section is dedicated to you and you just have to register on this same site and
make a request for access.
Download the documentation relating to the various products (Boxes SOLEO and SPEEDEO
Connect, electrolyser, IntelliFlo filtration pump etc.).

Installation and Operation Guide Version E-Box SOLEO Connect - Security
8 / 64 Ref. SB-CU-IMP-069EB / A - 12.05.2023
2 Security
2.1 Definition of safety pictograms
DANGER
This combination of symbol and keyword indicates an imminently hazardous situation
that will result in serious or fatal injury if not avoided.
WARNING
This combination of symbol and keyword indicates a potentially hazardous situation that
can result in serious or fatal injury if not avoided.
CAUTION
This combination of symbol and keyword indicates a potentially hazardous situation that
can result in minimal or minor injury if not avoided.
Caution - material
This combination of symbol and keyword indicates a potentially hazardous situation that
can entail material damage if not avoided.
Prohibition
Mandatory advice to follow.
Mandatory
Applicable guideline, measure.
Info
Informative comment.
2.2 Series label locations
Mandatory
Make sure that the serial and safety labels on the device are perfectly legible and clean!
If necessary, replace them with new labels to be placed in the same place.

Installation and Operation Guide Version E-Box SOLEO Connect - Security
Ref. SB-CU-IMP-069EB / A - 12.05.2023 9 / 64
2.3 Risks
All safety and protection instructions contained in this document must be followed in order to
avoid injury, property damage or environmental, irremediable or temporary pollution.
Likewise, all other regulations and measures for accident prevention and environmental
protection, as well as any recognised technical regulations relating to safe and appropriate
working methods applicable in the country and at the place of use of the device must be complied
with.
Any violation of safety and protection rules or any existing legal and technical regulations may
result in irreparable or temporary injury, property damage or environmental pollution.
2.3.1 Personnel
DANGER
Risk of electric shock or electrocution:
Before working on the E-Box SOLEO Connect:
• Always turn off the power to the controller SOLEO and SPEEDEO Connect to the
circuit breaker before the maintenance. Failure to do so could result in death or
serious injury to the technician, pool users or others due to electric shock.
• Please disconnect the connections before working on the SOLEO and SPEEDEO
Connect; the AC power can be supplied to the relay terminals close to other sources.
DANGER
Chemical burn hazard!
Be sure to shut off all pumps at the main circuit breakers on the home switchboard
before drilling in any line. Properly fix all electrical, water and chemical lines.
Consolidate feed pumps and chemical tanks in a safe and secure area.
WARNING
Safety tips on the standard solution!
The standard solution pH 4 is acidic. It must be kept away from children and securely
close it to the right of the bottle. Store in a dry, ventilated place. Do not expose to frost.

Installation and Operation Guide Version E-Box SOLEO Connect - Security
10 / 64 Ref. SB-CU-IMP-069EB / A - 12.05.2023
WARNING
Water temperatures above 37.7°C are a health hazard!
Prolonged immersion in hot water can cause hyperthermia. Taking alcohol, drugs or
medication is a factor aggravating the risk of hyperthermia in hot water baths and spas.
Hyperthermia occurs when the internal temperature of the body exceeds by several
degrees the normal temperature of 37°C. Hyperthermia can produce the following
effects:
• Inability to perceive imminent danger.
• Insensitivity to heat.
• Inability to perceive the need to leave the pool.
• Physical inability to leave the pool.
• Foetal injury in pregnant women.
• Syncope resulting in danger of drowning.
CAUTION
Risk of injury due to improper handling!
Only qualified personnel and duly trained professionals are authorised to carry out the
required work, according to their training, experience, instructions received and their
knowledge of the safety rules as well as the operations to be carried out.
Prohibition
Do not allow children to operate this equipment!
Risk of injury.
Prohibition
Do not use this product to control an automatic pool shutter!
Swimmers may find themselves trapped under the shutter.
Mandatory
Strictly follow the safety and handling procedures of the acid manufacturers!
Including protective measures for hands, body and eyes during transfer and handling of
acid. Also observe the safety precautions prescribed for handling muriatic acid intended
to control the pH of the water. Muriatic acid can cause serious bodily harm and damage
to swimming pool equipment.
Mandatory
Check the pH and disinfectant levels of the water before using the pool and make sure
the water filtration device is not clogged!
Use an independent pH and chlorine test kit very periodically to ensure that the pH and
chlorine level meet safety requirements. PH, RedOx, or conductivity sensors that are
degraded, discharged, or clogged by oils, lotions, or other contaminants are likely to
return incorrect results in the system and induce improper chemical treatment of the
water, thereby creating a hazard to people and equipment.

Installation and Operation Guide Version E-Box SOLEO Connect - Security
Ref. SB-CU-IMP-069EB / A - 12.05.2023 11 / 64
Mandatory
This installation and operation guide contains important information about the
installation, operation and safety of this product!
This guide should be provided to the owner and / or operator of this product.
2.3.2 Hardware
DANGER
Risk of electric shock or electrocution!
Connect the E-Box SOLEO Connect to a differential circuit breaker.
Reminder: the power cables of the pool lights must not be routed to the pool by means of
sheaths containing other electrical cables.
Refer to local standards for details.
Mandatory
Comply with regulations!
Most countries regulate the construction, installation and operation of public swimming
pools, spas and residential pools. It is important to comply with these rules, many of
which directly regulate the installation and use of this product. Check your building and
local health codes for more information.
Mandatory
When mixing acid and water, always add the acid to the water!
Never add water to the acid. When adding a chemical to the pool, be sure to follow the
manufacturer's instructions and be equipped with appropriate protective equipment.
Mandatory
Observe special precautions when installing, servicing and operating acid supply pump
systems!
The acid is dangerous to handle and requires the application of appropriate special
measures with regard to its containers, transport, filling, storage, distribution and
handling procedures.
Mandatory
Check the daily display SOLEO!
Make sure that no alarm message is active.
Mandatory
For all components other than remote controls, observe a distance of at least 1.5m from
the inner wall of the pool or spa!
Mandatory
Sufficient equipotential bonding (min. 4.5 mm2), according to local regulations, is
mandatory on all metal components of the pool, including the pool pump!
This is necessary for electrical safety, as well as to reduce the risk of corrosion.

Installation and Operation Guide Version E-Box SOLEO Connect - Security
12 / 64 Ref. SB-CU-IMP-069EB / A - 12.05.2023
Prohibition
Do not mix sodium hypochlorite and muriatic acid (hydrocloric acid)!
Do not mix out of water, chlorinated product and pH fix!
Info
Devices intended for any other use than use by a one person family, may require
additional safety equipment to comply with local regulations!
Info
This product is exclusively intended for swimming pool applications.

Installation and Operation Guide Version E-Box SOLEO Connect - Description
Ref. SB-CU-IMP-069EB / A - 12.05.2023 13 / 64
3 Description
3.1 Technical specifications
E-Box
Protection rating IP44
System pre-wiring SB-PF-ENS-005E
Operating voltage 230V
Input power supply frequency 50Hz
Power 14kW max
Number of inputs -
Number of outputs 8x (230V/16A max)
4x (12V/16A max)
4x dry contacts 8A max
Soleo, Speedeo Connect
Product specifications Model SB-PF-ENS-005E
Operating temperature 0° to 40°C
Operating humidity 40% at 75°C
Maximum operating altitude 2000 m
Weight (excluding probes) 3.5Kg
Soleo Consumption 16W
Speedeo Connect Consumption 16W
Soleo + Speedeo Connect (inner use) IP64
Internet Relay mains power supply
specifications 230V/DC Jack
5.5/2.1mm (external negative)
VEL05US060-EU-JA
Input 100-240V 50/60Hz 0.18A
Output 6.0V 0.83A max
Environmental conditions
• For inner use only;
• Temperature from 5°C to 40°C;
• Maximum relative humidity of 80 % for temperatures up to 31°C decreasing in a linear
manner to 50% relative humidity at 40°C;
• Mains power supply voltage variations of ±10% of the nominal voltage.

Installation and Operation Guide Version E-Box SOLEO Connect - Description
14 / 64 Ref. SB-CU-IMP-069EB / A - 12.05.2023
3.2 Congestion diagram
E-Box
Position of cable passages

Installation and Operation Guide Version E-Box SOLEO Connect - Description
Ref. SB-CU-IMP-069EB / A - 12.05.2023 15 / 64
Speedeo Connect and Soleo (both boxes have the same measurements)
Speedeo Connect Soleo

Installation and Operation Guide Version E-Box SOLEO Connect - Description
16 / 64 Ref. SB-CU-IMP-069EB / A - 12.05.2023
3.3 Product Description
3.3.1 General operation
The diagram below describes an example of a typical installation of a fully automated and
remotely controlled swimming pool. Refer to the relevant item for more information about it.
1Roller shutter 8Peristaltic pump
2Home automation swimming pool 9Heating
3Lighting 10 Speedeo Connect
4Internet Gateway Relay (option) 11 Filter
5User internet box 12 Probes (pH + RedOx)
6Electrolyser 13 Soleo
7E-Box 14 Pump

Installation and Operation Guide Version E-Box SOLEO Connect - Description
Ref. SB-CU-IMP-069EB / A - 12.05.2023 17 / 64
3.3.2 The E-Box
The E-Box is a turnkey system for quickly and simply making all the connections to the various
pieces of equipment in the installation.
The connections between the boxes provided (E-Box and the boxes of the SOLEO Connect) are
carried out through cables with quick connectors and thus facilitate operation with the possibility
of remote control and information (subject to the connection of the installation to the internet
through the WiFi network of the user's internet box, or if necessary with the addition of the
Gateway box).
Your E-Box SOLEO Connect does not require any additional electrical components.
No intervention is necessary inside your E-Box except the connection to the terminal blocks, in
order to carry out the connections of the various devices that constitute the installation.

Installation and Operation Guide Version E-Box SOLEO Connect - Description
18 / 64 Ref. SB-CU-IMP-069EB / A - 12.05.2023
3.3.3 The Speedeo Connect box
The SPEEDEO controls and automatically calculates the operating time of the equipment
connected to the system, it is the controller of the installation.
It receives the orders transmitted by the remote control device or by the internet and
communicates with the device concerned.
In addition, the activity can be consulted by the user and is stored in memory. It can be queried
through the dedicated application (Pentair Home and/or Pentair Pro).
01:0 3 Wa ter :+2 4.3 °C
F il tra tio n: V2
S1: OFF S 2: ON S3 :OF F
AIR :+ 25. 9°C
Quick connectors
Menu navigation buttons
Screen
Radio antenna
3.3.4 Soleo
The device is equipped with three probes that allow it to measure the properties and values of the
water.
The information collected is then transmitted to the SPEEDEO Connect to refine the adjustment of
the water regulation and allow the control of the various pieces of equipment of the swimming
pool.
Air Temperature Sensor (Optional)
Water Temperature Sensor
RedOx and pH probes
Quick connectors
Menu navigation buttons
Screen

Installation and Operation Guide Version E-Box SOLEO Connect - Description
Ref. SB-CU-IMP-069EB / A - 12.05.2023 19 / 64
3.3.5 Internet Gateway Relay (Option)
The Gateway allows access to your data in real time and you can also intervene on settings and
controls from a tablet or smart phone connected to the internet.
You must be connected to the internet through your box in order to be able to control and ask your
installation questions.
To be functional, the Gateway must be connected to your internet "box".
It is necessary to download the Pentair Home or Pentair Pro to connect to the installation.
Radio antenna
μUSB/USB cable
Power supply connector
230V/USB power supply
ref. VEL05US050-EU-BB
INPUT: 100-240V ~50/60Hz 0.18A
OUTPUT: 5.0V 1.0A max.

Installation and Operation Guide Version E-Box SOLEO Connect - Installation
20 / 64 Ref. SB-CU-IMP-069EB / A - 12.05.2023
4 Installation
4.1 Warnings
CAUTION
Risk of injury due to electric shock or pressurised elements!
It is strictly forbidden for any unqualified personnel to access the internal components of
the system in order to carry out any technical work whatsoever.
• Check that the power supply is switched off. Close the water inlet and relieve the
system of pressure before opening the hood to access the internal components.
Mandatory
The equipment is permanently connected.
Mandatory
The equipment must be installed by a qualified technician according to the local
regulations in force.
Info
Each output has a normally open dry contact for a maximum voltage of 230V.
The manufacturer is not responsible for any personal injury or material damage resulting from
improper use of the device or any use thay is not in accordance with the following instructions.
In case of any doubt in this manual regarding installation, operation or maintenance, please
contact the technical support of the company that installed the device.
The installation of the device must be carried out by a qualified technician in compliance with the
standards and regulations in force, using tools compatible with the device for safe use. This same
technician must also ensure the maintenance of the device.
In the event of a failure or malfunction, before performing any repair work on the device, ensure
that the E-Box SOLEO Connect is disconnected from the power supply:
1. Be careful when unpacking and during subsequent handling, as the weight is likely to cause
property and personal injury in the event of an accidental impact.
2. Before any electrical connection, earth the installation.
3. Ensure that the environment in which the appliances are installed does not reach
temperatures that may cause the water to freeze, as the valve may be damaged.
