Pepperl+Fuchs OHV1000-series User manual

OHV1000-*
Handheld
FACTORY AUTOMATION
QUICK START GUIDE

With regard to the supply of products, the current issue of the following document is applicable: The
General Terms of Delivery for Products and Services of the Electrical Industry, published by the
Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie
(ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation
of proprietorship"
OHV1000-*

OHV1000-*
Contents
2014-10
3
1 Introduction .......................................................................4
1.1 Purpose of this quick start guide ................................................................ 4
1.2 Intended Use.............................................................................................. 4
1.3 Operation, Maintenance, Repair................................................................. 5
1.4 Delivery, Transport, Disposal ...................................................................... 5
2 Product Description..........................................................6
2.1 Indicators and Operating Controls.............................................................. 6
2.2 Accessories................................................................................................ 7
3 Installation .........................................................................8
3.1 Installing/Removing the Cable.................................................................... 8
3.2 Establishing a USB Connection ................................................................. 9
3.3 Establishing an RS232 Connection ............................................................ 9
4 Operation .........................................................................11
4.1 Reading Codes ........................................................................................ 11
4.2 Keyboard Mode........................................................................................ 13

OHV1000-*
Introduction
4
2014-10
1Introduction
1.1 Purpose of this quick start guide
This quick start guide contains basic instructions for operating the device.
However, the manual takes priority over the quick start guide.
1.2 Intended Use
The handheld is used to identify 1-D and 2-D codes that have been applied
directly to the surface of a product. For example, the code may have been etched,
printed, or laser-engraved on a housing. The degree of flexibility offered when
decoding codes allows the handheld to be used in a number of industries.
Always operate the device as described in these instructions to ensure that the
device and connected systems function correctly. The protection of operating
personnel and plant is only guaranteed if the device is operated in accordance
with its intended use.

OHV1000-*
Introduction
2014-10
5
1.3 Operation, Maintenance, Repair
The handheld has bright LEDs to enable it to read 1-D and 2-D codes. The optical
light can be an irritant, especially in a dark environment. Do not point the handheld
at people. Do not look directly into the handheld's lens.
The device must not be repaired, changed or manipulated.
If there is a defect, the product must be returned to the manufacturer
Pepperl+Fuchs.
1.4 Delivery, Transport, Disposal
Check the packaging and contents for damage.
Check if you have received every item and if the items received are the ones you
ordered.
Keep the original packaging. Always store and transport the device in the original
packaging.
Store the device in a clean and dry environment. The permitted ambient
conditions (see datasheet) must be considered.
Disposing of device, packaging material, and possibly contained batteries must
be in compliance with the applicable laws and guidelines of the respective
country.

OHV1000-*
Product Description
6
2014-10
2 Product Description
2.1 Indicators and Operating Controls
1Mounting bracket
2Function indicator
310-pin connector socket
4Trigger button
5Optics
43 5
1 2

OHV1000-*
Product Description
2014-10
7
2.2 Accessories
Designation Description
ODZ-MAH-SUPPLY 5 VDC power supply, 1.2 A, short-circuit proof
V45-G-2M-PVC-ABG-USB-G Connection cable with USB plug, 4-pin, approx.
1.8 meters
V45-G-2M-PVC-SUBD9 Connection cable with D-sub plug and DC connector
socket, 6-pin, approx. 2.4 meters
Vision Configurator Configuration software for camera-based sensors

OHV1000-*
Installation
8
2014-10
3 Installation
3.1 Installing/Removing the Cable
Installing the Cable
1. Hold the end of the cable with the RJ50 plug and insert the plug into the RJ50
socket underneath the handle.
2. You must hear a click when the cable engages.
The cable is now securely connected to the handheld.
Removing the Cable
1. Insert a thin object such as a straightened paper clip into the hole at the bottom
of the handle.
2. Carefully pull the cable complete with RJ50 plug out of the handle.
The cable has now been detached from the handle.

OHV1000-*
Installation
2014-10
9
3.2 Establishing a USB Connection
Establishing a USB Connection
1. Insert the USB plug on the connection cable into a free USB port on the PC.
This step can be carried out even during operation.
2. To switch on the handheld, hold down the trigger button for approx. two
seconds.
3. When the handheld is successfully connected, an audible signal is emitted
and the handheld will vibrate.
The handheld is now ready.
3.3 Establishing an RS-232 Connection
Establishing an RS-232 Connection
1. Switch off the PC.
2. Insert the RS-232 plug on the connection cable into the RS-232 port on the
PC.
3. Insert the low-voltage plug on the power supply unit into the low-voltage
socket on the RS-232 connection cable.
4. Connect the mains power plug on the power supply unit to the mains.

OHV1000-*
Installation
10
2014-10
5. Switch on the PC.
Once you have switched on the PC, the handheld will switch itself on
automatically.
6. When the handheld is successfully connected, an audible signal is emitted
and the handheld will vibrate.
The handheld is now ready.
The handheld uses the following RS-232 factory settings:
■115,200 baud
■8 data bits
■No parity

OHV1000-*
Operation
2014-10
11
4Operation
4.1 Reading Codes
The handheld reads both very small 2-D codes (e.g., Data Matrix codes) and
larger 1-D codes (e.g., barcodes).
Reading Codes
1. Hold the handheld so that the contrast between the code and surface is as
high as possible. A reading angle of between 45°and 90°is optimal, depend-
ing on whether the code has been etched, laser-engraved, or printed on the
surface. The reading distance is approximately 25 mm or greater, depending
on the code type and code size.
Tip
If several codes are located directly next to each other, we recommend you cover
the codes that you do not wish to read. This prevents you from inadvertently
reading another code.

OHV1000-*
Operation
12
2014-10
2. Actuate the trigger button.
If the reading process is successful, the handheld's function indicator
briefly lights up green. When activated, an audible signal is emitted and the
handheld will vibrate.
3. If the code is not recognized, change the reading angle or the reading
distance and press the trigger button again.

OHV1000-*
Operation
2014-10
13
4.2 Keyboard Mode
Activating Keyboard Mode
1. Read the following code with the handheld.
The handheld's function indicator briefly lights up green.
2. Data is transferred using a US English keyboard layout by default. To select a
different keyboard layout, read one of the following control codes.
M0002_01

OHV1000-*
Operation
14
2014-10
ASCII characters Belgian keyboard layout German keyboard layout French keyboard layout
Japanese keyboard
layout Swiss keyboard layout
US English keyboard
layout
(standard)
M10413_01
M10115_01
M10415_01
M10414_01
M10416_01
M10116_01
M10111_01

OHV1000-*
Operation
2014-10
15
