QL INDUCTION
Philips QL Induction
Lighting Systems
Ideal for decorative street
lighting, bridges and tunnels,
hazardous areas, freezers and
hard-to-reach applications
Ultra dependable white light
Philips QL Induction Lighting System offer electrodeless
technology with an a azing 100,000 hours rated average life.1
Ultra-long life
• 100,000 hours rated average life1and virtually maintenance free
Crisp white light with no color shift
• 80 CRI and choice of color temperature
Operates in hot and cold environments—amalgam control
• High reliability–instant hot and cold (re)start
Low EMI—complies with FCC non-consumer limits
High lumen output
• 165W QL features 12,000 initial lumens
1) See back page for footnote

© 2008 Philips Lighting Company. All rights reserved.
Printed in USA 02/08
P-5456-J
www. philips.com
Philips Lighting Company
200 Franklin Square Drive
P.O. Box 6800
Somerset, NJ 08875-6800
1-800-555-0050
A Division of Philips Electronics North America Corporation
Philips Lighting
281 Hillmount Road
Markham, Ontario
Canada L6C 2S3
1-800-555-0050
A Division of Philips Electronics Ltd.
Philips QL Induction Lighting Systems: 55, 85 and 165 Watt Systems
1) Rated average life is the life obtained, on the average, fro large representative groups of la ps in laboratory tests under controlled conditions at 10 or ore operating hours per start.
It is based on survival of at least 50% of the la ps and allows for individual la ps or groups of la ps to vary considerably fro the average.
2) Approxi ate lu en values listed are for vertical operation of the la p.
3) Approxi ate lu en output at 60% of la p rated average life.
Note: QL Syste requires all three co ponents to operate (order 3 product nu bers).
Power Factor > .9,THD < 10%
QL System Listings: UL, CSA, FCC Class A
Above specifications subject to change without notice.
Ordering, Electrical and Technical Data
Rated Approx. Approx
Product Ordering Pack. MOL Average Initial Mean CCT
Number Code atts Qty. Description (In.) Life (Hrs.)1Lumens2Lumens3CRI (K)
13542-6 QL 55W/GEN100-120V 55 6 Generator, 120V 6 100,000 ————
13543-4 QL 55W/GEN200-277V 55 6 Generator, 277V 6 100,000 ————
13544-2 QL 55W/PC 55 6 Power Coupler 61⁄3100,000 ————
13545-9 QL 55W/830 55 6 Lamp 3 51⁄2100,000 3500 2800 80 3000
13546-7 QL 55W/840 55 6 Lamp 4 51⁄2100,000 3500 2800 80 4000
20095-6 QL 55W/850 55 6 Lamp 5 51⁄2100,000 3500 2800 80 5000
13547-5 QL 85W/GEN100-120V 85 6 Generator, 120V 6 100,000 ————
13548-3 QL 85W/GEN200-277V 85 6 Generator, 277V 6 100,000 ————
13549-1 QL 85W/PC 85 6 Power Coupler 71⁄2100,000 ————
13550-9 QL 85W/830 85 6 Lamp 3 71⁄8100,000 6000 4800 80 3000
13551-7 QL 85W/840 85 6 Lamp 4 71⁄8100,000 6000 4800 80 4000
20096-4 QL 85W/850 85 6 Lamp 5 71⁄8100,000 6000 4800 80 5000
14991-4 QL 165W/GEN100-120V 165 6 Generator, 120V 71⁄2100,000 ————
14990-6 QL 165W/GEN200-277V 165 6 Generator, 277V 71⁄2100,000 ————
36916-5 QL 165W/PC 165 6 Power Coupler 81⁄3100,000 ————
36917-3 QL 165W/830 165 6 Lamp 3 81⁄8100,000 12,000 9600 80 3000
36918-1 QL 165W/840 165 6 Lamp 4 81⁄8100,000 12,000 9600 80 4000
20097-2 QL 165W/850 165 6 Lamp 5 81⁄8100,000 12,000 9600 80 5000
190/7.47''
210/8.25''
128/5.01
L=154/6.06
Generator Width
76/2.97
41.5/1.63"
41.3/1.62"
32.8/1.29"
75.5/2.97"
128/5.01
L=154/6.06
Generator Width
76/2.97
41.5/1.63"
165 System 55 System 85 System
Note: The lamp system is UL, FCC and CSA approved. A booklet, Philips induction lamp systems—Information for Original
Equipment Manufacturers, is available on request. Lu inaire design and te perature para eters will be found in this booklet.
