TDA1510AQ
24 W BTL or 2 x 12 W stereo car
radio power amplifier

January 1992 2
Philips Semiconductors Product specification
24 W BTL or 2 x 12 W stereo car radio
power amplifier TDA1510AQ
GENERAL DESCRIPTION
The TDA1510AQ is a class-B integrated output amplifier encapsulated in a 13-lead single in-line (SlL) plastic power
package. Developed primarily for car radio application, the device can also be used to drive low impedance loads (down
to 1,6 Ω). With a supply voltage (VP) of 14,4 V, an output power of 24 W can be delivered into a 4 ΩBridge Tied Load
(BTL), or when used as a stereo amplifier, 2 ×12 W into 2 Ωor 2 ×7 W into 4 Ω.
Features
•Flexibility −stereo as well as mono BTL
•Low offset voltage at the output (important for BTL)
•Load dump protection
•A.C. short-circuit-safe to ground
•Low number, small sized external components
•Internal limiting of bandwidth for high frequencies
•High output power
•Large useable gain variation
•Good ripple rejection
•Thermal protection
•Low stand-by current possibility
•High reliability.
QUICK REFERENCE DATA
PACKAGE OUTLINE
TDA1510AQ: 13-lead SIL-bent-to-DIL; plastic power (SOT 141C); SOT141-6; 1996 Aug 01.
PARAMETER CONDITIONS SYMBOL MIN. TYP. MAX. UNIT
Supply voltage range:
operating VP6,0 14,4 18,0 V
non-operating VP−−28,0 V
non-operating, load
dump protection VP−−45,0 V
Repetitive peak output
current IORM −−4,0 A
Total quiescent current Itot −75 120 mA
Stand-by current Isb −−2mA
Switch-on current Iso 0,15 0,35 0,80 mA
Input impedance pins 1, 2,
12 and 13 |ZI|1−−MΩ
Storage temperature range Tstg −65 −+150 °C
Crystal temperature Tc−−150 °C

January 1992 3
Philips Semiconductors Product specification
24 W BTL or 2 x 12 W stereo car radio
power amplifier TDA1510AQ
Fig.1 Functional diagram; heavy lines indicate signal paths.

January 1992 4
Philips Semiconductors Product specification
24 W BTL or 2 x 12 W stereo car radio
power amplifier TDA1510AQ
RATINGS
Limiting values in accordance with the Absolute Maximum System (IEC 134)
PARAMETER CONDITIONS SYMBOL MIN. MAX. UNIT
Supply voltage:
operating pin 10 VP−18 V
non-operating VP−28 V
non-operating,
load dump protection during 50 ms VP−45 V
Peak output current IOM −6A
Total power dissipation see Fig.2 Ptot
Storage temperature range Tstg −65 +150 °C
Crystal temperature Tc−+150 °C
Fig.2 Power derating curves.

January 1992 5
Philips Semiconductors Product specification
24 W BTL or 2 x 12 W stereo car radio
power amplifier TDA1510AQ
HEATSINK DESIGN EXAMPLE
The derating of the encapsulation requires the following external heatsink (for sine-wave drive):
(Rth j-mb) = 3,5 K/W
24 W BTL (4 Ω) or 2 ×12 W stereo (2 Ω); maximum sine-wave dissipation = 12 W;
Tamb =65°C (maximum):
2×7 W stereo (4 Ω); maximum sine-wave dissipation = 6 W; Tamb =65°C (maximum):
D.C. CHARACTERISTICS
PARAMETER CONDITIONS SYMBOL MIN. TYP. MAX. UNIT
Supply voltage range VP6,0 14,4 18,0 V
Repetitive peak output current IORM −−4,0 A
Total quiescent current Itot −75 120 mA
Stand-by current Isb −−2mA
Switch-on current V11 ≤V10; note 1 Iso 0,15 0,35 0,80 mA
Rth h-a 150 65–
12
---------------------- 3,5 3,5 K/W=–=
Rth h-a 150 65–
12
---------------------- 3,5 10,5 K/W=–=

January 1992 6
Philips Semiconductors Product specification
24 W BTL or 2 x 12 W stereo car radio
power amplifier TDA1510AQ
A.C. CHARACTERISTICS
Tamb =25°C; VP= 14,4 V; f = 1 kHz; unless otherwise specified
PARAMETER CONDITIONS SYMBOL MIN. TYP. MAX. UNIT
Bridge Tied Load application (BTL)
Output power
with bootstrap note 6;
RL= 4 Ω
VP= 13,2 V
dtot = 0,5% Po−15,0 −W
dtot = 10% Po−20,0 −W
VP= 14,4 V
dtot = 0,5% Po15,5 18,0 −W
dtot = 10% Po20,0 24,0 −W
Open loop voltage gain Go−75 −dB
Closed loop voltage gain note 2 Gc39,5 40,0 40,5 dB
Frequency response at −3 dB; note 3 fr−20 to > 20 k −Hz
Input impedance note 4 |Zi|1−−MΩ
Noise output voltage
(r.m.s. value) f = 20 Hz to
20 kHz
RS=0ΩVn (rms) −0,2 −mV
RS= 10 ΩVn (rms) −0,35 0,8 mV
RS= 10 kΩ;
according to
IEC 179 curve A Vn (rms) −0,25 −mV
Supply voltage ripple rejection f = 100 Hz; note 5 SVRR 42 50 −dB
D.C. output offset voltage between
channels |∆V5-9|−250mV
Power bandwidth −1 dB;
dtot = 0,5% B −30 to > 40 k −Hz

January 1992 7
Philips Semiconductors Product specification
24 W BTL or 2 x 12 W stereo car radio
power amplifier TDA1510AQ
Stereo application
Output power; with bootstrap note 6;
RL= 4 Ω
VP= 13,2 V
dtot = 0,5% Po−4,5 −W
dtot = 10% Po−6,0 −W
VP= 14,4 V
dtot = 0,5% Po4,5 5,5 −W
dtot = 10% Po6,0 7,0 −W
RL= 2 Ω
VP= 13,2 V
dtot = 0,5% Po−7,5 −W
dtot = 10% Po−10,0 −W
VP= 14,4 V
dtot = 0,5% Po7,75 9,0 −W
dtot = 10% Po10,0 12,0 −W
Output power; without bootstrap notes 6, 8 and 9
RL=4Ω
VP= 14,4 V
dtot = 10% Po−6−W
Frequency response notes 3 and 6
−3 dB fr−40 to > 20 k −Hz
Supply voltage ripple rejection note 5
f = 1 kHz SVRR −50 −dB
Channel separation RS= 10 kΩ;
f = 1 kHz α40 50 −dB
Closed loop voltage gain note 7 Gc39,5 40,0 40,5 dB
Noise output voltage
(r.m.s. value) f = 20 Hz to 20 kHz;
RS=0ΩVn (rms) −0,15 −mV
RS= 10 kΩVn (rms) −0,25 −mV
RS= 10 kΩ;
according to
IEC179 curve A Vn (rms) −0,2 −mV
PARAMETER CONDITIONS SYMBOL MIN. TYP. MAX. UNIT

January 1992 8
Philips Semiconductors Product specification
24 W BTL or 2 x 12 W stereo car radio
power amplifier TDA1510AQ
Notes to the characteristics
1. If V11 > V10 then I11 must be < 10 mA.
2. Closed loop voltage gain can be chosen between 32 and 56 dB (BTL), and is determined by external components.
3. Frequency response externally fixed.
4. The input impedance in the test circuit (Fig.3) is typ. 100 kΩ.
5. Supply voltage ripple rejection measured with a source impedance of 0 Ω(maximum ripple amplitude 2 V).
6. Output power is measured directly at the output pins of the IC.
7. Closed loop voltage gain can be chosen between 26 and 50 dB (stereo), and is determined by external components.
8. A resistor of 56 kΩbetween pins 3 and 7 is required for symmetrical clipping.
9. Without bootstrap the 100 µF capacitor between pins 5 and 6 and the 100 µF capacitor between pins 8 and 9 can
be omitted. Pins 6 and 8 connected to pin 10.

January 1992 9
Philips Semiconductors Product specification
24 W BTL or 2 x 12 W stereo car radio
power amplifier TDA1510AQ
APPLICATION INFORMATION
Fig.3 Test and application circuit; Bridge Tied Load (BTL).
(1) belongs to power supply.
Fig.4 Test and application circuit; stereo mode.
(1) belongs to power supply.

January 1992 10
Philips Semiconductors Product specification
24 W BTL or 2 x 12 W stereo car radio
power amplifier TDA1510AQ
PACKAGE OUTLINE
UNIT A e1 A2bpcD
(1) E(1) Z(1)
deD
hLL 3m
REFERENCES
OUTLINE
VERSION EUROPEAN PROJECTION ISSUE DATE
IEC JEDEC EIAJ
mm 17.0
15.5 4.6 4.2 0.75 0.60 0.48 0.38 24.0 23.6 20.0 19.6 10 3.4
v
0.8
12.2
11.8 1.7
e2
5.08 2.4
1.6
Eh
62.00
1.45
2.1
1.8
3.4
3.1 4.3
DIMENSIONS (mm are the original dimensions)
Note
1. Plastic or metal protrusions of 0.25 mm maximum per side are not included.
12.4
11.0
SOT141-6
0 5 10 mm
scale
Qj
0.25
w
0.03
x
D
L
E
A
c
A2
m
L3
Q
wM
bp
1
d
D
Ze2
e
e
xh
113
j
E
h
non-concave
view B: mounting base side
95-03-11
97-12-16
DBS13P: plastic DIL-bent-SIL power package; 13 leads (lead length 12 mm) SOT141-6
vM
B

January 1992 11
Philips Semiconductors Product specification
24 W BTL or 2 x 12 W stereo car radio
power amplifier TDA1510AQ
SOLDERING
Introduction
There is no soldering method that is ideal for all IC
packages. Wave soldering is often preferred when
through-hole and surface mounted components are mixed
on one printed-circuit board. However, wave soldering is
not always suitable for surface mounted ICs, or for
printed-circuits with high population densities. In these
situations reflow soldering is often used.
Thistextgivesavery briefinsightto acomplextechnology.
A more in-depth account of soldering ICs can be found in
our
“IC Package Databook” (order code 9398 652 90011).
Soldering by dipping or by wave
The maximum permissible temperature of the solder is
260 °C; solder at this temperature must not be in contact
with the joint for more than 5 seconds. The total contact
time of successive solder waves must not exceed
5 seconds.
The device may be mounted up to the seating plane, but
the temperature of the plastic body must not exceed the
specified maximum storage temperature (Tstg max). If the
printed-circuit board has been pre-heated, forced cooling
may be necessary immediately after soldering to keep the
temperature within the permissible limit.
Repairing soldered joints
Apply a low voltage soldering iron (less than 24 V) to the
lead(s) of the package, below the seating plane or not
more than 2 mm above it. If the temperature of the
soldering iron bit is less than 300 °C it may remain in
contact for up to 10 seconds. If the bit temperature is
between300 and 400 °C, contact may be up to 5 seconds.
