PERMASTEEL PG-4021800L User manual

2
Table of Contents
Important Safety Information .........................................................................................................3
Safety Symbols................................................................................................................................3
Installation /Safety Precautions.....................................................................................................4
Propane & Gas Warning.................................................................................................................4
E ploded View.................................................................................................................................5
Parts List..........................................................................................................................................6
Before Assembly.............................................................................................................................7
Hardware & Tools .........................................................................................................................10
Assembly Steps.............................................................................................................................11
Gas Connection ............................................................................................................................22
Leak Testing...................................................................................................................................24
Final Installation Check Lists....................... ...............................................................................24
Lighting Instruction.......................................................................................................................26
Operating Instruction ...................................................................................................................27
Care & Maintain ............................................................................................................................28
Food Safety....................................................................................................................................29
Grill Storage ..................................................................................................................................29
Trouble Shooting...........................................................................................................................30
Warranty.........................................................................................................................................31

3
Important Safety Information
Thank you for your purchase of our BBQ Gas Grill. We sincerely wish you will enjoy
using our fine products.
• Please read this User’s Manual in its entirety efore using the grill.
• Please contact our customer service at (888)-287-0735 if you have any questions.
• Please read this User’s Manual carefully. Failure to follow the provided instruction
can result in seriously odily injury and/or property damage.
• Some parts of this grill may have sharp edges. Please wear suita le protective gloves.
• IMPORTANT: This grill is intended for outdoor use only and is not intended to e installed in or
on recreational vehicles or oats.
• NOTE TO INSTALLER: Leave this User’s Manual with the customer after delivery and/or
installation.
• NOTE TO CONSUMER: Leave this User’s Manual in a convenient place for future reference.
Safety Symbols
The sym ols listed here are eing used throughout this User’s Manual. Please pay
special attention to them. The meaning of each of the sym ols is listed here:
• DANGER: this sym ol indicates an imminently hazardous situation which will result in
death or serious odily injury if not properly followed.
• WARNING: this sym ol indicates a warning of potential serious odily injury if the
instructions are not strictly followed. Please e sure to read and follow all these messages
carefully.
• CAUTION: this sym ol indicates a potentially hazardous situation which may result in
minor or moderate odily injury if the instructions are not properly followed.

4
Installation / Safety Precautions
WARNING
READ THIS SECTION FIRST BEFORE INSTALLING THE GRILL
• This grill is designed to use LP gas only. Please use the grill with the regulator supplied y
PermaSteel.
• The installation of this appliance must conform with local codes or, in the a sence of local
codes, with either the National Fuel Gas Code, ANSI Z223 1, or CAN/CGA B149 1, Natural
Gas Installation Code or CAN/CGA-B149 2, Propane Installation Code
• The LP-gas supply cylinder is to e constructed and marked in accordance with the
specifications for LP-gas cylinders of the U S Department of Transportation (DOT) or the
National Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and Tubes for the
Transportation of Dangerous Goods
• This grill is safety certified for use in the United States and Canada only. Never modify to use in
other places. Modification may cause serious odily injury or property damage. PermaSteel is
not responsi le for any modifications, and all warranties will e void.
WARNING： This product can expose you to chemicals including lead,
which is known to the State of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.P65Warnings.ca.gov.
Propane & Gas Warning
WARNING
FOR YOUR SAFETY, PLEASE READ THIS SECTION FIRST
• If you smell gas:
1) Shut off gas to the grill.
2) Extinguish any open flames immediately.
3) Open the grill lid.
4) If the odor persists, please call your gas supplier or your fire department immediately.
• Do not store or use gasoline or other flamma le items in the vicinity of this grill.
• Any LP cylinder that is not connected for use should not e stored in the vicinity of this grill.

5
E ploded View

6
Parts List
Key Description Parts Code Qty Key Description Parts Code Qty
A01 Rotated Rod, Lid 21800001 2 C01 Manifold 21800021 1
A02-1 Lid (Color: Black) 21800045-1 1 C02 as Valve 21800050 2
A02-2 Lid (Color: Red) 21800045-2 2 C03 Regulator 30400051 1
A02-3 Lid (Color: Copper) 21800045-3 3 C04 Control Panel 21800051 1
A03 Temperature auge 30400 33 1 C05 Control Knob Bezel 30400 18P 2
A04 Front Silicone Rubber Bumper 21800004 2 C06 Control Knob 30400 35 2
A05 Large Insulation Plate 21800005P 2 D01 Door Handle Bushing 21800026 2
A06 Lid Handle Bezel 21800006P 2 D02 Door Handle 21800027 1
A07 Small Insulation Plate 21800007 4 D03-1 Door (Color: Black) 21800028 1
A08 Lid Handle 21800008P 1 D03-2 Door (Color: Red) 21800028-2 1
A09 Name Plate 30400 35 1 D03-3 Door (Color: Copper) 21800028-3 1
B01 Back Rail 21800009 1 D04 Set Screw 30400 25 1
B02 Rear Silicone Rubber Bumper 50300205 2 D05 Lighting Rod 21800029 1
B03 Firebox 21800010 1 D06 Drip Tray 21800030 1
B04 Left Back Side Shelf Support 21800011 1 D07 Drip Cup 30400 27 1
B05 Left Back Side Shelf Support Bracket 30400 05 1 D08 Electronic Ignition Module 218000502 1
B06 Left Front Side Shelf Support Bracket 30400 06 1 D09 Back Panel 21800033 1
B07 Front Side Shelf Support 21800012 2 D10 Door Bracket 21800034 1
B08 Right Front Side Shelf Support Bracket 30400 08 1 D11 Door Pin Bracket 21800035 1
B09 Right Back Side Shelf Support Bracket 30400 07 1 D12 Left Side Panel 21800036 1
B10 Right Back Side Shelf Support 21800013 1 D13 Left Drip Tray Bracket 21800037 1
B11 No.1 Igniter Wire 21800046 1 D14 Right Drip Tray Bracket 21800038 1
B12 No.2 Igniter Wire 21800047 1 D15 Right Side Panel 21800051 1
B13 Warming Rack 21800014 1 D16 Door Magnet 21800040 2
B14 Cooking rate 21800015 2 D17 Tank Holder 20700049 1
B15 Main Burner 21800016P 2 D18 Cotter Pin 110050 6
B16 Heat Diffuser 21800017 2 D19 Cart Support Angle Bar 21800041 2
B17 Left Side Shelf 21800048 1 D20 Bottom Panel 21800042 1
B18 Right Side Shelf 21800049 1 D21 Caster with Brake 40900213 2
B19 Tool Hook 30400 34 6 D22 Caster 40900212 2
Not Pictured
Manual 21800043P 1
Hardware Blister Pack 21800044P 1
If you are missing any parts or have
damage parts please call
888-287-0735 M-F 8:00-5:00
Pacific Time, for replacement
visit us at www.permasteel.net

7
BeforeAssembly
READANDFOLLOWTHE INSTRUCTIONS BELOWTO CORRECTLYUNPACK GRILL PARTS
FROMSHIPPING BOX.
Step 1:Carefullyopen the top ofthecartonwithaboxcutter,takeoutall the grill parts,andpacking
materialabovethe grill.

8
Step2:Withtheaidofanassistant, turn grill overon itssideas shownbelow,and remove
thetop styrofoamendcap. Take outthesideshelfcarton from it.

9
Step3:Removeanotherstyrofoamendcapfrom thegrill and place ituprighton thefloor.
Openthelid,and takeoutthesmall boxes packedinside. Removeall packing materials, and
take outall partsfromboxes.

10
Hardware
The following hardware is provided in a blister pack for convenient use.
M4X10 Screw: 35pcs M5X10 Screw: 4pcs M6 12 Shoulder Bolt: 8pcs
M6 13 Screw: 34pcs M6 Flat Washer: 2pcs M6 20 Screw: 2pcs
Cotter Pin: 1pc Hose Retain Pin: 1pc Battery (AA) : 1pc
Tools
The following tools are required for assembly:
 Adjustable wrench (not provided)
 Screwdriver (not provided)
 7/16” Combination wrench (not provided)

11
Assemble Steps
Step 1
 Turn the bottom panel upside down.
 Use (16) M6 13 screws to attach four casters to the bottom panel.
Note: Casters with brake are amount on the back of bottom panel.
 Turn the bottom panel upside down.
Caster with Brake
Back of Bottom

12
Step 2
 Attach the Left Side Panel to Bottom Panel with (3) M6 13 screws. Do not fully tighten them.
 Attach the Right Side Panel to Bottom Panel with (3) M6 13 screws. Do not fully tighten them.
 Attach the Back Panel to Left & Right Side Panels and Bottom Panel with (8) M4 10 screws as
shown.
L R

13
Step 3
 Attach the Cart Support Angle Bar to Left Side Panel and Bottom Panel with (4) M4 10 screws.
 Attach the Cart Support Angle Bar to Right Side Panel and Bottom Panel with (4) M4 10
screws.
 Attach the Door Bracket to Left & Right Side Panels with (4) M4 10 screws.
 Fully tighten all screws in Step 2.
inside view
inside view

14
Step 4
 Attach the Left Drip Tray Bracket to the top of Left Side Panel with (4) M4 10 screws.
 Attach the Right Drip Tray Bracket to the top of Right Side Panel with (4) M4 10 screws.

15
Step 5
 Remove any wire ties holding the regulator and gas hose under the grill head, making sure the hose hangs
freely. With the aid of an assistant, carefully lower the grill head onto the pedestal, use (4) M6 13 screws
from sides to attach head to pedestal. See A.
 Attach the Back Rail to the back of Firebox & Side Panels with (4) M4 10 screws. See B.
 Open the lid, to attach the Lid Handle, align the Large Insulation Washer, Lid Handle Bezel, two Small
Insulation Washers and Lid Handle, attach them to the Lid with (2) M6 20 Screws and (2) M6 Flat Washers
from inside of the lid. See C.
M6x20 screw
M6 flat washer
Large insulation washer
Lid handle bezel
Small
insulation
washer
A
B
C

16
Step 6
 Remove the 2 pre-installed screws from two sides of Control Panel. Attach the Front Side Shelf
Supports to each sides and reattach with previously removed 2 screws. See A & B.
 Underneath the firebox, fix the regulator to the right side panel with (1) Hose retain pin and (1)
Cotter pin. See C.
 Attach the Left & Right Back Side Shelf Supports to the rear sides of firebox with (4) M5 10
screws. See D & E.
 Note: Attach all the brackets so that the flanges on top.
D E
C
A B

17
Step 7
 Attach the 4 side shelf support brackets to firebox with (8) M6 13 screws. There is a location
label on each bracket.
Note: Attach the front brackets so that the flanges face to the front of the grill.
Attach the back brackets so that flanges face to the back of the grill.
Left Side after assemble Right Side after assemble
Left Back Side Shelf
Support Bracket
Left Front Side Shelf
Support Bracket
Right Front Side Shelf
Support Bracket
Right Back Side Shelf
Support Bracket

1
Step 8
 Place the 6 pcs of tool hooks on each side shelf end and tighten with nuts. See A.
 Screw (1) M6 12 shoulder screw into the lower hole of each side shelf support bracket. See B
& D.
 For each side shelf, hold the shelf in attachment position on the side of cart. Screw (1) M6 12
shoulder screw through the shelf attachment slot and into the upper hole of each side shelf
support bracket. See C & E.
NOTE: To raise shelf to use position, lift shelf from long side. To lower shelf, grasp by front and
back short sides and raise up slightly, then guide shelf down to collapsed position.
A
B C
D E

19
Step 9
 Attach the Door Handle to the Door with (2) Pre-assembled M6 15 Screws.
 Insert the door bottom pin into the hole in the front of bottom panel. Push down the door top pin,
align it with the hole in the door bracket, and release pin so that it insert in hole.

20
Step 10
 Place heat diffusers over burners. Diffusers will fit in firebox in either direction.
 Place cooking grates onto grate rests.
 Insert the two attachment tips at the back of the warming rack into the holes in the warming
rack brackets.
Step 11
 Install the drip tray into the cart from back.
 Install the drip cup into the drip tray from back.
