Phidgets 1048 User manual

What We Know about PHIDGETS
By: Susan at http://www.hukyforum.com/
You may use this under the CC BY-NC-ND license.
(See http://creati ecommons.org/licenses/by-nc-nd/4.0/ for details.)
Phidget 1048 temperature contro
Here's what Marko (the force behind Artisan) said about Phidgets in June 2013
The Phidgets are up to now the fastest (in terms of communication speed) and cheapest 4 channel
option. They are also the only devices that communicate directly via USB instead of the slow and error
prune serial2USB connection all other meters are using. Phidgets are supported y Artisan from v0.7
on. From Artisan v0.8 on Phidgets can e remote accessed too, via Ethernet networking or WiFi using
another computer or a Phidget SBC. The Phidgets InterfaceKits (eg. SBC and 1018) are now also
supported.
Phidgets
•Phidget 1048 4-Temperature Input
•Four J/K/E/T-Type pro es
•USB Interface with custom driver for Windows, Mac and Linux
•USB-powered
•Pure electronics oard without display or memory. Case availa le.
•Pro e wires have to e directly connection to the terminal locks
Purchase a Phidget 1048
Directly from Phidgets in Canada
http://www.phidgets.com/products.php?product_id=1048
Be sure to spend the extra on the enclosure:
http://www.phidgets.com/products.php?product_id=3827_0
You can also get the Phidgets from Mill City Roasters:
https://millcityroasters.com/shop/roaster-accessories/phidget-1048-thermocouple-usb-interface/
Phidgets 1048 User Guide
http://www.phidgets.com/docs/1048_User_Guide
Guide for putting the Acry ic Enc osure Together
http://www.phidgets.com/documentation/Phidgets/3810_0_AssemblyGuide.pdf

Wiring your Phidget between your HUKY and your computer
Remo e the miniplugs from the ends of the thermocouples.
BT is at the bottom. ET in the middle. MET at the top.
Loosen the Screws

Insert the wires. BT goes into the right most set of two holes. Red wire to the left (marked 0; black to
the right (marked G)

Next connect ET. Red in the slot marked 1; black in the slot marked G

And lastly comes MET
