Philips Azalis 288 User manual

GBۥ 4311 255 50571

Discover your Phone
* The keypad automatically unlocks when you receive a call. You can still place an emergency
call.
L
LL
L
NOTE:
Philips continuously strives to improve its products, and the information and specifications
described in this user manual are subject to change without notice.
Philips tries to ensure that all information in this user manual is correct, but does not accept
liability for any error, omission or discrepancy between this user manual and the product
described.
Earpiece
Green "Pick up" key D
- Press to answer a call.
- Press to dial a number, or
name displayed on the screen.
- In WAP mode, corresponds to a
softkey.
WAP @
- Press to access WAP browser.
Alphanumeric keypad
- Press keys to enter numbers
and text.
- Long press on a key to activate
hotkey function.
Microphone
Antenna
Screen
Idle screen displays the time,
date and network name.
Red "Hang up" Rand
"On/Off" key
- Long press to switch your
phone on/off.
- Press to end a call.
- In WAP mode, corresponds to a
softkey.
Menu M
- Press to enter carousel menu.
- Press to return to idle screen.
WAP mode:
- Press to open the browser
menu.
Compass key
Use this key to navigate in the
menus, the OK key is used to
validate information.
Cancel/back key C
Idle mode:
- Long press to lock/unlock the
keypad*.
Navigation mode:
- Press to return to previous
menu.
Edit mode:
- Press to delete a character.
- Long press to delete all
characters.
WAP mode:
- Press to go back one page.
- Long press to exit browser.
Language
- Long press
0 to choose a language in which the
telephone functions will be displayed.
OK O
OO
O
Idle mode:
- Long press for voice dial or
voice command.

Quick Reference
Switch on/off: Long press r
Enter PIN: 1. Enter PIN code on keypad
2. Press oto confirm
Make a call: 1. Enter phone number on keypad
2. Press dto dial
Answer a call: Press d
End a call: Press r
Use Names List: 1. Press >to access
2. Press < > to select name
3. Press dto dial
Enter a Name: Select <New> from the Names list

Access and tour the menu: 1. Press M
2. Press < > to select a menu
3. Press oto confirm
4. Press < > to select a sub-
menu
5. Press oto confirm
Return to previous menu: Press C
Return to idle screen: Press M
Visit our site and register on line @ http://www.pcc.philips.com
Service numbers
Messages Send SMS
Mailboxes
Read SMS
Settings
Security
Main
Menu
PHILIPS
* Subscription dependent. Please contact your operator for further details.
Broadcast SMS
Display
Time and Date
Hotkeys
Call settings
Names
Call list
Extras
Access settings
Settings
Help
OK
OK
OK
Sounds
SMS settings
Oper. services*
Voice command
Launch
OK
Network Services
WAP Last page
Favourites
Organiser

1
Table of contents
Discover your Phone 1
Introduction 3
Symbols used in this
guide 3
Before your first call 3
The SIM card 3
PIN and PUK codes 3
Insert the SIM card 4
The battery 5
Insert the battery 5
Attach the battery cover 5
Remove the battery 6
Charge the battery 6
Screen 7
Phone Functions 8
Switch on/off 8
Idle Screen 8
Make a call 9
Answer a call 9
End a call 10
Emergency call 10
Text Entry 10
The Carousel 13
Main Menus 13
Names 14
<New> 14
Send SMS 15
Voice Dial 15
Change or Delete 15
Messages 16
Send SMS or Reply 17
Read SMS 18
SMS Settings 18
Signature 18
Delivery report 18
Auto save SMS 18
Broadcast SMS 18
Reception 19
Topics 19
District code 19
Mailboxes 19
Call List 20
Organiser 21
Events 21
Day view, Week view and
Month view 21
Extras 22
Call counters 22
Accumulated call timers 22
Accumulated cost 22
Show 22
Reset 22
Cost limit 23
Show balance 23
Cancel cost limit 23
Charge rate 23
Last Call Information 23
-> Euro 23
<- Euro 24
Brick game 24
Calculator 24
Alarm Clock 25
Voice memo 25

2
Settings 26
Sounds 26
Ringer volume 26
Ringer 27
Key tones 28
New SMS tone 28
Vibra alert 28
Organiser alerts 28
Display 29
Zoom 29
Contrast 29
Security 29
Keypad lock 29
Public names 29
Call barring 29
Call restriction 29
Change codes 30
PIN protection 30
Time and date 30
Clock display 30
Set date and time 30
Hotkeys 31
Voice command 33
Network 34
Register again 34
Preferred list 34
Call settings 34
Call forward 34
Any key answer 35
Call waiting 35
Caller ID 35
Network Services 36
Touchtones (DTMF) 36
Make a second call 36
Autoredial 37
Answer a second call 37
Conference call 37
Operator services 39
WAP 39
Launch the Browser 40
Favourites 42
Last Page 42
Settings 42
Images 42
Status icons 43
Access settings 43
Gateway 43
Security 43
Home page 43
Phone Number 44
Login 44
Password 44
Glossary 45
Precautions 46
Environmental care 50
Troubleshooting 51
Index 53
Declaration of
conformity 56
Philips Authentic
Accessories 58

3
Introduction
Thank you for purchasing your Philips Az@lis 288.
This guide will help you to learn easily and quickly how to use your phone.
Symbols used in this guide
Ringer volume A function displayed on your phone screen.
1Represents a key on your phone keypad.
C < > o Represent a function on the compass key.
Long press: Press and hold the key for 2 seconds.
Activate/deactivate Pressing the same key (called a toggle key) or using
</ >will alternate between different options:
ex. Activate and Deactivate.
Press M -> Settings -> Call settings -> Call forward
This represents a series of commands to tour the menu until you
reach the specific function being discussed. The most important
point to remember is the necessity to press okey AFTER EACH
LEVEL before you can tour the next level. So, the above example is:
Press M-> Settings o-> Call settings o
-> Call forward o
Before your first call
The SIM card
To use your phone, you must insert a valid SIM card for your GSM
subscription.
This card contains your telephone number. It also has memory to store the
phone numbers and messages you wish to retain. If you use this card on
another phone, you still have the same phone number, stored numbers and
messages.
PIN and PUK codes
The PIN code is a secret code in your SIM card to protect it from abusive
use. If you or anyone else enters a wrong PIN code 3 times, your SIM card is
blocked. To unblock it, you must request the PUK code from your Network
Operator.
Read the safety instructions in the
Precautions section before use.

4
Insert the SIM card
1Remove the SIM card from
your card.
2Remove the battery
cover.
1Press on the battery
cover latch at the
back of the phone.
2Lift off the battery
cover.
3Push the metal retaining clip to
the left and lift the cardholder.
4Slide the SIM card into its slot until it stops.
Please ensure that the clipped corner is in the
identical position as on the drawing.
5Close the cardholder and push the clip to
the right.

5
The battery
Your phone is powered by a rechargeable battery.
• To optimise the battery capacity, please allow the battery to fully discharge
3 times in a row. To then maintain optimal battery capacity, do not wait
until the battery indicator reaches low. This level is reached when only one
bar is displayed in the battery indicator, see page 7.
• If you do not use the phone for several days, you should disconnect the
battery.
• For a full recharging please allow the charger to be connected for 53 mns.
Insert the battery
Attach the battery cover
1Plug the connector into the socket. If you
cannot plug the connector, try again
reversing the plug.
2Tilt battery and press lightly against the
battery latch.
3Press the battery downwards.
1Hook the battery cover onto the
hinges on the bottom of the phone.
2Press the top down until latch
catches.

6
Remove the battery
When disconnecting the battery, the settings for date and time will be lost.
Charge the battery
With the battery inside the phone:
L
LL
L
NOTE:
The only way to turn off the charger is to unplug it, so use an easily accessible AC
power socket. You can connect the charger to an IT supply (Belgium only).
Bars moving ➨battery is charging
Bars steady ➨battery is fully charged*
Battery outline flashing (see Troubleshooting page 51).
* Keeping the mobile plugged to the charger when the battery is fully charged does
not damage the phone.
1Press bottom of battery lightly
against battery latch.
2Lift bottom of battery and slide it
out of the phone.
3Unplug the connector from its slot.
1Plug the connector into the
right socket at the base of the
phone.
2Plug the transformer unit into
an easily accessible AC
power socket.

7
Screen
The screen displays information regarding various functions of your phone.
Alarm clock
Your alarm clock is activated.
Silent
Your phone will not ring when
receiving a call.
Vibrator
Your phone will vibrate when
receiving a call.
Keypad lock
Protects the keys from being
pressed accidentally.
SMS message
You have received a new
message.
SMS full
Memory for messages is full. You
must delete old messages before
you can receive new ones.
Battery
One bar = low charge, 4 bars =
full charge. If battery outline is
flashing see Troubleshooting
page 51.
Network
aNetwork
NetworkNetwork
Network: your phone is
connected to a network
Reception quality
Reception qualityReception quality
Reception quality: the more
bars are shown the better the
reception is.
Call Forward Unconditional to
number
All your incoming voice calls are
being forwarded to a number
other than voice mail.
Call Forward Unconditional to
voice mailbox
All your incoming voice calls are
being forwarded to voice mail.
Home zone
A zone designated by your
network operator. Subscription
dependent.
Roaming
Displayed when your phone is
registered to a network other
than your own, especially when
you are abroad.
Voice Mail
You have received a new voice
mail.
Network Name
Network NameNetwork Name
Network Name
12 jun 2000
12 jun 200012 jun 2000
12 jun 2000
s

8
Phone Functions
Switch on/off
Idle Screen
When the idle screen is displayed your phone is ready to use.
- If the network name is not displayed, the network is not currently
available. You may be in a bad reception area (perhaps in a tunnel or
between tall buildings). If possible, move to a different location.
1Long press r to switch on/off.
2Enter your PIN code if requested then press oto
confirm.
PIN CODE
PIN CODEPIN CODE
PIN CODE
Network Name
Network NameNetwork Name
Network Name
12 jun 2000
12 jun 200012 jun 2000
12 jun 2000

9
Make a call
• Press Cto delete the previous digit.
•Press
</ >to move through digits.
• Long press *to obtain "+" symbol on the screen for the International
prefix.
Other easy quick ways to make a call:
• Press >to access Names list. Press </ >to select a name or
press the key corresponding to the first letter of the name you wish to
call. Press dto dial.
• Press <to access Call List to redial last called numbers or reply
to last received or missed calls. Press <or >to select a number.
Press dto dial.
• Long press on a key that is set up for Flash dial (see page 31).
• Long press oto access Voice dial. Pronounce the voice tag, (see
page 15).
Answer a call
When receiving a call, your phone can ring and / or vibrate. Depending on
your subscription, the caller's number may be displayed, if the caller has
enabled this information to be transmitted. If this number is in the Names list,
the corresponding name is displayed instead of the number.
During a conversation, you can:
•Lower/raise earpiece volume by pressing </ >.
•Mute the microphone by pressing Mand selecting Mute.
•Enter a number you want to save by using the keypad. It reappears after
the call.
1Enter the phone number using the keypad.
2Press dto dial.
1Press dto answer a call.
2Press rto reject a call.

10
•Find a phone number by pressing :
M to access Names list, </ >to select name and oto confirm.
Press Mto return to your call screen.
End a call
Emergency call
Depending on the network operator, the emergency number can be dialled
without the SIM card inserted. 112 is the standard emergency number for
GSM networks (except for UK : 999).*
L
LL
L
NOTE:
* This number depends on the country where you make the call. Please contact your
Operator.
Text Entry
Text can be entered in editing screens in two different ways:
IBasic Text Entry Each key allows you to obtain several characters. Quickly press
the same key several times to reach the desired character:
Example:
to enter "my hat!"
To obtain
m y space h a t !
Press
6
once 9
3 times
quickly
1
once 4 twice
quickly
2
once 8 once 0 9 times
quickly
1Press r to end a call.
1Enter 112 using the keypad.
2Press d.

11
II T9™ uses ONE key press per letter. The
word changes after every keystroke so,
don't pay too much attention to how the
word appears on the display until you
have pressed all the appropriate keys.
T9™ proposes a final series of probable
words and you confirm the one you select.
Key Characters
1 space 1 @ _ # = < > ( ) & £ $ ¥
2 A B C 2 À Ä Å Æ Ç
3 D E F 3 É E ∆ Φ
4GHI4Γ Ι
5JKL5Λ
6 M N O 6 Ñ Ò Ö
7PQRS7βΠ Θ Σ
8 T U V 8 Ü Ù
9 W X Y Z 9 Ø Ω Ξ Ψ
0 . 0 , / : ; " ' ! ¡ ? ¿ * + - %
* Switch between Basic Text Entry / T9™ / digits / symbols
# Switch between Upper / Lower / Auto Case
Tegic Euro. Pat. App. 0842463

12
• Press Cto delete the previous digit.
• Press M to return to idle screen.
• Press <or >to move cursor left or right.
Example: to enter the word "home":
1Press * to enter T9™ mode unless T9™ symbol is already
displayed.
2Press keys 2to 9(one press per letter indicated on the key)
to spell the word you want to write.
3Press 0 to scroll the words T9™ proposes and select the
one you want.
4Press 1to confirm your word. T9™ inserts it in your
message and adds a space.
1Press 4 6 6 3. The screen displays the first word
of a list: Good.
2Press 0 to scroll and select Home.
3Press 1to confirm Home.
T9
Good
T9
Home

13
The Carousel
The carousel menu enables you to access the functions of your phone.
Here’s an overview :
Main Menus
Press M. Press </ >to select a function from the carousel displayed on
the screen then press oto confirm.
1Press Mto access the carousel.
2Press </ >to tour the menus and menu options.
3Press oto confirm a choice of menu and option.
4Press Mto return to the idle screen.
Service numbers
Messages Send SMS
Mailboxes
Read SMS
Settings
Security
Main
Menu
PHILIPS
* Subscription dependent. Please contact your operator for further details.
Broadcast SMS
DisplayTime and Date
Hotkeys
Call settings
Names
Call list
Extras
Access settings
Settings
Help
OK
OK
OK
Sounds
SMS settings
Oper. services*
Voice command
Launch
OK
Network Services
WAP Last page
Favourites
Organiser

14
Call list Extras Settings Operator
services
OrganiserNames Messages
Names
This is your directory of names and numbers you wish to store. They are
stored in your SIM card. The capacity only depends on it. For further
information, please contact your operator.
<New>
Press M-> Names -> Select a name from the list displayed on the screen.
<New>
,
Names
,
Own Number
,
Emergency
,
Telephone Number
Send SMS
Voice DialDelete
Change
Call
1Press < /> to select <New> to enter a new name and
number, then press oto confirm.
2Use the Basic Text Entry mode to enter the name (see
page 10).
3Enter the telephone number, then press oto confirm.

15
Call list Extras Settings Operator
services
OrganiserNames Messages
Send SMS
Voice Dial
You can dial a number simply by long pressing oand then pronouncing
the voice tag you associated with that number. To set up a voice tag for
someone not in the Names list, first create a <New> entry.
LNOTE:
In a very noisy environment your phone may not recognise your tag. Please repeat
or move to another location.
Change or Delete
1Press < /> to select a name.
2Press o o.
3Press < /> to select Send SMS.
See "Send SMS or Reply" page 17.
1Press < /> to select name.
2Press o o.
3Press < /> to select Voice Dial.
4Press o and the screen displays Add voice tag?
5Press o o.
6At screen message Speak now, clearly pronounce a short
voice tag.
7Repeat this a second time following instructions on your
screen.
1Press < /> to select name.
2Press o o.
3Press < /> to select Change or Delete.

16
Call list Extras Settings Operator
services
OrganiserNames Messages
Messages
You can send text messages (SMS) to other GSM phones and receive
messages on your phone. There are standard messages and you can
compose a new one. You can attach an "emotion icon" and/or a ringer
melody that you can create (see page 27) or download from Internet (see
page 28). The receiver must have a Philips mobile phone that supports this
feature to see the icon and/or hear the melody sent. Otherwise, he will not
hear the melody and the emotion icon will be replaced by its equivalent
translation code at the end of the message received (connect to Philips web
site : www.pcc.philips.com to have a list of the Philips phones supporting the
feature).
Note that the text length for the message would be less than 160 characters
when you attach an emotion icon.
To send messages, you must first enter a service centre number. If this is not
stored in your SIM card, ask your operator for it.
Press M -> Messages -> Select a function from the carousel displayed on
the screen.
Send SMS
Read SMS
SMS settings
Broadcast SMS
Mailboxes
1Press M-> Messages o-> SMS Settings o-> SMS
centre o.
2Enter service centre number then press oto confirm.
