Philip Payne 300SC User manual

300SC
Backlit Exit Sign Surface Mount
Class
1IP 54
FEATURES
EXIT SIGN DIMENSIONS
Model Features Supply voltage Maximum luminaires on a
Type B, 10A circuit breaker Part No.
Maintained MM3 220-240V AC 50/60Hz 90 Luminaires 300SCLM
Self Test MM3 Auto Test 220-240V AC 50/60Hz 90 Luminaires 300SCYL
DALI MM3 DALI 220-240V AC 50/60Hz 90 Luminaires 300SCDL
SPECTO-XT SPECTO XT 220-240V AC 50/60Hz 90 Luminaires 300SCXT
Central Supply 220-240V AC 50/60Hz
176-264V DC 30 Luminaires 300SCLA
Central Supply DALI DALI 220-240V AC 50/60Hz
176-280V DC 30 Luminaires 300SCDADA
IMPORTANT-SAFETY Before carrying out any servicing on this luminaire, ensure that the mains supply is fully isolated.
Disconnect luminaire before insulation testing of the installation.
WARNING Do not stare at operating lamp. It may be harmful to the eyes.
Important-Safety
Before carrying out any servicing on this luminaire, ensure that the mains supply is fully isolated. Disconnect luminaire before
insulation testing of the installation.

SUPPLY CONNECTIONS
P2 | 300SC
2.
CENTRAL SUPPLY
AND SPECTO XT
CENTRAL SUPPLY
DALI
SELF TEST DALI
SUPPLY CONNECTIONS
P2 | 250CM
GENERAL INSTALLATION METHOD
Wichtiger
Sicherheitshinweis
Stellen Sie vor Durchführen von
Wartungsarbeiten an diesem
Beleuchtungskörper sicher, dass die
Netzstromversorgung vollständig isoliert
ist.
Trennen Sie den Beleuchtungskörper von
der Stromversorgung, bevor Sie
die Isolierung der Anlage testen.
Important-Sécurité
Avant d'effectuer des réparations
sur ce luminaire, vérifiez que
l'alimentation secteur est coupée.
Débranchez le luminaire avant
d'effectuer un essai d'isolement
de l'installation.
Connections - Connexions - Conexiones
USLSLN
DALIDALI
LN USLLNLN
DALIDALI
DALI MM3
Basic
AutoTest
MM3
MM3
230V
230V DALI
Philip Payne Ltd
A SUBSIDIARY OF F.W. THORPE PLC
Thornhill Road, Solihull, B91 2HB, England.
Tel: [phone]
Fax: [phone]
e-mail: [e-mail]
Website: http://www.philippayne.co.uk
Philip Payne Ltd registered in England No. 1361523
ISO9001
FM55077 21LFT024_3
Operation and Maintenance
The 250CM uses plastic components in
its construction and when installed in
environments containing hemicals,
degradation may occur.
Please contact our Technical
Department for advice.
Modifications
Philip Payne products should not be
modified.
Any modification may render the product
unsafe and will invalidate any
Safety/Approval marks.
Philip Payne will not accept any
responsibility for any modified products
or for any damage caused as a result of
their modification.
Important-Safety
Before carrying out any servicing
on this luminaire, ensure that the mains
supply is fully isolated.
Disconnect luminaire before
insulation testing of the installation.
Importante - Sicurezza
Prima di eseguire la manutenzione,
assicurarsi chela rete elettrica sia
completamente isolata.
Scollegare il prodotto prima
di eseguire il test d'isolamento
dell'installazione.
Fonctionnement et Maintenance
Des composants en plastique ont été
intégrés dans la construction du
250CM, et une certaine détérioration
peut survenir lorsqu'il est installé dans
des environnements contenant des
produits chimiques. Veuillez contacter
notre Département Technique pour
obtenir de plus amples informations.
Modifications
Les produits Philip Payne ne doivent
pas être modifiés.
Toute modification peut compromettre
la sécurité du produit et annuler les
marques de sécurité / homologation.
Philip Payne refusera toute
responsabilité pour des produits
modifies ou pour tout dommage
entraîné par une modification.
Betrieb und Wartung
250CM-Produkte enthalten Kunststoffteile;
bei einer Installation in Umgebungen, die
Chemikalien enthalten, ist ein
Qualitätsverlust
nicht auszuschließen. Unsere Technische
Abteilung berät Sie gerne.
Änderungen
Philip Payne-Produkte sollten nicht
geändert werden.
Jegliche Änderungen können die
Produktsicherheit beeinträchtigen und
machen Sicherheits-
/Genehmigungskennzeichnungen
ungültig.
Philip Payne übernimmt keine
Verantwortung für modifizierte Produkte
bzw. Für Schäden, die durch
Produktänderungen verursacht werden.
Funzionamento e manutenzione
Il 250CM è stato costruito con
componenti di plastica e, se installato
in ambienti che contengono sostanze
chimiche, si può notare un
degradamento. Per ulteriori consigli si
prega di contattare il nostro reparto
tecnico.
Modifiche
I prodotti Philip Payne non devono
essere modificati, dato che qualsiasi
modifica potrebbe rendere il prodotto
insicuro e invalidare ogni segno di
sicurezza/approvazione.
Philip Payne non accetta nessuna
responsabilità per prodotti modificati e
per danni causati quale risultato delle
modifiche apportate agli stessi.
SpectoXT MM3
N N NNUSL LLL USL
DALI DALI
DALIDALI
SL
SURFACE CEILING
MOUNTED
x2
3
Edgelit Exit Sign IP20 Class 1 Surface Ceiling 250CM
74
107
155 or 100mm
LEGEND
170
202
8250
258
37
36
36
6 OFF Ø5 FIXING HOLES
2 OFF Ø14 KNOCKOUTSØ20 KNOCKOUT
CABLE ENTRY
1
x1
2
x2
4
Monthly and Annual tests should be carried out in accordance
with: BS EN 50172:2004, 7.2.
Testing can be carried out by using a sub circuit isolator
or by switching off the lighting circuit at the circuit breaker.
(Not for Autotest or Dali versions.)
Battery Pack shall be replaced if the specified 3 hour
duration is not met.
For replacement LED strip contact Philip Payne Ltd.
MM3
AutoTest
DALI
DALI 250CMDL
250CMYL
250CMLM
250CMDA
250CMLA
250CMLE
MM3
230V
230V
MM3
MM3
250CMXT
MM3
SpectoXT
SpectoXT Antenna
CABLE ENTRY
1.
SURFACE CEILING
MOUNTED
x2
3
Edgelit Exit Sign IP20 Class 1 Surface Ceiling 250CM
74
107
155 or 100mm
LEGEND
170
202
8250
258
37
36
36
6 OFF Ø5 FIXING HOLES
2 OFF Ø14 KNOCKOUTSØ20 KNOCKOUT
CABLE ENTRY
1
x1
2
x2
4
Monthly and Annual tests should be carried out in accordance
with: BS EN 50172:2004, 7.2.
Testing can be carried out by using a sub circuit isolator
or by switching off the lighting circuit at the circuit breaker.
(Not for Autotest or Dali versions.)
Battery Pack shall be replaced if the specified 3 hour
duration is not met.
For replacement LED strip contact Philip Payne Ltd.
MM3
AutoTest
DALI
DALI 250CMDL
250CMYL
250CMLM
250CMDA
250CMLA
250CMLE
MM3
230V
230V
MM3
MM3
250CMXT
MM3
SpectoXT
SpectoXT Antenna
2.
SURFACE CEILING
MOUNTED
x2
3
Edgelit Exit Sign IP20 Class 1 Surface Ceiling 250CM
74
107
155 or 100mm
LEGEND
170
202
8250
258
37
36
36
6 OFF Ø5 FIXING HOLES
2 OFF Ø14 KNOCKOUTSØ20 KNOCKOUT
CABLE ENTRY
1
x1
2
x2
4
Monthly and Annual tests should be carried out in accordance
with: BS EN 50172:2004, 7.2.
Testing can be carried out by using a sub circuit isolator
or by switching off the lighting circuit at the circuit breaker.
(Not for Autotest or Dali versions.)
Battery Pack shall be replaced if the specified 3 hour
duration is not met.
For replacement LED strip contact Philip Payne Ltd.
MM3
AutoTest
DALI
DALI 250CMDL
250CMYL
250CMLM
250CMDA
250CMLA
250CMLE
MM3
230V
230V
MM3
MM3
250CMXT
MM3
SpectoXT
SpectoXT Antenna
3.
SURFACE CEILING
MOUNTED
x2
3
Edgelit Exit Sign IP20 Class 1 Surface Ceiling 250CM
74
107
155 or 100mm
LEGEND
170
202
8250
258
37
36
36
6 OFF Ø5 FIXING HOLES
2 OFF Ø14 KNOCKOUTSØ20 KNOCKOUT
CABLE ENTRY
1
x1
2
x2
4
Monthly and Annual tests should be carried out in accordance
with: BS EN 50172:2004, 7.2.
Testing can be carried out by using a sub circuit isolator
or by switching off the lighting circuit at the circuit breaker.
(Not for Autotest or Dali versions.)
Battery Pack shall be replaced if the specified 3 hour
duration is not met.
For replacement LED strip contact Philip Payne Ltd.
MM3
AutoTest
DALI
DALI 250CMDL
250CMYL
250CMLM
250CMDA
250CMLA
250CMLE
MM3
230V
230V
MM3
MM3
250CMXT
MM3
SpectoXT
SpectoXT Antenna
4.
CENTRAL SUPPLY
AND SPECTO XT
CENTRAL SUPPLY
DALI
SELF TEST DALI
BASIC INSULATION IS MAINTAINED BETWEEN THE LV SUPPLY AND CONTROL CONDUCTORS ON THIS LUMINAIRE.
1.
GENERAL INSTALLATION METHOD
BASIC INSULATION IS MAINTAINED BETWEEN THE LV SUPPLY AND CONTROL CONDUCTORS ON THIS LUMINAIRE.
REMOVE GEAR-TRAY BEFORE
DRILLING/ FIXING TO WALL
MAINS CABLE ENTRY
VIA IP54 GLAND
SEALING KIT SUPPLIED
WITH LUMINAIRE:-
4 X RUBBER WAHSERS
4 X METAL WASHERS
FIXINGS NOT
SUPPLIED. PLEASE
SECURE LUMIANRE
USING APPROPIATE
FIXINGS
DRILL FIXING HOLES IN
BODY. MAX Ø6.0mm.

P3 | 300SC
GENERAL INSTALLATION
Mains Connections
Mains Connections
USL (UN-SW ITCHED LIVE)
SEALING KIT SUPPLIED
WITH LUMINAIRE:-
4 X RUBBER WAHSERS
4 X METAL WASHERS
FIXINGS NOT
SUPPLIED. PLEASE
SECURE LUMIANRE
USING APPROPIATE
FIXINGS
MAINS CABLE
ENTRY VIA
IP54 GLAND
Mains Connections
Mains Connections
USL (UN-SW ITCHED LIVE)
DRILL FIXING HOLES IN
BODY. MAX Ø6.0mm.
Cut clearance hole in ceiling to
accommodate IP54 cable gland.
(Suggested size = 40mm
diameter).
COVER/ LEGEND REMOVAL
A. USE KEY PROVIDED
B. SECURE LEGEND PANEL WITH HAND
C. LOCATE TOOL UNDER EDGE OF FRAME
D GENTLY PULL BACK ON THE TOOL TO REMOVE FRAME, LEAVING LEGEND FREE.
E. LIFT LEGEND TO ACCESS GEAR TRAY.

P4 | 300SC
LED STATUS INDICATION
Operation Led Status
Normal mode Green LED- ON
Commissioning Green LED- ON
Function test Green LED- Fast Flash
Duration test Green LED- Slow flash
Lamp fault/open circuit/short circuit Red LED - ON
Battery fault Red LED - Slow flash
Charge fault/Circuit fault Red LED - Fast flash
Emergency mode LED OFF
Identification Red/Green LED - Slow flash
IMPORTANT
To prevent lamp damage and false triggering of fault status please note the following :-
-Ensure LED’s are connected correctly to the luminaire prior to applying power.
-Do not interrupt unswitched supply during self-commissioning period.
-Please allow 51 hours for charge, discharge, charge cycle.
FAULT RECTIFICATION SEQUENCE
1.Fault Identification Slow Red Flash =
Battery Fault
Permanent Red =
Lamp Fault Charge Fault
2. Take Remedial Action Check Lamp/ Replace Lamp Check Battery/ Replace Battery Check Module/ Replace Module
3. Reset Unit/ Check Status Switch Luminaire unswitched mains o / on
For Specto-XT use the Specto-XT Programmer to check status of luminaire.
4. Automatic Reset
Philip Payne AutoTest automatically resets the module to confirm rectification of fault. The device then reverts to
standby mode if the fault has been cleared or returns to fault indication if fault persists.
For Specto-XT use the Specto-XT Programmer to initiate function/duration test. The luminaire will pend the test until
the battery is suciently charged. The test status can be retrieved using the Specto-XT Programmer (please leave at
least 60 seconds between test initiation and reading status).

P5 | AUTOTEST RECORD
Fitting Reference: Installation Date: Location:
MONTH TEST EXAMPLE 1ST YEAR 2ND YEAR 3RD YEAR 4TH YEAR 5TH YEAR 6TH YEAR 7TH YEAR 8TH YEAR
1. Functional PASSED
2. Functional PASSED 3. Functional PASSED 4. Functional PASSED 5. Functional PASSED 6. Functional PASSED 7. Functional FAILED- REPLACED
LAMP HEAD
8. Functional PASSED 9. Functional PASSED 10. Functional FAILED- REPLACED
BATTERY
11. Functional PASSED 12. 3-Hour Duration PASSED
Each month, or more frequently if a fault is identified, we recommend the installation is checked for status of L.E.D.’s. Corrective action if necessary should be taken and recorded on the above form. Follow good practice as laid down in relevant legislation such as BS 5266.
TO RESET AFTER A FAULT - SWITCH LUMINAIRE UNSWITCHED
MAINS OFF / ON.
SLOW RED LED FLASHING = BATTERY FAULT
PERMANENT RED LED = LAMP FAULT
EMERGENCY LIGHTING IS THERE TO SAVE LIVES

INFORMATION
P6 | 300SC
NOTICE TO CONTRACTOR PLEASE PASS THIS LEAFLET TO THE END-USER.
CLEANING INSTRUCTIONS
H2O
+
Mild Soap
Savon Doux
Milde Seife
Sapone Delicato
Mild Soap
Savon doux
Milde Seife
Il sapone dolce
Philip Payne Ltd, Thornhill House, Thornhill Road, Solihull, B91 2HB
[phone] | [e-mail] | www.philippayne.co.uk
21LFT087_3
Operation and Maintenance
Suitable for indoor use.
Ambient temperature 25°C.
Continual operation at mains voltages in excess of the rated
voltage will reduce LED and expected gear life.
This luminaire uses plastic components in its construction and
when installed in environments containing chemicals, degradation
may occur.
Operation outside intended / stated parameters may cause a
hazard, and in an extreme case, for example water ingress to
electronic circuits, may cause a fire.
Please contact our Technical Department for advice.
Modifications
Philip Payne products should not be modified.
Any modification may render the product unsafe and will invalidate
any Safety/Approval marks.
Philip Payne will not accept any responsibility for any modified
products or for any damage caused as a result of their modification.
Monthly and Annual Tests
Monthly and Annual tests should be carried out in accordance
with BS EN 50172:2004, 7.2.
Testing can be carried out by using a sub circuit isolator or by
switching o the lighting circuit at the circuit breaker (not for
AutoTest or DALI versions).
Battery pack shall be replaced if the specified 3 hour duration is
not met.
For replacement battery pack contact Philip Payne Ltd.
The light source contained in this luminaire shall only be replaced
by the manufacturer or his service agent or a similar qualified
person.
KM587259 FM-55077
BS EN ISO 60598-2-22
