Philco PDT 671 User manual

TABLE TOP DISHWASHER
USER’S MANUAL
PDT 671

Copyright © 2016, Fast ČR, a. s. 08/2016
Dear customer,
thank you for buying a PHILCO brand product. So that your appliance serves you well, please read
all the instructions in this user’s manual.

EN - 1
Copyright © 2016, Fast ČR, a. s. 08/2016
CONTENTS
1. IMPORTANT SAFETY INFORMATION ..................................................................................................... 3
2. QUICK OPERATION GUIDE ...................................................................................................................... 9
3. OPERATION INSTRUCTION ................................................................................................................... 11
4. PRIOR USING FOR THE FIRST TIME....................................................................................................... 12
5. LOADING THE DISHWASHER BASKETS................................................................................................ 17
6. STARTING A WASHING PROGRAMME.................................................................................................. 21
7. MAINTENANCE AND CLEANING........................................................................................................... 23
8. INSTALLATION INSTRUCTION .............................................................................................................. 27
9. TROUBLESHOOTING TIPS ..................................................................................................................... 30
10. TECHNICAL INFORMATION................................................................................................................... 32
11. DISPOSAL................................................................................................................................................ 34

EN - 2
Copyright © 2016, Fast ČR, a. s. 08/2016
Dear Customer,
≐Please carefully read this manual before using the dishwasher, it will help you to use and maintain
the dishwasher properly.
≐Keep it to refer to it at a later date.
≐Pass it on to any subsequent owner of the appliance.
This manual contains sections on safety Instructions, Operating Instructions, Installation Instructions and Trou-
bleshooting Tips, etc.
Before Calling for Service
≐To review the section on troubleshooting Tips will help you to solve some common problems by yourself.
≐If you can not solve the problems by yourself, please ask for the help of professional technicians.
NOTE:
≐The manufacturer, following a policy of constant development and updating of the product, may make
modifications without giving prior notice.
≐This user manual shall also be got from the manufacturer or responsible vendor.

EN - 3
Copyright © 2016, Fast ČR, a. s. 08/2016
1. IMPORTANT SAFETY INFORMATION
WARNING!
When using your dishwasher, follow the precautions
listed below:
≐This appliance is intended to be used in household
≐This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision. (For EN60335-1)
≐This appliance is not intended for use by persons
(including children )with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision

EN - 4
Copyright © 2016, Fast ČR, a. s. 08/2016
or instruction concerning use of the appliance by
a person responsible for their safety. (For IEC60335-1)
≐This appliance is for indoor household VTFPOMZ
≐To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
≐Please unplug before cleaning and maintenance
the appliance.
≐Use a soft cloth moisten with mild soap, and then
use a dry cloth to wipe it again.
EARTHING INSTRUCTIONS
≐This appliance must be earthed. In the event of
amalfunctionorbreakdown,groundingwillreduce
the risk of an electric shock by providing a path of
least resistance of electric current. This appliance
is equipped with a cord having an equipment-
earthing conductor and a earthing plug.
≐The plug must be plugged into an appropriate
outlet that is installed and earthed in accordance
with all local codes and ordinances.
≐Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
≐Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded.

EN - 5
Copyright © 2016, Fast ČR, a. s. 08/2016
≐Donotmodifytheplugprovidedwiththeappliance;
If it does not fit the outlet.
≐Have a proper outlet installed by a qualified
electrician.
≐Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
≐Donotoperateyourdishwasherunlessallenclosure
panels are properly in place.
≐Open the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
≐Do not place any heavy objects on or stand on
the door when it is open. The appliance could tip
forward.
≐When loading items to be washed:
1) Locate sharp items so that they are not likely
to damage the door seal;
2) Warning: Knives and other utensils with sharp
points must be loaded in the basket with their
points down or placed in a horizontal position.
≐Check that the detergent comparment is empty
after completion of the wash cycle.
≐Do not wash plastic items unless they are marked
dishwasher safe or the equivalent.
≐For plastic items not so marked, check the
manufacturer’s recommendations.

EN - 6
Copyright © 2016, Fast ČR, a. s. 08/2016
≐Use only detergent and rinse additives designed
for an automatic dishwasher.
≐Neverusesoap,laundrydetergent,orhandwashing
detergent in your dishwasher.
≐Children should be supervised to ensure that they
do not play with the appliance.
≐The door should not be left open, since this could
increase the risk of tripping.
Ifthesupplycordisdamaged,itmustbereplacedby
the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
≐During installation, the power supply must not be
excessively or dangerously bent or flattened.
≐Do not tamper with controls.
≐The appliance is to be connected to the water
mains using new hose sets and that old hose-sets
should not be reused.
≐The maximum number of place settings to be
washed is 6.
≐The maximum permissible inlet water pressure is
1MPa.
≐The minimum permissible inlet water pressure is
0.04MPa.

EN - 7
Copyright © 2016, Fast ČR, a. s. 08/2016
Disposal
≐Disposeofthedishwasherpackagingmaterial
correctly.
≐All packaging materials can be recycled.
≐Plastic parts are marked with the standard
international abbreviations:
PE — for polyethylene, e.g. sheet wrapping
material
PS — for polystyrene, e.g. padding material
POM — polyoxymethylene, e.g. plastic clips
PP — polypropylene, e.g. Salt filler
ABS — Acrylonitrile Butadiene Styrene,
e.g. Control Panel.
WARNING!
≐Packaging material could be dangerous for children!
≐For disposing of package and the appliance please
go to a recycling centre.Therefore cut off the power
supply cable and make the door closing device
unusable.
≐Cardboard packaging is manufactured from
recycled paper and should be disposed in the
waste paper collection for recycling.
≐Byensuringthisproductisdisposedofcorrectly,you
will help prevent potential negative consequences

EN - 8
Copyright © 2016, Fast ČR, a. s. 08/2016
for the environment and human health, which
could otherwise be caused by inappropriate waste
handling of this product.
≐For more detailed information about recycling of
this product, please contact your local city office
and your household waste disposal service.
≐DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste
separately for special treatment is necessary.

EN - 9
Copyright © 2016, Fast ČR, a. s. 08/2016
2. QUICK OPERATION GUIDE
For detailed operating method read the corresponding content on the instruction manual.
Switch on the appliance Press the Power switch button to switch on the appliance, Open the door.
Fill the detergent
dispenser
Compartment A:
With each wash cycle.
Compartment B:
For programmes with pre-wash only.
(Follow the user instructions!) &'
Check the rinse aid level Mechanical Indicator C.
Electric indicator on control panel (if provided).
Check the regeneration
salt level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill
the salt into the softener by the number of cycles
the dishwasher has run.
Load the baskets Scrape off any large amount of leftover food. Soften remnants of burnt food
in pans, then load the baskets. Refer to the dishwasher loading instructions.
Select a programme
Close the door, Press the programme button until the selected
programme lights up.
(See the section entitled “Operation instruction”)
Running the dishwasher Turn on the water tap and press the Start/Pause button. The machine will start
working after about 10 seconds.

EN - 10
Copyright © 2016, Fast ČR, a. s. 08/2016
• Changing the
programme
• 1. A running cycle can only be modified if it has been running for
a short time. Otherwise the detergent may have already been
released and the water already drained. If this is the case, the
detergent dispenser must be refilled.
2. Press the Start/Pause button ,then press the program button more
than 3 seconds to cancel the running programme.
3. Select a new programme.
4. Restart the dishwasher.
• Add forgotten dishes
in the dishwasher.
• 1. Press the start/pause button to stop the
machine.
2. Open the door.
3. Add the forgotten dishes.
4. Close the door, then press the start/pause
button, the dishwasher will start running
again after 10 seconds.
WARNING!
Open the door care-
fully Hot steam may
escape when the door
is opened!
• If the appliance is
switched off during
a wash cycle.
• If the appliance is switched off during a wash cycle, when switched on
again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state).
Switch off the appliance
When the working cycle has finished, the buzzer oh the dishwasher will sound
8 times, then stop.
Turn off the appliance using the Power button.
Since the appliance is standing by, it will power off automaticly after
30 minutes without any operation.
Turn off the water tap,
unload the baskets
Warning: wait a few minutes (about 15 minutes) before unloading the
dishwasher to avoid handling the dishes and utensils while they are still hot
and more susceptible to break.
They will also dry better. Unload the appliance, starting from the lower basket.

EN - 11
Copyright © 2016, Fast ČR, a. s. 08/2016
3. OPERATION INSTRUCTION
IMPORTANT
To get the best performance from your dishwasher, read all operating instructions before using it for the first time.
Control Panel
      

. % *
1
/
1Power Button: To turn on/off the power supply.
2Washing Program Selector: Press the button to select wash cycles.
3Program indicator light.
4Delay Button: To press the button to delay.
5Start/Pause Button: Press this button to start or pause the dishwasher.
6Display screen: to show the reminding time and the state(running state, delay time etc)
7Rinse Aid Warning Light: To be on when the rinse aid dispenser needs to be refilled.
8Salt Warning Light: To be on when the softener needs to be refilled.
Dishwasher Features
2(
1

.
/
%
*

Front view Back View
1Salt Container
2Detergent Dispenser
3Cutlery Basket
4Filter assembly
5Rinse Aid Dispenser
6Spray Arms
7Cup Shelf
8Basket
9Inlet pipe connector
0Drain pipe connector

EN - 12
Copyright © 2016, Fast ČR, a. s. 08/2016
4. PRIOR USING FOR THE FIRST TIME
NOTE: If your model have no water softener, you may skip this section.
A. Loading the Salt Into the Softener
Always use salt intended for use with dishwasher.
The salt container is located beneath the basket and should be filled as follows:
Attention!
≐Only use salt specifically designed for use in dishwashers! All other types of salt not specifically designed for
use in a dishwasher, especially table salt, will damage the water softener. in case of damages caused by the
use of unsuitable salt the manufacturer does not give any warranty nor is liable for any caused damages.
≐Only fill with salt just before starting one of the complete washing programmes. This will prevent any
grains of salt or salty water, which may have been split, remaining of the bottom of the machine for any
period of time, which may cause corrosion.
Open
ARemove the basket and then unscrew and remove the cap from the salt container. 1
BBefore first wash, add 1 lt. of water in the salt container of your machine.
CPlace the end of the funnel (supplied) into the hole and introduce about 1 kg of salt.
It is normal for a small amount of water to come out of the salt container. 2
DAfter filling the container, screw the cap tightly back clockwise.
EUsually, the salt warning light will be cease to be illuminated within 2-6 days after the salt container has
been filled with salt.
FImmediately after filling the salt into the salt container, a washing programme should be started (Suggest
choose rapid programme). Otherwise filter system, pump or other important parts of the machine may
be damaged by salty water. It is out of warranty.
NOTE:
1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how fully the salt dissolves, the salt warning light may still be on even though the salt
container is filled.
If there is no salt warning light in the control panel (For some Models), you can judge when to load the salt
into the softener by the cycles that the dishwasher had run.
2. If there are spills of the salt, a soak or a rapid program should be run to remove the excess salt.

EN - 13
Copyright © 2016, Fast ČR, a. s. 08/2016
Adjusting Salt Consumption
Step 1: Enter the status of salt adjustment
Close the door, within 60 seconds after power on, press Start/Pause button and hold for 5 seconds, the machine
will enter setting mode.
      
Step 2: select a certain level of salt consumption
Press the Start/pause button to select the proper set according to your local environment, the sets will change
in the following sequence: H1->H2->H3->H4->H5->H6;
Step 3: Exit the status of salt adjustment
Without any operation in five seconds, the machine will exit from set mode, the machine is into standby status
There are 6 levels of salt consumption in all. It is recommended to select the level according to below table:
Water Hardness level Setting on the water softener Digital display stalls
°dH1) mmol/l 2)
0-5 0-0.9 1 H1
6-11 1.0-2.0 2 H2
12-17 2.1-3.0 3 H3
18-22 3.1-4.0 4* H4
23-34 4.1-6.1 5 H5
35-45 6.2-8.0 6 H6
NOTE:
1) German degree of measurement for the water hardness
2) millimol, internationel unit for water hardness
*) factory setting
Contact your local water board for information on the hardness of your water supply.
B. Fill the Rinse Aid Dispenser
Rinse Aid Dispenser
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes. That
can leave spots and streaks. It also improves drying by allowing water to sheet off the dishes. Your dishwasher
is designed to use liquid rinse aids. The rinse aid dispenser is located inside the door next to the detergent
dispenser. To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator
turns completely black.
The volume of the rinse aid container is about 110ml.

EN - 14
Copyright © 2016, Fast ČR, a. s. 08/2016
Function of Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free
drying.
Function of Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free
drying.
ATTENTION!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances (e.g.
Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
When to Refill the Rinse Aid Dispenser
If there is no rinse-aid warning light in the control panel, you can judge the amount of rinse-aid by the color of
the optical level indicator“C” located next to the cap. When the rinse-aid container is full, the whole indicator
will be dark. As the rinse-aid diminishes, the size of the dark dot decreases. You should never let the rinse aid
get below 1 / 4 full.
C(Rinse-Aid indicator)
As the rinse aid diminishes, the size of the black dot on the
rinse aid level indicator changes, as illustrated below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
1To open the dispenser, turn the cap to the “open” (left) arrow and lift it out.
2Pour the rinse aid into the dispenser, being careful not to overfill.
3Replace the cap by inserting it aligned with“open”arrow and turning it to the closed (right) arrow.
NOTE:
Clean up any rinse aid split during filling with an absorbent cloth to avoid excessive foaming during the next
wash. Don’t forget to replace the cap before you close dishwasher door.

EN - 15
Copyright © 2016, Fast ČR, a. s. 08/2016
Adjusting Rinse Aid Dispenser
Adjust lever
(Rinse)
The rinse aid dispenser has six or four settings. Always start with the
dispenser set on “4”. If spots and poor drying are problems, increase
the amount of rinse aid dispensed by removing the dispenser lid and
rotating the dial to“5”. If the dishes still are not drying properly or are
spotted, adjust the dial to the next higher number until your dishes
are spot-free. The recommended setting is“4”. (Factory value is“4”.)
NOTE:
Increase the dose if there are drops of water or lime spots on the dish-
es after washing. Reduce it if there are sticky whitish stains on your
dishes or a bluish film on glassware or knife blades.
C. Function of Detergent
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the
dishwasher. Most of commercial quality detergents are suitable for this purpose.
Concentrated Detergent
Normally new pulverised detergent is without phosphate. The water softener function of phosphate is not
given. In this case we recommend to fill salt in the salt container even when the hardness of water is only 6 dH.
If detergents without phosphate were used in case of hard water often white spots appear at dishes and glass-
es. In this case please add more detergent to reach better results. Detergents without chlorine do only bleach
a little. Strong and coloured spots will not removed completely. In this case please choose a programme with
higher Temperature.
Based on their chemical composition, dishwasher can be split in two basic types:
≐conventional, alkaline detergents with caustic components
≐low alkaline concentrated detergents with natural enzymes
Detergent Tablets
Detergent tablets of different brands dissolve at different speeds. For this reason some detergent tablets can-
not dissolve and develop their full cleaning power during short programmes. Therefore please use long pro-
grammes when using detergent tablets, to ensure the complete removal of detergent residuals.
NOTE:
Detergent tablets are only for the models with 3 in 1 function or 3 in 1 program.
Detergent Dispenser
The dispenser must be refilled before the start of each wash cycle following the instructions provided in the
Wash Cycle Table . Your dishwasher uses less detergent and rinse aid then conventional dishwasher. Generally,
only one tablespoon of detergent is needed for a normal wash load. Also, more heavily soiled items need more
detergent. Always add the detergent just before starting the dishwasher, otherwise it could get damp and will
not dissolve properly.

EN - 16
Copyright © 2016, Fast ČR, a. s. 08/2016
Amount of Detergent to Use
Push latch to open
&'
AFor main wash detergent
AFor pre-wash detergent
Fill in Detergent
Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as illustrated on the
right:
AThe place of main wash cycle detergent placed.
BThe place of pre-wash cycle detergent placed.
Proper Use of Detergent
Use only detergent specifically made for use in dishwashers. Keep your detergent fresh and dry.
Don’t put powder detergent into the dispenser until you’re ready to wash dishes.
Please observe the manufacturers dosing and storage Recommendations as stated on the detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional detergent dose in the pre-wash detergent chamber. This
detergent will take effect during the pre-wash phase.
NOTE:
≐You find information about the amount of detergent for the single programme on the last page.
≐Please aware, that according to the level soiling and the specific hardness of water differences are possible.
≐Please observe the manufacturer’s recommendations on the detergent packaging.
≐If the lid is closed: press release button. The lid springs open.
≐Always add the detergent just before starting each wash cycle.
≐Only use branded detergent aid for dishwasher.

EN - 17
Copyright © 2016, Fast ČR, a. s. 08/2016
WARNING!
Dishwasher detergent is corrosive!
Take care to keep it out of reach of children.
5. LOADING THE DISHWASHER BASKETS
Recommendation
≐Consider buying utensils which are identified as dishwasher-proof.
≐Use a mild detergent that is described as ‘kind of dishes’. If necessary, seek further information from
detergent manufacturers.
≐For particular items, select a programme with as low a temperature.
≐To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the programme
has ended.
For washing in the dishwasher the following cutlery/dishes
Are not suitable
≐Cutlery with wooden, horn china or mother-of-pearl handles
≐Plastic items that are not heat resistant
≐Older cutlery with glued parts that is not temperature resistant
≐Bonded cutlery items or dishes
≐Pewter or copper items
≐crystal glass
≐Steel items subject to rusting
≐Wooden platters
≐Items made from synthetic fibres
Are of limited suitability
≐Some types of glasses can become dull after a large number of washes
≐Silver and aluminium parts have a tendency to discolour during washing
≐Glazed patterns may fade if machine washed frequently
Attention before or after loading the Dishwasher Baskets
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlery baskets may vary from your model.)
Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans It is not necessary to rinse
the dishes under running water.
Place objects in the dishwasher in following way:
1. Items such as cups, glasses, pots/pans, etc. are face down.
2. Curved items, or those with recesses, should be loaded at aslant so that water can run off.
3. All utensils are stacked securely and can not tip over.
4. All utensils are placed in the way that the spray arms can rotated freely during washing.
NOTE: Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
≐Load hollow items such as cups, glasses, pans etc. With the opening downwards so that water cannot
collect in the container or a deep base.
≐Dishes and items of cutlery must not lie inside one another, or cover each other.

EN - 18
Copyright © 2016, Fast ČR, a. s. 08/2016
≐To avoid damage to glasses, they must not touch.
≐Load large items which are most difficult to clean into the basket.
≐Long bladed knives stored in an upright position are a potential hazard!
≐Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in the basket.
≐Please do not overload your dishwasher. This is important for good results and for reasonable energy
consume.
Loading the Basket
Position the dishes and cookware so that they will not get moved by the spray of water.
%
/


1
2

*
(
.

Cups
Glasses
Dish
Dinner plates
Dessert dishes
Oval platter
Soup plates
Cutlery basket
Medium serving bowl
Saucers
Serving spoons
