INSTALLATION INSTRUCTIONS
ROUND CO-AXIAL
METAL CEILING
LOUDSPEAKERS
fRCS6/TCOAX
Hole cutout
190mm
RCS6/TCOAX
Circuit diagram 100V Common
fSTEP 1
Cut the required hole for the speaker
FITTING THE SPEAKER
fSTEP 3
Compress “V” spring and fit into the retaining ear within the
bracket.
Connect cable to terminal block and select wattage required.
fSTEP 2
Loosen the retaining sliders and push to the top of the bracket.
Once the bracket is through the hole pull down the sliders and
tighten the retaining nut clamping the ceiling
fSTEP 4
Fit second “V” clip into second retaining ears and gently push the
speaker up into the bracket (do not push the central perforated grille
area) the speaker will self locate into the bracket.
Thermal Fuse
1.25W
2.5W
5W
10W

RoHS
Penton UK Ltd
Unit 2 Teville Industrials | Dominion Way | Worthing | West Sussex | BN14 8NW
T: [phone] | F: [phone] | E: [email protected]
www.pentonuk.co.uk
IIA
Slide
IID
“C”
“B”
fSTEP 1
Remove the wing nut “A” located
on the inside of the fire dome.
FITTING THE DOME INTO A CEILING
fSTEP 6
Cut a 200mm diameter hole paying attention to ensure that the cut-out is accurately
made. As if it is not, the speaker may not fit correctly into the ceiling preventing the
speaker from sitting flush to the surface.
fSTEP 7
Loosen the slider knob “D”, push the knob & plate upwards to the top of the fire dome
and re-tighten the knob to hold the slider in place. Repeat the same process with the
other slider.
fSTEP 8
Push the complete fire dome into the cut-out.
fSTEP 9
Once in place loosen the slider knob “D”, push the knob & plate downwards until the
slider makes firm contact with the ceiling. Tighten the knob to secure it into place.
Repeat the same process with the other slider.
fSTEP 10
The fire dome should be firmly
secured into the ceiling.
fSTEP 11
Take the speaker and compress
one of the mounting springs &
place both ends of the spring
into one of the retaining
brackets located on the inside
wall of the fire dome. Release
the spring slowly into the
bracket. Once fully released the
spring will hold one side of the
speaker into the fire dome.
fSTEP 12
With the speaker in this position
connect the 3 wires hanging from the
termination plate on to the speaker
using the spade terminals provided.
fSTEP 13
Fit the second spring mount on the
speaker to the remaining bracket on
the inside of the fire dome. Finally
push the speaker into position.
fSTEP 14
If fitted correctly the speaker should
fit flush to the surface.
fSTEP 2
Lift the termination plate upwards
& away to separate it from the
fire dome “B”.
fSTEP 3
Gland the installation cable into the termination plate using suitably rated 20mm
glands. 2 gland entries are provided for “loop in” “loop out” termination if required.
fSTEP 4
Terminate the installation cable into the terminal block on the underside of the
termination plate “C”.
fSTEP 5
Fix the terminaton plate back into the fire dome and secure using the wing nut
previously removed. Do not over tighten to avoid damaging the thread.
NOVEMBER 2011
RCS6/FTSCOAX
Circuit diagram
100V Common
Thermal Fuse
1.25W
2.5W
5W
10W
INSTALLATION INSTRUCTIONS
ROUND CO-AXIAL
METAL CEILING
LOUDSPEAKERS
fRCS6/FTSCOAX
