Philips CTK700BLK/00 User manual

Discover your phone
Philips continuously strives to improve its products. Therefore, Philips reserves the rights to revise
this user guide or withdraw it at any time without prior notice. Philips provides this user guide "as is"
and does not accept, except as required by the applicable law, liability for any error, omission or
discrepancy between this user guide and the product described. The device is meant to be connected
to GSM/GPRS/EDGE networks.
Power on/off
key,
Unlock/lock
key
Side
volume
key
Camera key
Status pull-
down menu
262K TFT
LCD
Back key
3.2MP
Camera
lens
Loudspeaker
Loudspeaker
Light sensor
3.5mm
headset jack
Microphone
Shortcut icons
Multimedia
key
USB port/
charger

1
How to ...
Switch the phone On/Off Long press the Power on/off key )on the left side of the
phone..
Enter your PIN code Enter your PIN code through the on-screen keypad and
tap on OK to confirm.
Lock the keypad Short press )on the left side of the phone.
Unlock the keypad Short press )on the left side of the phone or slide the
lock icon on the idle screen to unlock.
Make a call On the idle screen, tap on to select a contact, or
to enter a phone number, and then, tap on Dial (Call).
Answer a call When the phone rings, tap on Answer.
Mute the ringing call or
sounding alarm
When the phone/ alarm rings, turn over the phone, front
side to the back, or back side to the front (if you have
turned on the options in > Settings > General > Motion
sensor).
Activate/Deactivate handsfree
mode
During a call, tap on Options to access the options list,
select to turn on or off the option Handsfree.

2
End a call Tap on the option End.
Access received messages/
missed calls
On the idle screen, tap on the icon for new messages or
miss calls.
Check all calls history On the idle screen, press the Back key ,.
Check or write messages On the idle screen, tap on .
Access the main menu On the idle screen, tap on .
Quickly return to idle when
browsing menus
Press the Back key ,.
Quickly access to the
multimedia screen
On the idle screen, press the multimedia key Mto
quickly access to the multimedia screen. Tap on the
desired multimedia functional icon (Browser, Image viewer,
Multimedia player, Music player and FM radio) to access the
corresponding menu. For more details, refer to
"Multimedia screen" on page 5.
Access the status pull-down
menu
Tap on at the top of idle screen. Tap to select
options.

3
Enter the camera/video mode On the idle screen, press the Camera key. Tap /
to select the camera/video mode.
Select on-screen input keypads/
modes
Qwerty keypad : On the editing screen, turn the
phone counterclockwise by 90 degrees, vertical to
horizontal.
Alphanumeric keypad : Turn the horizontal
phone clockwise by 90 degrees, horizontal to vertical.
Handwriting recognition mode : Tap on /
to switch between the two modes.
Tap on the language, numeric, or input method icon to
select.
Quick access to functions
You can quickly access functions directly from
the idle screen (using the shortcut icons, the
multimedia key M, or status pull-down menu),
or through the main menu.
Shortcut icons
On the idle screen, the four shortcut icons lead
you directly to four functional displays.
: Quick access to messaging
: Quick access to phonebooks
: Quick access to dial pad
: Quick access to main menu

4
Main menu
The main menu gives you access to all the
different features of your mobile phone. The
table below summarizes the functional icons on
the main menu. To find more information about
their functions, refer to the pages. Tap on on idle screen to access the main
menu. To select your option, tap on the icons
and lists, and then OK. Tap on Options to access
the options related to the selected item. Tap on
Back to return to the previous menu. Press ,
to return to the idle screen.
Fun Browser Multimedia
page 55 page 46 page 57
Camera Messaging My files
page 48 page 24 page 64
Tools Contacts Profiles
page 39 page 34 page 72
Bluetooth Calls Settings
page 69 page 67 page 73

5
Multimedia screen
On the idle screen, press the multimedia key M
to quickly access the multimedia functional
screen. As the following picture:
On this multimedia functional screen, you can
tap on the Browser icon to go to the internet; tap
on the Image viewer icon to enjoy pictures; tap
on the Multimedia player or Music player icon to
play video and audio files; tap on FM radio to
listen to the radio programs. For more details,
refer to "Multimedia" on page 57.
Status pull-down menu
By dragging at the top of the idle screen,
you can quickly turn on/off the alarm, GPRS
connection, Bluetooth, or silent mode; check
battery level; and select your desired profile, or
ring type for incoming calls or messages.
Stylus
The touch screen allows you to enter text by
directly writing on the screen, or tap to select
the desired option. The supplied stylus makes it
easier to do so.
The first time you switch on the phone, you are
asked to do calibration for the stylus. Thus,
strokes or taps by the stylus will be precisely
displayed on the screen.
You can also do the calibration in Settings >
General > Pen calibration by following the screen
instructions.

6
Sensor
With built-in motion and light sensors, the
phone can react to motion and ambient
luminance as desired or necessary.
To use the motion sensor
•InSettings > General > Motion sensor > Mute
incoming call or Snooze alarm, select On.
If a call rings, turn over the phone (front side to
back, or back side to front) to mute the ring
tone.
To interrupt the sounding alarm in the same
way, check that the Snooze is set to a time
interval in Tools > Alarm (see "To set an alarm"
on page 42). To stop the alarm, tap on Stop.
To use the light sensor
•InSettings > Display > Light sensor, select On.
The phone will adjust back light level
automatically according to ambient brightness.
For power-saving purposes, always turn on the
light sensor.
Power-saving mode
After the set time span, the phone has the idle
screen turned off automatically. To exit the
power-saving mode, press any key. For power-
saving purpose, set the time span to a low value
in Settings > Display > Backlight duration.
Auto screen lock
In the idle mode, your phone can have the
screen locked automatically after the set time
span.
To set the auto screen lock
Go to Settings > General > Auto screen lock. Select
the desired time span.
Select the option Off to cancel the auto screen
lock.

7
To unlock the screen
Short press )on the left side of the phone or
slide the lock icon on the idle screen to unlock.
To lock the screen manually
Short press )on the left side of the phone.

8Table of contents
Table of contents
1 Getting Started 11
Insert the SIM card 11
Charge the battery 13
Set clock 14
Insert the Micro-SD card 15
2 Text Entry 16
Using the Qwerty keypad 16
Using the supplied stylus 
(the handwriting recognition mode) 16
Using the alphanumeric keypad 17
3 Calling 20
Making a call 20
Answering and ending a call 20
Options during a call 21
Handling multiple calls 
(Network-dependent) 22
Making an emergency call 23
4 Messaging 24
Creating messages 24
Organizing your messages 26
Defining your message settings 28
E-mail 30
Broadcast message 33
5 Contacts 34
Adding or editing contacts 34
Searching for a contact 35
Managing your contacts 35
Sharing contact information 
with others 36
Backing up important contacts 37
Special numbers 37
6 Tools 39

Table of contents 9
Using your business organizer
Create your to-do list 39
Check your calendar 40
Edit your to-do list 40
Delete expired tasks 40
Using your business assistant
Record a sound memo 41
Alarm 41
World clock 42
Stopwatch 43
Text reader 43
Others 
Firewall 44
Calculator 45
Currency converter 45
7 Browser 46
Managing your browser 46
Accessing web sites 46
Enabling/disabling push messages 46
STK 47
8 Camera 48
Camera 48
Video recorder 52
9 Fun 55
Java 55
Sensor games 56
10 Multimedia 57
Multimedia player 57
Music player 58
FM radio 61
Image viewer 63
11 My files 64

10 Table of contents
Finding your files 64
Managing your files 64
Sharing your files 65
Using your files 66
12 Calls 67
Call history 67
Call options 67
13 Bluetooth 69
About Bluetooth 69
Connecting to a Bluetooth device 69
Getting connected by 
a Bluetooth device 70
Editting your device list 71
14 Profiles 72
Adjusting ring settings to 
different scenes 72
15 Settings 73
General 73
Display 75
Sounds75
Connectivity 76
Icons & Symbols 78
Precautions 80
Tips 87
Troubleshooting 88
Philips Authentic Accessories 92
Trademark Declaration 95
Specific Absorption Rate Information 96
Limited Warranty 98
Declaration of Conformity 102

Getting Started 11
1 Getting Started
Congratulations on your purchase and welcome
to Philips!
To get the most of your product and enjoy all
Philips has to offer, register your product at
www. philips. com/welcome.
Please read the safety instructions in the
"Precautions" section before use.
To use your phone, you must insert a valid SIM
card supplied by your GSM operator or retailer.
The SIM card contains your subscription
information, your mobile telephone number,
and a memory in which you can store phone
numbers and messages.
Insert the SIM card
Follow the steps below to insert your new SIM
card. Remember to switch off your mobile
phone before removing the back cover.
1. Press on the back cover and slide the cover
as shown.

12 Getting Started
2. As shown, take out the battery.
You may lose all your personal settings if you
remove the battery when the phone is switched
on.
3. As shown, align your SIM card with the SIM
card slot, clipped corner facing you and gold
contact downwards. Insert your SIM card
under the metal clip holder.
4. As shown, align the metallic connectors on
the battery and battery slot. Press the
battery down until it is locked.

Getting Started 13
5. As shown, slide the back cover along the
slots until it is locked.
Remove the protective film covering the screen
and camera lens before using the phone.
Charge the battery
Your phone is powered by a rechargeable
battery. A new battery is partially charged. The
battery symbol indicates the state of the battery.
To charge the battery, plug in the connector as
shown below. Then plug the other end into a
power socket.
During charging, the battery symbol scrolls.
Keeping the charger plugged to the mobile
phone when the battery is fully charged will not
damage the battery. The only way to turn off the
charger is to unplug it, so it is advisable to use an
easily accessible power socket.

14 Getting Started
If you do not intend to use your phone for
several days, we recommend that you remove
the battery.
You can use the phone while it is charging. If the
battery is completely flat, the battery symbol will
only reappear after a few minutes of charging.
Set clock
1. Check that your phone is switched on. 
Long press the power on/off key )if
necessary. Enter the PIN code if required. A
PIN code is a 4- to 8-digit secret code of
your SIM card. It is preset and
communicated to you by your network
operator or retailer.
If you enter an incorrect PIN code three times
in succession, your SIM card will be blocked. To
unblock it, you must request the PUK code from
your operator.
2. On the idle screen, tap on and go to
Settings > General > Time & date.
Set format: Select the time (12-hour or 24-
hour clock) and date format by tapping the
desired options, and or .
Set time / Set date: Enter the time and date.
Tap on the box to be defined. To enter
your desired digits, tap or
repeatedly, or long press or until
you reach the desired digits.
3. To show the clock display on idle screen, tap
on and go to Settings > General > Time
& date > Display time, select On.
Display local and international
clocks
You can display two clocks on the idle screen,
one showing your local time and one the time of
your destination.

Getting Started 15
1. Check that you have set your local time and
date.
2. Go to Tools > World clock.
Local settings/Foreign settings: Tap or
repeatedly to select a city. If necessary, tap
Options to turn Daylight saving/Daylight saving
for foreign city on or off. 
Switch local/foreign: Switch between local and
foreign clocks.
Insert a micro-SD card (memory
card)
You can expand the memory of your phone by
adding a micro-SD card.
Supported capacity: up to 8 GB
1. Follow Step 1 and 2 under “Insert the SIM
card”.
2. As shown, push down the card holder and
lift it up. Align your micro-SD card with the
slot. Put it in place.
3. Press down the card holder and pull it until
it is locked.

16 Text entry
2 Text entry
Your mobile phone supports text entry through
the on-screen Qwerty keypad, on-screen
alphanumeric keypad, or the supplied stylus
(handwriting recognition mode).
Using the Qwerty keypad
Select text entry modes
• On the editing screen, turn your phone, if in
the vertical position, counterclockwise by 90
degrees. 
Check that you are in an input mode other
than or .
Enter text
1. Ta p t o s e l e c t 
/ for English entry
: for Chinese entry
: for numeric entry
Depending on the language you select for your
phone, the supported input methods may vary.
2. Tap on the keys to enter your desired
letters or numbers.
: Tap to move to the beginning of the
next line.
: Tap to delete the previous character.
: Tap to enter a space.
:Tap to enter symbols and
punctuations. Tap again to exit.
: Tap to switch between upper and
lower cases (for English entry).
3. Tap on Done to complete editing.
Using the supplied stylus (the
handwriting recognition mode)
Select text entry modes
1. On the editing screen, turn your phone, if in
the horizontal position, clockwise by 90
degrees.

Text entry 17
2. If necessary, tap on to select 
: text entry through the supplied stylus
(handwriting recognition mode)
Enter text
1. Ta p t o s e l ec t 
/ / : for English
entry
: for Simplified Chinese
entry
: for Traditional Chinese
entry
: for numeric entry
Depending on the language you select for your
phone, the supported input methods may vary.
2. Write on the screen using the supplied
stylus, as you do on paper using a pen. 
: Tap to move to the beginning of the
next line.
: Tap to enter a space. 
: Tap to enter symbols and
punctuations. Tap again to exit.
Using the alphanumeric keypad
Select text entry modes
1. Follow Step 1 under "Using the supplied
stylus (the handwriting recognition mode)".
2. If necessary, tap on to select
: text entry through the alphanumeric
keypad
Enter text
1. Tap to select
/ / / : for English
entry
/ : for Traditional Chinese
entry
: for Simplified Chinese
entry
: for numeric entry

18 Text entry
- Long press to turn T9 input on or
off (for suitable input methods only).
- To set preferred input methods, long
press . On the screen, you will
only find the icons for preferred input
methods.
Depending on the language you select for your
phone, the supported input methods may vary.
2. Tap on the keys to enter your desired
letters, numbers, or strokes.
to Ta p to input letters (T9
input)
Tap repeatedly to input the desired 
letter (multi-tap input) 
/ Tap to browse candidate words 
on the previous/next page. 
Tap to input symbols and punctuations 
Tap to input a space
Clear Short press to clear a letter, 
long press to clear all entries.
If necessary, tap on Clear to exit
the input mode first.
- Tap on a candidate word or Select to
select.
- To move to the beginning of the next
line, tap on and select .
3. If necessary, tap on Clear to exit the input
mode.
T9®input
T9
®predictive text input is an
intelligent editing mode for
messages, which includes a
comprehensive dictionary. It
allows you to quickly enter text.
You need to press only once on
the key corresponding to each letter needed to
spell a word: keystrokes input are analyzed and
the word suggested by T9
®is displayed at the
pop-up window.
Examples: how to enter the word
"home":
Tegic Euro. Pat.
App. 0842463

Text entry 19
1. Tap on , , , .
The screen displays a list of candidate
words.
2. Tap to select “home”.
Multi-tap input (ABC/abc)
Press the keys that are marked with the
corresponding letter you wish to enter. Press
once to get the first letter on the key, press
twice quickly to get the second letter and so on
until the letter you want is displayed on the
screen.
Example: how to enter the word "home":
Press , (GHI) , ,
(MNO), (MNO), ,
(DEF).
