Philips AJB3552 User manual

AJB3552
EN User manual
Register your product and get support at
www.philips.com/welcome
AJB3552_05_UM_V1.1.indd 1 6/11/2010 10:34:33 AM

Contents
1 Important 5
Safety 5
Notice 7
2 Your DAB clock radio 9
Introduction 9
What’s in the box 9
Overview of the main unit 10
3 Get started 13
Connect power 13
Set clock 14
Turn radio on/off 15
4 Listen to Digital Audio Broadcasts (DAB) 16
Scan DAB radio stations automatically 16
Tune to a DAB radio station 17
Search for DAB radio station manually 17
Store favorite DAB radio stations in memory 17
Listen to a preset DAB radio station 18
Show DAB information 18
Use DAB menu 19
Select DRC setting 19
3EN
AJB3552_05_UM_V1.1.indd 3 6/11/2010 10:34:33 AM

4EN
5 Listen to FM radio 21
Tune to a radio station 21
Scan for FM radio stations 21
Store favorite FM radio stations in memory 22
Listen to a preset FM radio station 22
Display RDS information 22
Select FM radio searching scope 23
6 Adjust settings 24
Adjust time setting 25
Select backlight settings 26
Set alarm timer 27
Set the sleep timer 30
Enhance bass 30
7 Product information 31
Specications 31
8 Troubleshooting 33
AJB3552_05_UM_V1.1.indd 4 6/11/2010 10:34:33 AM

5EN
1 Important
Safety
Important safety instructions
aThe apparatus shall not be exposed to dripping or
splashing.
bDo not place any sources of danger on the apparatus
(e.g. liquid lled objects, lighted candles).
cNever insert objects into the ventilation slots or
other openings on the apparatus.
dProtect the power cord from being walked on or
pinched, particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
eUnplug this apparatus during lightning storms or when
unused for long periods of time.
f Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
AJB3552_05_UM_V1.1.indd 5 6/11/2010 10:34:33 AM

6EN
Safety-Important notes for users in the U.K.
Mains plug
Thisapparatusisttedwithanapproved13Ampplug.
To change a fuse in this type of plug proceed as follows:
aRemove fuse cover and fuse.
b Fix new fuse which should be a BS1362 3 Amp,
A.S.T.A. or BSI approved type.
c Ret the fuse cover.
How to connect a plug
The wires in the mains lead are coloured with the following
code: blue = neutral (N), brown = live (L).
As these colours may not correspond with the colour markings
identifying the terminals in your plug, proceed as follows:
Connect the blue wire to the terminal marked N or
•
coloured black.
Connect the brown wire to the terminal marked L or
•
coloured red.
Do not connect either wire to the earth terminal in the
•
plug, marked E (or e) or coloured green (or green and
yellow).
Before replacing the plug cover, make certain that the cord
grip is clamped over the sheath of the lead - not simply over
the two wires.
AJB3552_05_UM_V1.1.indd 6 6/11/2010 10:34:33 AM

7EN
Notice
This product complies with the radio interference requirements
of the European Community.
Recycling
Your product is designed and manufactured with high quality
materials and components, which can be recycled and reused.
When you see the crossed-out wheel bin symbol attached to
a product, it means the product is covered by the European
Directive 2002/96/EC:
Never dispose of your product with other household waste.
Please inform yourself about the local rules on the separate
collection of electrical and electronic products. The correct
disposal of your old product helps prevent potentially negative
consequences on the environment and human health.
Environmental information
All unnecessary packaging has been omitted. We have tried
to make the packaging easy to separate into three materials:
cardboard (box), polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
AJB3552_05_UM_V1.1.indd 7 6/11/2010 10:34:34 AM

8EN
Your system consists of materials which can be recycled
and reused if disassembled by a specialized company. Please
observe the local regulations regarding the disposal of
packaging materials, exhausted batteries and old equipment.
Anychangesormodicationsmadetothisdevicethatarenot
expressly approved by Philips Consumer Lifestyle may void
the user’s authority to operate the equipment.
2010 © Koninklijke Philips Electronics N.V. All rights reserved.
Specicationsaresubjecttochangewithoutnotice.
Trademarks are the property of Koninklijke Philips Electronics
N.V. or their respective owners. Philips reserves the right to
change products at any time without being obliged to adjust
earlier supplies accordingly.
AJB3552_05_UM_V1.1.indd 8 6/11/2010 10:34:34 AM

9EN
2 Your DAB clock
radio
Congratulations on your purchase, and welcome to Philips! To
fullybenetfromthesupportthatPhilipsoffers,registeryour
product at www.philips.com/welcome.
Introduction
With this unit, you can:
listen to either digital radio (DAB) or analog FM radio
•
know the time•
wake up by DAB/FM radio or buzzer alarm.•
The unit offers Dynamic Bass Boost (DBB) to enrich sound.
What’s in the box
Check and identify the contents of your package:
Main unit
•
Power adaptor•
User manual•
AJB3552_05_UM_V1.1.indd 9 6/11/2010 10:34:34 AM

10 EN
Overview of the main unit
a BACK
Return to previous menu.
•
Cancel a selection.•
bINFO/MENU
Access DAB/FM menu.
•
Display DAB/RDS information.•
cDBB
Turn on or off dynamic bass enhancement.
•
a
b
c
d
e
m
n
o
l
k
j
i
h
g
f
AJB3552_05_UM_V1.1.indd 10 6/11/2010 10:34:34 AM

11EN
dSLEEP
Set sleep timer.
•
e/
Navigate through the DAB/FM menu.•
Select a preset radio station.•
Scan for previous/next radio station.•
fDisplay panel
Show status.
•
gLight sensor
For backlight brightness adjustment.
•
hMINUTE/VOLUME
Set minute.
•
Adjust volume.•
i HOUR/TUNING +/-
Set hour.
•
Tune to a radio station.•
j SET ALARM/CLOCK/SET TIME
Set alarm/time.
•
Switch to clock screen.•
k REPEAT ALARM•SELECT
Repeat alarm.
•
Conrmselection.•
lALARM ON/OFF
Turn on/off alarm timer.
•
mRADIO ON/OFF
Turn on/off radio.
•
AJB3552_05_UM_V1.1.indd 11 6/11/2010 10:34:35 AM

12 EN
nSOURCE
Select DAB/FM source.
•
oAUTOSCAN
Scan radio stations.
•
Store favorite radio stations in memory.•
AJB3552_05_UM_V1.1.indd 12 6/11/2010 10:34:35 AM

13EN
3 Get started
If you contact Philips, you will be asked for the model and serial
number of this apparatus.The model number and serial number
are on the bottom of the apparatus.Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Connect power
Caution
Risk of product damage! Ensure that the power voltage corresponds•
to the voltage printed on the back or underside of the apparatus.
Risk of electric shock! When you unplug the AC adaptor, always
•
pull the plug from the socket. Never pull the cord.
Before connecting the AC adaptor, ensure that you have completed
•
all other connections.
Note
The type plate is located on the bottom of the main unit.•
AJB3552_05_UM_V1.1.indd 13 6/11/2010 10:34:35 AM

14 EN
1Connect the AC adaptor to the DC socket on the
apparatusrstandthentothepowersocket.
Set clock
1In standby mode, rotate SET ALARM/CLOCK/SET
TIME to the SET TIME position.
The hour and minute digits begin to blink.»
2Rotate HOUR to set the hour.
3Rotate MINUTE to set the minute.
4Rotate the SET ALARM/CLOCK/SET TIME to the
CLOCKpositiontoconrm.
AJB3552_05_UM_V1.1.indd 14 6/11/2010 10:34:36 AM

15EN
Turn radio on/off
1In standby mode, press RADIO ON/OFF to turn on
radio.
The last listened DAB or FM station broadcasts»
automatically.
Tip
You can also turn on radio by pressing•SOURCE.
To turn radio off, press
•RADIO ON/OFF.
AJB3552_05_UM_V1.1.indd 15 6/11/2010 10:34:36 AM

16 EN
4 Listen to Digital
Audio Broadcasts
(DAB)
Digital Audio Broadcasting (DAB), is a way of broadcasting radio
digitally through a network of transmitters. It provides you with
more choice, better sound quality, and more information.
1Press SOURCE repeatedly to select DAB.
The unit automatically scans DAB radio stations.The»
unit stores all available DAB radio stations and then
broadcaststherstavailablestation.
If no DAB service is available,»[No DAB Station] is
displayed, and then [Autoscan] is displayed.
Scan DAB radio stations automatically
You can perform full scan to search for DAB radio stations.
1In DAB mode, press AUTO SCAN for over 3 second.
The unit scans all available DAB radio stations and»
broadcaststherstavailablestation.
AJB3552_05_UM_V1.1.indd 16 6/11/2010 10:34:36 AM

17EN
Tune to a DAB radio station
1In DAB mode, rotate TUNING +/- to navigation through
available DAB stations.
2Press SELECTtoconrm.
Search for DAB radio station
manually
1In DAB mode, press INFO/MENU for over 3 seconds.
2Press /to select [Manual tune], then press SELECT.
3Rotate TUNING +/- to navigate DAB radio frequency.
4Press SELECTtoconrm.
Searching starts.»
5When searching is complete, press SELECT again to
start playing.
Store favorite DAB radio stations in
memory
You can store up to 20 DAB radio stations in preset channel.
1Select the DAB radio station.
2Press AUTO SCAN.
The preset channel number is displayed.»
AJB3552_05_UM_V1.1.indd 17 6/11/2010 10:34:36 AM

18 EN
3Press / to select a number: 1- 20.
4Press SELECTtoconrm.
5Repeat steps 1-4 to store other stations.
Note
To remove a pre-stored DAB radio station, store another station•
in its place.
Listen to a preset DAB radio station
1Press / to select a preset DAB radio channel.
2Press SELECTtoconrm.
Show DAB information
1During listening to DAB radio, press INFO/MENU
repeatedly to scroll through the following information
(if available):
Dynamic Label Segment (DLS)
•
Signal strength•
Program type (PTY)•
Ensemble Name•
Channel and frequency•
Signal error rate•
AJB3552_05_UM_V1.1.indd 18 6/11/2010 10:34:36 AM

19EN
Bit rate and audio status•
Date•
Use DAB menu
You can remove all invalid stations from the available DAB
station list.
1In DAB mode, press INFO/MENU for over 3 seconds.
2Press / repeatedly until [Prune] is displayed.
3Press SELECTtoconrm.
»[No][Yes] is displayed.
4Press / to select [Yes].
5Press SELECT.
All invalid stations are removed.»
Select DRC setting
During listen to DAB radio, you can change DRC (Dynamic
Range Control) settings to adds or removes a degree of
compensation for dynamic range of audio performance.
1In DAB mode, press MENU for over 3 seconds.
2Press / until [DRC] is displayed.
3Press SELECTtoconrm.
AJB3552_05_UM_V1.1.indd 19 6/11/2010 10:34:37 AM

20 EN
4Press / repeatedly to select an option:
• [DRC off]: DRC is switched off.
• [DRC high]: DRC is switched on. Recommend to
use this setting in noisy environment.
• [DRC low]: DRC is set to half normal level.
5Press SELECTtoconrmtheselection.
AJB3552_05_UM_V1.1.indd 20 6/11/2010 10:34:37 AM

21EN
5 Listen to FM radio
Tune to a radio station
Tip
Position the antenna as far as possible from TV, VCR or other•
radiation source.
For optimal reception, fully extend and adjust the position of
•
the antenna.
1Press SOURCE repeatedly to select FM tuner.
2Press and hold or .
The radio tunes to a station with strong reception»
automatically.
To tune to a weak station, rotate»TUNING +/- until
youndoptimalreception.
Scan for FM radio stations
1In FM radio mode, press and hold AUTO SCAN for
over 3 seconds.
up to 20 FM stations with strong signal are stored in»
channel 1 - 20.
The station stored in channel 1 starts broadcasting.»
AJB3552_05_UM_V1.1.indd 21 6/11/2010 10:34:37 AM
