Pentair Aurora CBV-S User manual

NOTE! To the installer: Please make sure you provide this manual to the owner of the equipment or to the responsible
party who maintains the system.
MODELS CBV-S/A
HARD FLANGED CIRCUIT
BALANCING VALVES
INSTALLATION AND OPERATION MANUAL
Part # A-03-354 | © 2015 Pentair Ltd. | 01/01/15

MODELS CBV-S/A
2
ITEM 1040 SERIES
DATED JANUARY 2015
CALIFORNIA PROPOSITION 65 WARNING:
This product and related accessories
contain chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
INSTALLATION:
To ensure accuracy of measurement, the CBV should be
located at least five pipe diameters downstream from any fitting
and at least ten pipe diameters downstream from a pump. Two
pipe diameters downstream from the CBV should be free of any
fitting (as illustrated in Fig. 1).
CBV valves must be installed with flow in the direction of the
arrow on the valve body. Easy access to the probe metering
ports (P.M.P’s) and handwheel must be provided.
CBV valves can be installed in horizontal or vertical piping.
The metering ports should never be installed below the
pipe (pointing down), as this will allow system sediment to
accumulate in the ports. (Illustrated below for horizontal piping
in Fig. 2.)
CBV angle-style valves are designed to replace piping elbows.
Metering ports and body plugs may be interchanged for
improved accessibility.
BOLT TIGHTENING:
Tighten all bolts evenly in standard star pattern. When used
with a “raised face” flange, there will be a gap between the
faces on the outer flange diameters.
CONVERSION (STRAIGHT TO ANGLE):
1. Open the valve one complete turn.
2. Remove the body bolts from the valve body.
 3.Rotateone-halfofthevalvebody180˚,makingsuretheseat
andO-ringstayinpositionanddonotgetnickedorcut.
4. Replace the body bolts and tighten evenly.
5. With no arrows visible, the inner scale set at 0 on the
indicator line aligned with the 0 on the outer scale, the valve
is closed. Refer to Fig. 3.
6. Figure 4 shows a valve setting of 2.0, indicating that the
valve is partially open.
7.With all arrows visible, the inner scale set at 6 and the
indicator line aligned with outer scale 0, the valve setting is
6.0 and the valve is fully open. Refer to Fig. 5.
OPERATION:
The valve operates from closed (Fig. 3) to fully open by a
counterclockwise rotation of the red handwheel. Use five (5)
380˚ turns for the 2-1/2" and 3" valves, six (6) turns for the
4", 5", and 6" valves, 12 turns for the 8" and 10" valves and
14turnsforthe 12"valve. Twoscales indicatethe positionof
the valve.
Inner Scale (Figs. 4 and 5) – This sleeve has a vertical arrowed
scale which indicates the number of full turns the valve has
been opened.
Outer Scale (Figs. 4 and 5) – This scale is a micrometer-type
scale marked 0–9 at the tapered base of the handwheel. Each
gives 1/10th indications for each 360˚ turn of opening against
the indicator line of the inner scale. Connect meter quick-
disconnect hoses to metering ports as follows:
• Remove protective cap from metering ports.
 •Insertandlockthemeterprobeintothemeteringports.
Model CBV-A – Angle Design Model CBV-S – Straight Design
Fig. 1
Fig. 3
Fig. 4
Fig. 5
Fig. 2
(1) Metering Port
(2) Body Port & Drain
(3) Handwheel

MODELS CBV-S/A
3
ITEM 1040 SERIES
DATED JANUARY 2015
The hose with the red fitting is upstream; the hose with the blue
fitting is downstream.
The probe should not be left inserted into the fitting for
prolongedperiodsoftime,suchasovernight,asleakage
of the P.M.P may occur when the probe is removed.
The locking nut on the probe is designed to hold it in the
P.M.P.whentakingreadingsinsystemshavingahighworking
pressure. As sealing is accomplished internally on the probe
stem,itisonlynecessarytotightenthelockingnutfinger-tight.
Overtightening may cause damage to the P.M.P. or locking
nut threads.
Safety glasses should be used.
Beforetaking aflow measurementreading,setthevalvetoits
fully open (4.0) or at a preset position. Read the pressure drop
across the valve. Curves are in the Aurora catalog.
MEMORY SETTING – 2-1/2"– 6" VALVES (FIG. 6):
After the valve has been adjusted to its balance setpoint and
without moving the handwheel, remove the retaining bolt from
theendofthehandwheelusinga1/4"Allenwrench.
Carefully remove the handwheel and turn indicator sleeve
assembly, leaving the valve at its balance setpoint.
Turn the plastic memory stop (clockwise) down until it stops.
Finger-tight pressure is sufficient. Do not overtighten.
Holding the memory stops in position, turn the lock collar
(clockwise) down until it stops against the valve bonnet. The
memory has now been set.
With the handwheel/turn indicator sleeve assembly still at its
balance setpoint indication, reinstall them on the valve stem and
holdinplacewiththe1/4"retainingbolt.
Care must be taken not to rotate the valve stem or
change the handwheel/indicator setting while setting
the memory.
REPOSITIONING HANDWHEEL – 2-1/2"– 6" VALVES:
Thehandwheelcanberemovedandrepositionedinanyofsix
positions around the stem.
a. Close valve fully.
b. Remove handwheel-retaining bolt.
c. Remove handwheel and turn indicator sleeve by grasping
the handwheel and pulling away from the valve body
along the stem.
d. Select a new position for easy reading and with the sleeve
and handwheel held together in the closed position (0.0),
pushthembackoverthebonnetheadandvalvestem.
e. Replace handwheel-retaining bolt.
f. Open valve.
If handwheel is removed for any reason, it is important to
first close the valve and then replace the handwheel
per d. and e. above.
REPACKING CBV UNDER FULL SYSTEM PRESSURE –
2-1/2"– 6" VALVES:
1. Open valve fully to its memory setting and, on a piece of
paper, record the valve setting.
 2.Remove the handwheel/indicator sleeve assembly as
instructed in the first and second paragraphs under “Memory
Setting.”
 3.Loosenthelockcollarbyturningitcounterclockwiseuntilit
seats against the top of the memory stop.
 4.Remove the memory stop/lock collar assembly by turning
theplasticmemorystopcounterclockwise.
 5.UsingthehandwheelWITH THE INDICATOR SLEEVE
REMOVED,turnthevalvestemcounterclockwiseuntilthe
valve is fully open and will not turn any further (45 ft. lbs.).
Asteponthevalveplughasnowbeenback-seatedagainst
the upper portion of the valve body (metal-to-metal).
6. The valve bonnet may now be removed. There may be slight
leakage,asthemetal-to-metalbackseatingdoesnotprovide
a drip-tight seal.
 7.Cleanexposedportionofvalvestem(donotscratch).
 8.RemoveandreplacetheO-ringandgasket.
 9.Installthevalvebonnet.
10.Replace memory stop/lock collar assembly into the valve
bonnet.
11.Close the valve fully by turning the stem in a clockwise
direction. Tightening valve bonnet is necessary to stop
anyleaks.
12.Replace handwheel/indicator sleeve assembly per d. and a.
under “Repositioning Handwheel.”
13.Open valve to balance setpoint as recorded from first
paragraph under “Repacking CBV Under Full System
Pressure.”
14. Reset memory. Refer to “Memory Setting” on page 2.
CAUTION
O-RING
Fig. 6
CAUTION

WARRANTY
Seller warrants equipment (and its component parts) of its own manufacture against defects in materials and workmanship under normal use
and service for one (1) year from the date of installation or start-up, or for eighteen (18) months after the date of shipment, whichever occurs
first. Seller does not warrant accessories or components that are not manufactured by Seller; however, to the extent possible, Seller agrees to
assign to Buyer its rights under the original manufacturer's warranty, without recourse to Seller. Buyer must give Seller notice in writing of
any alleged defect covered by this warranty (together with all identifying details, including the serial number, the type of equipment, and the
date of purchase) within thirty (30) days of the discovery of such defect during the warranty period. No claim made more than 30 days after
the expiration of the warranty period shall be valid. Guarantees of performance and warranties are based on the use of original equipment
manufactured (OEM) replacement parts. Seller assumes no responsibility or liability if alterations, non-authorized design modifications
and/or non-OEM replacement parts are incorporated If requested by Seller, any equipment (or its component parts) must be promptly
returned to Seller prior to any attempted repair, or sent to an authorized service station designated by Seller, and Buyer shall prepay all
shipping expenses. Seller shall not be liable for any loss or damage to goods in transit, nor will any warranty claim be valid unless the
returned goods are received intact and undamaged as a result of shipment. Repaired or replaced material returned to customer will be
shipped F.O.B., Seller's factory. Seller will not give Buyer credit for parts or equipment returned to Seller, and will not accept delivery of
any such parts or equipment, unless Buyer has obtained Seller's approval in writing. The warranty extends to repaired or replaced parts of
Seller's manufacture for ninety (90) days or for the remainder of the original warranty period applicable to the equipment or parts being
repaired or replaced, whichever is greater. This warranty applies to the repaired or replaced part and is not extended to the product or any
other component of the product being repaired. Repair parts of its own manufacture sold after the original warranty period are warranted for
a period of one (1) year from shipment against defects in materials and workmanship under normal use and service. This warranty applies to
the replacement part only and is not extended to the product or any other component of the product being repaired. Seller may substitute
new equipment or improve part(s) of any equipment judged defective without further liability. All repairs or services performed by Seller,
which are not covered by this warranty, will be charged in accordance with Seller's standard prices then in effect.
THIS WARRANTY IS THE SOLE WARRANTY OF SELLER AND SELLER HEREBY EXPRESSLY DISCLAIMS AND BUYER
WAIVES ALL OTHER WARRANTIES EXPRESSED, IMPLIED IN LAW OR IMPLIED IN FACT, INCLUDING ANY WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Seller's sole obligation under this warranty shall be, at its
option, to repair or replace any equipment (or its component parts) which has a defect covered by this warranty, or to refund the purchase
price of such equipment or part. Under the terms of this warranty, Seller shall not be liable for (a) consequential, collateral, special or
liquidated losses or damages; (b) equipment conditions caused by normal wear and tear, abnormal conditions of use, accident, neglect, or
misuse of said equipment; (c) the expense of, and loss or damage caused by, repairs or alterations made by anyone other than the Seller; (d)
damage caused by abrasive materials, chemicals, scale deposits, corrosion, lightning, improper voltage, mishandling, or other similar
conditions; (e) any loss, damage, or expense relating to or resulting from installation, removal or reinstallation of equipment; (f) any labor
costs or charges incurred in repairing or replacing defective equipment or parts, including the cost of reinstalling parts that are repaired or
replaced by Seller; (g) any expense of shipment of equipment or repaired or replacement parts; or (h) any other loss, damage or expense of
any nature.
The above warranty shall not apply to any equipment which may be separately covered by any alternate or special warranties.
PERFORMANCE: In the absence of Certified Pump Performance Tests, equipment performance is not warranted or guaranteed.
Performance curves and other information submitted to Buyer are approximate and no warranty or guarantee shall be deemed to arise as a
result of such submittal. All testing shall be done in accordance with Seller's standard policy under Hydraulic Institute procedures.
LIABILITY LIMITATIONS: Under no circumstances shall the Seller have any liability under the Order or otherwise for liquidated
damages or for collateral, consequential or special damages or for loss of profits, or for actual losses or for loss of production or progress of
construction, regardless of the cause of such damages or losses. In any event, Seller's aggregate total liability under the Order or otherwise
shall not exceed the contract price.
ACTS OF GOD: Seller shall in no event be liable for delays in delivery of the equipment or other failures to perform caused by fires, acts of
God, strikes, labor difficulties, acts of governmental or military authorities, delays in transportation or procuring materials, or causes of any
kind beyond Seller's control.
COMPLIANCE WITH LAW: Seller agrees to comply with all United States laws and regulations applicable to the manufacturing of the
subject equipment. Such compliance shall include: The Fair Labor Standards Acts of 1938, as amended; Equal Employment Opportunity
clauses of Executive Order 11246, as amended; Occupational Safety and Health Act of 1970 and the standards promulgated thereunder, if
applicable. Since compliance with the various Federal, State, and Local laws and regulations concerning occupational health and safety,
pollution or local codes are affected by the use, installation and operation of the equipment and other matters over which Seller has no
control, Seller assumes no responsibility for compliance with those laws and regulations, whether by way of indemnity, warranty, or
otherwise. It is incumbent upon the Buyer to specify equipment which complies with local codes and ordinances.
800 Airport Road
North Aurora, Illinois 60542
630-859-7000
www.aurorapump.com
