OWNER’SMANUAL
Signature 2000
High Pressure Booster Pump
60 Hz. 1/2 through 3 HP
© 2018 Pentair, Inc. All Rights Reserved. S327-ARB (12/06/18)
293 WRIGHT STREET, DELAVAN, WI 53115 WWW.STARITE.COM
PH: 8887827483

READ AND FOLLOW
SAFETY INSTRUCTIONS!
This is the safety alert symbol. When you see
this symbol on your pump or in this manual, look for
one of the following signal words and be alert to the
potential for personal injury:
warns about hazards that will cause seri-
ous personal injury, death or major property damage if
ignored.
warns about hazards that can cause seri-
ous personal injury, death or major property damage if
ignored.
warns about hazards that will or can
cause minor personal injury or property damage if
ignored.
The label NOTICE indicates special instructions which
are important but not related to hazards.
Carefully read and follow all safety instructions in
this manual and on pump.
Keep safety labels in good condition.
Replace missing or damaged safety labels.
ELECTRICAL SAFETY
Some models of
pump are supplied
with 3-connector
grounding type cord.
Connect only to properly
grounded, GFCI protected
outlet. Do not lift pump by
electrical cord.
Pump is non-
submersible. Keep
motor dry at all times. Do
not wash motor. Do not
immerse. Protect motor
from wet weather.
If using extension
cord, use only
UL approved indoor/
outdoor, 3-wire, grounding
type cord. Do not allow
any part of cord or receptacle ends to sit in water
or damp locations.
Unplug pump before servicing.
Burn Hazard. Do not touch an
operating motor. Modern motors can operate at high
temperatures. To avoid burns when servicing pump,
allow it to cool for 20 minutes after shut-down before
handling.
Follow local and/or national plumbing and electrical
codes when installing.
Hazardous Pressure. DO NOT run the
pump with discharge shutoff, as hose may burst or
pump may be damaged due to high temperatures.
GENERAL SAFETY
To avoid risk of serious bodily injury and property
damage, read safety instructions carefully before
installing pump.
Do not allow pump or any system component to freeze.
To do so may damage system and will void warranty.
Risk of electric shock. To avoid fatal
shocks, proceed as follows if pump needs servicing.
A. Disconnect power to pump outlet box before pul-
ling pump cord plug. After plug is pulled, let pump
cool for 20 minutes before attempting to work on it.
B. Take extreme care when changing fuses. To
re-duced chance of fatal electrical shocks, DO NOT
stand in water or put your finger in the fuse socket.
C. Ground electrical outlet box.
D. Use only Ground Fault Circuit Interrupter (GFCI)
protected grounded outlet for cord plug.
Never run pump dry. Running pump dry can damage
internal parts, overheat pump (which can cause burns
to people handling or servicing pump), and will void
warranty.
Do not pump chemicals or corrosive liquids with pump.
Hazardous Pressure.
A. Use high pressure reinforced type discharge
hose ONLY. See parts list for available hose,
nozzle and fittings. A high pressure relief valve is
recommended.
B. DO NOT use garden hose with High Pressure
Booster pump. Garden hose will not stand the
discharge pressure produced and will fail.
C. High pressure discharge stream is dangerous. To
avoid injury, DO NOT aim the discharge stream at
any person or animal.
D. BE SURE that the pump suction pipe pressure
plus the pump discharge pressure does not
exceed the pressure rating of hose and fittings.
See Table I for pump discharge pressure ratings.
2
WARNING
Hazardous voltage.
Can shock, burn, or
cause death.
Ground pump before
connecting to power
supply.

INSPECT THE SHIPMENT
The high pressure booster pump has been carefully
inspected and packaged to assure safe delivery.
Inspect the pump and fittings and report to the carrier
any items which are damaged or missing.
INSTALLATION
The pump is designed to boost city water pressure or
water pressure from a private water system. Use this
high pressure stream to wash down milk parlors, barns,
garages and driveways, or for fire protection.
The pump is portable with a convenient carrying handle.
If an existing pressure water system is to be used as a
water supply, it can be connected with available fittings
and 3/4”or 1”high pressure hose to the pump inlet. A
special heavy duty 3/4”or 1”suction hose with fittings
is available as an accessory. If pump is permanently
mounted on wall, use a 3/4”or 1”pipe or heavy-duty
hose for suction line. 20 GPM models require one-inch
discharge hose to reduce friction losses and 30 GPM
models require 1-1/4”.
Hazardous pressure. Pump body may
explode if pressures exceed rated limits. Maximum
inlet pressure is 80 PSI (551kPa). Minimum Inlet
Pressure is 3PSI (20.7 kPa). Maximum discharge
pressure is 315 PSI. Warranty is void if these pressure
limits are exceeded.
Product should not be permanently
connected to water mains when hoses are used.
HIGH PRESSURE BOOSTER PUMP
INSTALLATION INSTRUCTIONS
These instructions cover high pressure booster pump
installations as shown below:
3
Figure 1 – Connection to house service.
1208 0894
From pressurized
house service
Suction Discharge
Discharge Discharge
Pressure Pressure
No. of PSI at PSI at
GPM HP Stages Rated Flow No Flow
71/2 9 90 130
73/4 12 123 173
71 16 162 229
10 1/2 6 74 113
10 3/4 8 97 147
10 1 10 134 188
10 1 11 146 202
10 1-1/2 14 173 206
10 2 16 197 260
20 1 7 75 110
20 1-1/2 9 97 143
20 2 11 123 175
20 3 15 195 250
30 1 5 59 75
30 1-1/2 6 71 91
30 2 7 81 106
30 3 11 129 167
TABLE I - DISCHARGE PRESSURE
*For total discharge pressure, add this pressure to suction
pipe pressure. For example, an HP7C pump taking suction from
a 80 psi water service line will produce 130 + 80 = 210 psi total
discharge pressure at 0 GPM flow. If suction pressure drops to
50 psi, discharge pressure will drop to 180 psi.
NOTE: Model numbers that include an “S” (HPS7C, HPS10D, etc)
have a stainless steel suction, discharge assembly, and capscrews.
Model numbers ending in “3” (HP7C3, HPS10C3, etc) have 3-phase
motors. Models numbers ending in “T” have TEFC motors.
Model
Protective
device to
be installed
for 3 phase
pumps
Maximum
shut-off
head
Maximum
flow Operation
duty rating
Maximum fluid
temperature
Maximum system
pressure
Meters Feet L/min @ m GPM @ ft. °C °F bar psi
HPS7DXSAE NO 134 440 45 @ 6 12 @ 20
S3 50% 60 140 21.7 315
HPS1OEXSAE NO 134 440 57 @ 52 15 @ 170
HPS10F-01-MSSAE NO 184 605 57 @ 58 15 @ 190
HPS10G-01-MSSAE NO 207 680 57 @ 68 15 @ 225
HPS20G-01-MSSAE NO 154 505 104 @ 39 27.5 @ 130
HPS20H-01-MSSAE NO 176 580 104 @ 91 27.5 @ 300

To reduce friction losses to a minimum, inlet (suction)
line should be short and have as few elbows as
possible.
Size the inlet according to the chart below:
An inlet strainer will prevent suspended debris from
clogging pump.
The internal running surfaces of the pump and seals
require water lubrication for good, consistent operation.
Allowing pump to run dry will severely damage
pump and seals.
Install a pressure gauge in pump inlet line. Keep at
least two pounds per square inch pressure (2 PSI)
in inlet line whenever pump is operating. If this is not
possible, consult customer service representative.
LUBRICATION
It is not necessary to lubricate pump or motor. The
motor is equipped with sealed ball bearings, lubricated
for the life of the bearing. The mechanical shaft seal
in the pump is self-lubricating and requires no adjust-
ment. Disassemble pump to replace seal (See “Main-
tenance”, Pages 8 to 9).
OPERATION
NOTICE: Observe the following precautions when
operating the pump:
1. Keep the motor dry! Do not direct stream from
pump discharge onto the motor!
2. Hazardous pressure. Do not run the
pump with discharge shutoff, as hose may burst or
pump may be damaged due to high temperatures.
3. Do not use a standard trigger gun with this pump.
Use only trigger guns with an automatic weeping
feature. These are available as accessories and are
provided with three nozzles. The smallest nozzle
4
Figure 3 – Cistern or shallow well installation.
Male Pipe to Male Hose Adapter
Female Hose Connection
Male Hose
Connection
High Pressure
Hose
15 Feet
Maximum
Gun Nozzle
Weeping Type ONLY
Priming Plug
Tee 90 Elbow
Water Supply
Foot Valve
1210 0894
Recommended Recommended
Ave. Threaded Inlet Discharge
GPM Inlet Size Line Size Line Size
7 3/4” NPT 1” 1”
10 3/4” NPT 1” 1”
20 1” NPT 1-1/4” 1-1/4”
30 1-1/4” NPT 1-1/2” 1-1/2”
Figure 2 – Connection to water reservoir.
1207 0894
Water tank
or reservoir
Suction Discharge
Figure 4 – Wall mounted to pressurized service line.
To Power
Gate Valve or Hose Bibb
Male Pipe to Male Hose Adapter
Male Pipe to Male Hose Adapter
High Pressure Hose with two
Female Connections
Service Line
Male Pipe to Male Hose Adapter
(Suction)
(Discharge)
Female Hose Connection
High Pressure Hose
Gun Nozzle
Weeping Type ONLY
1209 0894

restricts the flow, allowing use of a smaller water
source. The two larger nozzles are used if the water
source will supply the pump’s full capacity.
4. Do not run pump dry; to do so may damage the
seal.
5. To avoid internal damage to pump, Do not operate
with water temperature above 140 degrees F.
ELECTRICAL
Ground motor before connecting to electrical
power supply.
Failure to ground motor can cause severe or
fatal electrical shock hazard.
Explosion hazard. Do not ground to a gas
supply line.
To avoid dangerous or fatal electrical shock,
turn OFF power to motor before working on
electrical connections.
Supply voltage must be within ±10% of
nameplate voltage. Incorrect voltage can
cause fire or serious damage to motor and voids
warranty. If in doubt consult a licensed electrician.
Use wire size specified in Wiring Chart (Table II,
Page 6). If possible, connect pump to a separate
branch circuit with no other appliances on it.
Wire motor according to diagram on motor
nameplate. If nameplate diagram differs from
diagrams above, follow nameplate diagram.
Not to be used by persons (including children)
having diminished capacity or a lack of
experience unless they have been given supervision
or instruction.
Children must be supervised to ensure that
they do not play with the appliance.
Only service agent or qualified person should
replace power cord to avoid injury.
A complete power disconnect switch must be
incorporated in the fixed wiring in accordance
with the national wiring rules.
WIRING CONNECTIONS
1. Install, ground, wire and maintain this pump in
compliance with all applicable national and local
codes and ordinances. Consult your local building
inspector for code information.
2. Make sure that the voltage, frequency and phase
(single phase or three phase) of the power supply
agree with that stamped on the motor nameplate. If
in doubt, check with the power company.
5
For All 3-phase and TEFC Motors: Follow
the wiring diagram on the motor junction box
or on the motor nameplate.

To Check For Proper Rotation – 3 Phase Motors
Risk of electrical shock.
1. Be sure power is disconnected to motor when
working on electrical connections.
2. Remove the motor end cover, exposing motor shaft.
Momentarily start pump. If hookup is correct, the
shaft will rotate clockwise.
3. If rotation is not clockwise, reverse any two leads to
the starter. The rotation will now be correct.
GROUNDING THE MOTOR
Ground the pump permanently using a wire of size and
type specified by local or National Electrical Code.
Models without cord and plug:
1. Connect ground wire first. Connect the ground first,
then to green grounding terminal provided under
motor canopy identified as GRD. Make ground
connection to this terminal. Do not connect motor
to electrical power supply until unit is permanently
grounded; otherwise serious or fatal electrical shock
hazard may be caused.
2. For best ground connection, connect to a grounded
lead in the service panel or to a metal underground
water pipe or well casing at least 10 ft. long. If
plastic pipe or insulated fittings are used, run ground
wire directly to the metal well casing or use ground
electrode furnished by the power company.
6
TABLE II - RECOMMENDED FUSING AND WIRING
Voltage Max Load
Amps
14 12 10 8 Non Delay Dual Element Inverse
time
breaker
J1218-582A-LSA 220 4.95 423 674 10 10 10
J218-590-LSA 220 6.2 338 538 15 10 10
J218-596-LSA 220 7. 4 283 451 719 15 10 15
J218-601-LSA 220 9.95 2 11 335 535 20 15 20
J218-883A-LSA 220 12 175 278 443 702 25 20 20
J218-628A-48-LSA 220 12 175 278 443 702 25 20 20
J218-951-LSA 220 13.3 251 400 633 30 20 25

MAINTENANCE
Pump Disassembly
Hazardous voltage. Can shock, burn or
cause death. Disconnect power before servicing.
Tools required:
1. 7/16” open end wrench (2 required).
2. Flat blade screwdriver with insulated handle.
3. Work bench with vise recommended.
4. Pliers or similar tool.
5. Pipe wrench.
Impeller Stack Changeout (See Figure 8)
Remove pump from service and mount vertically in
vise (if available) motor side down. Hold at center of
motor. It may be desirable to wrap motor with a shop
rag to protect outside surface.
Proceed as follows:
1. Attach pipe wrench to flats on discharge connection
and turn clockwise to remove (left hand threads).
2. Remove screws holding motor canopy and remove
canopy. Pull straight off as shown. Leave switch
wires attached (if present).
Capacitor voltage may be
hazardous. To discharge capacitor, hold insulated
handle screwdriver by the handle and short
capacitor terminals together. Do not touch metal
screwdriver blade or capacitor terminals.
3. Unscrew the overload and move it aside. Do not
disconnect wires. Slide 7/16”open end wrench in
behind spring loaded centrifugal switch as shown.
Place on motor shaft flats to hold shaft stationary.
4. With one 7/16”wrench in place on motor shaft,
place second wrench on shaft hex at pump end and
unscrew impeller stack by turning counter-clockwise.
5. Once loose from motor shaft, hold shaft by snap
ring using a pliers or similar tool, and pull stack
from shell. You may have to apply a back and forth
motion to break stack loose from shell.
To assemble with replacement impeller stack, keep
pump in the vertical position, motor down, and reverse
instructions 1 through 5.
Assembly hints:
A. Apply a soapy water solution to suction and
discharge O-Rings to ease seating of shell.
B. Make sure mechanical shaft seal spring is in
proper position on motor shaft.
C. On three-phase models, apply Loctite No. 271 to
motor shaft threads before reinstalling stack.
7
Disconnect from
power source.
Motor end view with
canopy removed
Motor Canopy
See View A-A View A-A
Centrifugal
Switch
Capacitor
Impeller
Stack
Snap
Ring
Remove with
Counter-clockwise
rotation.
1
3
3
4
5
1211 0605
A
Discharge
Connection
Remove with
clockwise
rotation.
2
7 / 16
Overload Protector
(Moved for access)
Overload screw
(remove)
7/16" Open
End Wrench
Torque discharge
connection to 80 - 100 ft-lbs
at reassembly
Figure 8 – Impeller stack changeout.

8
Ceramic Seat
3/4" pipe or
3/4" socket
with extender
Polished
Face
Rotating
Half
Cardboard
washer (supplied
w/seal)
Rotating Half
of Mechanical
Seal
Remove shell;
turn clockwise.
Push ceramic
seat out of
pump body
Remove
Pump Body
6
8
7
9
10
11
12
1212 0605
Torque bolts to
15-27 ft-lbs
during
reassembly.
Figure 9 – Mechanical seal changeout.
Mechanical Seal Changeout
(Refer to Figures 8 and 9)
This procedure is best completed with the pump held in
a vertical position, motor down.
First complete “Disassembly” instructions 1 through
5 under “Impeller Stack Changeout.” (See Figure 8).
6. Remove 4 capscrews holding pump body to motor.
Pump handle will come off with top capscrews.
7. Unscrew pump shell from pump body, turning
clockwise (left hand threads).
8. Remove mechanical shaft seal spring and rotating
half from motor shaft. Use care not to scratch motor
shaft when removing rotating half.
9. Remove pump body from motor and place on flat
surface, face down. Again, use care not to scratch
motor shaft.
10. Use a screwdriver to push ceramic seat out from
seal cavity as shown.
11. Installation of ceramic seat:
A. Turn pump body over so seal cavity is up; clean
cavity thoroughly.
B. Clean polished surface of ceramic seat with a
clean cloth.
C. Lubricate outside rubber surface of seat with
soapy water. Place cardboard washer over
polished face of seat and press into seal cavity
using a 3/4”socket or a piece of 3/4”standard
pipe.
D. Be sure polished surface of seat is free of
dirt and has not been damaged by insertion.
Re-move excess soapy water. Dispose of card-
board washer.
12. Installation of rotating half and spring:
A. Reinstall pump body on motor using extreme
caution not to hit ceramic portion of seal on
motor shaft. Reattach pump body to motor using
capscrews. Be sure to reinstall pump handle at
this time.
B. Inspect shaft to make sure that it is clean.
C. Clean face of rotating half of seal with a clean
cloth.
D. Lubricate inside diameter of rotating half with
soapy water and slide onto motor shaft (sealing
face first).
E. Place spring over motor shaft so it rests on
rotating half.
13. To complete reassembly from this point, reverse
instructions 1 through 5 under “Impeller Stack
Changeout.”
NOTICE: Lubricate suction and discharge O-Rings
with soapy water for easier installation of shell.

89
1
10
2
3
4
5
5
6
7
8
9
1206 0605 NCBSW/NB
7A
Figure 9 – Exploded view.
Hose 6’-3/4” w/Female Ends
(150 PSI Rating) PKG 83
Hose 25’-3/4” w/Male & Female Ends
(150 PSI Rating) PKG 84
Adapter 3/4” NPT x 3/4” Hose PKG 85
Nozzle - High Pressure PKG 86
Suction Vacuum Relief Valve PKG 96
THE FOLLOWING ACCESSORIES
MAY BE ORDERED FOR HIGH
PRESSURE BOOSTER PUMPS
HP7E
HP7D HP10E
Key HP10D HP10E311 HP10F HP10G
No. Description Qty. 1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP
1 Motor - 220 Volt, 1 Phase 1 J218-590-LSA J218-596LSA J218-601-LSA J218-883A-LSA J218-628A-48-LSA
2 Handle (†) 1 C54-21 C54-21 C54-21 – –
3 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
4 Pump Body 1 C2-85 C2-85 C2-85 C2-85 C2-85
5 O-Ring 2 U9-430 U9-430 U9-430 U9-430 U9-430
6 Shaft Seal Assembly 1 U109-118 U109-118 U109-118 U109-118 U109-118
7 Pump Stack (7 GPM Pump) 1 P325-422 P325-423 P325-424 – –
7 Pump Stack (10 GPM Pump)†† 1 P325-425 P325-426 P325-439 P325-428 P325-429
7A Nylatron Bearing
(included with Key No. 9) 1 W31112 W31112 W31112 W31112 W31112
8 Pump Shell (7 GPM Pump) 1 P56-430SSL P56-431SSL P56-432SSL – –
8 Pump Shell (10 GPM Pump)††† 1 P56-460SSL P56-461SSL P56-469SSL P56-452SSL P56-432SSL
9 Discharge Assembly 1 C152-3 C152-3 C152-3 C152-3 C152-4
10 Capscrew - 3/8 x 16 x 1-1/2” 4 U30-982ZP U30-982ZP U30-982ZP U30-982ZP U30-982ZP
# Cord Connector** 1 U71-7 U71-7 – – –
# Cord** 1 U17-402 U17-1238 – – –
REPAIR PARTS LIST
# Not Illustrated.
** Included with Model Numbers HP7C-01 and the HP7D Series Model Numbers.
† Handle comes with HP7 series and HP10E series.
†† Model HP10E311-02 uses Part Number P325-362.
††† Model HP10E311-02 uses Part Number P56-404SSL.

10
1
9
2
3
4
4
5
6
7
8
1206 0605 NHW/NB
6A
Figure 10 – Exploded view.
HPS7C HPS7D HPS7E
Key HPS10C HPS10D HPS10E HPS10F HPS10G
No. Description Qty. 1/2 HP 3/4 HP 1HP 1-1/2 HP 2 HP
1 Motor - 220 Volt, 1 Phase 1 J218-590LSA J218-596-LSA J218-601-LSA J218-883A-LSA J218-628A-48-LSA
2 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3 Pump Body 1 C2-86SS C2-86SS C2-86SS C2-86SS C2-86SS
4 O-Ring 2 U9-430 U9-430 U9-430 U9-430 U9-430
5 Shaft Seal Assembly 1 U109-118 U109-118 U109-118 U109-118 U109-118
6 Pump Stack (7 GPM) 1 P325-422R P325-423R P325-424R – –
6 Pump Stack (10 GPM) 1 P325-425R P325-426R P325-439R P325-428R P325-429R
6A Nylatron Bearing
(included with Key No. 9) 1 W31112 W31112 W31112 W31112 W31112
7 Pump Shell (7GPM) 1 P56-430SSL P56-431SSL P56-432SSL – –
7 Pump Shell (10GPM) 1 P56-460SSL P56-461SSL P56-469SSL P56-452SSL P56-432SSL
8 Discharge Assembly 1 C152-4 C152-4 C152-4 C152-4 C152-4
9 Capscrew
3/8 x 16 x 1-1/2”, S.S. 4 S25983 S25983 S25983 S25983 S25983
REPAIR PARTS LIST
Hose 6’-3/4” w/Female Ends
(150 PSI Rating) PKG 83
Hose 25’-3/4” w/Male & Female Ends
(150 PSI Rating) PKG 84
Adapter 3/4” NPT x 3/4” Hose PKG 85
Nozzle - High Pressure PKG 86
Suction Vacuum Relief Valve PKG 96
THE FOLLOWING ACCESSORIES
MAY BE ORDERED FOR HIGH
PRESSURE BOOSTER PUMPS

11
1
10
2
3
4
5
5
6
7
8
9
1206 0605 NCBSW/NB
7A
Figure 11 – Exploded view.
HP20H
Key HP20E HP20F HP20G HP20HT
No. Description Qty. 1 HP 1-1/2 HP 2 HP 3 HP
1 Motor - 220 Volt, 1 Phase 1 J218-601-LSA J218-883A-LSA J218-678A-LSA –
2 Handle 1 C54-21 C54-21 C54-21 C54-21
3 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009
4 Pump Body 1 C2-85A C2-85A C2-85A C2-85A
5 O-Ring 2 U9-430 U9-430 U9-430 U9-430
6 Shaft Seal Assembly 1 U109-118 U109-118 U109-118 U109-118
7 Pump Stack 1 P325-602R P325-431R P325-432R P325-718R
7A Nylatron Bearing
(included with Key No. 9) 1 W31112 W31112 W31112 W31112
8 Pump Shell 1 P56-433SSL P56-434SSL P56-452SSL P56-620SSL
9 Discharge Assembly 1 C152-3A C152-3A C152-3A C152-3A
10 Capscrew - 3/8 x 16 x 1-1/2” 4 U30-982ZP U30-982ZP U30-982ZP U30-982ZP
REPAIR PARTS LIST
Hose 6’-3/4” w/Female Ends
(150 PSI Rating) PKG 83
Hose 25’-3/4” w/Male & Female Ends
(150 PSI Rating) PKG 84
Adapter 3/4” NPT x 3/4” Hose PKG 85
Nozzle - High Pressure PKG 86
Suction Vacuum Relief Valve PKG 96
THE FOLLOWING ACCESSORIES
MAY BE ORDERED FOR HIGH
PRESSURE BOOSTER PUMPS

12
1
9
2
3
4
4
5
6
7
8
1206 0605 NHW/NB
6A
Figure 12 – Exploded view.
HPS20H
HPS20H3
HPS20F HPS20G HPS20HT
Key HPS20E3 HPS20F3 HPS20G3 HPS20H3T
No. Description Qty. 1HP 1-1/2 HP 2 HP 3 HP
1 Motor - 220 Volt, 1 Phase 1 J218-601-LSA J218-883A-LSA J218-628A-48LSA -
2 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009
3 Pump Body 1 C2-86SSA C2-86SSA C2-86SSA C2-86SSA
4 O-Ring 2 U9-430 U9-430 U9-430 U9-430
5 Shaft Seal Assembly 1 U109-118 U109-118 U109-118 U109-118
6 Pump Stack 1 P325-440R P325-431R P325-432R P325-718R
6A Nylatron Bearing
(included with Key No. 8) 1 W31112 W31112 W31112 W31112
7 Pump Shell 1 P56-470SSL P56-434SSL P56-452SSL P56-620SSL
8 Discharge Assembly 1 C152-4A C152-4A C152-4A C152-4A
9 Capscrew 3/8 x 16 x 1-1/2” 4 S25983 S25983 S25983 S25983
REPAIR PARTS LIST
Hose 6’-3/4” w/Female Ends
(150 PSI Rating) PKG 83
Hose 25’-3/4” w/Male & Female Ends
(150 PSI Rating) PKG 84
Adapter 3/4” NPT x 3/4” Hose PKG 85
Nozzle - High Pressure PKG 86
Suction Vacuum Relief Valve PKG 96
THE FOLLOWING ACCESSORIES
MAY BE ORDERED FOR HIGH
PRESSURE BOOSTER PUMPS

13
1
10
2
3
4
5
5
6
7
8
9
1206 0605 NCBSW/NB
7A
Figure 13 – Exploded view.
HP30E HP30F HP30G HP30H
Key HP30ET HP30FT HP30GT HP30HT
No. Description Qty. 1 HP 1-1/2 HP 2 HP 3 HP
1 Motor - 220 Volt, 1 Phase 1 J218-601-LSA J218-883A-LSA J218-628A-48-LSA –
2 Handle 1 C54-21 C54-21 C54-21 C54-21
3 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009
4 Pump Body 1 C2-85B C2-85B C2-85B C2-85B
5 O-Ring 2 U9-430 U9-430 U9-430 U9-430
6 Shaft Seal Assembly 1 U109-118 U109-118 U109-118 U109-118
7 Pump Stack 1 P325-719R P325-720R P325-721R P325-722
7A Nylatron Bearing
(included with Key No. 9) 1 W31112 W31112 W31112 W31112
8 Pump Shell 1 P56-621SSL P56-622SSL P56-434SSL P56-615SSL
9 Discharge Assembly 1 C152-3B C152-3B C152-3B C152-3B
10 Capscrew - 3/8 x 16 x 1-1/2” 4 U30-982ZP U30-982ZP U30-982ZP U30-982ZP
REPAIR PARTS LIST
Hose 6’-3/4” w/Female Ends
(150 PSI Rating) PKG 83
Hose 25’-3/4” w/Male & Female Ends
(150 PSI Rating) PKG 84
Adapter 3/4” NPT x 3/4” Hose PKG 85
Nozzle - High Pressure PKG 86
Suction Vacuum Relief Valve PKG 96
THE FOLLOWING ACCESSORIES
MAY BE ORDERED FOR HIGH
PRESSURE BOOSTER PUMPS

14
1
9
2
3
4
4
5
6
7
8
1206 0605 NHW/NB
6A
Figure 14 – Exploded view.
HPS30E HPS30F HPS30G HPS30H
Key HPS30ET HPS30FT HPS30GT HPS30HT
No. Description Qty. 1HP 1-1/2 HP 2 HP 3 HP
1 Motor - 220 Volt, 1 Phase 1 J218-601-LSA J218-883A-LSA J218-628A-48-LSA –
2 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009
3 Pump Body 1 C2-86SSB C2-86SSB C2-86SSB C2-86SSB
4 O-Ring 2 U9-430 U9-430 U9-430 U9-430
5 Shaft Seal Assembly 1 U109-118 U109-118 U109-118 U109-118
6 Pump Stack 1 P325-719R P325-720R P325-721R P325-722R
6A Nylatron Bearing
(included with Key No. 9) 1 W31112 W31112 W31112 W31112
7 Pump Shell 1 P56-621SSL P56-622SSL P56-434SSL P56-615SSL
8 Discharge Assembly 1 C152-4B C152-4B C152-4B C152-4B
9 Capscrew 3/8 x 16 x 1-1/2” 4 S25983 S25983 S25983 S25983
REPAIR PARTS LIST
Hose 6’-3/4” w/Female Ends
(150 PSI Rating) PKG 83
Hose 25’-3/4” w/Male & Female Ends
(150 PSI Rating) PKG 84
Adapter 3/4” NPT x 3/4” Hose PKG 85
Nozzle - High Pressure PKG 86
Suction Vacuum Relief Valve PKG 96
THE FOLLOWING ACCESSORIES
MAY BE ORDERED FOR HIGH
PRESSURE BOOSTER PUMPS

Limited Warranty
STA-RITE warrants to the original consumer purchaser (“Purchaser” or “You”) of the products listed below, that they will be free
from defects in material and workmanship for the Warranty Period shown below.
Product Warranty Period
Water Systems Products — jet pumps, small centrifugal pumps,
submersible pumps and related accessories
whichever occurs first:
12 months from date of original installation,
or 18 months from date of manufacture
Pro-Source™ Composite Tanks 5 years from date of original installation
Pro-Source™ Steel Pressure Tanks 5 years from date of original installation
Pro-Source™ Epoxy-Lined Tanks 3 years from date of original installation
Sump/Sewage/Effluent Products 12 months from date of original installation, or
18 months from date of manufacture
Our warranty will not apply to any product that, in our sole judgement, has been subject to negligence, misapplication,
improper installation, or improper maintenance. Without limiting the foregoing, operating a three phase motor with single phase
power through a phase converter will void the warranty. Note also that three phase motors must be protected by three-leg,
ambient compensated, extra-quick trip overload relays of the recommended size or the warranty is void.
Your only remedy, and STA-RITE’s only duty, is that STA-RITE repair or replace defective products (at STA-RITE’s choice). You
must pay all labor and shipping charges associated with this warranty and must request warranty service through the installing
dealer as soon as a problem is discovered. No request for service will be accepted if received after the Warranty Period has
expired. This warranty is not transferable.
STA-RITE SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, OR CONTINGENT DAMAGES WHATSOEVER.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. THE FOREGOING WARRANTIES SHALL NOT EXTEND BEYOND THE DURATION EXPRESSLY PROVIDED HEREIN.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on the duration of an
implied warranty, so the above limitations or exclusions may not apply to You. This warranty gives You specific legal rights and
You may also have other rights which vary from state to state.
This Limited Warranty is effective June 1, 2011 and replaces all undated warranties and warranties dated before June 1, 2011.
STA-RITE INDUSTRIES
293 Wright Street • Delavan, WI U.S.A. 53115
Phone: [phone] • Fax: [phone] • Web Site: sta-rite.com
15

This page intentionally left blank

This page intentionally left blank

18
STA-RITE
1218 0894 NC

2000

31/260
 




















  
  














 

       








         

  

      

  

 
           

  
            






   
        

 

    

 
1        






19



    








1
1         

1
     
1


55180 
20.73 


           




1
1208 0894
ﻝﺰﻨﻤﻟﺍ ﺔﻠﺻﻭ ﻦﻣ
ﺔﻃﻮﻐﻀﻤﻟﺍ
ﺐﺤﺳ ﻎﻳﺮﻔﺗ
     
     
     
     
     
  9 7
173 123 12  7
229   17
113    10 
 97 8 10 
188   110 
  11 110 
 173   10 
 197  210 
  7120 
 97 9 20 
 123 11 220 
   320 
   130 
91 71   30 
 81 7230 
 129 11 330 
1
  
HP7C


  
S
            
3

  

































HPS7DXSAE13444045 @ 612 @ 20
S3 50%6014021.7315
HPS1OEXSAE13444057 @ 5215 @ 170
18460557 @ 5815 @ 190
20768057 @ 6815 @ 225
154505104 @ 3927.5 @ 39
176580104 @ 91
27.5 @
300
