Pet Gear AT3 GENERATION 2 User manual

INSTRUCTION MANUAL
AT3 NO-ZIP PET STROLLER
PG8350NZ
To see our full line of products, visit us online at: www.petgearinc.com
CUSTOMER SERVICE HELP DESK
[email protected]
Interior Dimensions:
"L x 13"W x 22"H
29

AT3 NO-ZIP PET STROLLER • PG8350NZ
Toll-Free 877-752-9123 - Eastern Standard Time 8am-3pm, Monday through Friday
PARTS LIST
Check that you have all the parts shown BEFORE assembling
your product.
If any parts are missing, call
Customer Se
rvice.
Stroller
Back Tray
Front
Wheel
Axle
2-Rear
Wheels
ASSEMBLY INSTRUCTIONS
Step 1. Push back wheels on to axle, as shown Step 2. Pull on wheel to make sure the
wheel is in Figure A, until they lock into place.
should look like Figure B.
B.
Shown with both back wheels in place.
A.

AT3 NO-ZIP PET STROLLER • PG8350NZ 3
2
Back Wheels
Inside Outside
C.To remove wheel, push the
lock/release button
(Figure C) and pull wheel off.
Lock/Release Button
Step 3. To attach front wheel, slide plastic wheel support Step 4. Slide wheel up, until
velco pins pop out up and onto tubing. of holes.
Step 5. To use stroller in locked position for jogging, Step 6. To use stroller in swivel
position, pull pin move pin so that it is at the top of the “L” shaped down, and to the
right. cutout.
Tubing
Tubing
Velco Pin
Velco Pin

AT3 NO-ZIP PET STROLLER • PG8350NZ
UNFOLDING THE STROLLER
Step 1. Release folding latch (D).
Step 2. Spread handle (E) and seat apart until
the frame clicks and locks on both sides.
Step 3. Ensure that the stroller is locked in on
both D. sides before using.
4
Locked Position
Swivel
Position
E.

AT3 NO-ZIP PET STROLLER • PG8350NZ 5
TO SECURE COMPARTMENT TO FRAME
Step 1. Open stroller and pull
compartment down.
Step 2. Clip onto frame.

tube and fasten to the bottom of the compartment.

AT3 NO-ZIP PET STROLLER • PG8350NZ 7
TO ASSEMBLE BACK TRAY
two holes on the side of the tray with the two rivets.
Step 2. Align the other side of the tray with the Step 3. Push down on the tray to lock it
into place. single rivet on that side.

6 AT3 NO-ZIP PET
STROLLER • PG8350NZ
Step 1. To close
compartment, pull
downward and clip the
canopy into the front of
the stroller until it locks.
Step 2. To open the
stroller canopy, simply
push and release button
to unlock.
Step 1. To open the stroller canopy, Step 2. Slide back frame lock release (F) to the right,
simply push and release button to while squeezing the front frame lock release (G) and

AT3 NO-ZIP PET STROLLER • PG8350NZ 9
unlock. rotate the folding mechanism almost 180 degrees forward
until stroller releases and handle is lowered. C.
F.
G.
SLIDE TO RIGHT
Squeeze front lock release (G.) and rotate
180 degrees forward

AT3 NO-ZIP PET STROLLER • PG8350NZ
INSTRUCTIONS FOR USE
Apply brake lever by pushing down
with toe. Back View of
Stroller Ensure brakes are applied
when parking stroller.
Release by lifting brake lever with
toe.
WARNING: Never leave your
stroller parked without applying
brakes.
LOOKING AFTER YOUR STROLLER
• Always store product in a clean, dry place.
• Not recommended for use on the beach.
• Do not put heavy items on top of the stroller.
• Clean frame by wiping with a lightly oiled cloth.
•
warm water.
• To ensure easy maneuverability and to minimize wear and tear, (especially
wheels, axles, and swivels), keep all moving parts clean and lubricated with
WD40® or light machine oil.
• NOTE: Do not lubricate brake components or swivel locks.
• Regularly check stroller for loose parts. These should be tightened or replaced.
WHEEL MAINTENANCE
• To clean and lubricate front and rear wheels, push out locking lever under
wheel housing to release rear wheel.
Step Here

AT3 NO-ZIP PET STROLLER • PG8350NZ 11
• To ensure ease of maneuverability and to minimize wear and tear, keep all
moving parts clean and lubricated with WD40® or light machine oil.
• Push wheel sets back on until they click and lock in position; pull on wheel
housings to ensure they are secure.
• Push stroller back and forth and rotate swivels around to work in lubricant.
• Clean the rear wheel assembly and the rest of the frame with warm, soapy
water; clean off with warm water and dry thoroughly.
• NOTE: Do not lubricate brake components or swivel locks.
8
WARNING!
FOR PETS ONLY.
Not intended to be used as a restraining device for aggressive or dangerous animals that
dig, chew or paw aggressively. Do not leave your pet unattended. PET GEAR is not liable
for any damage caused by aggressive,
warnings and the instructions could result in serious injury or death.
• Do not carry additional bags, goods, or accessories in or on stroller except
as recommended in the manufacturer’s instructions.
•
• Do not leave pet unsupervised in stroller.
• Before making adjustments to stroller ensure that pet’s body is clear of any
moving parts.
• This stroller is designed for one pet only.
• Do not hang bags from handles as this may cause the product to become
unstable.
• Do not use on escalator or stairs; fold stroller and carry.
• Put on brake whenever you park the stroller.
• Ensure stroller is completely erected and check that all locks are engaged
before placing pet in stroller.
• Do not overload as stroller may become unstable; maximum weight of pet
using this stroller not to exceed 75 lbs.
• Any goods carried in the basket not to exceed 6 lbs.

AT3 NO-ZIP PET STROLLER • PG8350NZ
REPLACEMENT PARTS
Use only PET GEAR replacement parts.
Please have your model number ready before calling.
You can also request parts: http://www.petgearinc.com/main.asp?sel=2
192 Sheldon Avenue • West Rutland, VT 05777 • 877-752-9123 • www.petgearinc.com
