OWNER'S MANUAL
PRO STRAIGHT CENTRIFUGAL PUMPS
P15008 (04-15-2023)
©2023 Pentair. All Rights Reserved.
ENGLISH: 1-22 FRENCH: 23-44 SPANISH: 45-66

2P15008 (04-15-2023)
TABLE OF CONTENTS
SAFETY INSTRUCTIONS ..................................................................................................3
INSTALLATION & OPERATION .............................................................................................4
ELECTRICAL ............................................................................................................6
MAINTENANCE ..........................................................................................................8
REPAIR PARTS ..........................................................................................................10
TROUBLESHOOTING.....................................................................................................19
WARRANTIES...........................................................................................................20
THIS MANUAL COVERS THE FOLLOWING MODEL SERIES:
 BERKELEY MODELS: CP/CB Series
 MYERS MODELS: CTJ Series
 STA-RITE MODELS: J/JB Series

3
P15008 (04-15-2023)
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS: For optimal performance and
operation, read these instructions carefully before installing
your new pump. This manual provides valuable guidance and
instructions that should be followed to perform installation,
operation and maintenance procedures for this product. It
should be kept near the installation for immediate reference.
Record nameplate data from your new pump on the blank
template located in “Maintenance” on for future reference.
This is the safety alert symbol. When you see this symbol
on your pump or in this manual, look for one of the following
signal words and be alert to the potential for personal injury.
warns about hazards that will cause serious
personal injury, death or major property damage if ignored.
warns about hazards that can cause serious
personal injury, death or major property damage if ignored.
warns about hazards that will or can cause minor
personal injury or property damage if ignored.
The word NOTE indicates special instructions that are important
but not related to hazards.
The hazards stated in this manual are not all-inclusive. To
minimize the risk of hazard, it is strongly recommended that
installation, operation and maintenance be performed by a
qualified professional in accordance with local codes and
standards for safe operation.
CALIFORNIA PROPOSITION 65 WARNING
This product and related accessories contain
chemicals known to the State of California to cause cancer,
birth defects or other reproductive harm.
ELECTRICAL SAFETY
RISK OF ELECTRIC SHOCK Can shock, burn or kill
All wiring should be done by a qualified electrician.
 Wire motor for correct voltage. See “Installation” section of
this manual and motor nameplate.
 Ground motor before connecting to power supply.
 Follow wiring instructions in this manual when connecting
motor to power lines.
 A complete power disconnect switch must be incorporated
in the fixed wiring.
 Install, ground, wire and maintain your pump in compliance
with all applicable national and local codes and ordinances.
Consult your local building inspector for code information.
GENERAL SAFETY
RISK OF EXPLOSION. The pump body may explode
if used to boost pressure above the pressures noted on.
Do not use this pump with inlet pressure greater than 70 psi
(483 kPa) or less than 3 psi (20.7 kPa). If not already in the piping
system, install a pressure relief valve in the pump discharge
line capable of passing the full pump flow at maximum rated
pressure. If local code requires installation of a pressure relief
valve capable of handling the full pump flow at a pressure less
than 100 psi (689 kPa), follow the code requirements.
RISK OF FIRE OR EXPLOSION. To avoid risk of fire
and explosion, pump water only with this pump. Do not pump salt
water, flammable liquids or chemicals. Do not use the pump near
gas pilot lights or where chemical or gas fumes are present.
Use of an electric pump with liquids other than water or in an
atmosphere containing chemical or gas fumes may ignite those
liquids or gases and cause injury or death due to an explosion
and/or fire. Pump approved liquids only with this pump.
RISK OF BURNS. If water is trapped in the pump
during operation it may turn to steam. Trapped steam may cause
an explosion resulting in injury or property damage. Never run
the pump with the outlet closed or obstructed.
RISK OF FREEZING. Do not allow pump, piping,
or any other system component containing water to freeze.
Freezing may damage system, leading to injury or flooding.
Allowing pump or system components to freeze will void the
warranty.
NOTE: Only service agent or qualified person should replace
power cord to avoid injury.
Periodically inspect pump and system components.
Wear safety glasses at all times when working on pumps.
Keep work area clean, uncluttered and properly lighted; store
properly all unused tools and equipment.
ORDERING REPLACEMENT PARTS
Locate the Pentair nameplate on pump. This plate is normally on
the pump case or bracket (seal plate).
To ensure receipt of correct parts, provide all nameplate data
when ordering. Catalog number is most important to reference.
Write the nameplate information below, as nameplates can
become worn or lost.
Model:
S.N. or Date:
Impeller Dia.:
Catalog No.:

4P15008 (04-15-2023)
INSTALLATION & OPERATION
PIPING - GENERAL
Support both suction and discharge piping independently at
a point near the pump to avoid putting a strain on the pump
housing. Start all piping at the pump.
Increase pipe diameter at both the suction and discharge by one
(1) standard pipe size (minimum) to obtain desired performance
and flow rate. Refer to Table I when sizing pipe for your pumping
system.
NOTE: Do not use pipe with smaller diameter on the suction side
of pump.
SUCTION PIPE
Increase pipe size from pump tapping as shown in Table I shown
above. Figure 1 depicts a recommended run of pipe and fittings
for the suction side of a centrifugal pump. Please refer to this
illustration when choosing pipe and fittings for your suction
connection.
IMPORTANT: All connections must be air tight!
Figure 2 depicts conditions that are not desirable on the suction
side of a centrifugal pump and may cause problems in flow rate
and priming. Please look this illustration over carefully before
choosing pipe and fittings for your suction connection.
DISCHARGE PIPING
Increase pipe size from pump tapping as show in Table I.
Figure 1 depicts a recommended run of pipe and fittings for
the discharge. Install tee with priming plug as close to pump
as possible. Figure 2 notes conditions that should be avoided.
Please read over carefully before making discharge connection.
PRIMING THE PUMP
A pump is primed when all air in the suction line and pump volute
has been evacuated and replaced with water.
To Prime:
1. Close valve in discharge line.
2. Remove priming plug from tee and fill pump and suction line
with water until water is flowing back out of tee.
3. Replace priming plug.
4. Start pump and slowly open valve until desired water flow is
achieved.
NOTE: If water is not being pumped, turn off pump, close valve,
and repeat steps 1 through 4.
If pump volute is rotated as shown in Figure 1, loosen vent plug
when priming to evacuate air trapped inside volute and tighten
when volute is completely filled with water.
RISK OF EXPLOSION AND SCALDING.Never run
pump against closed discharge. To do so can boil water inside
pump, causing hazardous pressure buildup and possible
explosion.
RISK OF FLOODING.Do not run the pump dry. This
will damage mechanical seal and void warranty. It may cause
burns to person handling pump.
MOTOR NORMALLY OPERATES AT HIGH
TEMPERATURE AND WILL BE TOO HOT TO TOUCH. It is protected
from heat damage during operation by an automatic internal
cutoff switch. Before handling pump or motor, stop motor and
allow it to cool for 20 minutes.
PIPE TAPPING SIZE ON PUMP RECOMMENDED PIPE SIZE
Suction Discharge Suction Discharge
1-1/4 11-1/2 1-1/4
1-1/2 1-1/4 21-1/2
21-1/2 3 2
TABLE I - PIPE TAPPING AND RECOMMENDED PIPE SIZE DATA

5
P15008 (04-15-2023)
INSTALLATION & OPERATION
Support suction pipe
as required
Support discharge
pipe as required
As close
as possible
4 x "D"
minimum
Foot
Valve
Pipe diameter
"D"
Straight run, short as
possible but at least 6
times pipe diameter ("D")
sloping away from pump
Short length of
straight pipe
after reducer
Important:
All connections must
be air tight
Eccentric
Reducer
Solid, level
base
Tee and
Priming Plug
Rotated Volute
Gate
Valve
Union
Discharge
to service
Recommended pump suction
and discharge connections
Vent
Plug
Priming
Plug
Street Elbow
Not Recommended pump suction
and discharge connections
Elbow immediately
in front of pump
suction.
On the discharge avoid:
Quick closing valves.
Small I.D. pipe.
Numerous fittings.
Misalignment.
Sharp turns in piping run.
High
lift
Pipe diameter "D"
insucient size
Pipe submerged
less than 4 x "D"
will cause vortexing
Long suction
run
Concentric
Reducer
Use of excess fittings
means potential air leaks
Valve
Unsupported
Pipe
Concentric Reducer causes high
spots along the suction line resulting
in air pockets.
684 0294
Figure 1
Figure 2

6P15008 (04-15-2023)
Figure 3: Changing the Voltage Setting
Figure 4: Motor Set for 115 Volt Operation
ELECTRICAL
CONNECTION DIAGRAM FOR DUAL VOLTAGE, SINGLE-
PHASE MOTORS
Your dual-voltage motor’s terminal board (under the motor end
cover) will match one of the diagrams below. Follow that diagram
if necessary to convert motor to 115 Volt power. Connect power
supply wires to L1 and L2. For 3-phase motors, or if motor does
not match these pictures, follow the connection diagram on the
motor nameplate.
THE MOTOR IS SET FOR 230 VOLTS WHEN SHIPPED.
To change the motor to use 115 volts:
1. Turn off power
2. Remove the back motor cover.
3. Use a screwdriver or 1/2” wrench and turn the voltage
selector dial counterclockwise until 115 shows in the
dial opening.
4. Reinstall the motor cover.
HAZARDOUS VOLTAGE.Can shock, burn, or cause
death. Disconnect power to motor before working on pump or
motor. Ground motor before connecting to power supply.
WIRING
Ground motor before connecting to electrical power
supply. Failure to ground motor can cause severe or fatal electrical
shock hazard.
Do not ground to a gas supply line.
To avoid dangerous or fatal electrical shock, turn OFF power to motor
before working on electrical connections.
Supply voltage must be within ±10% of nameplate voltage. Incorrect
voltage can cause fire or damage motor and voids warranty. If in doubt
consult a licensed electrician.
Use wire size specified in Wiring Chart. If possible, connect pump to a
separate branch circuit with no other appliances on it.
Wire motor according to diagram on motor nameplate. If nameplate
diagram differs from diagrams above, follow nameplate diagram.
1. Install, ground, wire and maintain your pump in compliance with
the National Electrical Code (NEC) in the U.S., or the Canadian
Electrical Code (CEC), as applicable, and with all local codes and
ordinances that apply. Consult your local building inspector for
code information.
2. Provide a correctly fused disconnect switch for protection while
working on motor. For switch requirements, consult your local
building inspector for information about codes.
3. Disconnect power before servicing motor or pump. If the
disconnect switch is out of sight of pump, lock it open and tag it to
prevent unexpected power application.
4. Ground the pump permanently using a wire of the same size as
that specified in Wiring Chart. Make ground connection to green
grounding terminal under motor canopy marked GRD. or .
5. Connect ground wire to a grounded lead in the service panel or
to a metal underground water pipe or well casing at least 10 feet
long. Do not connect to plastic pipe or insulated fittings.
6. Protect current carrying and grounding conductors from cuts,
grease, heat, oil, and chemicals.
7. Connect current carrying conductors to terminals L1 and L2 under
motor canopy. When replacing motor, check wiring diagram on
motor nameplate against Figure ##. If the motor wiring diagram
does not match either diagram in Figure 3, follow the diagram
on the motor. IMPORTANT: 115/230 Volt single phase models are
shipped from factory with motor wired for 230 volts. If power
supply is 115 volts, remove motor canopy and reconnect motor as
shown in Figure 3. Do not try to run motor as received on
115 volt current.
8. Motor has automatic internal thermal overload protection. If
motor has stopped for unknown reasons, thermal overload may
restart it unexpectedly, which could cause injury or property
damage. Disconnect power before servicing motor.
9. Always consult a licensed electrician for clarification of this
procedure or the wiring diagrams.

7
P15008 (04-15-2023)
HORSEPOWER VOLTAGE PHASE MOTOR
TYPE
MAX. LOAD
AMPS
BRANCH
FUSE RATING
AMP
DISTANCE IN FEET (METERS) FROM MOTOR TO SUPPLY
0-100 (0-30) 101-200 (31-61) 201-300 (62-91) 301-400 (92-122)
AWG WIRE SIZE (MM^2)
1/2 115/230 1ODP 8.5/4.3 15/15 14/14 (2/2) 12/14 (3/2) 10/14 (5.5/2) 8/14 (8.4/2)
1/2 230/460 3ODP 2.3/1.15 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
1/2 115/230 1TEFC 8.2/4.1 15/15 14/14 (2/2) 12/14 (3/2) 10/14 (5.5/2) 8/14 (8.4/2)
1/2 230/460 3TEFC 2.2/1.1 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
3/4 115/230 1ODP 11.4/5.7 20/15 14/14 (2/2) 10/14 (5.5/2) 8/14 (8.4/2) 6/12 (14/3)
3/4 230/460 3ODP 3.1/1.55 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
3/4 115/230 1TEFC 11.6/5.8 15/15 14/14 (2/2) 10/14 (5.5/2) 8/14 (8.4/2) 6/14 (14/2)
3/4 230/460 3TEFC 2.9/1.45 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
1115/230 1ODP 12.2/6.1 25/15 12/14 (3/2) 8/14 (8.4/2) 8/14 (8.4/2) 6/12 (14/3)
1230/460 3ODP 3.6/1.8 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
1115/230 1TEFC 14.2/7.1 20/15 12/14 (3/2) 8/14 (8.4/2) 6/14 (14/2) 6/12 (14/3)
1230/460 3TEFC 3.6/1.8 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
1-1/2 115/230 1ODP 18.4/9.2 30/20 10/14 (5.5/2) 8/14 (8.4/2) 6/12 (14/3) 4/10 (21/5.5)
1-1/2 230/460 3ODP 4.7/2.35 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
1-1/2 115/230 1TEFC 18.0/9.0 25/15 10/14 (5.5/2) 8/14 (8.4/2) 6/12 (14/3) 4/10 (21/5.5)
1-1/2 230/460 3TEFC 4.8/2.4 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 14/14 (2/2)
2115/230 1ODP 22.8/11.4 45/25 10/14 (5.5/2) 6/12 (14/3) 6/12 (14/3) 4/10 (21/5.5)
2230/460 3ODP 6.8/3.4 15/15 14/14 (2/2) 14/14 (2/2) 12/14 (3/2) 12/14 (3/2)
2230 1TEFC 10.4 15 14 (2) 14 (2) 12 (3) 10 (5.5)
2230/460 3TEFC 6.0/3.0 15/15 14/14 (2/2) 14/14 (2/2) 14/14 (2/2) 12/14 (3/2)
2-1/2 115/230 1ODP 22/11 45/25 10/14 (5.5/2) 8/12 (8.4/3) 6/12 (14/3) 4/10 (21/5.5)
2-1/2 230/460 3ODP 8.5/4.25 15/15 14/14 (2/2) 14/14 (2/2) 12/14 (3/2) 10/14 (5.5/2)
2-1/2 230 1TEFC 11.7 15 14 (2) 14 (2) 12 (3) 10 (5.5)
2-1/2 230/460 3TEFC 7.0/3.5 15/15 14/14 (2/2) 14/14 (2/2) 12/14 (3/2) 12/14 (3/2)
TABLE II - RECOMMENDED FUSING AND WIRING DATA - 60 CYCLE MOTORS
ELECTRICAL

8P15008 (04-15-2023)
MAINTENANCE
PUMP SERVICE
This centrifugal pump requires little or no service other than
reasonable care and periodic cleaning. Follow the procedure
outlined below for shaft seal replacement.
NOTE: Pumps use mechanical seals with a rubber seat ring or a
sealing O-Ring. These seals are completely interchangeable.
NOTE:The highly polished and lapped faces of this seal are
easily damaged. Read instructions and handle the seal with
care.
Some models are equipped with an impeller screw, which has a
left-hand thread. Before unscrewing the impeller, remove the
impeller screw.
REMOVAL OF OLD SEAL
1. After unscrewing impeller, carefully remove rotating part of
seal by prying up on sealing washer, using two screwdrivers
(see Figure 5-A shown below). Use care not to scratch
motor shaft.
2. Remove seal plate from motor and place on flat surface,
face down. Use a screwdriver to push ceramic seat out
from seal cavity (see Figure 5-B shown below).
INSTALLATION OF FLOATING SEAT (SEE FIGURE 5-C
SHOWN BELOW)
1. Clean polished surface of floating seat with clean cloth.
2. Turn seal plate over so seal cavity is up, clean cavity
thoroughly.
3. Lubricate outside rubber surface of ceramic seat with
soapy water and press firmly into seal cavity with finger
pressure. If seat will not locate properly in this manner,
place cardboard washer over polished face of seat and
press into seal cavity using a 3/4” socket or 3/4” piece of
standard pipe.
4. Dispose of cardboard washer. Be sure polished surface of
seat is free of dirt and has not been damaged by insertion.
Remove excess soapy water.
INSTALLATION OF ROTATING PART OF SEAL UNIT (SEE
FIGURE 5-D SHOWN BELOW)
1. Reinstall seal plate using extreme caution not to hit ceramic
portion of seal on motor shaft.
2. Inspect shaft to make sure that it is clean.
3. Clean face of sealing washer with clean cloth.
4. Lubricate inside diameter and outer face of rubber drive
ring with soapy water and slide assembly on motor shaft
(sealing face first) until rubber drive ring hits shaft shoulder.
5. Screw impeller on shaft until impeller hub hits shaft
shoulder. This will automatically locate seal in place and
move the sealing washer face up against seat facing.
Reinstall impeller screw (if used).
Seal Plate
Mechanical seal
rotating half
Mechanical seal
stationary half
A-Seal removal-rotating half B-Seal removal-stationary half C-Stationary half installation D-Rotating half installation
T
u
r
n
o
v
e
r
Polished
surface Rubber
surface
Cardboard
washer
(supplied w/seal)
3/4" socket
or pipe
Sealing
face
Rubber drive
ring
Impeller
Shaft
shoulder
5939 0109
Figure 5: Pump Service

9
P15008 (04-15-2023)
PAGE INTENTIONALLY LEFT BLANK

10 P15008 (04-15-2023)
2409 0496 SPC
1
2
3
4
56
7A
6A
7
8
10 9
9A
8
8
This drawing is for use with
Models using a capscrew conguration.
11
REPAIR PARTS
2410 0496 SPC
1
2
3
4
5
6
7A
6A
7
8
12
11
12
10
10A
9
This drawing is for use with
Models using a stud conguration.
TEFC MOTOR MODELS WITH
STUD CONFIGURATION.
TEFC MOTOR MODELS WITH CAP
SCREW CONFIGURATION.
12

11
P15008 (04-15-2023)
REPAIR PARTS
KEY
NO.
PART
DESCRIPTION
QTY.
USED
JHCT-61H
JBHCT-61S
JHC3T-61H
JBHC3T-61S
JHDT-62H
JBHDT-62S
JHD3T-62H
JBHD3T-62S
JHET-63H
JBHET-63S
JHE3T-63H
JBHE3T-63S
JHFT-51H
JBHFT-51S
JHF3T-51H
JBHF3T-51S
JHGT-52H
JBHGT-52S
JHG3T-52H
JBHG3T-52S
JBHHGT-53S
JHHG3T-53H
JBHHG3T-53S
1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
1 Motor - 115/230v, 1ph 1 A1 0 0 C L-T A100DL-T A100EL-T A100FL-T AE100GL-T A E 1 0 0 G 5 L-T
1 Motor - 230/460v, 3ph 1 A P 1 0 0 C L-T AP100DL-T AP100EL-T AP100FL-T AP100GL-T A P 1 0 0 G 5 L-T
2 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3 Seal Plate 1 C3-178 C3-178 C3-178 C3-178 C3-181 C3-181
4 Seal Plate Gasket 1 C20-121N C20-121N C20-121N C20-121N C20-122N C20-122N
5 Shaft Seal 1 U109-6B U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 C105-92PNX C105-92PM X C105-92PLX C105-92PBX C105-214PCA -
6 Impeller - Bronze, 1ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6 Impeller - Noryl, 3ph 1 C105-92PNXA C105-92PMXA C105-92PLXA C105-92PBXA C105-214PCA C105-214PA
6 Impeller - Bronze, 3ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6A Impeller Screw 1 C30-14SS** C30-14SS** C30-14SS** C30-14SS** C30-14SS C30-14SS
7Volute Assembly with
Wear Ring 1C101-284A C101-284A C101-284A C101-284A C101-264 C101-264B
7A Wear Ring 1 C23-27 C23-27 C23-27 C23-27 C23-19 C23-19
8Pipe Plug, 1/4” NPT
Sq. Hd. 1 - - - - - -
8Pipe Plug, 1/4” NPT
Hex Hd. ( ) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV U78-941ZPV U78-941ZPV (3) U78-941ZPV (3)
9Base 1 J104-9A J104-9A J104-9A J104-9A J104-9A J104-9A
9A Motor Pad 1 C35-5S C35-5S C35-5S C35-5S C35-5S C35-5S
10
Socket Head
Capscrew, 3/8” - 16 x
1-1/4” Lg.
4U30-104ZP U30-104ZP U30-104ZP U30-104ZP U30-104ZP U30-104ZP
11 Stud, 3/8 - 16 x 1-13/16” 4 - - - - - -
12 Hex Nut, 3/8 - 16 4 - - - - - -
Seal Kit PP1700 PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
STA-RITE MODELS (TEFC MOTORS)

12 P15008 (04-15-2023)
REPAIR PARTS
KEY
NO.
PART
DESCRIPTION
QTY.
USED
JMCT-56
JBMCT-56S
JMC3T-56
JBMC3T-56S
JMDT-57
JMD3T-57
JBMD3T-57S
JMET-58
JBMET-58S
JME3T-58
JBME3T-58S
JMFT-40
JBMFT-40S
JMF3T-40
JBMF3T-40S
JMGT-41
JBMGT-41S
JMG3T-41
JBMG3T-41S
JBMMGT-59S
JBMMG3T-59S
1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
1 Motor - 115/230v, 1ph 1 A1 0 0 C L-T A100DL-T A100EL-T A100FL-T AE100GL-T A E 1 0 0 G 5 L-T
1 Motor - 230/460v, 3ph 1 A P 1 0 0 C L-T AP100DL-T AP100EL-T AP100FL-T AP100GL-T A P 1 0 0 G 5 L-T
2 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3 Seal Plate 1 N3-8 N3-8 N3-8 C3-52 C3-52 C3-52
4 Seal Plate Gasket 1 N20-26N N20-26N N20-26N C20-21N C20-21N C20-21N
5 Shaft Seal 1 U109-6B U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 J105-42PHA J105-42PJA J105-42P C105-114PNF C105-114PNGA -
6 Impeller - Bronze, 1ph 1 J105-42MA -J105-42NA C105-79BA C105-73BA C105-80DA
6 Impeller - Noryl, 3ph 1 J105-42PHA J105-42PJA J105-42PPA C105-114PNFA C105-114PNGA -
6 Impeller - Bronze, 3ph 1 J105-42MA J105-42LA J105-42NA C105-79BA C105-73BA C105-80DA
6A Impeller Screw 1 C30-6SS** C30-6SS** C30-6SS** C30-14SS** C30-14SS** C30-14SS**
7Volute Assembly with
Wear Ring 1C101-122E C101-122E C101-122 C101-123 C101-123 C101-123B
7A Wear Ring 1 N23-7 N23-7 N23-7 C23-19 C23-19 C23-19
8Pipe Plug, 1/4” NPT
Sq. Hd. 1 - - - U78-57DT U78-57DT U78-57DT
8Pipe Plug, 1/4” NPT
Hex Hd. ( ) U78-941ZPV (4) U78-941ZPV (4) U78-941ZPV (4) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3)
9Base 1 J104-9A J104-9A J104-9A J104-9A J104-9A J104-9A
9A Motor Pad 1 C35-5 C35-5 C35-5 C35-5S C35-5S C35-5S
10
Socket Head
Capscrew, 3/8” - 16 x
1-1/4” Lg.
4U30-104ZP U30-104ZP U30-104ZP - - -
11 Stud, 3/8 - 16 x 1-13/16” 4 - - - U30-35SS U30-35SS U30-35SS
12 Hex Nut, 3/8 - 16 4 - - - U36-38ZP U36-38ZP U36-38ZP
Seal Kit PP1700 PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
STA-RITE MODELS (TEFC MOTORS)

13
P15008 (04-15-2023)
2410 0496 SPC
1
2
3
4
5
6
7A
6A
7
8
12
11
12
10
10A
9
This drawing is for use with
Models using a stud conguration.
2409 0496 SPC
1
2
3
4
56
7A
6A
7
8
10 9
9A
8
8
This drawing is for use with
Models using a capscrew conguration.
11
REPAIR PARTS
ODP MOTOR MODELS

14 P15008 (04-15-2023)
REPAIR PARTS
KEY
NO.
PART
DESCRIPTION
QTY.
USED
S39516
S39529
S39517
S39530
S39518
S39531
S39519
S39532
S39520
S39533
S39521
S39534
S39522
S39535
S39523
S39536
S39524
S39537
S39525
S39538
S39526
S39539
S39527
S39540
1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
1Motor - 115/230v, 1ph,
ODP 1J218-1651 J218-1652 J218-1653 J218-1655 J218-1656 J218-1657
1Motor - 230/460v, 3ph
ODP 1AP100CL AP100DL AP100EL AP100FL AP100GL AP100G5L
2Water Slinger 117351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3Seal Plate 1C3-178 C3-178 C3-178 C3-178 C3-181 C3-181
4 Seal Plate Gasket 1 C20-121N C20-121N C20-121N C20-121N C20-122N C20-122N
5Shaft Seal 1U109-6B U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 C105-92PN C105-92PM C105-92PL C105-92PB C105-214PCAB C105-214PAB
Impeller - Bronze, 1ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6 Impeller - Noryl, 3ph 1 C105-92PNA C105-92PMA C105-92PLA C105-92PBA C105-214PCAB C105-214PAB
Impeller - Bronze, 3ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6A Impeller Screw 1C30-14SS** C30-14SS** C30-14SS** C30-14SS** C30-14SS C30-14SS
7Volute Assembly with
Wear Ring 1C101-284E C101-284E C101-284E C101-284E C101-264E C101-264EB
7A Wear Ring 1C23-27 C23-27 C23-27 C23-27 C23-19 C23-19
8Pipe Plug, 1/4” NPT
Sq. Hd. 1 - - - - - -
9Pipe Plug, 1/4” NPT
Hex Hd. ( ) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3)
10 Base 1J104-9F J104-9F J104-9F J104-9F J104-9F J104-9F
10A Motor Pad 1 C35-5S C35-5S C35-5S C35-5S C35-5S C35-5S
11 Stud, 3/8 - 16 x 1-13/16” 4 - - - - - -
12 Hex Nut, 3/8 - 16 4 - - - - - -
12* Hex Capscrew, 3/8" -
16 x 1-1/2" Lg. (Bottom) ( ) - - - - - -
12* Hex Capscrew, 3/8" -
16 x 1-1/4" Lg. (Top) ( ) U30-75ZP (4) U30-75ZP (4) U30-75ZP (4) U30-75ZP (4) U30-75ZP (2) U30-75ZP (2)
12* Hex Capscrew, 3/8" -
16 x 1" Lg. (Bottom) ( ) - - - - U30-74ZP (2) U30-74ZP (2)
Seal Kit PP1700 PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
BERKELEY MODELS (ODP MOTORS)

15
P15008 (04-15-2023)
REPAIR PARTS
KEY
NO.
PART
DESCRIPTION
QTY.
USED
S39490
S39503
S39491
S39504
S39492
S39505
S39493
S39506
S39494
S39507
S39495
S39508
S39496
S39509
S39497
S39510
S39498
S39511
S39499
S39512
S39500
S39513
S39514
1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
1Motor - 115/230v, 1ph,
ODP 1J218-1651 J218-1652 J218-1653 J218-1655 J218-1656 J218-1657
1Motor - 230/460v, 3ph
ODP 1AP100CL AP100DL AP100EL AP100FL AP100GL AP100G5L
2Water Slinger 117351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3Seal Plate 1N3-8 N3-8 N3-8 C3-52 C3-52 C3-52
4 Seal Plate Gasket 1 N20-26N N20-26N N20-26N C20-21N C20-21N C20-21N
5Shaft Seal 1U109-6B U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 J105-42PHA J105-42PJA J105-42P C105-114PNF C105-114PNGA -
Impeller - Bronze, 1ph 1 J105-42MA J105-42LA J105-42NA C105-79BA C105-73BA C105-80DA
6 Impeller - Noryl, 3ph 1 J105-42PHA J105-42PJA J105-42PPA C105-114PNFA C105-114PNGA -
Impeller - Bronze, 3ph 1 J105-42MA J105-42LA J105-42NA C105-79BA C105-73BA C105-80DA
6A Impeller Screw 1C30-6SS** C30-6SS** C30-6SS** C30-14SS** C30-14SS C30-14SS
7Volute Assembly with
Wear Ring 1C101-122E C101-122E C101-122 C101-123 C101-123 C101-123B
7A Wear Ring 1N23-7 N23-7 N23-7 C23-19 C23-19 C23-19
8Pipe Plug, 1/4” NPT
Sq. Hd. 1 - - - U78-57DT U78-57DT U78-57DT
9Pipe Plug, 1/4” NPT
Hex Hd. ( ) U78-941ZPV (4) U78-941ZPV (4) U78-941ZPV (4) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV
10 Base 1J104-9F J104-9F J104-9F J104-9F J104-9F J104-9F
10A Motor Pad 1 C35-5S C35-5S C35-5S C35-5S C35-5S C35-5S
11 Stud, 3/8 - 16 x 1-13/16” 4 - - - U30-35SS U30-35SS U30-35SS
12 Hex Nut, 3/8 - 16 4 - - - U36-38ZP U36-38ZP U36-38ZP
12* Hex Capscrew, 3/8" -
16 x 1-1/2" Lg. (Bottom) ( ) U30-76ZP (2) U30-76ZP (2) U30-76ZP (2) - - -
12* Hex Capscrew, 3/8" -
16 x 1-1/4" Lg. (Top) ( ) U30-75ZP (2) U30-75ZP (2) U30-75ZP (2) - - -
12* Hex Capscrew, 3/8" -
16 x 1" Lg. (Bottom) ( ) - - - - - -
Seal Kit PP1700 PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
BERKELEY MODELS (ODP MOTORS)

16 P15008 (04-15-2023)
KEY
NO.
PART
DESCRIPTION
QTY.
USED
CTJ05
CTJ05B
CTJ053
CTJ05B3
CTJ07
CTJ07B
CTJ073
CTJ07B3
CTJ10
CTJ10B
CTJ103
CTJ10B3
CTJ15
CTJ15B
CTJ153
CTJ15B3
CTJ20
CTJ20B
CTJ203
CTJ20B3
CTJ25
CTJ25B
CTJ253
CTJ25B3
1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
1Motor - 115/230v, 1ph,
ODP 1J218-1651 J218-1652 J218-1653 J218-1655 J218-1656 J218-1657
1Motor - 230/460v, 3ph
ODP 1AP100CL AP100DL AP100EL AP100FL AP100GL AP100G5L
2Water Slinger 117351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3Seal Plate 1C3-178 C3-178 C3-178 C3-178 C3-181 C3-181
4 Seal Plate Gasket 1 C20-121N C20-121N C20-121N C20-121N C20-122N C20-122N
5Shaft Seal 1U109-6B U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 C105-92PN C105-92PM C105-92PL C105-92PB C105-214PCAB C105-214PAB
Impeller - Bronze, 1ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6 Impeller - Noryl, 3ph 1 C105-92PNA C105-92PMA C105-92PLA C105-92PBA C105-214PCAB C105-214PAB
Impeller - Bronze, 3ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6A Impeller Screw 1C30-14SS** C30-14SS** C30-14SS** C30-14SS** C30-14SS C30-14SS
7Volute Assembly with
Wear Ring 1C101-284E C101-284E C101-284E C101-284E C101-264E C101-264EB
7A Wear Ring 1C23-27 C23-27 C23-27 C23-27 C23-19 C23-19
8Pipe Plug, 1/4” NPT
Sq. Hd. 1 - - - - - -
9Pipe Plug, 1/4” NPT
Hex Hd. ( ) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3)
10 Base 1J104-9F J104-9F J104-9F J104-9F J104-9F J104-9F
10A Motor Pad 1 C35-5S C35-5S C35-5S C35-5S C35-5S C35-5S
11 Stud, 3/8 - 16 x 1-13/16” 4 - - - - - -
12 Hex Nut, 3/8 - 16 4 - - - - - -
12* Hex Capscrew, 3/8"-
16 x 1-1/2" Lg. (Bottom) ( ) - - - - - -
12* Hex Capscrew, 3/8"-
16 x 1-1/4" Lg. (Top) ( ) U30-75ZP (4) U30-75ZP (4) U30-75ZP (4) U30-75ZP (4) U30-75ZP (2) U30-75ZP (2)
12* Hex Capscrew, 3/8"-
16 x 1" Lg. (Bottom) ( ) - - - - U30-74ZP (2) U30-74ZP (2)
Seal Kit PP1700 PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
REPAIR PARTS
MYERS MODELS (ODP MOTORS)

17
P15008 (04-15-2023)
KEY
NO.
PART
DESCRIPTION
QTY.
USED
JHC-61HL
JBHC-61S
JHC3-61H
JBHC3-61S
JHD-62HL
JBHD-62S
JHD3-62H
JBHD3-62S
JHE-63HL
JBHE-63S
JHE3-63H
JBHE3-63S
JHF-51HL
JBHF-51S
JHF3-51H
JBHF3-51S
JHG-52HL
JBHG-52S
JHG3-52H
JBHG3-52S
JHHG-53HL
JBHHG-53S
JHHG3-53H
JBHHG3-53S
1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
1Motor - 115/230v, 1ph,
ODP 1J218-1651 J218-1652 J218-1653 J218-1655 J218-1656 J218-1657
1Motor - 230/460v, 3ph
ODP 1AP100CL AP100DL AP100EL AP100FL AP100GL AP100G5L
2Water Slinger 117351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3Seal Plate 1C3-178 C3-178 C3-178 C3-178 C3-181 C3-181
4 Seal Plate Gasket 1 C20-121N C20-121N C20-121N C20-121N C20-122N C20-122N
5Shaft Seal 1U109-6B U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 C105-92PNX C105-92PMX C105-92PLX C105-92PBX C105-214PCA C105-214PA
Impeller - Bronze, 1ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6 Impeller - Noryl, 3ph 1 C105-92PNXA C105-92PMXA C105-92PLXA C105-92PBXA C105-214PCA C105-214PA
Impeller - Bronze, 3ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6A Impeller Screw 1C30-14SS** C30-14SS** C30-14SS** C30-14SS** C30-14SS C30-14SS
7Volute Assembly with
Wear Ring 1C101-284A C101-284A C101-284A C101-284A C101-264 C101-264B
7A Wear Ring 1C23-27 C23-27 C23-27 C23-27 C23-19 C23-19
8Pipe Plug, 1/4” NPT
Sq. Hd. 1 - - - - - -
9Pipe Plug, 1/4” NPT
Hex Hd. ( ) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3)
10 Base 1J104-9F J104-9F J104-9F J104-9F J104-9F J104-9F
10A Motor Pad 1 C35-5S C35-5S C35-5S C35-5S C35-5S C35-5S
11 Stud, 3/8 - 16 x 1-13/16” 4 - - - - - -
12 Hex Nut, 3/8 - 16 4 - - - - - -
12* Hex Capscrew, 3/8" -
16 x 1-1/2" Lg. (Bottom) ( ) - - - - - -
12* Hex Capscrew, 3/8" -
16 x 1-1/4" Lg. (Top) ( ) U30-75ZP (4) U30-75ZP (4) U30-75ZP (4) U30-75ZP (4) U30-75ZP (2) U30-75ZP (2)
12* Hex Capscrew, 3/8" -
16 x 1" Lg. (Bottom) ( ) - - - - U30-74ZP (2) U30-74ZP (2)
Seal Kit PP1700 PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
REPAIR PARTS
STA-RITE MODELS (ODP MOTORS)

18 P15008 (04-15-2023)
KEY
NO.
PART
DESCRIPTION
QTY.
USED
JMC-56L
JBMC-56S
JMC3-56
JBMC3-56S
JMD-57L
JBMD-57S
JMD3-57
JBMD3-57S
JME-58L
JBME-58S
JME3-58
JBME3-58S
JMF-40L
JBMF-40S
JMF3-40
JBMF3-40S
JMG-41L
JBMG-41S
JMG3-41
JBMG3-41S
JBMMG-59S
JBMMG3-59S
1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
1Motor - 115/230v, 1ph,
ODP 1J218-1651 J218-1652 J218-1653 J218-1655 J218-1656 J218-1657
1Motor - 230/460v, 3ph
ODP 1AP100CL AP100DL AP100EL AP100FL AP100GL AP100G5L
2Water Slinger 117351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3Seal Plate 1N3-8 N3-8 N3-8 C3-52 C3-52 C3-52
4 Seal Plate Gasket 1 N20-26N N20-26N N20-26N C20-21N C20-21N C20-21N
5Shaft Seal 1U109-6B U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 J105-42PHA J105-42PJA J105-42P C105-114PNF C105-114PNGA -
Impeller - Bronze, 1ph 1 J105-42MA J105-42LA J105-42NA C105-79BA C105-73BA C105-80DA
6 Impeller - Noryl, 3ph 1 J105-42PHA J105-42PJA J105-42PPA C105-114PNFA C105-114PNGA -
Impeller - Bronze, 3ph 1 J105-42MA J105-42LA J105-42NA C105-79BA C105-73BA C105-80DA
6A Impeller Screw 1C30-6SS** C30-6SS** C30-6SS** C30-14SS** C30-14SS C30-14SS
7Volute Assembly with
Wear Ring 1C101-122E C101-122E C101-122 C101-123 C101-123 C101-123B
7A Wear Ring 1N23-7 N23-7 N23-7 C23-19 C23-19 C23-19
8Pipe Plug, 1/4” NPT
Sq. Hd. 1 - - - U78-57DT U78-57DT U78-57DT
9Pipe Plug, 1/4” NPT
Hex Hd. ( ) U78-941ZPV (4) U78-941ZPV (4) U78-941ZPV (4) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV
10 Base 1J104-9F J104-9F J104-9F J104-9F J104-9F J104-9F
10A Motor Pad 1 C35-5S C35-5S C35-5S C35-5S C35-5S C35-5S
11 Stud, 3/8 - 16 x 1-13/16” 4 - - - U30-35SS U30-35SS U30-35SS
12 Hex Nut, 3/8 - 16 4 - - - U36-38ZP U36-38ZP U36-38ZP
12* Hex Capscrew, 3/8" -
16 x 1-1/2" Lg. (Bottom) ( ) U30-76ZP (2) U30-76ZP (2) U30-76ZP (2) - - -
12* Hex Capscrew, 3/8" -
16 x 1-1/4" Lg. (Top) ( ) U30-75ZP (2) U30-75ZP (2) U30-75ZP (2) - - -
12* Hex Capscrew, 3/8" -
16 x 1" Lg. (Bottom) ( ) - - - - - -
Seal Kit PP1700 PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
REPAIR PARTS
STA-RITE MODELS (ODP MOTORS)

19
P15008 (04-15-2023)
TROUBLESHOOTING
SYMPTOMS
PROBABLE CAUSE
ELECTRICAL MECHANICAL SYSTEM
A B C D E F G H I A B C D E F A B C
Pump runs, but no water delivered X X X X
Not enough water delivered X X X X
Not enough pressure X X X X
Excessive vibration X X
Abnormal Noise X X
Pump stops X X X X X X X X
Overheating X X X X X X X X X
CAUSE CORRECTIVE ACTION
ELECTRICAL
A. No voltage in power system. Check phase-to-phase on line side of starter contactor.
Check circuit breaker or fuses
B. No voltage on one phase (Three Phase units). Check phase voltage on line side of starter contactor. Isolate open circuit
(circuit breaker, fuse, broken connections, etc.)
C. Low voltage at motor. Running voltage across each leg of motor must be ±10% of nominal voltage
shown on nameplate.
D. Motor leads improperly grouped for voltage. Refer to lead grouping diagram on motor nameplate.
E. Control failure. Check control device, starter contactor, H-O-A selector switch, etc., for malfunction.
F. Thermal overload switch open Check phase-to-phase on line side of starter contactor.
G. Installation failure. Check motor or windings to ground with megohmmeter.
H. Open windings. Check leg-to-leg with ohmmeter.
I. Frequency variation. Check frequency of power system. Must be less than 5% variation from
motor nameplate rating.
MECHANICAL
A. Flow through pump completely or partially
obstructed. Locate and remove obstruction. Refer to repair instructions for disassembly.
B. Wrong direction of rotation. Reverse rotation of three phase motor by interchanging any two leads. See manufacturer’s
instructions for reversing single phase motor.
C. Pump lost prime. Reprime. Inspect suction system for air leaks.
D. Internal leakage. Check impeller for wear of controlled clearances (See Repair Instructions).
E. Loose parts Inspect. Repair.
F. Stung box not properly adjusted Adjust gland.
SYSTEM
A. Pressure required by system at design ow rate
exceeds pressure rating of pump.
Compare pump pressure and ow rate against pump characteristic curve. Check for
closed or partially closed valve in discharge piping system.
Reduce system pressure requirement. Increase pressure capability of pump.
B. Obstruction in suction piping Locate and remove obstruction.
C. Pressure rating of pump exceeds pressure
requirement of system at design ow rate.
Compare pump pressure and ow rate against pump characteristic curve.
Inspect discharge piping system for breaks, leaks, open by-pass valves, etc.
If necessary, reduceow rate by partially closing discharge valve.

20 P15008 (04-15-2023)
BERKELEY WARRANTY
Pentair BERKELEY® warrants to the original consumer purchaser (“Purchaser” or “You”) of the products listed in the table below, that they will be
free from defects in material and workmanship for the Warranty Period shown in the table below.
PRODUCT WARRANTY PERIOD
WHICHEVER OCCURS FIRST:
Water Systems Products — jet pumps, small centrifugal pumps,
submersible pumps and related accessories
12 months from date of original installation, or
18 months from date of manufacture
Pentair Pro-Source® Composite Tanks 5 years from date of original installation
Pentair Pro-Source Steel Pressure Tanks 5 years from date of original installation
Pentair Pro-Source Epoxy-Lined Tanks 3 years from date of original installation
Agricultural/Commercial:
Centrifugals – close-coupled motor drive, frame mount, SAE mount,
engine drive, VMS, SSCX, SSHM
12 months from date of original installation, or 24 months from date of
manufacture
Submersible Turbines, 6” diameter and larger 12 months from date of original installation, or 24 months from date of
manufacture
Our warranty will not apply to any product that, in our sole judgement, has been subject to negligence, misapplication, improper installation, or
improper maintenance. Examples that may result in denial of a warranty claim (this list is not all inclusive):
 Damage caused by careless handling, improper repackaging, or shipping.
 Damage due to misapplication, misuse, abuse, or failure to operate equipment as specified in the owner’s manual.
 Damage caused by failure to install products as specified in the owner’s manual.
 Damage due to unauthorized product modifications or failure to use Pentair original replacement parts.
 Damage caused by negligence, or failure to properly maintain products as specified in the owner’s manual.
 Damage caused by water freezing inside the product.
 Accidental damage, fire, acts of God, or other circumstances outside the control of Pentair.
Without limiting the foregoing, operating a three phase motor with single phase power through a phase converter will void the warranty. Note also
that three phase motors must be protected by three-leg, ambient compensated, extra-quick trip overload relays of the recommended size or the
warranty is void.
All impeller diameters specified in the BEC2 pump sizing program have been tested and determined to not exceed the service factor of the specified
motor. Oversized impeller diameters can be requested, however, use of an oversized impeller will void any warranty claims.
Your only remedy, and BERKELEY’s only duty under this warranty, is that BERKELEY repair or replace defective products (at BERKELEY’s choice).
THE REMEDIES DESCRIBED HERE ARE YOUR SOLE AND EXCLUSIVE REMEDIES AND OUR ENTIRE LIABILITY FOR ANY BREACH OF THIS WARRANTY.
You must pay all labor and shipping charges associated with the warranty and must request warranty service through the installing dealer as soon as
a problem is discovered. No request for service will be accepted if received after the Warranty Period has expired. This warranty is not transferable.
BERKELEY’S LIABILITY SHALL UNDER NO CIRCUMSTANCES EXCEED THE ACTUAL AMOUNT PAID BY YOU FOR THE PRODUCT AT ISSUE. BERKELEY
SHALL NOT, UNDER ANY CIRCUMSTANCES, BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, SPECIAL, PUNITIVE, OR CONTINGENT DAMAGES
OR LOSSES WHATSOEVER, WHETHER DIRECT OR INDIRECT. THE FOREGOING WARRANTY IS EXCLUSIVE. EXCEPT FOR THE WARRANTY SET FORTH
HEREIN, BERKELEY MAKES NO WARRANTY WHATSOEVER WITH RESPECT TO THE PRODUCTS, INCLUDING, BUT NOT TO ANY WARRANTIES OF
MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, WHETHER EXPRESS OR IMPLIED BY LAW, COURSE OF DEALING,
COURSE OF PERFORMANCE, USAGE OF TRADE OR OTHERWISE.
THE FOREGOING WARRANTIES SHALL NOT EXTEND BEYOND THE DURATION PROVIDED HEREIN. Some states do not allow the exclusion or
limitation of incidental or consequential damages or limitations on the duration of an implied warranty, so the above limitations or exclusions may not
apply to You. This warranty gives You specific legal rights and You may also have other rights which vary from state to state.
This Warranty is effective July 14, 2020 and replaces all undated warranties and warranties dated before July 14, 2020.
