CMOS digital decoding IC with
RAM for Compact Disc

1998 Feb 16 2
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
FEATURES
•Integrated data slicer and clock regenerator
•Digital Phase-Locked Loop (PLL)
•Demodulator and Eight-to-Fourteen Modulation (EFM)
decoding
•Subcoding microcontroller serial interface
•Integrated programmable motor speed control
•Error correction and concealment functions
•Embedded Static Random Access Memory (SRAM) for
de-interleave and First-In First-Out (FIFO)
•FIFO overflow concealment for rotational shock
resistance
•Digital audio interface [European Broadcasting Union
(EBU)]
•2 to 4 times oversampling integrated digital filter
•Audio data peak level detection
•Versatile audio data serial interface
•Digital de-emphasis filter
•Kill interface for Digital-to-Analog Converter (DAC)
deactivation during digital silence
•Double speed mode
•Compact Disc Read Only Memory (CD-ROM) modes
•A single speed only version is available
(SAA7345GP/SS).
GENERAL DESCRIPTION
The SAA7345 incorporates the CD signal processing
functions of decoding and digital filtering. The device is
equipped with on-board SRAM and includes additional
features to reduce the processing required in the analog
domain.
SupplyofthisCompactDiscICdoesnotconveyanimplied
license under any patent right to use this IC in any
Compact Disc application.
QUICK REFERENCE DATA
ORDERING INFORMATION
SYMBOL PARAMETER MIN. TYP. MAX. UNIT
VDD supply voltage 3.4 5.0 5.5 V
IDD supply current −22 50 mA
fxtal crystal frequency 8 16.9344 or
33.8688 35 MHz
Tamb operating ambient temperature −40 −+85 °C
Tstg storage temperature −55 −+125 °C
TYPE
NUMBER PACKAGE
NAME DESCRIPTION VERSION
SAA7345GP QFP44 plastic quad flat package; 44 leads (lead length 2.35 mm); body
14 ×14 ×2.2 mm SOT205-1

1998 Feb 16 3
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
BLOCK DIAGRAM
Fig.1 Block diagram.
MGA371 - 2
CFLG
RAB
CL
DA
CLA
PORE
KILLV3 V4 V5
MOTO2
CL11
IREF
DOBM
V1 V2
TEST2
TEST1
ISLICE
HFIN
HFREF
VDDA
SAA7345
MOTO1
CRIN
VDD1 VSS1
CL16
MISC
DATA
SCLK
WCLK
VSSA VDD2 VSS2
CROUT
DIGITAL
PLL
EBU
INTER-
FACE
AUDIO
PROCESSOR
FLAGS
ERROR
CORRECTOR
MOTOR
CONTROL
Q - CHANNEL
CRC CHECK
Q - CHANNEL
REGISTER
RAM
ADDRESSER
SRAM
EFM
DEMODULATOR
VERSATILE PINS
INTERFACE
PEAK
DETECT
KILL
SERIAL
DATA
INTER-
FACE
SUBCODE
MICRO-
CONTROLLER
INTERFACE
TIMING
PLL
FRONT-
END
8
9
7
10
6
5
13
14
1
29
17
31
30
32
28 3 4 26 25 24 27
22
23
33
2
21
20
19
18
11 12 15 16 44 43

1998 Feb 16 4
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
PINNING
Note
1. All supply pins must be connected to the same external power supply.
SYMBOL PIN DESCRIPTION
CL11 1 11.2896 or 5.6448 MHz clock output (3-state); (divide-by-3)
DOBM 2 bi-phase mark output (externally buffered; 3-state)
V1 3 versatile input pin
V2 4 versatile input pin
TEST2 5 test input; this pin should be tied LOW
TEST1 6 test input; this pin should be tied LOW
ISLICE 7 current feedback output from data slicer
HFIN 8 comparator signal input
HFREF 9 comparator common-mode input
IREF 10 reference current pin (nominally 1⁄2VDD)
VDDA 11 analog supply voltage; note 1
VSSA 12 analog ground; note 1
CRIN 13 crystal/resonator input
CROUT 14 crystal/resonator output
VDD1 15 digital supply to input and output buffers; note 1
VSS1 16 digital ground to input and output buffers; note 1
CL16 17 16.9344 MHz system clock output
MISC 18 general purpose DAC output (3-state)
DATA 19 serial data output (3-state)
WCLK 20 word clock output (3-state)
SCLK 21 serial bit clock output (3-state)
MOTO1 22 motor output 1; versatile (3-state)
MOTO2 23 motor output 2; versatile (3-state)
V5 24 versatile output pin
V4 25 versatile output pin
V3 26 versatile output pin (open-drain)
KILL 27 kill output; programmable (open-drain)
PORE 28 power-on reset enable input (active LOW)
CLA 29 4.2336 MHz microcontroller clock output
DA 30 interface data I/O line
CL 31 interface clock input line
RAB 32 interface R/W and acknowledge input
CFLG 33 correction flag output (open-drain)
n.c. 34 to 42 no internal connection
VSS2 43 digital ground to internal logic; note 1
VDD2 44 digital supply voltage to internal logic; note 1

1998 Feb 16 5
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
Fig.2 Pin configuration.
MGA359 - 1
1
2
3
4
5
6
7
8
9
10
11
33
32
31
30
29
28
27
26
25
24
23
12 13 14 15 16 17 18 19
20 21 22
44
43 42
41 40 39 38 37
36 35 34
CFLG
RAB
CL
DA
CLA
PORE
KILL
V3
V4
V5
MOTO2
CL11
IREF
DOBM
V1
V2
TEST2
TEST1
ISLICE
HFIN
HFREF
VDDA
SAA7345
MOTO1
CRIN
CROUT
VDD1
VSS1
CL16
MISC
DATA
SCLK
WCLK
VSSA VDD2
VSS2
Pins 34 to 42 (inclusive)
have no internal connection

1998 Feb 16 6
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
FUNCTIONAL DESCRIPTION
Demodulator
FRAME SYNC PROTECTION
This circuit will detect the frame synchronization signals.
Two synchronization counters are used in the SAA7345:
1. The coincidence counter which is used to detect the
coincidence of successive syncs. It generates a Sync
coincidence signal if 2 syncs are 588 ±1 EFM clocks
apart.
2. The main counter is used to partition the EFM signal
into 17-bit words. This counter is reset when:
a) A Sync coincidence is generated.
b) A sync is found within ±6 EFM clocks of its
expected position.
The Sync coincidence signal is also used to generate the
Lock signal which will go active HIGH when 1 Sync
coincidence is found. It will reset to LOW when, during 61
consecutive frames, no Sync coincidence is found. This
Lock signal is accessed via the status signal when the
status control register (address 0010) is set to X100. See
section on “Microcontroller interface” .
Data Slicer and Clock Regenerator
The SAA7345 has an integrated slice level comparator
which is clocked by the crystal frequency clock. The slice
level is controlled by an internal current source applied to
an external capacitor under the control of the digital
phase-locked loop (DPLL).
Regeneration of the bit clock is achieved with an internal
fully digital PLL. No external components are required and
the bit clock is not output. The PLL has two microcontroller
control registers (addresses 1000 and 1001) for
bandwidth and equalization.
For certain applications an off-track input is necessary. If
this flag is HIGH, the SAA7345 will assume that the servo
is following on the wrong track, and will flag all incoming
HF data as incorrect. The off-track is input via the V1 pin
when the versatile pins interface register (address 1100)
bit 0 is set to logic 1.
EFM demodulation
The 14-bit EFM data and subcode words are decoded into
8-bit symbols.
Subcode data processing
Q-CHANNEL PROCESSING
The 96-bit Q-channel word is accumulated in an internal
buffer. Sixteen bits are used to perform a Cyclic
Redundancy Check (CRC). If the data is good, the
SUBQREADY-I signal will go LOW. SUBQREADY-I can
be read via the status signal when the status control
register (address 0010) is set to X000 (normal reset
condition). Good Q-channel data may be read via the
microcontroller interface.
Fig.3 Data slicer showing typical application components.
47 pF
22 nF
2.2 kΩHFIN
HFREF
Iref
ISLICE
22 kΩ
100 nF
2.2 nF
HF
input
crystal
clock
DQ
DPLL
1/2VDD
VSSA VSS
VSSA
MGA368 - 1
VDD
100 µA
100 µA

1998 Feb 16 7
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
OTHER SUBCODE CHANNELS
Data of the other subcode channels (Q-to-W) may be read
via the V4 pin if the versatile pins interface register
(address 1101) is set to XX01.
The format is similar to RS232. The subcode sync word is
formedbyapauseof200 µsminimum.Eachsubcodebyte
starts with a logic 1 followed by 7 bits (Q-to-W). The gap
between bytes is variable between 11.3 µs and 90 µs.
The subcode data is also available in the EBU output
(DOBM) in a similar format.
Microcontroller interface
The SAA7345 has a 3-line microcontroller interface which
is compatible with the digital servo IC TDA1301.
WRITING DATA TO SAA7345
The SAA7345 has thirteen 4-bit programmable
configuration registers as shown in Table 2. These can be
written to via the microcontroller interface using the
protocol shown in Fig.5.
Write operation sequence
•RAB is held LOW by the microcontroller to hold the
SAA7345 DA pin at high-impedance.
•Microcontroller data is clocked into the internal shift
register on the LOW-to-HIGH clock transition CL.
•Data D (3 : 0) is latched into the appropriate control
register [address bits A (3 : 0)] on the LOW-to-HIGH
transition of RAB with CL HIGH.
•If more data is clocked into SAA7345 before the
LOW-to-HIGH transition of RAB then only the last 8 bits
are used.
•If less data is clocked into SAA7345, unpredictable
operation will result.
•If the LOW-to-HIGH transition of RAB occurs with CL
LOW, the command will be disregarded.
Fig.4 Subcode format and timing at V4 pin.
W96 1 Q1 R1 S1 T1 U1 V1 W1 1 Q2
200 µs
min 11.3 µs11.3 µs min 90 µs max
MGA369
Fig.5 Microcontroller WRITE timing.
A3 A2 A1 A0 D3 D2 D1 D0
DA (SAA7345)
CL
(microcontroller)
RAB
(microcontroller)
DA
(microcontroller)
MGA379 - 1
high impedance

1998 Feb 16 8
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
WRITING DATA TO SAA7345; REPEAT MODE
The same command can be repeated several times (e.g. for fade function) by applying extra RAB pulses as shown in
Fig.6.
READING STATUS INFORMATION FROM SAA7345
There are several internal status signals which can be made available on the DA line (Table 1).
Table 1 Internal status signals.
The status signal to be output is selected by status control register (address 0010). The timing for reading the status
signal is shown in Fig.7.
Status read operation sequence
•Write appropriate data to register 0010 to select required status signal.
•With RAB LOW; set CL LOW.
•Set RAB HIGH; this will instruct the SAA7345 to output status signal on DA.
SIGNAL DESCRIPTION
SUBQREADY-I LOW if new subcode word is ready in Q-channel register.
MOTSTART1 HIGH if motor is turning at 75% or more of nominal speed.
MOTSTART2 HIGH if motor is turning at 50% or more of nominal speed.
MOTSTOP HIGH if motor is turning at 12% or less of nominal speed.
PLL Lock HIGH if Sync coincidence signals are found.
V1 Follows input on V1 pin.
V2 Follows input on V2 pin.
MOTOR-OV HIGH if the motor servo output stage saturates.
Note that CL must stay HIGH between RAB pulses.
Fig.6 Microcontroller WRITE timing; repeat mode.
A3 A2 A1 A0 D3 D2 D1 D0
DA (SAA7345)
MGA380 - 1
CL
(microcontroller)
RAB
(microcontroller)
DA
(microcontroller)
high impedance

1998 Feb 16 9
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
READING Q-CHANNEL SUBCODE FROM SAA7345
To read Q-channel subcode from SAA7345, the SUBQREADY-I signal should be selected as status signal. The subcode
read timing is shown in Fig.8.
Read subcode operation sequence
•Monitor SUBQREADY-I status signal.
•When this signal is LOW, and up to 2.3 ms after its LOW-to-HIGH transition, it is permitted to read subcode.
•Set CL LOW, SAA7345 will output first subcode bit (Q1).
•After subcode read starts, the microcontroller may take as long as it wants to terminate read operation.
•SAA7345 will output consecutive subcode bits after each HIGH-to-LOW transition of CL.
•When enough subcode has been read (1 to 96 bits), stop reading by pulling RAB LOW.
PEAK DETECTOR OUTPUT
In place of the CRC-bits (bits 81 to 96), the peak detector information is added to the Q-channel data. The peak
information corresponds to the highest audio level (absolute value) and is measured on positive peaks. Only the most
significant 8 bits of the peak level are given, in unsigned notation. Bits 81 to 88 contain the LEFT peak value
(bit 88 = MSB) and bits 89 to 96 contain the RIGHT channel (bit 96 = MSB). Value is reset after reading Q-channel data.
Fig.7 SAA7345 status READ timing.
DA (SAA7345)
MGA381 - 1
STATUS
CL
(microcontroller)
RAB
(microcontroller)
DA
(microcontroller) high impedance
Fig.8 SAA7345 Q-channel subcode READ timing.
Q1 Q2 Q3 Qn–1DA (SAA7345)
MGA382 - 1
Qn–2 Qn
STATUS
CRC
OK
CL
(microcontroller)
RAB
(microcontroller)

1998 Feb 16 10
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
BEHAVIOUR OF THE SUBQREADY-I SIGNAL
When the CRC of the Q-channel word is good, and no
subcodeisbeingread, the SUBQREADY-I signalwillreact
as shown in Fig.9.
When the CRC is good and subcode is being read, the
timing in Fig.10 applies.
If t1(SUBQREADY-I LOW to end of subcode read) is
below 2.6 ms, then t2= 13.1 ms (i.e. the microcontroller
can read all subcode frames if it completes the read
operation within 2.6 ms after subcode ready).
If this criterion is not met, it is only possible to guarantee
that t3will be below 26.2 ms (approximately).
If subcode frames with failed CRCs are present, the t2and
t3times will be increased by 13.1 ms for each defective
subcode frame.
SHARING THE MICROCONTROLLER INTERFACE
When the RAB pin is held LOW by the microcontroller, it is
permitted to put any signal on the DA and CL lines
(SAA7345 will set output DA to high-impedance). Under
this circumstance these lines may be used for another
purpose (e.g. TDA1301 microcontroller interface Data and
Clock line, see Fig.11).
Fig.9 SUBQREADY-I timing when no subcode is read.
DA (SAA7345)
10.8 ms 15.4 ms
2.3
ms
READ start allowed
high
impedance CRC OK CRC OK
MGA373 - 1
CL
(microcontroller)
RAB
(microcontroller)
Fig.10 SUBQREADY-I timing when subcode is being read.
Q1 Q2 Q3 QnDA (SAA7345)
t1
t2t3
MGA374 - 1
CL
(microcontroller)
RAB
(microcontroller)

1998 Feb 16 11
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
Table 2 Command registers.
The ‘INITIAL’ column shows the power-on reset state
REGISTER ADDRESS DATA FUNCTION INITIAL
Fade and Attenuation 0 0 0 0 X 0 0 0 Mute Reset
X 0 1 X Attenuate
X 0 0 1 Full Scale
X 1 0 0 Step Down
X 1 0 1 Step Up
Motor mode 0 0 0 1 X 0 0 0 Motor off mode Reset
X 0 0 1 Motor brake mode 1
X 0 1 0 Motor brake mode 2
X 0 1 1 Motor start mode 1
X 1 0 0 Motor start mode 2
X 1 0 1 Motor jump mode
X 1 1 1 Motor play mode
X 1 1 0 Motor jump mode 1
1 X X X anti-windup active
0 X X X anti-windup off Reset
Status control 0 0 1 0 X 0 0 0 status = SUBQREADY-I Reset
X 0 0 1 status = MOTSTART1
X 0 1 0 status = MOTSTART2
X 0 1 1 status = MOTSTOP
X 1 0 0 status = PLL Lock
X 1 0 1 status = V1
X 1 1 0 status = V2
X 1 1 1 status = MOTOR-OV
0 X X X L channel first at DAC (WCLK normal) Reset
1 X X X R channel first at DAC (WCLK inverted)
Fig.11 SAA7345 microcontroller interface application diagram.
MGA361 - 1
MICROCONTROLLER
TDA1301 SAA7345
I/O
O
O
O
SIDA SICL SILD
DA CL RAB

1998 Feb 16 12
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
DAC output 0 0 1 1 1 0 1 0 I2S CD-ROM mode
1 0 1 1 EIAJ; CD-ROM mode
110X I
2
S; 4fsmode Reset
1111 I
2
S; 2fsmode
1110 I
2
S; fsmode
0 0 0 X EIAJ; 16-bit; 4fs
0 0 1 1 EIAJ; 16-bit; 2fs
0 0 1 0 EIAJ; 16-bit; fs
0 1 0 X EIAJ; 18-bit; 4fs
0 1 1 1 EIAJ; 18-bit; 2fs
0 1 1 0 EIAJ; 18-bit; fs
Motor gain 0 1 0 0 X 0 0 0 Motor gain G = 3.2 Reset
X 0 0 1 Motor gain G = 4.0
X 0 1 0 Motor gain G = 6.4
X 0 1 1 Motor gain G = 8.0
X 1 0 0 Motor gain G = 12.8
X 1 0 1 Motor gain G = 16.0
X 1 1 0 Motor gain G = 25.6
X 1 1 1 Motor gain G = 32.0
Motor bandwidth 0 1 0 1 X X 0 0 Motor f4= 0.5 Hz Reset
X X 0 1 Motor f4= 0.7 Hz
X X 1 0 Motor f4= 1.4 Hz
X X 1 1 Motor f4= 2.8 Hz
0 0 X X Motor f3= 0.85 Hz Reset
0 1 X X Motor f3= 1.71 Hz
1 0 X X Motor f3= 3.42 Hz
Motor output configuration 0 1 1 0 X X 0 0 Motor power maximum 37% Reset
X X 0 1 Motor power maximum 50%
X X 1 0 Motor power maximum 75%
X X 1 1 Motor power maximum 100%
0 0 X X MOTO1, MOTO2 pins 3-state Reset
0 1 X X Motor Pulse Width Modulation (PWM) mode
1 0 X X Motor Pulse Density Modulation (PDM) mode
1 1 X X Motor Compact Disc Video (CDV) mode
REGISTER ADDRESS DATA FUNCTION INITIAL

1998 Feb 16 13
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
Loop BW
(Hz) Internal BW (Hz) Low-pass BW (Hz)
PLL loop filter bandwidth 1 0 0 0 0 0 0 0 1640 525 8400
0 0 0 1 3279 263 16800
0 0 1 0 6560 131 33600
0 1 0 0 1640 1050 8400
0 1 0 1 3279 525 16800
0 1 1 0 6560 263 33600
1 0 0 0 1640 2101 8400
1 0 0 1 3279 1050 16800 Reset
1 0 1 0 6560 525 33600
1 1 0 0 1640 4200 8400
1 1 0 1 3279 2101 16800
1 1 1 0 6560 1050 33600
PLL loop filter equalization 1 0 0 1 0 0 0 1 PLL 30 ns over-equalization
0 0 1 0 PLL 15 ns over-equalization
0 0 1 1 PLL nominal equalization Reset
0 1 0 0 PLL 15 ns under-equalization
0 1 0 1 PLL 30 ns under-equalization
EBU output 1 0 1 0 X X 0 0 EBU data before concealment
X X 1 0 EBU data after concealment and fade Reset
X X 1 1 EBU off −output LOW
X 0 X X Level II clock accuracy (<1000 ×10−6) Reset
X 1 X X Level III clock accuracy (>1000 ×10−6)
0 X X X Flags in EBU off Reset
1 X X X Flags in EBU on
Speed control 1 0 1 1 1 X X X double-speed mode
0 X X X single-speed mode Reset
X 0 X X 33.869 MHz crystal present Reset
X 1 X X 16.934 MHz crystal present
X X 0 0 standby 1: ‘CD-STOP’ mode (note 1) Reset
X X 1 0 standby 2: ‘CD-PAUSE’ mode (note 1)
X X 1 1 operating mode
Versatile pins interface 1 1 0 0 X X X 1 off-track input at V1
X X X 0 no off-track input (V1 may be read via status) Reset
X X 0 X Kill-L at KILL output, Kill-R at V3 output
X 0 1 X V3 = 0; single Kill output Reset
X 1 1 X V3 = 1; single Kill output
REGISTER ADDRESS DATA FUNCTION INITIAL

1998 Feb 16 14
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
Note
1. Standby modes = CL, DA and RAB; normal operation.
a) MISC, SCLK, WCLK, DATA, CL11 and DOBM; 3-state.
b) CRIN, CROUT, CL16 and CLA; normal operation.
c) V1, V2, V3, V4 and V5; normal operation.
d) MOTO1 and MOTO2 - in standby 2 ‘CD-PAUSE’; normal operation.
e) MOTO1 and MOTO2 - in standby 1 ‘CD-STOP’; held LOW in PWM mode; 3-state in PDM mode.
Versatile pins interface 1 1 0 1 0 0 0 0 4-line motor (using V4, V5)
X X 0 1 Q-to-W subcode at V4
X X 1 0 V4 = 0
X X 1 1 V4 = 1 Reset
0 1 X X de-emphasis signal at V5
10XX V5=0
1 1 X X V5 = 1 Reset
REGISTER ADDRESS DATA FUNCTION INITIAL
Error corrector
Theerror corrector carriesout t = 2, e = 0error corrections
on both C1 (32 symbol) and C2 (28 symbol) frames. Four
symbols are used from each frame as parity symbols. The
strategy t = 2, e = 0 means that the error corrector can
correct two erroneous symbols per frame and detect all
erroneous frames.
The error corrector also contains a flag controller. Flags
are assigned to symbols when the error corrector cannot
ascertain if the symbols are definitely good. C1 generates
output flags which are read (after de-interleaving) by C2,
to help in the generation of C2 output flags.
The C2 output flags are used by the interpolator for
concealment of non-correctable errors. They are also
output via the EBU signal (DOBM) and the MISC output
with I2S for CD-ROM applications.
The flags output pin CFLG provides information on the
state of all error correction and concealment flags.
Audio functions
DE-EMPHASIS AND PHASE LINEARITY
When de-emphasis is detected in the Q-channel subcode,
the digital filter automatically includes a de-emphasis filter
section. When de-emphasis is not required, a phase
compensation filter section controls the phase linearity of
the digital oversampling filter to ≤±1°within the band
0 to 16 kHz.
DIGITAL OVERSAMPLING FILTER
The SAA7345 contains a 2 to 4 times oversampling filter.
The filter specification of the 4 ×oversampling filter is
given in Table 2 and shown in Fig.12.
These attenuations do not include the sample and hold at
the DAC output or the DAC post filter.
When using the oversampling filter, the output level is
scaled −0.5 dB down, to avoid overflow on full-scale
sinewave inputs (0 to 20 kHz).

1998 Feb 16 15
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
Table 3 Digital filter passband characteristics
Table 4 Digital filter stopband characteristics.
CONCEALMENT
A 1-sample linear interpolator becomes active if a single sample is flagged as erroneous but cannot be corrected. The
erroneous sample is replaced by a level midway between the preceding and following samples. Left and right channels
have independent interpolators.
If more than one consecutive non-correctable sample is found, the last good sample is held. A 1-sample linear
interpolation is then performed before the next good sample (see Fig.13).
PASSBAND ATTENUATION
0 to 19 kHz ≤0.001 dB
19 to 20 kHz ≤0.03 dB
STOPBAND ATTENUATION
24 kHz ≥25 dB
24 to 27 kHz ≥38 dB
27 to 35 kHz ≥40 dB
35 to 64 kHz ≥50 dB
64 to 68 kHz ≥31 dB
68 kHz ≥35 dB
69 to 88 kHz ≥40 dB
Fig.12 Digital filter characteristics.
40
20
0
40
60 010 30
MGA385
20
20 50
magnitude
(dB)
frequency (kHz)

1998 Feb 16 16
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
Fig.13 Concealment mechanism.
Interpolation Hold Interpolation
MGA372
OK Error OK Error Error Error OK OK
MUTE,ATTENUATION AND FADE
A digital level controller is present on the SAA7345 which
performs the functions of soft mute, attenuation and fade.
Mute and Attenuation
Soft mute is activated by sending the Mute command to
the fade control register (address 0000, data X000). The
signal will reduced to zero in up to 128 steps (depending
on the current position of the fade control), taking a
maximum of 3 ms.
Attenuation(−12 dB) isactivated bysending the Attenuate
command to the fade control register (data X01X).
Attenuation and mute are cancelled by sending the Full
Scale command to the fade control register (data X001). It
willtake3 msto ramp theoutputfrommute to thefull-scale
level.
Fade
The audio output level is determined by the value of the
internal fade counter.
•The counter is preset to 128 by the Full Scale command
if no oversampling is required.
•Thecounterispresetto 120(−0.5 dBscaling)bytheFull
Scale command if either 2fsor 4fsoversampling is
programmedin the DAC output register(address 0011).
•The counter is preset to 32 by the Attenuate command.
•The counter is preset to 0 by the Mute command.
Level counter
128
---------------------- maximum level×=
To control the fade counter in a continuous way, the
step-up and step-down commands are available (fade
control register data X101 and X100). They will increment
or decrement the counter by 1 for each register write
operation.
•When issuing more than 1 step-up or step-down
command in sequence, the write repeat mode may be
used (see Fig.6).
•A pause of at least 22 µs is necessary between any two
step-up or step-down commands.
•When a step-up command is given when the fade
counter is already at its full-scale value, the counter will
not increment.
DAC Interface
The SAA7345 is compatible with a wide range of
Digital-to-Analog Converters. Eleven formats are
supported and are shown in Table 5.
All formats are MSB first. fsis 44.1 kHz in single-speed
mode and 88.2 kHz in double-speed mode.

1998 Feb 16 17
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
Table 5 DAC interface formats
Note
1. n = disc speed.
2. EIAJ is the abbreviation for: Electronic Industries Associated of Japan.
MODE DAC CONTROL
REGISTER DATA SAMPLE FREQUENCY BITS SCLK (MHz) FORMAT INTERPOLATION
1 1010 f
s16 2.1168 ×n(1) CD-ROM (I2S) no
2 1011 f
s16 2.1168 ×n(1) CD-ROM (EIAJ)(2) no
3 1110 f
s16 2.1168 ×n(1) Philips I2S−16 bits yes
4 0010 f
s16 2.1168 ×n(1) EIAJ −16 bits yes
5 0110 f
s18 2.1168 ×n(1) EIAJ −18 bits yes
6000X 4f
s16 8.4672 ×n(1) EIAJ −16 bits yes
7010X 4f
s18 8.4672 ×n(1) EIAJ −18 bits yes
8110X 4f
s18 8.4672 ×n(1) Philips I2S−18 bits yes
9 0011 2f
s16 4.2336 ×n(1) EIAJ −16 bits yes
10 0111 2f
s18 4.2336 ×n(1) EIAJ −18 bits yes
11 1111 2f
s18 4.2336 ×n(1) Philips I2S−18 bits yes

1998 Feb 16 18 Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for Compact Disc SAA7345
This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in
_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in
white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...
LEFT CHANNEL DATA (WCLK NORMAL POLARITY)
SCLK
15 150DATA
WCLK
LSB VALID MSB VALID LSB VALID MSB VALIDMISC
CD-ROM
MODE ONLY
MGA383
0
Fig.14 Philips I2S data format (16-bit word length shown).
MGA384
SCLK
17 170DATA
WCLK
MISC
0
LEFT CHANNEL DATA
Fig.15 EIAJ data format (18-bit word length shown).

1998 Feb 16 19
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
EBU interface
The biphase-mark digital output signal at pin DOBM is in accordance with the format defined by the “IEC 958 ”
specification.
Three different modes can be selected via the EBU output control register (address 1010).
Table 6 EBU output modes
FORMAT
The digital audio output consists of 32-bit words (subframes) transmitted in biphase-mark code (two transitions for a
logic 1 and one transition for a logic 0). Words are transmitted in blocks of 384 (see Table 7).
Table 7 EBU word format
EBU CONTROL
REGISTER DATA EBU OUTPUT AT DOBM PIN EBU VALIDITY FLAG (BIT 28)
XX11 DOBM pin held LOW −
XX00 data taken before concealment, mute and fade HIGH if data is non-correctable
(concealment flag)
XX10 data taken after concealment, mute and fade HIGH if data is non-correctable
(concealment flag)
WORD BITS FUNCTION
Sync 0 to 3 −
Auxiliary 4 to 7 not used; normally zero
Error flags 4 CFLG error and interpolation flags when bit 3 of EBU control
register is set to logic 1
Audio sample 8 to 27 first 4 bits not used (always zero)
Validity flag 28 valid = logic 0
User data 29 used for subcode data (Q-to-W)
Channel status 30 control bits and category code
Parity bit 31 even parity for bits 4 to 30
SYNC
The sync word is formed by violation of the biphase rule
and therefore does not contain any data. Its length is
equivalent to 4 data bits. The three different sync patterns
indicate the following situations:
•Sync B:
– Start of a block (384 words), word contains left
sample.
•Sync M:
– Word contains left sample (no block start).
•Sync W:
– Word contains right sample.
AUDIO SAMPLE
Left and right samples are transmitted alternately.
VALIDITY FLAG
Audio samples are flagged (bit 28 = logic 1) if an error has
been detected but was non-correctable. This flag remains
the same even if data is taken after concealment.
USER DATA
Subcode bits Q-to-W from the subcode section are
transmittedviatheuserdatabit.Thisdata isasynchronous
with the block rate.

1998 Feb 16 20
Philips Semiconductors Product specification
CMOS digital decoding IC with RAM for
Compact Disc SAA7345
CHANNEL STATUS
The channel status bit is the same for left and right words. Therefore a block of 384 words contains 192 channel status
bits. The category code is always CD. The bit assignment is shown in Table 8.
Table 8 EBU channel status
WORD BITS FUNCTION
Control 0 to 3 copy of CRC checked Q-channel control bits 0 to 3;
bit 2 is logic 1 when copy permitted;
bit 3 is logic 1 when recording has pre-emphasis
Reserved mode 4 to 7 always zero
Category code 8 to 15 CD: bit 8 = logic 1; all other bits = logic 0
Clock accuracy 28 to 29 set by EBU control register:
00 = Level II
01 = Level III
Remaining 16 to 27 and 30 to 191 always zero
KILL circuit
The KILL circuit detects digital silence by testing for an
all-zero or all-ones data word in the left or right channel
before the digital filter. The output is switched active LOW
when silence has been detected for at least 200 ms. Two
modesareavailable,selected by the versatilepinsregister
(address 1100):
1-PIN KILL MODE
Active LOW signal on KILL pin when digital silence has
been detected on both LEFT and RIGHT channels for
200 ms.
2-PIN KILL MODE
Independent digital silence detection for left and right
channels. The KILL pin is active LOW when digital silence
hasbeen detected intheLEFTchannelfor200 ms,andV3
is active LOW when digital silence has been detected in
the RIGHT channel for 200 ms.
When MUTE is active then the KILL output is forced LOW.
Spindle motor control
The spindle motor speed is controlled by a fully integrated
digital servo. Address information from the internal
±8 frame FIFO and disc speed information are used to
calculate the motor control output signals.
Several output modes are supported:
1. PulseDensity, 2-line (truecomplement output), 1 MHz
sample frequency.
2. PWM output, 2-line, 22.05 kHz modulation frequency.
3. PWM-output, 4-line, 22.05 kHz modulation frequency.
4. CDV motor mode.
Themodes areselected via the motor output configuration
register (address 0110).
PULSE DENSITY MODE
In the Pulse Density mode the motor output pin MOTO1 is
the pulse density modulated motor output signal. A 50%
dutycycle corresponds withthe motor notactuated, higher
duty cycles mean acceleration, lower mean braking.
In this mode, the MOTO2 signal is the inverse of the
MOTO1 signal. Both signals change state only on the
edges of a 1 MHz internal clock signal.
Possible application diagrams are shown in Fig.16.
