PhiBer Dash 2.0 User manual

OPERATOR’S MANUAL
www.phiber.ca
The Dash
Delivery System
Model: Dash 2.0 & 4.0

i
Limitation of Liability
PhiBer®Manufacturing Inc. shall not be liable for special, incidental or consequential
damages arising out of the use of, the misuse of, or the inability to use any product sold
by PhiBer®Manufacturing Inc. including, but without limitation: damages or loss of other
property or equipment, personal injury, loss of life, loss of profits or revenue, or claims
of purchaser for any such damage or loss.
Warranty
PhiBer®Manufacturing Inc. warrants its products to be free from defect in factory
workmanship and material under normal use and service, when set-up and operated
according to factory instructions. Warranty should be handled through PhiBer®or an
authorized selling dealer. Warranty is subject to the following conditions:
Warranty Claims: Must be completed within 30 days of replacement of part(s). Claim
must include serial number of Dash, date of delivery, explanation of problem and all
other necessary particulars.
Warranty Parts: Must be kept for PhiBer’s®inspection unless otherwise specified.
Warranty Labor: PhiBer®must authorize any labor subject to warranty. PhiBer®
Manufacturing Inc. reserves the right to set the labor rate and time required to complete
a warranty repair.
Warranty Limitations: Warranty will not be granted on any product that has been
misused, altered, or modified in any way. Diagnostic and service calls are not covered
by warranty. Warranty covers only the cost of repair and parts; it does not include shop
supplies, mileage and freight costs.
Government Legislation: Warranty terms and conditions are subject to provincial or
state legislation and laws.
Warranty on cylinders, hydraulic components, electronic components, and other trade
accessories are limited to the warranties made by the respective manufacturers and not
by PhiBer®Manufacturing Inc.
The following table shows the available warranty:
Item Time from Purchase
Frame and other structural components One (1) Year
Electronic components One (1) Year
Hydraulic components One (1) Year
Hydraulic cylinders One (1) Year

iii
Table of Contents
TABLE OF CONTENTS ..............................................................................................................................III
INTRODUCTION...........................................................................................................................................1
DESCRIPTION OF THE MACHINE....................................................................................................................2
ILLUSTRATION OF THE MACHINE...................................................................................................................2
Dash 2.0 & 4.0......................................................................................................................................2
Serial Number Location........................................................................................................................3
SAFETY........................................................................................................................................................4
SAFETY ALERT SYMBOLS ............................................................................................................................4
SIGNAL WORDS ..........................................................................................................................................4
OPERATOR RESPONSIBILITY........................................................................................................................5
Key Safety Reminders:.........................................................................................................................5
GENERAL SAFETY PRACTICES .....................................................................................................................5
MAINTENANCE SAFETY................................................................................................................................6
WATER AND CHEMICAL SAFETY ...................................................................................................................7
INSTALLATION SAFETY.................................................................................................................................8
TRANSPORT SAFETY ...................................................................................................................................8
STORAGE SAFETY.......................................................................................................................................9
SAFETY SIGNS..........................................................................................................................................10
Safety Sign Location...........................................................................................................................10
Safety Sign Explanation .....................................................................................................................10
Road Safety Sign Location.................................................................................................................11
Road Safety Sign Explanation............................................................................................................11
Safety Sign Maintenance ...................................................................................................................12
SPECIFICATIONS......................................................................................................................................13
DASH......................................................................................................................................................13
HARDWARE TORQUE.................................................................................................................................14
MOUNTING AND INSTALLATION ............................................................................................................15
MOUNTING THE DASH ..............................................................................................................................15
MOUNTING THE DASH ACCESSORIES........................................................................................................15
Cage...................................................................................................................................................15
Tote Platform (4.0 only)......................................................................................................................15
Light Kit...............................................................................................................................................15
Boom Kit.............................................................................................................................................15
Step Kit...............................................................................................................................................16
Manifold Kit.........................................................................................................................................16
Working Platform ( Center Mount 4.0 only)........................................................................................16
Deck Bulkhead ...................................................................................................................................16
Flow Meter..........................................................................................................................................16
Pump Mount Kit ( 2.0 only).................................................................................................................16
Auxiliary Chemical Meter ( 2.0 only)...................................................................................................16
Jug Knife Kit .......................................................................................................................................16
Hose Reel...........................................................................................................................................17
Honda Motor w/ Pump........................................................................................................................17
Chemical Transfer Pump....................................................................................................................17

iv
Water Tanks.......................................................................................................................................17
OPERATION...............................................................................................................................................18
PRE-LOADING PRODUCTS..........................................................................................................................18
Jugs and Liquid Products...................................................................................................................18
Dry Products.......................................................................................................................................18
LOADING THE SPRAYER.............................................................................................................................18
CLEANING THE DASH ...............................................................................................................................18
SERVICE AND MAINTENANCE................................................................................................................19
WINTERIZING ............................................................................................................................................19
SPRINGTIME PREPARATION .......................................................................................................................19
Rear Mount Dash Light Schematic.....................................................................................................20
TROUBLESHOOTING................................................................................................................................20
INDEX .........................................................................................................................................................22

1
Introduction
Congratulations on your purchase of the PhiBer®Dash Delivery System. The PhiBer
®
Dash Delivery
System offers the agricultural industry a machine for quickly mixing and loading spraying chemicals.
All persons authorized to operate this equipment should read and understand the contents of this
Operator’s Manual, especially the Safety section. The owner or operator should seek assistance from
the dealer, distributor or PhiBer®for any information not fully understood regarding the safe operation,
adjustment, maintenance or repair of this equipment.
Keep this Operator’s Manual in a clean, dry place that is easily accessible for reference when more
detailed information is required to perform tasks related to the operation, adjustment, maintenance or
repair of this equipment. It is further recommended that the contents of this Operator’s Manual be
reviewed at least annually by persons operating, adjusting, maintaining or repairing this PhiBer®Dash
Delivery System and any time a new person is assigned to any of the above-mentioned tasks.
Any information in this Operator’s Manual that is not fully understood should be clarified by contacting
the dealer, distributor or manufacturer.
The contents of this Operator’s Manual are accurate up to the time of printing.
PhiBer®reserves the right to make design changes without prior notice to the end user.

2
Description of the Machine
The Dash has two primary objectives; reduce fill times to keep the sprayer spraying, and to keep
chemicals separated. The Dash comes with two pumps, a high delivery water pump with a 13hp
Honda motor and air diaphragm pump capable of 40 gpm used for auto rinsing and the agitation of
dry products. The design allows operators to load multiple products for the next sprayer load ahead of
time while keeping chemicals separated. Once connected to the sprayer, the operator can stand at
the side of the trailer, completely loading the sprayer with up to four different products without moving.
The process of loading four different chemicals into a 1,200 gal sprayer will take less than four
minutes.
Illustration of the Machine
IMPORTANT! All references to “LEFT” and “RIGHT”,
as used throughout this Operator’s Manual, are
determined by facing the direction of forward travel
when in use.
Dash 2.0 & 4.0
7. 1”WaterIn
8. 3”Waterin
1. Battery
2. Motor/SuctionPump
3. ChemicalDumpHandles
4. ChemicalInductor
5. AirPump
6. AirInput
1
1
2
2
3
3
44
5
5
6
6
7
7
8
8

3
Serial Number Location
The serial number plate (Figure 1.2) is located inside
the front right hand side of the frame.
Record the machine Model and Serial Number in the
spaces provided below. Use these numbers when
contacting the dealer for repair parts or service
assistance.
Model Number: ________________
Serial Number: _________________
Figure 1.2

4
Safety
Safety Alert Symbols
Safety Alert Symbols are intended to draw attention of the machine operator to important safety
information both published in the Operator’s Manual and applied to the machine. Whenever a Safety
Alert Symbol is seen, it means that associated information is provided for recognizing, responding
appropriately to and avoiding potentially hazardous situations.
An equilateral triangle surrounding an exclamation point or a double line equilateral triangle
surrounding symbols or graphics indicates a potentially hazardous situation. Information included on
a safety sign or printed in the Operator’s Manual describes the hazardous situation and indicates
appropriate response and/or avoidance procedures.
Remember:
ACCIDENTS DISABLE AND KILL
ACCIDENTS ARE COSTLY
ACCIDENTS CAN BE AVOIDED
Signal Words
DANGER
Indicates an imminently hazardous situation that,
if not avoided, WILL result in death or serious
injury if proper precautions are not taken.
WARNING
Indicates a potentially hazardous situation that, if
not avoided, COULD result in death or serious
injury if proper precautions are not taken.
CAUTION
Indicates a potentially hazardous situation that, if
not avoided, MAY result in minor or moderate
injury if proper precautions are not taken, or it
serves as a reminder to follow appropriate safety
practices.
DANGER
WARNINGWARNING

CAUTIONCAUTION


5
Operator Responsibility
Remember, YOU, the operator, are responsible for the safe operation, adjustment, maintenance and
repair of this PhiBer®Dash Delivery System. It is the responsibility of the owner, or authorized person
in charge, to ensure that all persons who operate, adjust, maintain and/or repair this implement are
familiar with the information provided in this Operator’s Manual.
A safe operator is the key to safety. Good safety practices not only protect you, but also persons who
may be near the DASH. Make good safety practices a part of your farming operation. Ensure that all
persons operating, adjusting, maintaining and/or repairing this equipment are familiar with the
procedures recommended in this Operator’s Manual.
Always heed safety warnings and follow recommended safety precautions to avoid hazardous
situations. Do not risk personal injury or death by ignoring safety warnings and safety precautions.
Key Safety Reminders:
•The most important safety device is a safe and qualified operator.
•A safe operator is one who has read and understood the contents of this Operator’s Manual
prior to performing any tasks related to the machine.
•Owners have a responsibility to provide training to persons who may operate, adjust, maintain
and/or repair the equipment prior to performing any of these tasks.
•Do not perform any unauthorized modifications to the Dash or use the Dash for any purpose
other than what is described in the contents of this Operator’s Manual.
•Plan tasks and work schedules to reduce exposure to unnecessary stress and fatigue.
•Observe all workplace safety and health requirements.
•Read all supplied products manuals.
General Safety Practices
•Read and understand the contents of this Operator’s Manual prior to operating, adjusting,
maintaining and/or repairing the Dash.
•Locate, read and understand all safety signs applied to the Dash before performing any tasks.
•Review the contents of this Operator’s Manual at least annually, and any time a new person is
assigned to perform any task with the Dash.

6
•Do not allow riders on any part of the Dash or trailer.
•Ensure all guards and shields are intact and in place prior to operating the Dash.
•Keep hands, feet, hair and loose clothing away from moving and/or rotating parts.
•Stop the engine, remove the ignition key and allow time for moving parts to stop prior to
adjusting, maintaining or repairing the equipment.
•Ensure that all equipment lighting and marking is intact, clean and operating properly prior to
traveling on public roads. Check with local highway authorities to confirm that the Dash is
properly equipped for highway travel.
•Provide a fully stocked First-Aid kit in a highly visible and easily accessible location.
•Keep a fully charged fire extinguisher in a highly visible and easily accessible location.
•Ensure that the Dash is securely blocked and supported prior to working underneath (if it
needs to be raised for repair).
•Ensure that all persons operating, adjusting, maintaining and/or repairing the Dash know how
to seek or summon medical assistance should an injury occur.
•Ensure deck remains clean and dry to reduce slipping/tripping.
•Do not climb onto tote deck or cage, use ladder from ground to secure tote straps.
•Only allow one operator at any time
•Use caution when using jug knives
Maintenance Safety
•Read and understand all of the information provided in this Operator’s Manual covering the
operation, adjustment, maintenance and repair prior to performing any of these tasks.
•Ensure proper tools, equipment and personal protective equipment is available prior to working
on the Dash.

7
•Stop the engine, remove the ignition key and allow time for moving parts to stop prior to
adjusting, maintaining or repairing the equipment.
•Ensure that all moving parts have come to a complete stop before performing adjustments,
maintenance or repairs.
•Prior to operating equipment, ensure that all guards and shields are intact and in place after
performing adjustment, maintenance or repairs.
•Check for bushing wear and weldment fatigue on moving parts.
•Store flammable fluids in approved containers and store out of access by unauthorized
persons, especially children.
•Wear appropriate clothing when performing tasks around the Dash. Ill-fitting and/or frayed
clothing as well as loose or dangling items should not be worn when working near the
equipment.
•Ensure that pressure in hoses, lines and components is fully relieved prior to performing
maintenance or repairs to the system.
Water and Chemical Safety
•Periodically inspect condition of hoses, lines and components. Remove and replace any parts
showing damage or deterioration.
•Use only repair or replacement parts specified by the manufacturer.
•Follow instructions provided by the manufacturer when making repairs.
•Wear appropriate personal protective equipment when unsure if residual pressure may exist in
components during trouble-shooting and/or making repairs.
•Wear appropriate personal protective equipment when handling chemicals.
•Ensure all fittings, couplings and other connections are intact and properly tightened before
operation.

8
•Store flammable/ toxic fluids in approved containers and store out of reach by unauthorized
persons, especially children.
•Ensure that pressure in hoses, lines and components is fully relieved prior to performing
maintenance or repairs to the fluid system.
•Ensure that all persons operating, adjusting, maintaining and/or repairing the Dash know how
to seek or summon medical assistance should an injury occur.
•Insecticide should be poured directly into sprayer tank to limit exposure.
•Follow all local regulations for chemical spills
•Follow all chemical manufacturer’s instructions for use and safety.
Installation Safety
•Read, review and understand all Dash installation instructions before attempting to attach
Dash to trailer.
•Ensure the trailer is properly hitched to the tractor.
•Ensure that tractor engine is shut off, key is removed from the ignition and the parking brake is
set and/or wheels blocked.
Transport Safety
•Ensure that the Dash, Dash accessories, and all loads or chemical totes are attached to the
trailer according to local regulations.
•Ensure the trailer hitch is in place and engaged properly.
•Ensure all lighting and implement marking devices are intact and visible.
•Ensure equipment is properly marked according to local road regulations and heed all local
traffic regulations.
•Reduce travel speed on rough roads and surfaces.
•Come on and off approaches or roads slowly; too much speed can cause the trailer to
tip.

9
•Use additional caution and reduce speed when towing under adverse surface conditions and
when turning.
•Do not allow riders on any part of the Dash or trailer.
•Ensure boom and/or end gate is securely latched before transport.
Storage Safety
•Store the Dash away from areas of human activity.
•Do not allow children to play on or around Dash or trailer.

10
Safety Signs
Safety Sign Location
Figure 2.1
Safety Sign Explanation
BOOM LATCH (Figure 2.2)
•WARNING!
U Ensure boom is securely latched before
transport.
Figure 2.2

11
READ THE OPERATOR’S MANUAL (Figure 2.3)
WARNING! U Read and understand the contents of the
Operator’s Manual before performing any tasks related to
the operation, adjustment, maintenance or repair of the
machine.
CHEMICAL HAZARD (Figure 2.4)
WARNING! U Read and understand the contents of the
manufacturers handling and use instructions
Road Safety Sign Location
Road Safety Sign Explanation
CONSPICUITY TAPE- RED/WHITE (Figure 2.12)
Tape serves as reflectors to render vehicle visible in low light
or dark driving conditions.
Figure 2.3
Figure 2.12
Figure 2.4

12
Safety Sign Maintenance
Safety Sign Legibility
All safety signs applied to the Dash must be visible and legible. Keep dust and dirt cleared from
safety signs and ensure that visibility is not obscured.
Damaged or Deteriorated Safety Signs
Remove and replace any safety signs that have been damaged or show signs of deterioration.
Safety Sign Replacement
Replacement safety signs may be ordered through your dealer or distributor. Contact PhiBer®if you
are unable to obtain replacement safety signs from a dealer or distributor.
Safety Signs on Replacement Parts
Ensure that replaced parts or components on the Dash, that had a safety sign attached originally,
include a safety sign when they are shipped to you.
Affixing Safety Signs to Machine
1. Ensure proper position and orientation before installing.
2. Ensure installation area is clean and dry.
3. Ensure ambient temperature is above 50° F (10° C).
4. Remove backing material to expose label adhesive.
5. Place one edge of label to machine surface.
6. Slowly press the label onto the surface.
7. Ensure no air pockets exist under surface of the label.

13
Specifications
DASH
2.0 Center Mount 4.0 Rear Mount 4.0
Width 65 in (165 cm) 102 in (259 cm) 102 in (259 cm)
Length 40 in (102 cm) 36 in (91 cm) 36 in (91 cm)
Height 62 in (158 cm) 66 in (168 cm) 78 in (198 cm)
Weight 440 lbs. (200 kg) 1400 lbs. (635 kg) 1550 lbs. (704 kg)
Requirements 3” Water Supply Line, 1” Water Supply Line

14
Hardware Torque
SAE
Bolt Diameter Bolt Torque
inches SAE 2 n·m (lb-ft) SAE 5 n·m (lb-ft) SAE 8 n·m (lb-ft)
1/4 8 (6) 12 (9) 19 (12)
5/16 13 (10) 25 (19) 36 (27)
3/8 27 (20) 45 (33) 63 (45)
7/16 41 (30) 72 (53) 100 (75)
1/2 61 (45) 110 (80) 155 (115)
9/16 95 (70) 155 (115) 220 (165)
5/8 128 (95) 215 (160) 305 (220)
3/4 225 (165) 390 (290) 540 (400)
7/8 230 (170) 570 (420) 880 (650)
1 345 (225) 850 (630) 1320 (970)
Metric
Bolt Diameter Bolt Torque
mm 8.8 n·m (lb-ft) 10.9 n·m (lb-ft)
M3 0.5 (0.4) 1.8 (1.3)
M4 3 (2.2) 4.5 (3.3)
M5 6 (4) 9 (7)
M6 10 (7) 15 (11)
M8 25 (18) 35 (26)
M10 50 (37) 70 (52)
M12 90 (66) 125 (92)
M14 140 (103) 200 (148)
M16 225 (166) 310 (229)
M20 435 (324) 610 (450)
M24 750 (555) 1050 (774)
M30 1495 (1103) 2100 (1550)
M36 2600 (1917) 3675 (2710)
Valve Bolts
Valve Size
in
Nut Size
across flats
in
Handle Bolt
Torque
n·m (in-lb)
Body Bolt
Torque
n·m (in-lb)
3/4 7/16 5 (45) 5 (45)
1 1/2 5 (45) 5 (45)
2 9/16 17 (150) 10 (88)
3 9/16 28.3 (250) 10 (88)
NOTE:U Torque values listed are based on lubricated connections in reassembly.

15
Mounting and Installation
Mounting the DASH
1. Place Dash on trailer where desired.
2. Drill holes through trailer deck through dash feet.
3. Insert mounting bolts through Dash feet.
4. Attach 3” water line to suction supply line.
5. Attach 1” water supply line.
6. Attach airline to air supply line.
7. Attach output hose to outlet.
Mounting the DASH Accessories
Cage
1. Place Cage on trailer where desired.
2. Drill holes through trailer deck through Cage feet.
3. Insert mounting bolts through Cage feet.
Tote Platform (4.0 only)
1. Use supplied bolts to bolt platform legs to platform.
2. Use supplied U-bolt to bolt Tote Platform to Dash.
3. Drill holes through trailer deck through Platform feet.
4. Insert mounting bolt through Platform feet.
Light Kit
1. Use supplied U-bolts to bolt Light Kit onto Dash frame.
2. Mount Switch Box using supplied screws.
3. Connect power wires to battery.
4. Use supplied p-clips to secure wire to Dash frame
Boom Kit
1. If not mounting to Dash frame, bolt Standalone Boom Kit to trailer deck.
2. Use supplied U-bolts to bolt Boom Kit onto Dash frame or Standalone Boom Kit. Bottom U-bolt
~9” from deck, with ~19” in-between U-bolts.
3. Mount Boom Latch to deck at desired location under one of the boom supports.
4. Attach hoses to boom.
