Penton PBC6T/EN User manual

ZCL0504-075 P
>
>
Technical Specifications
2.Horizontal coverage angles & Vertical angles
1 Oct.Pink noise
1 Oct.Pink noise
1 Oct.Pink noise
1 Oct.Pink noise
500 Hz
1K Hz
2K Hz
4K Hz
Horizontal Vertical
218°186°
119°77°
100°99°
67°58°
PBC6 SPECIFICATIONST/ENC
>
PBC6T/EN
>
EN54-24:2008
0359-CPD-0151
TYPE A
With Transformer:
100V/70V line
100V 3W 1.5W 0.75W0.25W
3.33k
6.66k 13.3k40k
White wire plus tapping Black
IMP.(Ω)
COM
70V 1.5W 0.75W 0.375W COM
6W
1.67k
3W 0.125W
IP-rating..........................................21
Max/Min amb temp.............55°C/-10°C
Relative humidity........................≦95%
3.Environmental
Penton Communications Inc, Taichung, Taiwan.
PBC6T/EN & PBC6T/ENC
±
has been tested in 100 hours max power (6W). The model does
not deviate more than 3dB from the original test value. The freq. response curve and impedance
complies with the original one. All SPL tests are preformed in a anechoic chamber ( <70m/3).
330x240x90
1.15
RAL9016
Low smoke zero Halogen
UL-94V0 Plastic with UV inhibitors
Keyhole and/or screws
Dimensions, Front & Depth, mm
Net weight, Kgs
Colour
Material
Mounting
(Unless Specified)
5.Mechanical
6
6/3/1.5/0.75/0.25
1.67K/3.33K/6.66K/13.3K/40K
3/1.5/0.75/0.375/0.125
8
160-18,000
70
96
78
104
4.Electrical
Rated power, Watts
Tappings 100 volt line, Watts
Transformer Impedance , Ohms 100V
Tappings 70.7 volt line, Watts
Driver impedance, Ohms
Effective Frequency Range, Hz (BSEN60268-5)
S.P.L. @ 4m, 1watt, dB,1/3 Octave, 1KHz
S.P.L. @ 1m, 1watt, dB, Octave 1KHz
S.P.L. @ 4m, Full power, dB, 1/3 Octave 1KHz
S.P.L. @ 1m, Full power, Octave 1KHz
PENTON
R
0359
13
SPL(dB)
Frequency(Hz)
Sensitivity 100Hz-10000Hz 1/3 Oct. Pink noise 1W/4 Meters)
Sensitivity 100Hz-10000Hz Oct. Pink noise 1W/1 Meter)
*Active Equalizer Applied: NO
100 200 500 1k 2k 5k 10k
100
60
70
80
90
1.Frequency response
50
BK
P1
Service Germany: 49-6027-979875 ; France: 33-4-76992630 ; Switzerland: 41-21-8812510
Phone USA: 1-401-7271600 ; The Rest of Europe: 31-10-2088690(Netherlands)
:
“Voice alarm loudspeaker for fire detection and fire alarm system for building”
33 0
243.5
Key Hole
2-mounting
holes
90
210

1.
2.reference axis
3.horizontal plane
4.reference plane
loudspeaker enclosure
0359
13
PENTON
R
EN54-24:2008 TYPE A 0359-CPD-0151
PBC6T/ENC INSTALLATION GUIDE
>
PBC6T/EN
>
P2
1
2
4
3
COM.
100V
Circuit Diagram
TPBC6 /EN
Thermal Fuse
COM.
100V
Circuit Diagram
PBC6T/ENC
Thermal Fuse
* with capacitor
*
3W
1.5W
0.75W
6W
0.25W
3W
1.5W
0.75W
6W
0.25W
4)With the cable in place the speaker can be screwed through the
mounting holes into position. Once in position the two mounting
hole caps can be put in place to hide the offending screw heads.
There is also provided a key hole mounting plate, as shown on the
drawing, this can only be used if the loudspeaker is wall mounted
and in a vertical position.
3)Cabling can now take place, connect the 100 volt line supply
to your required volume as shown on the circuit diagram.
1)On selecting the chosen position for the loudspeaker (it can be
mounted vertically or horizontally) use a spirit level to ensure that it
is level. Offer the speaker to the wall or ceiling and mark through
the mounting holes, as shown on the drawing to the right, the
position required for drilling.
0.25W 0.75W 1.5W 3W 6W
2)Drill 2 holes 210mm apart and then raw plug them.
Mounting
Hole
Key
Hole
Mounting
Hole
