Philips AJ7010 User manual

AJ7010
www.philips.com/welcome
User manual
Always there to help you
Register your product and get support at
Question?
Contact
Philips

2EN
Contents
1 Important 3
2 Your clock radio 4
Introduction 4
What's in the box 4
Overview of the main unit 5
Overview of the outdoor sensor 7
3 Get started 8
Install battery 8
Connect power 8
Plug and set 9
Select time zone 9
Set clock 9
4 Listen to FM/MW radio 9
Tune to radio stations 9
Store radio stations automatically 9
Store radio stations manually 10
Select a preset radio station 10
Adjust volume 10
5 Other features 10
Display indoor/outdoor temperature 10
Enjoy nature sound 11
Set alarm timer 11
Set sleep timer 11
Select DST (daylight saving time) mode 12
Adjust display brightness 12
6 Product information 12
Specications 12
7 Troubleshooting 13
8 Notice 13

3EN
1 Important
• Read these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or
otherapparatus(includingampliers)that
produce heat.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the clock radio.
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Unplug this clock radio during lightning
storms or when unused for long periods
of time.
• Referallservicingtoqualiedservice
personnel. Servicing is required when
the clock radio has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the clock radio, the
clock radio has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
• The main unit of the clock radio shall not
be exposed to dripping or splashing.
• Do not place any sources of danger on
the main unit of the clock radio (e.g. liquid
lledobjects,lightedcandles).
• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
Risk of swallowing batteries!
• The product or remote control may
contain a button cell battery, which is
possible to be swallowed. Keep the battery
out of reach of children at all times! If
swallowed, the battery can cause serious
injury or death. Severe internal burns can
occur within two hours of ingestion.
• If you suspect that a battery has been
swallowed or placed inside any part of the
body, seek immediate medical attention.
• When you change the batteries, always
keep all new and used batteries out of
reach of children. Ensure that the battery
compartment is completely secure after
you replace the battery.
• If the battery compartment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.

4EN
2 Your clock radio
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this clock radio, you can:
• listen to FM/MW radio;
• set two alarms;
• view time, date, and indoor/outdoor
temperature;
• adjust time zone and daylight saving time;
and
• wake up to buzzer, radio, or stored nature
sounds.
What's in the box
Check and identify the contents of your
package:
• Main unit (with button cell battery)
• Outdoor temperature sensor
• Power adapter
• User manual
• Quick start guide

5
d TIME ZONE
• Set time zone.
e DISPLAY
• Activate temperature display setting
mode.
f NATURE SOUND
• Activate nature sound setting mode.
g AC 6V ~ 450mA
• Connect power.
EN
Overview of the main unit
a AL1/AL2
• Set alarm.
• View alarm settings.
• Activate or deactivate alarm timer.
b Display panel
• Show current information.
c DST
• Select daylight saving time (DST)
mode.
a
f
e
d
ck
l
j
i
n
m
o
g
h
b

6EN
h FM ANT
• Improve FM reception.
i TUNING MODE
• Select tuning mode.
j PRESET
• Select a preset radio station.
k FM/MW
• Select FM or MW tuner mode.
l SET TIME/PROG
• Set time.
• Program radio stations.
m SLEEP
• Set sleep timer.
n Main knob
• Adjust volume.
• Conrmselection.
• Adjust settings.
• Deactivate nature sound.
o SNOOZE/BRIGHTNESS
• Snooze alarm.
• Adjust display brightness.
Overview of the outdoor
sensor
g
f
e
d
a
c
b
a Display panel
• Show outdoor temperature and RF
channel.
b LED light
• Blink when transmitting data to the
main unit.
c Sensor support
d °C/°F slide
• Switch between Centigrade (°C) or
Fahrenheit (°F) temperature display.
e CHANNEL1/2/3
• Select RF channel to transmit signals.
f Lock for battery compartment (with
screw)
g RESET
• Reset to restart transmission.

7EN
3 Get started
Always follow the instructions in this chapter in
sequence.
Install battery
Caution
•Risk of explosion! Keep batteries away from heat,
sunshineorre.Neverdiscardbatteriesinre.
•Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
•The battery contains chemical substances, so it should
be disposed of properly.
•Keep children away from the battery.
Install batteries into the sensor
Note
•Do not mix batteries (old and new or carbon and
alkaline, etc.).
1 Turn the screw anticlockwise to unlock the
battery compartment.
2 Insert 2 AA batteries (not supplied) with
correct polarity (+/-) as indicated.
3 Turn the screw clockwise to lock the
battery compartment.
Replace battery of the main unit
Note
•You can only use AC power as power supply.The pre-
installed CR2032 battery can only back up clock and
alarm settings.
When the low battery icon is displayed, replace
the battery as indicated.
Connect power
Caution
•Risk of product damage! Make sure that the power
voltage corresponds to the voltage printed on the back
or underside of the clock radio.
•Risk of electric shock! When you unplug the AC
adapter,alwayspulltheplugfromthesocket.Never
pull the cord.
Note
•The type plate is located on the bottom of the clock
radio.

8EN
Plug and set
Time has been preset at the factory.When
power is connected, the set time is displayed
automatically.
The built-in lithium battery can maintain clock
setting despite power interruption.
Select time zone
You can adjust time zone setting according to
your location.
1 In standby mode, press TIME ZONE.
» The current time zone number blinks
on the display.
2 Rotate the main knob to set time zone.
3 Presstheknobtoconrm.
For China:
China Standard Time (CST) +8 (Default)
Xinjiang Time +6
Set clock
If the preset time is inaccurate, you can set time
and date manually.
1 In standby mode, press SET TIME to
activate clock setting mode.
» The hour digits begin to blink.
2 Rotate the main knob to adjust hour.
3 Presstheknobtoconrm.
» The minute digits begin to blink.
4 Repeat Steps 2-3 to set the minute, 12/24
hour format, year, month, day, and month-
day display mode in sequence.
Tip
•In time and date setting mode, if you press and hold the
knob for 3 seconds, the clock radio will save the change
and quit the setting mode.

9EN
4 Listen to FM/
MW radio
Tune to radio stations
Tip
•Position the antenna as far as possible from TV,VCR, or
other radiation source.
•For better reception, fully extend and adjust the
position of the antenna.
1 Press FM/MW to select FM or MW tuner
source.
2 Press TUNING MODE repeatedly until
[FIND](nd)blinks.
3 Rotate the main knob slowly.
» The clock radio tunes to a station with
strong reception automatically.
4 Presstheknobtoconrm.
5 Repeat Steps 3-4 to tune to more radio
stations.
To tune to a station manually:
1 In tuner mode, press TUNING MODE
repeatedly until [STEP] (step) blinks.
2 Rotate the knob slowly to select a
frequency.
Store radio stations
automatically
You can store a maximum of 20 FM radio
stations and 10 MW radio stations.
1 In tuner mode, press TUNING MODE
repeatedly until [AUTO] (auto) blinks.
2 Rotate the main knob slowly.
» The clock radio stores all the available
FM/MW radio stations and broadcasts
therstavailablestationautomatically.
Store radio stations manually
1 Tune to a radio station.
2 Press PROG.
» The preset number begins to blink.
3 Rotate the main knob to select a number.
4 Presstheknobtoconrm.
» [DONE] (done) is displayed.
5 Repeat steps 1 to 4 to store other stations.
Note
•To remove a pre-stored station, store another station
in its place.
Select a preset radio station
In tuner mode, press PRESET, then rotate the
main knob to select a preset number.
Adjust volume

10EN
5 Other features
Display indoor/outdoor
temperature
Adjust temperature display
1 Press DISPLAY.
2 Rotate the knob to select a temperature
display mode for the main unit:
• Display indoor temperature;
• Display outdoor temperature detected
from channel 1/2/3; or
• Display indoor and outdoor
temperature alternatively.
3 Presstheknobtoconrm.
Tip
•To convert between Centigrade (°C) and Fahrenheit
(°F) temperature display, adjust °C/°F slide inside the
battery compartment of the sensor.
•If the main unit fails to receive signal from the sensor,
only indoor temperature can be displayed.
Improve sensor reception
When battery is correctly installed in the sensor,
the sensor starts to transmit RF signal to the
main unit through Channel 1/2/3.
To improve the sensor reception:
• Adjust the CHANNEL control inside the
battery compartment of the sensor.
• Reduce the distance between the main
unit and the sensor.
• Press RESET on the sensor to restart
transmission, in case of sudden error or
abnormal state.
To change to Channel 2 or 3 to transmit RF
signal:
1 Press DISPLAY.
2 Rotate the knob until the corresponding
icon appears.
3 Presstheknobtoconrm.
4 Switch the CHANNEL control to 2or 3.
» The main unit and sensor begin to
detect signal from Channel 2or 3 and
then display the outdoor temperature.
Enjoy nature sound
This clock radio provides realistic nature sounds
of rooster, forest, sea, rain, bell, and bird.
1 Press NATURE SOUND.
2 Rotate the knob to select a nature sound.
3 Presstheknobtoconrm.
4 Rotate the knob to adjust the volume level
of the nature sound (0-8).
5 To deactivate the nature sound, press the
knob again.
Set alarm timer
Set alarm
You can set two alarms to ring at different time.
Note
•Make sure that the clock is set correctly.
1 In standby mode, press and hold AL1/AL2
for two seconds to activate alarm setting
mode.
» The hour digits and [AL1]/[AL2] blink.
2 Rotate the main knob to adjust hour.

11 EN
3 Pressthemainknobtoconrm.
» The minute digits and [AL1]/[AL2]
blink.
4 Repeat step 2-3 to set minute.
5 Repeat step 2-3 to select whether to ring
alarm for the whole week, on weekdays
(Monday to Friday), or on the weekend
(Saturday and Sunday).
6 Repeat steps 2-3 to select an alarm source:
radio, buzzer, or a nature sound.
7 Repeat steps 2-3 to set the alarm volume.
Activate/deactivate alarm timer
1 Press AL1/AL2 to view alarm settings.
2 Press AL1/AL2 again to activate or
deactivate the alarm timer.
» [AL1]/[AL2] appears if alarm timer is
on and disappears if it is off.
• To stop the ringing alarm, press the
corresponding AL1/AL2.
» The alarm repeats ringing for the next
day.
Snooze the alarm
When alarm sounds, press SNOOZE.
» The alarm snoozes and repeats ringing
nine minutes later.
Set sleep timer
This clock radio can switch to standby mode
automatically after a preset period.
1 Press SLEEP.
2 Rotate the main knob to select the sleep
timer period (in minutes).
3 Presstheknobtoconrm.
» When the sleep timer is activated,
appears.
To deactivate the sleep timer:
In sleep timer setting mode, rotate the knob
until [OFF] (off) appears, then press the knob.
Select DST (daylight saving
time) mode
For countries with daylight saving time (DST),
the clock radio offers you DST option to adjust
summer time.
In standby mode, press and hold DST for 3
seconds.
» The clock advances by one hour and [DST]
is displayed.
Adjust display brightness
Press BRIGHTNESS repeatedly to select
different brightness levels: [HI] (high), [MID]
(mid), and [LOW] (low).
15 30 60 90 120
OFF

12EN
6 Product
information
Note
•Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output Power 0.6 W RMS
Tuner
Tuning Range FM: 87.5 - 108 MHz
MW: 531-1602 KHz
Sensitivity
-Mono,26dBS/NRatio
FM: <22 dBu
MW: <92 dBuV/M
Search Selectivity FM: <28 dBf
MW:<98 dBuV/M
Total Harmonic
Distortion
FM: <3%
MW:<5%
SignaltoNoiseRatio FM: >45 dB
MW:>40 dB
General information
AC Power Model :
ACC060V0450T;
Input : 220V ~, 50Hz;
Output : AC6V, 450mA
Operation Power
Consumption <5 W
Standby Power
Consumption <2 W
Dimensions - Main Unit
(W x H x D) 197 x 80 x 45 mm
Weight (Main Unit) 0.5 kg
7 Troubleshooting
Warning
•Neverremovethecasingofthisdevice.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page
(www.philips.com/support).When you contact
Philips, make sure that the device is nearby
and the model number and serial number are
available.
No power
•Ensure that the AC power plug of the
clock radio is connected properly.
•Ensure that there is power at the AC
outlet.
No response from the clock radio
•Disconnect and reconnect the AC power
plug, then turn on the clock radio again.
Poor radio reception
•Keep the clock radio away from other
electronic devices to avoid radio
interference.
•Fully extend and adjust the position of the
FM antenna.
No signal detected from the sensor
•Check if the battery is correctly installed in
the sensor.
•Reduce the distance between the main
unit and the sensor.
•Press RESET on the sensor to restart
transmission.
•Change to another channel to transmit
signal.

13 EN
8 Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
Neverdisposeofyourproductwithother
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products and batteries.
The correct disposal of these products helps
prevent potentially negative consequences on
the environment and human health.
Your product contains batteries, which cannot
be disposed of with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries.The correct
disposal of batteries helps prevent potentially
negative consequences on the environment and
human health.
Please visit www.recycle.philips.com for
additional information on a recycling center in
your area.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
This is CLASS II apparatus with double
insulation, and no protective earth provided.
2012©KoninklijkePhilipsElectronicsN.V.All
rights reserved.
Specicationsaresubjecttochangewithout
notice.Trademarks are the property of
KoninklijkePhilipsElectronicsN.V.ortheir
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.

Specifications are subject to change without notice
© 2012 Koninklijke Philips Electronics N.V.
All rights reserved.
AJ7010_93_UM_V1.0
