PG2000®Owner's Manual
Pentair Water Pool and Spa, Inc.
1620 Hawkins Ave., Sanford, NC 27330 • [phone] • [phone]
10951 West Los Angeles Ave., Moorpark, CA 93021 • [phone] • [phone]
Visit us on the Internet at: www.pentairpool.com or www.staritepool.com
Specifications:
Electrical: 120 VAC 60 Hz
Operating load: 2 amps
Material: High Strength Plastic
Weight: 20 lbs.
Lamp: 150 Watt Metal-Halide
LampLife: 6000 hours
Restrike time: 2-3 minutes

P/N 840263 2 Rev. C 5-15-09
IMPORTANTSAFETYINSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS BEFORE OPERATING SYSTEM
Operating the PG2000®
Refer to the toggle switch position diagram below for the appropriate switch positions for your particular installation.
The switches are located on the lower right side of the unit. The PG2000®should always operate in manual mode no
matter what type of control system is installed.
NOTE
When cycling system off, then back on, it may take up to 3-4 minutes before the lamp "restrikes" or comes
back on. The lamp must cool down before restriking. All metal halide lamps have this characteristic and this is
a normal function of the PG2000®.
CAUTION
PG2000®Illuminator must have good ventilation to operate properly.
Blockage of air flow or air intake will shorten the bulb life and could
damage the unit. Make sure foliage; grass, groundcover, yard debris, etc.
is kept clear of intake vents on back of the unit in order to allow for proper
air flow. Do not install PG2000® Illuminator in an underground utility box or
similar appliance. Damage to the unit due to blocked air vents or poor
ventilation will void the warranty.
Replacing the Bulb.
1. Turn power to unit off.
WARNING
Turn off power before changing bulb. Failure to turn off power
may lead to severe electrical shock, which can result in death
or severe injury.
2. Remove two screws securing outer body and lift outer body
straight up.
WARNING
Bulb socket, and reflector are extremely hot during and following operation.
Allow sufficient time for cooling before touching them, or you may suffer
severe burns.
3. Remove screws (3) at bottom of socket bracket, (see Figure 1.)
and separate socket bracket assembly from reflector.
Remove bulb from socket and insert new bulb. Be sure not to
touch the glass of the bulb.
CAUTION
Do not touch the bulb with your bare fingers - fingerprints can actually cause
the bulb to overheat and crack. Handle the bulb using sheath provided in
packaging.
4. Reassemble socket bracket and make sure bulb is centered in
reflector.
5. Replace outer body and secure with two screws.
COLOR
POWER
RF2000 WIRELESS CONTROL
COLOR
POWER
REMOTE SWITCH CONTROL
COLOR
ON
POWER
ON
MANUAL CONTROL
TOGGLE SWITCH POSITIONS
COLOR
OFF
POWER
OFF
Figure 1.
Remove
Screws
Intake
Vents

Rev. C 5-15-09 3 P/N 840263
PG2000®Synchronization Procedures with SAm®light
Listed below are the procedures to follow if you have a SAm®underwater color light installed in your pool or spa and wish
to synchronize your fiber optics with SAm®.
NOTE
There may be slight color variations between the SAm®and PG2000®depending on the application. These variations are caused by
differences in initial light intensity and attenuation of the water and/or reflective surfaces (i.e. pool wall coloring).
In order for instructions to work you must have P/N 840242 – 7 Color, Electronic Synchronized PG2000®
(all other part numbers must use visual synchronization method)
Synchronization Start Conditions
1. SAm®is ON and colorwheel is stopped on ANY color (including white).
2. PG2000®power is ON and the colorwheel is OFF.
Synchronization Procedure
1. Simultaneously toggle SAm®OFF/ON and turn the PG2000®colorwheel ON.
2. Allow about 1½ minutes for colors to synchronize. Enjoy!
3. To stop both lights on the same color, simultaneously toggle SAm®OFF/ON and turn the PG2000®colorwheel OFF.
Visual Synchronization Method (for use with P/N 840241 only)
1. Turn SAm®ON, colorwheel is stopped on ANY color (including white).
2. Turn PG2000®ON and colorwheel ON.
3. When PG2000®transitions between purple and magenta toggle SAm®OFF/ON.
4. To stop both lights on the same color, simultaneously toggle SAm®off and on while turning the PG2000®colorwheel off.
Troubleshooting
If the PG2000®does not come on at all…
• Make sure the power switch is on (see switch position diagram). On Auto Remote Control (Compool®/Jandy®) make
sure the proper auxiliary is turned on. The PG2000®should always operate in manual mode no matter what type of
control system is installed.
• Check that the circuit breaker is not tripped.
• Check the incoming voltage at the PG2000®to verify power supply.
• Check the fuse(es) inside the unit. Replace if fuse is open.
If there is no light…
• Check that the bulb is in place securely in the socket.
• If you can hear the fan running the lamp has probably failed. Replace lamp.
If the fan runs, but the light cycles on and off…
• Check the vents of obstructions. There must be adequate air flow or PG2000®will overheat and begin to cycle.
• If the unit is operating in direct sunlight during a very hot day it may exceed the recommended operating temperature and
cycle on and off. This protects the end of the fiber optic cables from damage and is normal.
If the light comes on, but the fan is not running…
• Turn off PG2000®immediately and check for obstructions in the fan!
• DO NOT continue to operate PG2000®without the fan running! The excess heat can damage the fiber optic cable.
Colors do not change….
• Make sure the colorwheel power is on. On Auto Control (Compool®/Jandy®) make sure the proper auxiliary is turned on.
• Remove the body and check the colorwheel for obstructions or debris that might be interfering with the rotation of the
color wheel.
TROUBLESHOOTING NOTE:
If none of the above suggestions solve your particular problem, contact your pool contractor, or Pentair Water Pool and Spa, Inc.'s Customer
Service hotline at: 800-831-7133, Monday through Friday 7:30 a.m. – 4:30 p.m.
