Performance Tool W2230 User manual

WARNING!
It is the owner and/or operators’ responsibility to study all WARNINGS, operating, and
maintenance instructions contained on the product label and instruction manual prior to operation
of this work light. The owner/operator shall retain product instructions for future reference.
The owner and/or operator are responsible for maintenance, maintaining all decals or
warning labels and while in use, maintaining the unit in good working order. If the owner
and/or operator are not fluent in English, the product warnings and instructions shall be
read and discussed with the operators’ native language by the purchaser/owner or his
designee. Make sure that the operator comprehends its contents. Safety information shall
be emphasized and understood prior to usage. The work light shall be inspected per the
operating instructions.
Protect yourself and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage!
WIDE ANGLE LED WORK LIGHT
OWNER'S MANUAL
Item Number W2230
On occasion, after printing of our literature is completed, our manufacturers may make changes
and/or modifications to merchandise which will not be reflected in this manual. Although we strive
to maintain complete and accurate information, it is possible in some instances, that the product
may differ slightly from printed specifications. Illustrations are intended for reference only. Actual
merchandise may vary. Wilmar is not responsible for typographical errors.
1 YEAR LIMITED WARRANTY
PT POWER® extends only the following warranties, and only to original retail purchasers. These
warranties give specific legal rights. Except where prohibited by local law, the law of the State of
Washington governs all warranties and all exclusions and limitations of warranties and remedies.
There may be other rights which vary from state to state.
PT POWER ® warrants the product to be free from defects in materials and workmanship under
normal use and service. A defective product may be returned for a free replacement within 90
days from the date of purchase, provided that product is returned to place of purchase
immediately after discovery of defect. After 90 days and up to one year from date of purchase, PT
POWER ® will replace at no charge any parts which our examination shall disclose to be
defective and under warranty.
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other
consumables which must be replaced under normal use and service. These warranties shall not
apply to any product or part which is used for a purpose for which it is not designed, or which
has been repaired or altered in any way so as to affect adversely its performance or reliability,
nor shall these warranties apply to any product or part which has been subject to misuse,
neglect, accident or wear and tear incident to normal use and service.
PT POWER® does not authorize any other person to make any warranty or to assume any
liability in connection with its products.
Except for warranties of title and the limited express warranties set forth above, PT POWER®
makes no express or implied warranties of any kind with respect to its products. In particular, PT
POWER® makes no implied warranty of merchantability and no implied warranty of fitness for
any particular purpose, except that for goods purchased primarily for personal, family or
household use and not for commercial or business use, PT POWER® makes an implied
warranty of merchantability (and, if otherwise applicable, an implied warranty of fitness for a
particular purpose), but only for the particular qualities or characteristics, and for the duration,
expressly warranted above.
The laws on limitation of implied warranties may differ from state to state, so the above
limitations may not apply in all cases.
PT POWER® shall not be liable for consequential, incidental or special damages resulting from
or in any manner related to any product, or to the design, use, or any inability to use the
product. The sole and exclusive remedy for a defective product or part shall be the repair, or
replacement thereof as provided above. The laws on limitation of remedies or on consequential,
incidental or special damages may vary from state to state, so the above limitations may not
apply in all cases.

WARNING! TO PREVENT ELECTRIC SHOCK AND DEATH FROM INCORRECT
GROUNDING WIRE CONNECTION: ALWAYS USE A GROUNDED 3-PRONG OUTLET.
Check with a qualied electrician if you are in doubt as to whether the outlet is properly grounded.
Do not modify the power cord plug provided with the light. Never remove the grounding
prong from the plug. Do not use the light if the power cord or plug is damaged. If damaged,
have it repaired by a service facility before use. If the plug will not t the outlet, have a
proper outlet installed by a qualied electrician.
WARNING! If the supply cord of this light is damaged, it must be replaced only by
a qualied service technician.
Note: Replacement parts may not be available for this item.
IMPORTANT SAFETY INSTRUCTIONS
WARNING – To reduce the risk of FIRE, ELECTRIC SHOCK, EXPOSURE TO
EXCESSIVE UV RADIATION, OR INJURY TO PERSONS:
1. Do not look directly at lighted work light.
2. Avoid electric shock. Do not use with an extension cord near water or where water
may accumulate. Keep the light at least 16 feet (5 m) from pools and spas. Keep plugs and
receptacles dry. Use only on GFCI-protected circuits. Do not submerge the light in water.
3. The light is not waterproof. Use extreme caution in any wet location.
4. Be careful if using a tripod. Make certain that the area is clear of debris and obstructions
that may bump the light.
5. Do not obstruct walkways or common areas with the cord.
6. Maintain labels and nameplates on the light. These carry important safety information.
7.
This product is not intended for use in a residence or to be mounted in a cabinet. This product
is not suitable for recessed installation in ceilings or on buildings. This product can cause a re.
8. Do not leave the light unattended when it is plugged into an electrical outlet. Turn off the
light, and unplug it from its electrical outlet before leaving.
9. This product is not a toy. Keep it out of reach of children.
10. People with pacemakers should consult their physician(s) before use. Electromagnetic
elds in close proximity to heart pacemaker could cause pacemaker interference or
pacemaker failure. In addition, people with pacemakers should:
· Avoid operating alone. · Properly maintain and inspect to avoid electrical shock.
· Properly ground power cord. Ground Fault Circuit Interrupter (GFCI) should also be
implemented – it prevents sustained electrical shock
11. WARNING: Handling the cord on this product will expose you to lead, a chemical
known to the State of California to cause cancer, and birth defects or other reproductive
harm. Wash hands after handling.
12. The warnings, precautions, and instructions discussed in this instruction manual cannot
cover all possible conditions and situations that may occur. It must be understood by
the operator that common sense and caution are factors which cannot be built into this
product, but must be supplied by the operator.
13.
Do not operate the light in explosive atmospheres, such as in the presence of ammable
liquids, gases, or dust. A light creates sparks which may ignite the dust or fumes.
14. Do not abuse the cord. Never use the cord for carrying, pulling, or unplugging the light.
Keep the cord away from heat, oil, sharp edges, and moving parts. Damaged or
entangled cords increase the risk of electric shock.
15.
Stay alert, watch what you are doing, and use common sense when operating the light.
Do not use light while you are tired or under the inuence of drugs, alcohol, or medication.
A moment of inattention while operating light may result in serious personal injury.
16. Do not use the light if the On/Off Button does not turn it on and off. Any light that
cannot be controlled with the power button is dangerous and must be repaired.
17. Have the light serviced by a qualied repair person. Use only identical replacement
parts. This will ensure that the safety of the light is maintained.
18. Wear ANSI-approved goggles during setup and use.
SETUP
1. Place the base assembly (19) on a at surface and position the U-bracket (15) bolts so
the hole in the bottom lines up with the hole in the cross bar.
2. Thread bracket thumbscrew (18) through both holes and hand tighten.
3. Position the light assembly so the holes at the top of U-Bracket (15) align with the holes
on the back sides of the light assembly and thread side bracket thumbscrews (13) .
OPERATING INSTRUCTIONS
Read the ENTIRE IMPORTANT SAFETY INSTRUCTIONS section at the beginning of this
manual, including all text under subheadings therein before setup or use of this product.
1. Plug the Light into a standard 120V grounded, electric outlet.
2. To turn on, push the power switch on the back of the light to the on position.
3. To turn off, push the power switch to the off position.
4. To prevent accidents; turn off light and disconnect power supply after use.
Clean, then store the light indoors out of children’s reach.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Make sure that the On/Off Button is in the OFF position and unplug the tool from its
electrical outlet before performing any procedure in this section.
TO PREVENT SERIOUS INJURY FROM LIGHT FAILURE:
Do not use damaged equipment. If damage is noted, have the problem corrected before further use.
1. BEFORE EACH USE, inspect the general condition of the light.
Check for loose hardware, damaged cord/electrical wiring, cracked or broken parts and any
other condition that may affect its safe operation.
2. AFTER USE, wipe external surfaces of the light with a clean cloth.
Part Description Qty
1 Front Cover ............................... 1
2 Glass Lens ................................ 1
3 Sealing Ring.............................. 1
4 Reector.................................... 1
5 Circuit Board.............................. 1
6 LED ......................................... 14
7 Heat Sink................................... 1
8 Switch........................................ 1
9 Rear Housing ............................ 1
10 Cable Bracket............................ 1
11 Insulated Wire Connector.......... 1
12 Power Supply ............................ 1
13 Side Bracket Thumbscrew ........ 2
Part Description Qty
14 Hex Nut (M6)............................. 2
15 U-Bracket .................................. 1
16 Lock Washer ............................. 2
17 Power Cord ............................... 1
18 Bracket Thumbscrew................. 1
19 Base Assembly.......................... 1
20 Feet Cap.................................... 4
21 Crossbar Cap ............................ 2
22 Rear Housing Screw ............... 14
23 Cover Screw.............................. 4
24 Handle....................................... 1
25 Foam Cover............................... 1
PARTS DIAGRAM
Please read these instructions carefully and retain them for future use.
