Introduction
Congratulations on your purchase and welcome to Philips!To fully
benet from the support that Philips offers, register your product at
www.philips.com/welcome.
Make your coffee moments truly special with SENSEO®.This unique
system combines the easy-to-use Philips SENSEO®coffee machine with
the specially developed Douwe Egberts SENSEO® coffee pods, giving you
a full, smooth coffee with a delicious foam layer.
The SENSEO®Latte Select coffee machine offers you delicious coffee specialties
made with fresh frothed milk. Choose from cappuccino, latte macchiato,
caffè latte and regular SENSEO®black coffee - all at the touch of a button.
General description (Fig. 1)
1 Water reservoir
2 Control panel
A Coffee selector
B SENSEO®black coffee indicator
C Cappuccino indicator
D Latte macchiato indicator
E Caffè latte indicator
F CLEAN/CALC CLEAN button
G CALC CLEAN indicator
H CLEAN indicator
I Strong black coffee indicator
J Normal black coffee indicator
K Mild black coffee indicator
L Strength selector
3 Lid lever
4 Sealing ring
5 Water distribution disc
6 Milk container lever
7 Height adjustment knob for drip tray
8 Cup tray
9 Drip tray
10 Light rings
11 2-cup button qq
12 On/off button with light ring
13 1-cup button q
14 Milk container unit
15 Milk container
16 Milk tube
17 Milk container lid release lever
18 Steam inlet
19 Milk container lid, including frothing unit
20 Milk container lid cover
21 Release tab of milk container lid cover
22 Calc-Clean tool
23 Coffee spout
24 Coffee spout cover
25 1-cup pod holder q
26 2-cup pod holder qq
27 Coffee collector
ENGLISH

Important
Read this user manual carefully before you use the
machine and save it for future reference.
Danger
- Never immerse the machine in water or any other
liquid.
Warning
- Check if the voltage indicated on the bottom of
the machine corresponds to the local mains voltage
before you connect the machine.
- This appliance can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
- Children shall not play with the appliance.
- Do not use the machine if the plug, the mains cord
or the machine itself is damaged.
- If the mains cord is damaged, you must have it
replaced by Philips, a service centre authorised by
Philips or similarly qualied persons in order to avoid
a hazard.
Caution
- Correct cleaning of the milk container is very
important for reliable performance of the milk
container unit and good frothing results. See chapter
‘Cleaning the milk container unit’.
- Always return the machine to a service centre
authorised by Philips for examination or repair. Do
not attempt to repair the machine yourself, otherwise
your guarantee becomes invalid.
- Never put normal ground coffee or use torn pods in
the SENSEO® machine, as this causes it to become
blocked.
ENGLISH 7

- Do not use the machine in combination with a
transformer, as this could cause hazardous situations.
- Always put the machine on a at and stable surface.
- Never let the machine operate unattended.
- Do not use the machine at altitudes higher than
2200 metres above sea level.
- The machine does not work at temperatures
below 10°C.
- Flush the coffee machine with fresh water before
you use it for the rst time (see chapter ‘First use’).
This causes the boiler to ll with water, which is
essential for the machine to work properly.
- Do not use the SENSEO®machine in combination
with water softeners based on sodium exchange.
- Philips strongly advises you to descale this SENSEO®
machine when the CALC CLEAN indicator tells
you that descaling is required. If the machine is not
descaled in time and according to the procedure
described in chapter ‘Descaling’, this may lead to
technical failures.
- Never use a descaling agent based on mineral acids
such as sulphuric acid, hydrochloric acid, sulphamic
acid and acetic acid (e.g. vinegar). These descaling
agents may damage your SENSEO®coffee machine.
- Never turn your SENSEO® machine on its side, as
water may leak from the boiler. Always keep it in
upright position, also during transport.
- This machine is intended for normal household use
only. It is not intended for use in environments such
as staff kitchens of shops, ofces, farms or other
work environments. Nor is it intended to be used by
clients in hotels, motels, bed and breakfasts and other
residential environments.
Compliance with standards
- This machine complies with all standards regarding electromagnetic
elds (EMF). If handled properly and according to the instructions in
this user manual, the machine is safe to use based on scientic evidence
available today.
- The energy consumption of this machine in off mode is less than 1
watt.This means that this machine complies with European Directive
2005/32/EC, which sets the ecological design requirements for energy-
using products.
ENGLISH8

First use
Unpacking
1 Remove the machine from the box.
Note: Make sure that you store the loose parts, i.e. the 2-cup pod holder and
the Calc-Clean tool, in a safe place.They are essential parts of the machine.
The Calc-Clean tool is equipped with a magnet.To avoid damage, keep
the Calc-Clean tool away from credit cards, bank cards or other data
carriers that can be damaged by magnetism.
Flushing the machine to ll the boiler
YOU CANNOT BREW COFFEE IFYOU HAVE NOT FLUSHED THE
SENSEO COFFEE MACHINE FIRST!
Flushing causes the boiler to be lled with water. After this, the machine is
ready for use.
Flush the machine in the following way:
1 Place a bowl with a capacity of at least 1.5 litres on the cup tray.
2 Fill the water reservoir with cold water up to the MAX indication
and put it back onto the machine.
3 Make sure that the milk container unit is in place.
4 Make sure that a pod holder, without pod or pods, is in place.
5 Put the plug in an earthed wall socket.
ENGLISH 9

6 Press the on/off button 3.
,The light rings around the 1-cup button qand the 2-cup button
qq light up continuously.
7 Tostartushing,pressthe1-cupbuttonqand the 2-cup button
qqbrieyatthesametime.
,Duringtheushingcycle,thewaterinthewaterreservoirisushed
throughthemachineandtheboilerislledwithwater.Theushing
cycle takes some time (approx. 90 to 150 seconds).
Neverinterrupttheushingcyclehalfway.Ifyoudo,theboilerdoesnot
llitselfproperly.
Note: During the ushing cycle, the machine produces more noise than during
a regular brewing cycle.
,Themachineswitchesoffautomaticallywhentheushingcycleends.
Now your Philips SENSEO®coffee machine is ready for use.
Note: If the machine does not work, repeat steps 1-7. Do not interrupt the
ushing cycle.
Brewing SENSEO®coffee
Tips for the best SENSEO®quality
- Use fresh water every time.
- Use the SENSEO®coffee pods that have been specially developed by
Douwe Egberts for your SENSEO® coffee machine for a full, round
taste.
- Always use milk at refrigerator temperature (5-8°C) to obtain hot
frothed milk of high quality for your cappuccino, latte macchiato or
caffè latte.
- We advise you not to use rice or soy milk.These types of milk do not
produce high-quality frothed milk.
ENGLISH10

- Remove used coffee pods directly after brewing.
- Rinse the milk container unit after you have brewed a cappuccino, latte
macchiato or caffè latte with the CLEAN button (see section ‘Rinsing
after every use’ in chapter ‘Cleaning the milk container unit’).
- Clean the milk container and the lid thoroughly if you are not going
to use the milk container again that day (see section ‘Cleaning all parts
after the last use of the day’ in chapter ‘Cleaning the milk container
unit’).
- If you have not used the coffee machine for some time, ush the
machine before you use it again (see section ‘Flushing the coffee
machine in chapter ‘Cleaning the machine’) with fresh water before you
use it again.
Filling the water reservoir
1 Fill the water reservoir with cold water to a level above the MIN
indication and place it back onto the machine.
The MIN indication indicates the minimum amount of water required for
brewingcoffee.AlwaysllthewaterreservoirbeyondtheMINlevel.
Never pour milk, coffee, hot water or carbonated water into the water
reservoir.
Switching on the machine
1 Put the plug in an earthed wall socket.
2 Press the on/off button 3.
,Thelightringlightashesslowlywhilethewaterisheatingup.
Heating up takes approx. 90 seconds.
,The coffee machine is ready for use when the light ring around the
on/off button lights up continuously.
,Ifthelightringaroundtheon/offbuttonashesrapidly,thewater
reservoir does not contain enough water for brewing coffee.
Placing a pod holder
1 Move the lid lever upwards to release the lid.
2 Open the lid.
3 Place the appropriate pod holder in the machine.
Note:You can only brew 2 cups at the same time if you brew SENSEO®black
coffee.
ENGLISH 11

- Use the 1-cup pod holder q if you want to make cappuccino, latte
macchiato or caffè latte or one cup of SENSEO® black coffee,
- Use the 2-cup pod holder qq if you want to make two cups of
SENSEO®black coffee.
Placing one or two pods
Never put normal ground coffee or use torn pods in the SENSEO®
machine, as this causes it to become blocked.
1 Place the SENSEO®coffee pod or pods properly in the centre of the
pod holder, with the convex side pointing downwards.
- Place 1 SENSEO®coffee pod in the 1-cup pod holder q.
- Place 2 SENSEO®coffee pods in the 2-cup pod holder qq.
Note: Make sure that the coffee in the pod or pods is evenly distributed and
press the pod or pods lightly into the pod holder.
ENGLISH12

2 Close the lid and lock the lid lever.
Make sure that you push down the lid lever until it snaps home with a click.
Note: Make sure the lid is closed properly and the lid lever is locked before you
start brewing coffee.
Selecting the desired coffee variety
1 Press the coffee selector to select the desired coffee variety with or
without milk.
- Select Àto brew SENSEO®black coffee.
- Select fto brew cappuccino.
- Select gto brew latte macchiato.
- Select bto brew caffè latte.
2 If you have selected SENSEO®black coffee À, press the strength
selector to select the desired coffee strength. By varying the
strength, you also change the amount of coffee that is brewed.
- Select e for a smaller amount of strong black coffee (60ml).
- Select d for a normal amount of normal black coffee (125ml).
- Select c for a larger amount of mild black coffee (145ml).
Note:You cannot press the strength selector when you have selected one of the
coffee varieties with milk.
Filling the milk container unit
Note:This section only applies if you have selected one of the coffee varieties
with milk as described in the previous section ‘Selecting the desired coffee
variety’. If you have selected SENSEO®black coffee, go straight to section
‘Adjusting the cup tray height’.
1 Pullthemilkcontainerleverupwardswithyourngertoreleasethe
milk container unit.
2 Pull the milk container unit forwards to remove it from the machine.
ENGLISH 13

3 Press the milk container lid release lever (1), tilt the milk container
lid slightly (2) and pull the milk container lid upwards to remove it
from the milk container (3).
4 Fill the milk container with cold milk straight from the refrigerator
(5-8°C) up to the level required for the coffee variety.
Note:The amount of milk added to the coffee may vary due to variations in
milk temperature or type of milk. It may also depend on how clean the milk
container unit is.
5 Fasten the milk container lid onto the milk container (‘click’).
Alwayscheckifthelidisxedproperlyontothemilkcontainerto
prevent spillage when you place the milk container unit in the machine.
6 Slide the milk container unit into the coffee machine (1) and push
down the milk container lever (‘click’) (2).
Note: Push down the milk container lever as far as possible (‘click’) to make
sure that the milk container unit is placed properly in the machine.You only
obtain properly frothed milk if the milk container unit is placed properly.
Adjusting the cup tray height
1 Place one or two cups under the coffee spout.
Tip: Do not use cups that are too large as they cause the coffee to get cold
more quickly.
2 To minimise splattering, turn the knob to adjust the height of the cup
tray so that the top of your cup is just under the spout.
ENGLISH14

Brewing the desired coffee variety
1 Press the button indicating the number of cups of SENSEO®coffee
you want to brew.
- Press the 1-cup button qfor one cup of SENSEO® black coffee,
cappuccino, latte macchiato or caffè latte.
- Press the 2-cup button qq for two cups of SENSEO®black coffee.
,The SENSEO®coffee machine starts brewing and automatically
supplies the correct amount of water and milk, depending on the
coffee variety you have selected.
Do not remove the water reservoir during a brewing cycle, as this
causes the machine to draw in air.When this happens, the next cup is
onlypartlylled.
Do not remove the milk container during a brewing cycle.
2 Remove the coffee pod or pods after use by lifting the pod holder
out of the machine and emptying it.
Be careful when you do this, as there may still be some water or coffee on
the coffee pod or pods.
Coffee varieties with milk
Each coffee variety with milk has its own distinctive brewing process:
- Cappuccino fis a rich combination of one-third coffee and two-
thirds of freshly frothed hot milk with a creamy froth layer.When
you brew a cappuccino, your cup is rst lled with hot milk froth and
then strong black coffee is brewed onto the froth.This causes the
coffee to sink below the froth layer.
Note: It is not possible to brew 2 cups of cappuccino at the same time. If you
want to brew 2 cups of cappuccino, you have to ll the milk container up to
the 2-cup cappuccino indication and brew two cups of cappuccino after each
other by pressing the 1-cup button n.
- Latte macchiato gis a 3-layer drink. It contains more milk than
coffee. When you brew a latte macchiato, the machine rst lls your
cup with hot milk and milk froth and then stops for 15 seconds. During
this time the milk sinks below the froth.Then the machine brews black
coffee, which also sinks below the froth and settles above the layer of
hot milk.
- Caffè latte bis a drink that contains milk and coffee in more or less
equal amounts. When you brew a caffè latte, your cup is rst lled with
coffee and then hot frothed milk is added.
Note: Each time you have used the milk container unit to brew a coffee
variety with milk, the CLEAN indicator lights up to remind you to rinse the
milk container unit if you no longer intend to brew a coffee variety with milk
straightaway. See section ‘Rinsing after every use’ in chapter ‘Cleaning the milk
container unit’
ENGLISH 15

Interrupting the brewing process
1 Press the on/off button 3to interrupt the brewing process.
Note: If you switch the machine back on after having interrupted the brewing
process, the machine does not complete the interrupted brewing cycle.
Switching off
1 After use, press the on/off button 3to switch off the machine.
Note: If you do not switch off the machine, it switches off automatically after
30 minutes.
Cleaning the milk container unit
It is important that you clean the milk container unit regularly and
thoroughly. Only a properly cleaned milk container unit performs well and
produces consistently good frothing results.
1 If you do not plan to brew a coffee variety with milk again straightaway,
rinse the milk container within 30 minutes after use.
2 After the last use of the day, clean all parts of the milk container
unit thoroughly.
To clean the milk container unit properly, follow the procedure described below.
Note: If you are unable to obtain high-quality milk froth, the milk container unit
is probably dirty.
Rinsing after every use
- The CLEAN indicator lights up to remind you to rinse the milk
container unit each time after you have used the machine to brew a
coffee variety with milk.
Note: If you do not plan to brew a coffee variety with milk again straightaway,
rinse the milk container unit within 30 minutes after use.
ENGLISH16

1 Pullthemilkcontainerleverupwardswithyourngertoreleasethe
milk container unit.Then pull the milk container unit forwards to
remove it from the machine.
2 Press the milk container lid release lever (1), tilt the milk container
lid slightly (2) and pull the milk container lid upwards to remove it
from the milk container (3).
3 Pour out any milk that is left in the milk container and rinse the milk
containerbrieyunderthetap.
4 Fill the milk container with cold water up to 2-cup cappuccino ff
indication.
Note: Do not ll the milk container with warm or hot water. If you do, the
machine only produces steam and does not clean the milk container unit
properly.
5 Fasten the milk container lid onto the milk container (‘click’).
6 Slide the milk container unit into the coffee machine (1) and push
down the milk container lever (‘click’) (2).
7 Place an empty cup under the coffee spout.
ENGLISH 17

8 Press the CLEAN button.
,The milk container unit is rinsed.
Cleaning all parts after the last use of the day
1 Press the milk container lid release lever (1), tilt the milk container
lid slightly (2) and pull the milk container lid upwards to remove it
from the milk container (3).
2 Pull the release tab at the front of the milk container lid cover
upwards to open the cover.
3 Open the steam inlet by pulling it forward (1) and then move the
steam inlet to the right (2).This part stays attached to the lid by
means of a hinge.
Note:You can only open the steam inlet if the milk container lid cover is open.
4 Pull the milk tube off the milk container lid.
ENGLISH18

5 Clean the milk container, the milk container lid and the milk tube in
the dishwasher or with a washing-up brush in hot water with some
washing-up liquid. Rinse the parts with fresh water after cleaning.
Note: Cleaning in the dishwasher is recommended, especially when the milk
container unit is very dirty. Before you put the milk container unit In the
dishwasher, all parts that can be opened should be opened and all detachable
parts should be detached.
6 After cleaning, push back the steam inlet (1), connect the milk tube
(2) and close the milk container lid cover (3).
Note: Push back the steam inlet before you close the lid, otherwise the steam
inlet does not t anymore.
Note: Make sure that you push the milk tube far enough onto the connector so
that the holes in the connector are covered. If you do not push the milk tube
far enough onto the connector, you get less milk froth.
7 Fasten the milk container lid onto the milk container (‘click’).
Note: Make sure that all parts of the milk container lid are dry before you
reassemble the lid.
8 Slide the milk container unit into the coffee machine (1) and push
down the milk container lever (‘click’) (2).
ENGLISH 19

Cleaning the machine
Danger: Never immerse the machine in water or any other liquid.
Cleaning the coffee machine
1 Always unplug the machine before you clean it.
2 Clean the outside of the machine with a damp cloth.
3 Remove the coffee collector.
4 Remove the coffee spout cover and take the coffee spout out of the
machine.
5 Clean the coffee spout cover, the coffee spout, the
coffee collector and the drip tray in hot water, if necessary with
some washing-up liquid, or in the dishwasher.
6 Hold the cup tray in your hand while you clean it with hot water.
If necessary, use some washing-up liquid.
The cup tray can also be cleaned in the dishwasher.
To clean the cup tray, always remove it from the machine. It may prove
sharp when handled incorrectly.Always handle it carefully.
7 Clean the pod holders in hot water, if necessary with some washing-
up liquid, or in the dishwasher.
If the sieve in the centre of the pod holder is clogged, rinse the pod holder
under a running tap. If necessary, use a washing-up brush.
ENGLISH20
