Perfect Aire 1PHCF14 User manual

Perfect Aire, LLC
5401 Dansher Rd.
Countryside, IL 60525
Distributed by:
844-4PA-AIRE | 844-472-2473
www.perfectaire.us
OSCILLATING PARABOLIC
HEATER
FOR MODEL:
1PHCF14
Before using your oscillating parabolic heater
please read this manual carefully and keep
it for future reference, along with your receipt.
Specification and performance data is subject to change without notice.
Printed in China
USER MANUAL
PA/User_1PHCF14/05102019

2
Thank you for choosing our Dish Heater. This owner’s manual will provide you with
valuable information necessary for the proper care and maintenance of your new
product. Please take a few moments to thoroughly read the instructions and familiarize
yourself with all the operational aspects of your new heater.
IMPORTANT INSTRUCTIONS
When using this electric unit, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, and injury to persons, including the following:
1. Read ALL instructions before using this unit.
2. CAUTION: Risk of Electric Shock. DO NOT open or try to repair the heater
yourself.
3. This heater may get hot when in use. To avoid burns, DO NOT let bare skin
touch hot surfaces. If provided, use handles when moving this heater.
4. Keep combustible materials, such as furniture, pillows, bedding, paper, clothes,
and curtains at least 3 ft from the front of the heater and keep them away from
the sides, top, and rear. DO NOT place towels or other objects on the heater.
5. Extreme caution is necessary when any heater is used by or near children or the
disabled, or when the heater is left operating and unattended.
6. DO NOT operate any heater with a damaged cord or after the heater
malfunctions, has been dropped or damaged in any manner. Return heater to
authorized service facility for examination, electrical or mechanical adjustment,
or repair.
7. This heater is not intended for use in bathrooms, laundry areas and similar
indoor locations. NEVER locate heater where it may fall into a bathtub or other
water container. To protect against electrical hazards, DO NOT immerse in
water or other liquids.
8. DO NOT touch the control panel or plug with a wet hand.
9. DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners,
or similar coverings. Arrange cord away from traffic area and where it will not be
tripped over.
10. DO NOT insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the heater.
11. To prevent a possible fire, DO NOT block the air intakes or exhaust in any
manner. DO NOT use on soft surfaces, like a bed, where openings may become
blocked.
12. A heater has hot and arcing or sparking parts inside. DO NOT use in areas
where gasoline, paint, explosive and/or flammable liquids are used or stored.
Keep unit away from heated surfaces and open flames.
13. Always plug heaters directly into a wall outlet receptacle. Never use with an
extension cord or relocatable power tap (outlet/power strip).

3
14. To avoid fire or shock hazard, plug the unit directly into a 120 V AC electrical
outlet.
15. To disconnect heater, turn controls to OFF, then remove plug from outlet. Pull
firmly on the plug, DO NOT unplug by pulling on the cord.
16. Always unplug the unit before moving or cleaning, or whenever the heater is not
in use.
17. Use only for intended household use as described in this manual. Any other use
not recommended by the manufacturer may cause fire, electric shock, or injury
to persons. The use of attachments not recommended or sold by unauthorized
dealers may cause hazards.
18. Always use on a dry, level surface. Use on floor only.
19. DO NOT use outdoors.
20. WARNING: To reduce the risk of fire or electric shock, DO NOT use this unit
with any solid-state speed control device.
21. DO NOT attempt to repair or adjust any electrical or mechanical functions on this
unit. Doing so will void your warranty. The inside of the unit contains no user
serviceable parts. Qualified personnel should perform all servicing only.
SAVE THESE INSTRUCTIONS
SPECIFICATIONS
Voltage Rating 120V (60Hz)
Power
Consumption
800W
Current:
Maximum continuous draw:6.67 Amps
Power:
Low heat=400W High heat =800W
SAFETY FEATURES
Tip-Over Safety Feature
This heater is equipped with a tip-over safety feature. Once the heater is tipped over, an
internal switch will automatically shut the heater off. Once the heater is restored an
upright position, the heater will reset. To continue operation, turn on the heater using
the supplied remote control or the control panel on the heater.
Overheat Safety Feature
This heater is equipped with a overheat safety feature. When the heaters internal
components reach a certain temperature that could cause overheat and possible fire,
the heater will automatically shut off.

4
WARNING: It is normal for the power cord to feel warm to the touch; however, a loose
fit between the outlet and the plug may cause overheating of the plug. If this occurs, try
inserting the plug into a different outlet. Contact a qualified electrician to inspect the
original outlet for damage.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is
wider than the other). To reduce the risk of electric shock, this
plug is intended to fit in a polarized outlet only one way. If the
plug does not fit fully in the outlet, reverse the plug. If it still does
not fit, contact a qualified electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT
THIS SAFETY FEATURE IN ANY WAY.
IN THE BOX
·DISH HEATER
·INSTRUCTION BOOKLET
PRODUCT DIAGRAM
1. Built-in Carrying Handle (in back)
2. Protective Front Grille
3. Parabolic Reflection Hood
4. Base
5. Timer Knob
6. Tip-over Safety Switch (on bottom)
7. Power Knob

5
Control Panel
1. Power Off
2. OSC ＆Low heat setting
3. OSC ＆High heat setting
4. Low heat setting
5. High heat setting
6.Timer knob
7.Timer Off
8.Timer normal open
PREPARATION
Place the heater on a firm, level surface and plug directly into a grounded 120V 60Hz power
outlet.

6
OPERATING YOUR HEATER
1. Turn the power knob to the desired heat setting. (Timer must be set in ON position).
LOW: heating up to 400W
HIGH: heating up to 800W
OSC. LOW: heater will rotate left to right, and heat up to 400W
OSC. HIGH: heater will rotate left to right, and heat up to 800W
OFF: heater will stop operating
NOTE: Do not manually rotate heater. It should only be rotated using oscillation function.
2. To operate the timer, turn the timer knob clock- wise to the desired position. The value will
vary from 0 to 2hr (10 minutes interval) in circulation. The heater will stop automatically
after the set timer is reached.
3. To tilt the adjustable head, pull the reflection hood and gently tilt it forward or backwards
until you hear a click. The reflection hood can be tilt into 4 positions.
CAUTION: When tilting the adjustment head, the heater must be turned off.
MAINTENANCE
1. Turn off the power switch.
2. Unplug the unit and let it cool completely.
3. To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth. You
may use a mild detergent if necessary. After cleaning, dry the unit with a soft cloth.
CAUTION: DO NOT let liquid enter the heater.
4. DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough brushes to
clean the heater. This may cause damage or deterioration to the surface of the heater.
5. DO NOT immerse the heater in water.
Wait until the unit is completely dry before use
TROUBLE SHOOTING
If the heater will not operate, please check the following before seeking repair of service:
1. Check if the power cord is plugged into an electrical outlet, if not, plug in.
2. Check if electricity to the outlet is working.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt build-
up, use the original packaging to repack the unit.
