Philips SCD560 User manual

SCD560
EN User manual 3
BG Ръководство за потребителя 23
CS Příručka pro uživatele 46
ET Kasutusjuhend 66
HR Korisnički priručnik 86
HU Felhasználói kézikönyv 106
KK Қолданушының нұсқасы 127
LT Vartotojo vadovas 149
LV Lietotāja rokasgrāmata 169
PL Instrukcja obsługi 189
RO Manual de utilizare 210
RU Руководство пользователя 231
SK Príručka užívateľa 255
SL Uporabniški priročnik 275
SR Korisnički priručnik 295
UK Посібник користувача 316

2

Table of contents
1 Introduction 3
2 Product overview 3
3 Preparing for use 4
3.1 Baby unit 4
3.2 Parent unit 5
4 Using the baby monitor 6
4.1 Positioning the baby monitor 6
4.2 Linking parent unit and baby unit 7
5 Functions and feedback on
the baby unit 8
5.1 Nightlight 8
5.2 Lullaby function 8
5.3 Paging the parent unit 9
5.4 Battery status light 10
6 Functions and feedback on the
parent unit 10
6.1 Volume 10
6.2 Talk function 11
6.3 Battery status indications 11
6.4 Signal strength indicator 13
6.5 Reset 13
7 Menu of the parent unit 13
7.1 Navigating the menu 13
7.2 Sensitivity 14
7.3 Eco Max mode 15
7.4 Nightlight 16
7.5 Lullaby 16
7.6 Feed timer 16
7.7 Temperature 17
7.8 Clock 18
7.9 Language 18
8 Neck strap 18
9 Cleaning and maintenance 19
10 Storage 19
11 Ordering accessories 19
12 Guarantee and support 19
13 Frequently asked questions 19
1 Introduction
Congratulations on your purchase and welcome
to Philips AVENT! To fully benet from the
support that Philips AVENT offers, register your
product at www.philips.com/welcome.
Philips AVENT is dedicated to producing
caring, reliable products that give parents the
reassurance they need.This Philips AVENT baby
monitor provides round-the-clock support
by ensuring you can always hear your baby
clearly without any distracting noise.The DECT
technology guarantees zero interference and a
crystal clear sound between the baby unit and the
parent unit.
The temperature sensor enables you to monitor
the temperature in your baby’s room, and offers
you personalised settings to help keep your baby’s
room comfortable.
2 Product overview
•I Display
1 Signal strength indicator
2 Eco Max indicator
3 Mute symbol
4 Battery status indicator
5 Navigation arrow
6 Message eld
7 Microphone sensitivity indicator
8 Lullaby symbol
9 Nightlight symbol
10 Timer symbol
11 Temperature symbol
3
ENGLISH

4
3 Preparing for use
IMPORTANT: Read the safety instructions
carefully before you use the baby monitor
and keep them for future reference.
3.1 Baby unit
Use the baby unit from the mains.To guarantee
automatic power backup in case of mains failure,
we advise you to insert non-rechargeable
batteries.
3.1.1 Mains operation
1 Put the adapter in a wall socket and insert the
small appliance plug into the baby unit.
3.1.2 Placing the non-rechargeable batteries
In case of mains failure the baby unit can run on
four 1.5V R6 AA alkaline batteries (not included).
Do not use rechargeable batteries.The baby
unit does not have a charging function and
rechargeable batteries discharge slowly when they
are not in use.
BWarning:
Unplug the baby unit and make sure your hands
and the unit are dry when you insert non-
rechargeable batteries.
DNote:
We advise you to use the baby unit on mains
power, as the baby unit has a limited operating
time when you use it on non-rechargeable alkaline
batteries.The operating time on non-rechargeable
batteries is 24 hours.
•II Parent unit
1 On/off button
2 TALK button
3 - button
4 Microphone
5 ’link’ light
6 Display
7 Sound level lights
8 MENU button
9 + button
10 Battery status light
11 OK button
12 Handgrip/attachment hole for neck strap
13 Compartment for rechargeable batteries
14 Lid of compartment for rechargeable
batteries
15 Socket for small plug of adapter
16 Neck strap
17 Rechargeable batteries
18 Small plug of adapter
19 Adapter
•III Baby unit
1 Nightlight and nightlight on/off button
2 Power-on light
3 FIND button
4 Microphone
5 Next lullaby button
6 Lullaby play/stop button
7 On/off button
8 Volume + button
9 Battery status light
10 Volume - button
11 Temperature sensor
12 Loudspeaker
13 Socket for small plug of adapter
14 Compartment for non-rechargeable
batteries
15 Lid of compartment for non-rechargeable
batteries
16 Small plug of adapter
17 Adapter

4 Then push down the lid until the lock closes
with a click.
3.2 Parent unit
The parent unit runs on two rechargeable
batteries that are supplied with the baby monitor.
3.2.1 Inserting the rechargeable batteries
1 Slide the lid of the compartment for the
rechargeable batteries off the parent unit.
2 Insert the rechargeable batteries.
DNote:
Make sure the + and - poles of the batteries
point in the right direction.
5
1 Push the lock to release the lid of the
compartment for non-rechargeable batteries
and remove the lid.
2 Insert four non-rechargeable batteries.
DNote:
Make sure the + and - poles point in the right
direction.
3 To reattach the lid, rst insert the lugs into the
openings in the rim of the compartment for
non-rechargeable batteries.
ENGLISH

6
4 Using the baby
monitor
4.1 Positioning the baby
monitor
BWarning:
Keep the baby unit out of the reach of the baby.
Never place the baby unit inside or mount it on
the baby’s bed or playpen.
1 Because the cord of the baby unit presents a
potential strangulation hazard, make sure that
the baby unit and its cord are at least
1 metre/3.5 feet away from your baby.
2 To prevent a high-pitched sound from one
or both units, make sure the parent unit is at
least 1 metre/3.5 feet away from the baby
unit.
3 Slide the lid of the compartment for the
rechargeable batteries back onto the parent
unit. Push the lid home until it locks into place
with a click.
3.2.2 Charging the parent unit
Charge the parent unit before you use it for the
rst time or when the parent unit indicates that
the batteries are low.
Important:You have to charge the parent
unit for the full 10 hours to have a cordless
operating time of 18 hours.
1 Put the adapter in a wall socket and insert the
small appliance plug into the parent unit.
•The display goes on and the battery status
indications show that the parent unit is
charging. For battery status indications,
see ‘Battery charge indications’ in chapter
‘Functions and feedback on the parent unit’.
2 Leave the parent unit connected to the mains
until the rechargeable batteries are fully
charged.
DNote:
When you start using the baby monitor, it takes
four charge and discharge cycles before the
rechargeable batteries reach their full capacity.

7
•The ‘link’ light on the parent unit starts
ashing red and the message ‘LINKING’
appears on the display.
•When the parent unit and baby unit are
linked, the ‘link’ light turns solid green.The
signal strength indicator and the message
‘LINKED’ appear on the display.
•If no connection is established within 10
seconds, the message ‘NOT LINKED’ on the
display alternates with ‘LINKING’. If still no
connection is established after 30 seconds,
the parent unit starts to beep and only the
message ‘NOT LINKED’ is shown.
4.2 Linking parent unit and
baby unit
1 Press and hold the on/off button 3on the
baby unit for 2 seconds.
•The nightlight, the battery status light and
the power-on light go on briey.
2 Press and hold the on/off button 3on the
parent unit for 2 seconds.
•The display goes on and briey displays all
indicators and symbols. Then the indicators
and symbols fade out and the battery status
indicator appears.
DNote:
When you switch on the parent unit for
the rst time or after a reset, you have
to select your preferred display language
(see ‘Language’ in chapter ‘Menu of the
parent unit’).
2 sec.
ENGLISH

8
5 Functions and
feedback on the
baby unit
5.1 Nightlight
The nightlight produces a soft glow that comforts
your baby.
1 Press the nightlight on/off button on the baby
unit to switch on the nightlight.
•Qappears on the display of the parent unit.
2 Press the nightlight on/off button again to
switch off the nightlight.
•The nightlight dims gradually before it goes
out completely.
•Q disappears from the display of the parent
unit.
5.2 Lullaby function
1 Press the lullaby play/stop button Kon the
baby unit to play the last selected lullaby.
•The selected lullaby repeats for 15 minutes.
•If no lullaby was selected before, lullaby 1
is played.
What to do if no link is established
•The parent unit may be out of range
of the baby unit. Place the parent unit
closer to the baby unit, but not closer
than 1 metre/3.5 feet.
•The baby unit or the parent unit may
lose connection because it is too
close to another DECT appliance
(e.g. a cordless phone). Switch off this
DECT appliance or place the unit
further away from this appliance.
•The baby unit may be switched off.
Switch on the baby unit.
4.2.1 Operating range
•The operating range is 330 metres/1000
feet outdoors and up to 50 metres/150 feet
indoors.
•The operating range of the baby monitor
varies depending on the surroundings and
factors that cause interference.Wet and moist
materials cause so much interference that
the range loss is up to 100%. For interference
from dry materials, see table below
Dry materials Material
thickness
Loss of
range
Wood, plaster, cardboard,
glass (without metal,
wires or lead)
< 30cm
(12in)
0-10%
Brick, plywood < 30cm
(12in)
5-35%
Reinforced concrete < 30cm
(12in)
30-100%
Metal grilles or bars < 1cm
(0.4in)
90-100%
Metal or aluminium
sheets
< 1cm
(0.4in)
100%

9
5.3 Paging the parent unit
If you have lost the parent unit, you can use the
FIND button on the baby unit to locate the
parent unit.
DNote:
The paging function only works when the parent
unit is switched on.
1 Press the FIND button on the baby unit.
•The message ‘PAGING’ appears on the
display of the parent unit and the parent
unit produces a paging alert tone.
2 To stop the paging alert tone, press the FIND
button on the baby unit again or press any
button on the parent unit.
DNote:
The paging alert tone stops automatically after
2 minutes.
2 Press the next lullaby button to select
another lullaby from the list.
•If no lullaby is playing, the last selected
lullaby starts playing when you press the
next lullaby button .
•When you press the next lullaby button
while a lullaby is playing, the next lullaby
starts playing.
3 To adjust the sound level of the lullaby, press
the volume + or the volume - button on the
baby unit.
DNote:
You can only set the loudspeaker volume on
the baby unit when a lullaby is playing. If you
have set the volume for the lullaby higher on
the baby unit, the sound will also be louder
when you use the talk function on the parent
unit.
4 To stop lullaby playing, press the lullaby play/
stop button Kon the baby unit.
ENGLISH

10
6 Functions and
feedback on the
parent unit
6.1 Volume
The volume can be set if the menu is not active.
There are seven volume levels and a ‘volume off’
setting.
6.1.1 Setting the volume level
1 Press the + button or the - button once.
•The current volume level appears on the
display.
2 Press the + button to increase the volume or
press the - button to decrease the volume.
•The parent unit beeps at every volume step
•At maximum volume, the parent unit gives
two beeps.
•If no button is pressed for more than
2 seconds, the volume level indication
disappears and the volume setting is saved.
6.1.2 Volume off
Below the lowest volume setting, there is a
‘volume off’ setting.
1 Press the + button or the - button once.
•The current volume level appears on the
display.
5.4 Battery status light
1 The battery status light is solid green when
the baby unit runs on battery power and the
batteries contain enough energy.
2 The battery status light ashes red quickly
when the batteries run low while the baby
unit is running on battery power.
•Replace the batteries when they run low.
•If the batteries run out of power while the
baby unit is running on battery power, the
baby unit switches off and the parent unit
loses connection with the baby unit.
DNote:
We advise you to use the baby unit on mains
power, as the baby unit has a limited operating
time when you use it on non-rechargeable alkaline
batteries.The operating time on non-rechargeable
batteries is 24 hours.
