Philips Senseo HD7811 User manual

HD7811, HD7810 Coffee Machine

IMPORTANT
SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed including the following:
Read all instructions before using the appliance.
1. Do not touch hot surfaces. Use handles or knobs. Care must be
taken to prevent burns which can occur from touching hot parts
or spilling hot liquids.
2.To protect against fire, electrical shock and injury to persons, do
not immerse cord, plug, or appliance in water or other liquid.
3. Close supervision is necessary when any appliance is used by or
near children.
4. Unplug from outlet when not in use and before cleaning. Allow to
cool before putting on or taking off parts and before cleaning
appliance.
5. Do not operate this appliance with a damaged cord or plug, or
after the appliance malfunctions or has been damaged in any
manner. Return the Coffee Machine to the nearest Authorized
Norelco Service Location for examination, repair or adjustment.
6. Use this appliance only for its intended purpose as described in
this manual. Do not use accessory attachments not recommended
by Philips Electronics North America Corporation as they may
result in fire, electric shock or injury to persons.
7. Do not use outdoors.
8. Do not let cord hang over edge of table or counter or touch hot
surfaces. Operate on a flat, stable surface away from edge of
counter to prevent accidental tipping.
9. Do not place Coffee Machine on or near a hot gas or electric
burner, or in a microwave or heated oven.
10.This appliance is intended for household use ONLY; it is not for
commercial or industrial use.
11. Any service to the Coffee Machine should be performed by the
nearest Authorized Norelco Service Location.
12.To disconnect Coffee Machine, press power button (I) to ‘OFF’,
then remove plug from electrical outlet. Remove plug by gripping
plug body and pulling it from the outlet. Never yank or twist cord
to unplug.
13. Do not use Coffee Machine if lid has a cracked, loose, weakened
or damaged lever.
14.This appliance does not work at temperatures below 50ºF/10ºC.

15. Do not use this appliance at altitudes higher than 6800 ft./
2200m above sea level.
16. Flush the Coffee Machine with fresh water before using it for
the first time (See ‘Preparing the machine for use’).This will
cause the boiler to fill with water; which is essential for the
machine to work properly.
17.To prevent scalds and/or property damage, always make sure
Coffee Machine lid is securely in place and properly locked
before you start using the machine and during brew cycle. Do
not force when opening or closing lid.
18. Do not open lid until Coffee Machine has finished brew cycle.
Hot steam or hot water trapped under lid cover could burn
your fingers.
19.Warning:To reduce the risk of fire or electric shock,
do not remove the bottom cover. No user serviceable
parts are inside. Return the Coffee Machine to the
nearest Authorized Norelco Service Location for
examination, repair or adjustment.
SAVE THESE
INSTRUCTIONS
SPECIAL INSTRUCTIONS
This Coffee Machine has a short cord to reduce the hazards of
becoming entangled in or tripping over a longer cord. An extension
cord may be used if the rating is equal to or greater than the rating
of the Coffee Machine. Use an extension cord rated 13 amperes or
greater. Care must be taken to arrange extension cord so that it
does not hang over the edge of counter top or table top, where it
can be pulled on by children or tripped over unintentionally.
Operating the Coffee Machine and another appliance at the same
time from the same electrical circuit could cause an electrical
overload, which would blow the fuse or trip the circuit breaker.
SPECIAL POLARIZED PLUG
INSTRUCTIONS
This Philips Coffee Machine has a polarized plug (one blade is wider
than the other) as an added safety feature.To reduce the risk of
electric shock:
- Plug will fit into polarized outlet only one way.
- If plug does not properly fit into outlet at first, reverse it.
- If plug still does not fit, contact a qualified electrician.
DO NOT ATTEMPT TO DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
3

WARNING:
- To avoid risk of personal injury or damage to property as a result
of overflow, be sure that the cup or mug is centered under the
coffee outflow unit during the brew cycle.
- Brewed coffee and coffee pods are very hot. Handle with care to
avoid scalding.
- If coffee outflow unit overflows or fails to drain into cup/mug
during brewing cycle, do not open lid or handle coffee outflow
unit or coffee pod holder(s). Unplug Coffee Machine and wait for
contents to cool before handling.
- Do not remove any part of Coffee Machine or cup/mug during
the brew cycle as scalding could occur.
- Use only fresh, cool water in this appliance. Do not put any other
liquids in this appliance except as instructed in the ‘Descaling’
section. Do not refill the water reservoir with hot water or
coffee.
- DO NOT attempt to move an appliance containing hot liquids or
during the brewing process. Allow appliance to cool completely
before moving.
- Keep appliance at least 4 inches away from walls or other objects
while operating. Do not place any object on top of coffee
machine while operating.
PLEASE READ AND SAVE THIS
INSTRUCTION BOOKLET.
4

5
TABLE OF CONTENTS
Features 6
Introduction 7
Preparing the machine for use 8
Brewing coffee 10
Cleaning 12
Descaling 13
Storage 14
Assistance 15
Trouble shooting guide 15
Warranty 17

6
HD7
8
1
0
HD7
8
1
1
Features
AWater reservoir
BReservoir splash guard
C1-pod holder; for 1 small cup of coffee (125 ml/app. 4.0 oz)
D2-pod holder, for 2 small cups of coffee (125 ml/app. 4.0 oz each)
or 1 mug of coffee (250 ml/app. 8.0 oz)
ECoffee outflow unit
FCover of coffee outflow unit
GDrip tray
HCup tray
IMetal distribution disk
JSealing ring
KOutflow valve
LIndicator light

7
Introduction
With the Senseo™ coffee machine by Philips you can enjoy a perfect
cup of coffee - topped with a rich frothy coffee layer - whenever you
feel like it. Each cup is freshly brewed, so you're always sure of that
pure, smooth taste.The patented Senseo brewing system from Philips
in combination with the special Senseo coffee pods makes sure you get
only the very best in flavor and aroma from freshly roasted coffee.
To optimize the taste of the coffee, you should keep the following
aspects in mind:
Fresh water
Use fresh water every day. Before using for the first time or if you have
not used the machine for some time, rinse the water reservoir, fill it
with fresh water and flush the machine before you begin brewing
coffee (see ‘Preparing the machine for use’).
Senseo coffee pods
In order to avoid damage, use only Senseo coffee pods that have been
specifically developed for your Senseo coffee machine for a pure,
smooth taste.The Senseo coffee pods will stay fresh longer if you close
the package by means of the keep-fresh seal after use or if you store
them in a storage container.
A clean machine
Scale build-up may cause overheating of the heating element and may
make the safety cut-out operate prematurely, switching off before the
water boils. Scale may also reduce the working life of the machine and
may lengthen the brewing time.
Clean and descale your Philips Senseo coffee machine regularly (see
'Cleaning' and 'Descaling'). Remove used coffee pods after brewing. If a
used pod has been left in the coffee machine and you have not used
the machine for some time, flush the machine before you use it again
(see 'Preparing the machine for use').

Preparing the machine for use
◗Use this Senseo coffee machine for its intended household use as
described in this manual.
YOU CANNOT BREW COFFEE IF YOU HAVE NOT
FLUSHED THE SENSEO COFFEE MACHINE FIRST!
The flushing cycle causes the boiler to be filled with water. After this
the coffee machine is ready for use.
Flush the machine in the following way:
C1Remove the water reservoir.
C2Fill the water reservoir with cold water up to the MAX
indication and put it back into the machine.
C3Release the lid by moving the lever upwards.
C4Open the lid.
8

C5Put either the 1- or 2-pod holder in the machine without using
any coffee pod(s).
C6Close the lid and lock the lever.
BMake sure the lever is properly locked by pushing it down until it snaps
home with a click.
BNever flush the machine with the lid open! The lid must be properly
locked.
7Put the plug into a 120V AC electrical outlet.
C
8Put a bowl (with a capacity of at least 1.5 liters/1.6 qt.) under
the coffee outflow unit to collect the water.
C9Press on/off button I.Then press both the °and °°
buttons briefly at the same time.
◗The machine will fill itself with water from the water reservoir.
This will take some time and you will probably not notice that this
is happening.After a while, the machine will start flushing and it will
switch itself off after the flushing cycle. During the flushing cycle
the machine produces more noise than during a regular brewing
cycle.
BBefore brewing coffee for the first time, clean the coffee outflow unit and
the pod holders with hot water and some dish soap or in a dishwasher.
Clean the water reservoir thoroughly in hot water, if necessary with some
dish soap.
◗Now your Philips Senseo coffee machine is ready for use!
9
CLICK

Brewing coffee
C1Fill the water reservoir with cold water up to the MAX
indication and put it back into the machine.
Never pour milk, coffee, hot water or carbonated water into the water
reservoir.
-°MIN: minimum amount of water required to brew one 4.0 oz.
cup of Senseo coffee.
-°° MIN: minimum amount of water required to brew one 8.0 oz.
mug or two 4.0 oz. cups of Senseo coffee.
- HD7810: A full reservoir allows you to make up to five 4.0 oz. cups
Senseo coffee.
- HD7811: A full reservoir allows you to make up to ten 4.0 oz. cups
Senseo coffee.
C2Press on/off button I.
The indicator light blinks while the water is heating up. Heating up takes
approx. 90 seconds.
◗The coffee machine is ready for use when the indicator light is lit
continuously.
C3Release the lid by moving the lever upwards.
4Open the lid.
5First place the appropriate coffee pod holder in the machine.
BMake sure the coffee pod holder is clean and the small hole in the
center is not clogged (i.e. with loose coffee grounds).
C◗If you want to make one 4.0 oz. cup of Senseo coffee, use the 1-
pod holder.
C◗If you want to make one 8.0 oz. mug or two 4.0 oz. cups of
Senseo coffee, use the deeper 2-pod holder.
6Place the Senseo coffee pod(s) properly in the center of the
pod holder, with the flat Senseo side up and the rounded side
facing down.
BUse Senseo coffee pods that have been specifically developed for your
Senseo coffee machine for a pure and smooth taste.
10

C◗Place 1 Senseo coffee pod in the 1-pod holder or
C◗Place 2 Senseo coffee pods in the 2-pod holder.
BMake sure the coffee in the pod(s) is evenly distributed and press the
pod(s) lightly into the pod holder.
BNever use torn pods or normal ground coffee, as this could cause the
machine to become blocked.
C7Close the lid and lock the lever.
Always check if the lid is properly locked.The lever must be pushed
down until it snaps home with a click.
Never start brewing coffee with the lid open! The lid must be properly
closed.
C8Place one cup, two cups or one mug under the outflow
openings.
If you are using cups, make sure they have a capacity of app. 5.0 oz. If
you are using a mug, make sure the mug has a capacity of app. 10.0 oz.
Do not use cups or mugs that are too large, as they will cause the
coffee to get cold more quickly. If using one cup or one mug, be sure to
position the cup or mug right under the coffee outflow unit with its
two openings
C9Press the button indicating the number of cups of Senseo
coffee you want to brew.
-°for one 4.0 oz. cup
-°° for two 4.0 oz. cups or one 8.0 oz. mug
◗The Senseo coffee machine starts brewing.
- The machine automatically supplies the optimal amount of water.
- You can interrupt the brewing process at any time by pressing the
on/off button I. If you switch the machine back on after having
interrupted the brewing process, the machine will NOT complete
the interrupted brewing cycle.
11
CLICK

Do not remove the water reservoir during a brewing cycle, as this will
cause the machine to draw in air.When this happens, the next cup will
only be partly filled.
If the mug/cups is/are half full when the machine stops brewing, there
was not enough water left in the water reservoir to brew two cups or
one mug. Refill the water reservoir and press button °to fill up the
two cups or mug.
10 Remove and discard the coffee pod(s) after use by lifting the
coffee pod holder out of the machine and emptying it. Coffee
pod(s) should not be used more than one time.
Be careful when doing this, for there may still be some hot
water/coffee on the coffee pod(s) or steam may escape. If the coffee
pod sticks to the metal distribution disk inside the lid, let the pod cool
down first before carefully removing it, making sure not to touch the
hot metal disk.
Tips
◗By rinsing the coffee pod holders and the coffee outflow unit
regularly, you will make sure that the coffee always tastes best.
◗Senseo coffee will taste best if you stir it before drinking it.
C◗If you intend to make another cup of Senseo coffee later, just
leave the coffee machine switched on.The machine will
automatically switch itself off after app. one hour.
Cleaning
Never immerse the Senseo coffee machine in water or any other
liquid.
Never clean the machine by flushing it with the lid open.
1Always turn machine off and unplug the machine before
cleaning it.
2Clean the outside of the machine with a moist cloth.
C3Remove the coffee outflow unit.
C◗You can disassemble the coffee outflow unit for more thorough
cleaning!
12

C4Clean the coffee outflow unit, the cup tray and the drip tray in
hot water, if necessary with some dish soap, or in the
dishwasher.
C5Clean the coffee pod holders in hot water, if necessary with
some dishwashing soap or in the dishwasher.
Check if the hole in the center of the pod holders is clogged. If the
hole is clogged, unclog it by holding the pod holder under a running
faucet. If necessary, you can use a soft brush, toothpick or a pin to
unclog the hole.
C6Clean the water reservoir in hot water, if necessary with some
dish soap or in the dishwasher.
BThe splash guard on the water reservoir can be removed to allow
thorough cleaning of the inside.
BIf you are using a soft brush or mesh covered sponge, be careful not to
damage the valve in the bottom of the water reservoir.
7Rinse the parts with fresh water after cleaning and put them
back into the machine.
C8Clean the metal distribution disk with a moist cloth.
Be careful when you do this; make sure that the rubber sealing ring
does not get stuck under the edge of the metal distribution disk. If it
does, the coffee machine will start leaking!
Descaling
Regular descaling will prolong the life of your Senseo coffee machine
and will guarantee optimal brewing results for a long time. If the
machine is used twice a day on average, it must be descaled once
every 3 months.
C1Fill the water reservoir up to the MAX indication with white
vinegar or with a mixture of descaler and water according to
the instructions on the package of the descaler.Then put the
water reservoir back into the coffee machine.
Use a citric acid based descaler.
13

C2Press on/off button I.
The machine is ready for use when the indicator light is lit continuously.
3Place the 1-pod holder in the coffee machine, preferably with a
used coffee pod in it. Close the lid and make sure it is properly
locked.
We advise you to put a used coffee pod in the pod holder when you
descale the machine, as it will serve as a 'filter' to prevent the hole in
the pod holder from getting clogged with scale residues.
C4Put a bowl with a capacity of at least 1.5 liters/1.6 qt. under the
coffee outflow unit to collect the vinegar or the mixture of
descaler and water.
C5Press button °° and let the machine operate. Repeat this
until the water reservoir is empty.
Never descale the Senseo coffee machine with the lid open. Make
sure the lid is properly locked.
6Repeat steps 1 to 5 with new vinegar or a new mixture of
descaler and water.
7Empty the water reservoir to remove the last vinegar or
mixture of descaler and water. Repeat step 1 to 5 with fresh
water only (i.s.o. vinegar or descaler) at least 3 times to fully
clean the machine. Discard hot water each time.
◗Do not refill water reservoir with used hot water.
8Discard the used coffee pod and clean the coffee pod holder
after descaling to prevent the hole in the center from getting
clogged.
This coffee machine has no other user-serviceable parts. Any other
service should be performed by an Authorized Norelco Service
Location.
Storage
◗If the coffee machine has already been used and therefore has
been flushed with water, it may only be used and stored in a safe,
frost-free place to prevent it from becoming damaged.
◗Empty water reservoir before storing.
14

Assistance
For assistance call toll free: 1-866-4SENSEO (1-866-473-6736) or visit
our website: www.senseo.com.
Authorized Norelco Service Location information is available 24 hours
a day, 7 days a week.
15
Troubleshooting guide
If you experience a problem with your Philips Senseo coffee machine,
you may find the solution in the table below. If the table does not
provide the solution to your problem or if you have a question, see the
chapter 'Assistance'.
Solution
You need to flush the coffee machine. See 'Preparing the machine for
use'.
You are using the Senseo coffee machine at an altitude higher than
2200 m/6800 ft. above sea level.This has caused the water in the
machine to start boiling before it has reached the required
temperature, which prevents the machine from functioning properly.
Switch the machine off and do not use it at altitudes higher than 2200
m/6800 ft. above sea level.
The coffee machine must be flushed with water before using it for the
first time, so that the boiler will be completely filled with water. Flush
the coffee machine (see 'Preparing the machine for use') before you
start brewing coffee.
Make sure that the water reservoir has been properly placed;
Make sure that there is enough water in the water reservoir (water
level above the °MIN level if you want to brew one 4.0 oz. cup and
above °° if you want to brew one 8.0 oz. mug or two 4.0 oz. cups);
Make sure that the ambient temperature is not lower than 10cC/50cF.
If it is lower, the appliance will not function properly.
Make sure that the lid is properly closed (the lever must be properly
locked);
Make sure that the water reservoir has not been filled beyond the
MAX level;
Make sure that the hole in the center of the coffee pod holder is not
clogged. If it is, unclog the hole by holding the coffee pod holder under
a running tap. If necessary, you can use a soft brush, pin or a toothpick
to unclog the hole;
Make sure the coffee pod(s) has/have been put properly in the center
of the coffee pod holder with the flat Senseo side up;
Make sure the sealing ring has not gotten stuck under the edge of the
metal distribution disk (see drawing at the beginning of these
instructions for use);
Make sure that the drip tray does not overflow. It is unlikely that it will
overflow, but it is easier to empty when half full than full.
Problem
The indicator light continues to blink slowly
The Senseo coffee machine does not
produce coffee when used for the first time
The indicator light continues to blink rapidly
Water leaks from the coffee machine

Solution
It is perfectly normal for some drops of water to spill onto the counter.
This may happen, for instance, when you place or remove the water
reservoir. Be careful when removing used coffee pods, for there may
still be some water on the pods.
Do not remove the water reservoir when the coffee machine is
heating up, as this may cause some water to leak out of the machine
(this water would normally end up in the water reservoir).
In all other cases, contact the Authorized Norelco Service Location
nearest you.
A vacuum may have temporarily formed under the lid.Turn the
machine off. Pull the lever up as far as it will go and wait 24 hours
before opening the lid.
Make sure that the hole in the center of the coffee pod holder is not
clogged. If it is, unclog the hole by holding the coffee pod holder under
a running faucet. If necessary, you can use a soft brush or a toothpick to
unclog the hole.
If problems continue to occur, contact the Authorized Norelco Service
Location nearest you.
Descale the machine (see 'Descaling').
Check if a used coffee pod is sticking to the metal distribution disk. If
this is the case, remove the used pod. Make sure that the sealing ring is
lying flat.
Contact the Authorized Norelco Service Location nearest you.
Make sure you have used the correct number of pods and pressed the
right button. Use 1 pod in combination with the 1-pod holder and the
°button. Use 2 pods in combination with the 2-pod holder and the
°° button;
Check if the coffee pod(s) has/have been placed properly in the center
of the pod holder, to prevent water from escaping along the edge of
the pod(s).When you are using two coffee pods on top of each other,
make sure that the flat Senseo sides of both pods are facing up and
rounded sides are facing down. Press the pods lightly into the pod
holder;
Make sure you have not used the same pod twice by accident. Do not
use a pod twice, as it will give the coffee a bad taste. Use a fresh pod
for every brew;
The coffee in the pod needs to be evenly distributed;
If you prefer a more robust flavor, Senseo coffee pods with a stronger
blend are available.
If you prefer a milder flavor, Senseo coffee pods with a milder blend are
available.
Do not use cups that are too large.When using cups, make sure they
have a capacity of 150 ml/app. 5.0 oz.When using a mug, make sure it
has a capacity of 280 ml/10.0 oz.
Problem
The lid cannot be opened.
The coffee machine produces less coffee than
before.
The lid cannot be closed properly.
The machine has been stored in a room that
was not frost-free.
The Senseo coffee is not strong enough.
The Senseo coffee is too strong
The coffee is not hot enough
16

17

18

17
FULL TWO YEAR WARRANTY
Philips Electronics North America Corporation warrants each new Philips Product, model
HD7810 and HD7811 (except cord, coffee pods and accessories) against defects in materials
or workmanship for a period of two years from the date of purchase, and agrees to repair or
replace any defective product without charge.
IMPORTANT: This warranty does not cover damage resulting from accident, misuse or abuse,
lack of reasonable care, the affixing of any attachment not provided with the product or loss of
parts or subjecting the product to any but the specified voltage.* Use of unauthorized replace-
ment parts will void this warranty.
PHILIPS ELECTRONICS NORTH AMERICA CORPORATION WILL NOT PAY
FOR WARRANTY SERVICE PERFORMED BY A NON-AUTHORIZED REPAIR
SERVICE AND WILL NOT REIMBURSE THE CONSUMER FOR DAMAGE
RESULTING FROM WARRANTY SERVICE PERFORMED BY A NON-AUTHO-
RIZED REPAIR SERVICE.
NO RESPONSIBILITY IS ASSUMED FOR ANY SPECIAL, INCIDENTAL OR CONSE-
QUENTIAL DAMAGES.
In order to obtain warranty service, simply take or ship the product postage prepaid to the
nearest Authorized Norelco Service Location. It is suggested that for your protection you
return shipments of product by insured mail, insurance prepaid. Damage occurring during
shipment is not covered by this warranty.
NOTE: No other warranty, written or oral, is authorized by Philips Electronics North
America Corporation.
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state. Some states do not allow the exclusion or limitation of incidental or con-
sequential damages, so the above exclusion and limitations may not apply to you.
* Read enclosed instructions carefully.
Manufactured for: Norelco Consumer Products Company
A Division of Philips Electronics North America Corporation
1010 Washington Blvd.
Stamford, CT 06912-0015
COFFEE PODS PACKAGED IN BELGIUM.
This symbol on the product’s nameplate means it is listed by Underwriters’
Laboratories, Inc.
PHILIPS and Philips Shield are Registered Trademarks of Koninklijke Philips Electronics N.V.
Senseo is a Trademark of Koninklijke Philips Electronics N.V. when used for coffee makers.
Senseo is a Trademark of Sara Lee/DE N.V. when used for coffee pods.
© 2004 Philips Electronics North America Corporation.All Rights Reserved.
®
LISTED

www.philips.com 4222 002 29982
