Philips UM10011 User manual

UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
Semiconductors Rev. 04.00 — 17 June 2004 User manual
Document information
Info Content
Keywords ISP1521, hub controller, USB, universal serial bus
Abstract This document describes the ISP1521 hub demo board. It also contains
the related schematics, the PCB layout, and the Bill of Material.

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 2 of 20
Revision history
Contact information
For additional information, please visit: http://www.semiconductors.philips.com/
For sales office addresses, please send an email to: [email protected]
Rev Date Description
4.0 June 2004 Updated the schematics.
3.0 Apr 2004 Updated the following:
• Section 2
• Section 5.7
• Removed Section 5.8 on hybrid power
• Section 6.
1.1 Mar 2003 Updated Section 5.7 and Section 6.
Corrected I2C to I2C-Bus
1.0 Nov. 2002 First release.

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 3 of 20
This is a legal agreement between you (either an individual or an entity) and Philips Semiconductors. By accepting
this product, you indicate your agreement to the disclaimer specified as follows:
DISCLAIMER
PRODUCT IS DEEMED ACCEPTED BY RECIPIENT. THE PRODUCT IS PROVIDED “AS IS” WITHOUT
WARRANTY OF ANY KIND. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, PHILIPS
SEMICONDUCTORS FURTHER DISCLAIMS ALL WARRANTIES, INCLUDING WITHOUT LIMITATION ANY
IMPLIED WARRANTIES OF MERCHANT ABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NONINFRINGEMENT. THE ENTIRE RISK ARISING OUT OF THE USE OR PERFORMANCE OF THE
PRODUCT AND DOCUMENTATION REMAINS WITH THE RECIPIENT. TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL PHILIPS SEMICONDUCTORS OR ITS SUPPLIERS BE
LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, DIRECT, INDIRECT, SPECIAL, PUNITIVE, OR OTHER
DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS
PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR OTHER PECUNIARY LOSS)
ARISING OUT OF THIS AGREEMENT OR THE USE OF OR INABILITY TO USE THE PRODUCT, EVEN IF
PHILIPS SEMICONDUCTORS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 4 of 20
Contents
1. INTRODUCTION...................................................................................................................................................................5
2. ISP1521 HUB DEMO BOARD FEATURES.........................................................................................................................5
3. SYSTEM REQUIREMENTS.....................................................................................................................................................6
4. POWER SUPPLY ADAPTER REQUIREMENTS................................................................................................................6
5. HUB DEMO BOARD DESCRIPTION.................................................................................................................................6
5.1. ISP1521 80-Pin LQFP Package.......................................................................................................................................6
5.2. Port Indicators..................................................................................................................................................................7
5.3. Power LED Indicator......................................................................................................................................................7
5.4. GoodLink Indicator.........................................................................................................................................................7
5.5. Port Power Switch Transistors.....................................................................................................................................8
5.6. Overcurrent Circuit Detection....................................................................................................................................8
5.7. Power Supply....................................................................................................................................................................8
5.8. I2C-Bus Interface............................................................................................................................................................10
5.9. Other Jumpers................................................................................................................................................................11
5.9.1. J13 (NOOC)..........................................................................................................................................................11
5.9.2. J14 (SUSPEND)......................................................................................................................................................11
6. SCHEMATICS..........................................................................................................................................................................11
7. INSTALLING THE BOARD.................................................................................................................................................19
8. BILL OF MATERIALS FOR THE ISP1521 HUB DEMO BOARD.................................................................................20
9. REFERENCES...........................................................................................................................................................................20
GoodLink and I2C-Bus are trademarks of Koninklijke Philips Electronics N.V. Microsoft is a registered trademark of
Microsoft Corp. The names of actual companies and products mentioned herein may be the trademarks of their
respective owners. All other names, products, and trademarks are the property of their respective owners.

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 5 of 20
1. Introduction
The ISP1521 is a Hi-Speed Universal Serial Bus (USB) hub IC, with seven downstream facing
ports. The ISP1521 Hub Demo Board is designed to demonstrate the features and functionality
of the ISP1521.
This document describes the ISP1521 Hub Demo Board. It also contains the related schematics,
the PCB layout, and the Bill of Material (BoM).
Figure 1-1: ISP1521 Hub Demo Board
2. ISP1521 Hub Demo Board Features
• Complies with Universal Serial Bus Specification Rev. 2.0
• Supports self-powered operation
• Configurable number of downstream facing ports (from two to seven)
• Customizable Vendor ID, Product ID and Serial Number (by using an external EEPROM or
an external microcontroller)
• Individual power switching and individual overcurrent protection
• USB traffic indication (GoodLinkTM LED) on the upstream facing port
• Port status indicators.

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 6 of 20
3. System Requirements
This hub can be attached to a computer that has a USB or Hi-Speed USB host installed, and
running any of these operating systems:
• Windows®98
• Windows Me
• Windows 2000
• Windows XP
• MacOS®.
If the hub is plugged into a USB host controller, it will work only as a full-speed hub.
4. Power SupplyAdapter Requirements
Regulated Output: 5.1 VCC ± 5%, 4 A.
Warning: The power plug polarity is (-) at the core and (+) at the outer shield.
5. Hub Demo Board Description
5.1. ISP1521 80-Pin LQFP Package
The ISP1521 has these port configurations:
• One Hi-Speed USB and USB capable upstream facing port (USB0), and
• Seven Hi-Speed USB and USB capable downstream facing ports (USB1, USB2, USB3, USB4,
USB5, USB6, USB7).
The port numbers are marked near the USB connectors on the silkscreen. The downstream
facing ports USB3, USB4, USB5, USB6 and USB7 can be disabled. Disabling a port will also disable
all higher-number ports. For example, disabling port USB4 will disable ports USB5, USB6 and
USB7 as well. Therefore, apart from port USB7, it is not possible to selectively disable a port
(For example, only USB5.). By design, ports USB1 and USB2 cannot be disabled.
Table 5-1: Jumper Settings vs. Port Activation
*—Default settings.
These jumpers are set to “ON” by placing a solder joint on the provided footprints.
J2, J1 J4, J3 J6, J5 J10, J9 J8, J7 Active Ports
OFF, OFF OFF, OFF OFF, OFF OFF, OFF OFF, OFF USB1 to USB7*
ON, ON OFF, OFF OFF, OFF OFF, OFF OFF, OFF USB1 to USB6
OFF, OFF ON, ON OFF, OFF OFF, OFF OFF, OFF USB1 to USB5
OFF, OFF OFF, OFF ON, ON OFF, OFF OFF, OFF USB1 to USB4
OFF, OFF OFF, OFF OFF, OFF ON, ON OFF, OFF USB1 to USB3
OFF, OFF OFF, OFF OFF, OFF OFF, OFF ON, ON USB1 to USB2

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 7 of 20
5.2. Port Indicators
The D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13 and D14 are port indicators.
Conforming to the Universal Serial Bus Specification Rev. 2.0, each downstream facing port has two
port indicators—green and amber—placed to its right.
If the green LED is ON, it means the device connected to the port was successfully enumerated
and is functional.
If the amber LED is ON, it means there is an overcurrent condition.
Custom software applications or drivers may flash these LEDs to attract user attention.
5.3. Power LED Indicator
When power is supplied to the board, LED D16 lights up (red).
5.4. GoodLink Indicator
A Philips GoodLinkTM LED D15 (red) is located near the upstream facing port. This LED blinks on
every successful USB transactions.
J
1 and J2 solder
joints to disable a
port

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 8 of 20
5.5. Port Power Switch Transistors
The hub switches on or off the bus power to each downstream facing port through a low ohmic
PMOS transistor.
5.6. Overcurrent Circuit Detection
The integrated analog overcurrent detection circuit of the ISP1521 senses the voltage drop
across the power switch. When the port draws too much current, the voltage drop across the
power switch exceeds the trip voltage threshold. The overcurrent circuit detects this and
automatically switches off the power switch. More information on choosing the switch and
trimming the overcurrent detection voltage can be found in the ISP1521 Hi-Speed Universal Serial
Bus hub controller data sheet.
5.7. Power Supply
To power up the hub, plug the power supply into the power supply socket (PWR_C1).
Jumper J15 will set the powering mode in the hub’s descriptors as self-powered hub; see
Table 5-2.
Table 5-2: Setting the Power Mode Using J15
*—Default settings.
J15 Power Mode Logic State
OFF Self* 1 (HIGH)
J15

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 9 of 20
Figure 5-1: Windows Reporting of the Bus-Powered Mode

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 10 of 20
Figure 5-2: Windows Reporting of the Self-Powered Mode
5.8. I2C-Bus Interface
The ISP1521 can use either its USB descriptors from the internal ROM, or from an external I2C-
BusTM EEPROM or microcontroller. Mode selection is done through jumpers J11and J12 (see
Table 5-3).
Table 5-3: Mode Selection Using J11 and J12
*—Default settings.
An external I2C-Bus controller acting as a master can also be used to update hub descriptors
through the CN1 connector.
Note: The I2C-Bus external EEPROM cannot be programmed on-board.
J11 J12 Mode SCL SDA
ON ON Internal ROM LOW LOW
OFF OFF I2C-Bus EEPROM* HIGH HIGH

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 11 of 20
5.9. Other Jumpers
5.9.1. J13 (NOOC)
This jumper will set the OC capabilities in the hub’s descriptors (see Table 5-4).
Table 5-4: Overcurrent Support Selection Using J11 and J12
*—Default settings.
Note: this jumper is for setting the hub’s descriptor only. To inhibit the overcurrent detection,
the OC pins must be tied to VCC (5 V)
5.9.2. J14 (SUSPEND)
This jumper is provided for debugging purposes. Logic 1 on the SUSPEND signal indicates that
the hub is in the suspend mode. In the default setting jumper J14 is used (pulled down to GND).
Table 5-5: J14 Mode Setting
6. Schematics
J13 NOOC Logic State
OFF No overcurrent support 1 (HIGH)
ON Overcurrent support* 0 (LOW)
J14 Mode
OFF Debugging purpose
ON Normal mode (default)

1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
D D C C B B A A
Ti tle
Nu mb er Re vis io nSize
A3
Date: 2004-03-24 Sheet of Fil e: C:\My N ot eBo ok Raw\ . .\IS P15 21 _Up dat e. SchDrawn By:
ISP1521 EVAL BOARD
VBU S 1
D-
2
D+
3
GND 4
CHASSIS 5 CHASSIS 6
USB_D OWN USB1
L11
0. 1uF C25
150u F
C31
15KR29
15KR30
SDA 5
SCL 6
WP 7
VCC 8
A0
1
A1
2
A2
3
GND
4
PCF8582 U2
RESET
40
PSW7
37
HP
21
PSW6
26 PSW5 28 PSW4 33 PSW3 35 PSW2 39 PSW1 24
OC7
36 OC6 25 OC5 27 OC4 32 OC3 34 OC2 38 OC1 23
SP/BP
22
SUSPEND
1
ADOC
41
NOOC
60
PIGRN1 72
PIGRN2 67
PIGRN3 63
PIGRN4 61
PIGRN5 76
PIGRN6 74
PIGRN7 65
PIABR1 73
PIABR2 68
PIABR3 64
PIABR4 62
PIABR5 77
PIABR6 75
PIABR7 66
HUBGL 78
SCL 79
SDA 80
DP7 49
DM7 48
DP6 16
DM6 15
DP5 10
DM5 9
DP4 59
DM4 58
DP3 55
DM3 54
DP2 46
DM2 45
DP1 20
DM1 19
DP0 4
DM0 3
XTAL1 42 XTAL2 43
RPU
5
RREF
7
DGND
29
DGND
71
AGND
2
AGND
6
AGND
8
AGND
12
AGND
14
AGND
18
AGND
44
AGND
47
AGND
51
AGND
53
AGND
57
VCC5
31
VCC5
69
VCC4
70 VCC4 30
VCC3
11
VCC3
13
VCC3
17
VCC3
50
VCC3
52
VCC3
56
ISP152 1_LQFP80
U1
1N 41 48 D18
10K R43
0. 1uF C16
V3.3REG
TP
1K5, 1 % R52
12K, 1%R53
1 2 3 4
SIP_4P CN1
12MHz
X1
22pF C17
22pF C18
0. 1uFC14
REF1 1
I/O1
2
I/O2
3REF2 4
PSR05
ESD 1
VBU S1 0. 01u FC3 1nFC4
VBU S 1
D-
2
D+
3
GND 4
CHASSIS 5 CHASSIS 6
USB_U P USB0
REF1 1
I/O1
2
I/O2
3REF2 4
PSR05
ESD 0
VBU S 0. 01u FC2 1nFC1
VBU S 1
D-
2
D+
3
GND 4
CHASSIS 5 CHASSIS 6
USB_D OWN USB3
L31
0. 1uF C30
150u F
C70
15KR31
15KR32
REF1 1
I/O1
2
I/O2
3REF2 4
PSR05
ESD 3
VBU S3 0. 01u FC68 1nFC69
VBU S 1
D-
2
D+
3
GND 4
CHASSIS 5 CHASSIS 6
USB_D OWN USB2
L21
0. 1uF C36
150u F
C85
15KR51
15KR54
REF1 1
I/O1
2
I/O2
3REF2 4
PSR05
ESD 2
VBU S2 0. 01u FC83 1nFC84
VBU S 1
D-
2
D+
3
GND 4
CHASSIS 5 CHASSIS 6
USB_D OWN USB5
L51
0. 1uF C34
150u F
C75
15KR33
15KR34
REF1 1
I/O1
2
I/O2
3REF2 4
PSR05
ESD 5
VBU S5 0. 01u FC73 1nFC74
VBU S 1
D-
2
D+
3
GND 4
CHASSIS 5 CHASSIS 6
USB_D OWN USB4
L41
0. 1uF C37
150u F
C90
15KR49
15KR50
REF1 1
I/O1
2
I/O2
3REF2 4
PSR05
ESD 4
VBU S4 0. 01u FC88 1nFC89
VBU S 1
D-
2
D+
3
GND 4
CHASSIS 5 CHASSIS 6
USB_D OWN USB7
L71
0. 1uF C35
150u F
C80
15KR38
15KR39
REF1 1
I/O1
2
I/O2
3REF2 4
PSR05
ESD 7
VBU S7 0. 01u FC78 1nFC79
VBU S 1
D-
2
D+
3
GND 4
CHASSIS 5 CHASSIS 6
USB_D OWN USB6
L61
0. 1uF C38
150u F
C95
15KR47
15KR48
REF1 1
I/O1
2
I/O2
3REF2 4
PSR05
ESD 6
VBU S6 0. 01u FC93 1nFC94
10KR55
10KR18
10KR19
NCR20
V3.3REG
J15
J13
J14
2K2 R63
2K 2 R65
VCC5
J12
J11
J1
J2
J3
J4
J5
J6
DP7
V3.3REG
J10
J9
J8
J7
V3.3REG
DM0
DP0
DM1
DP1
DM2
DP2
DM3
DP3
DM4
DP4
DM5
DP5
DM6
DP6
DM7
PSW7 PSW6 PSW1 PSW2 PSW3 PSW4 PSW5
OC1 OC2 OC3 OC4 OC5 OC6 OC7
VCC5(6 9) VAUX(3 0) V3.3(1 1)
330RR40
REDD15
330RR4
AMBRD1 2
330RR8
GRND9
330RR12
GRND4
330RR1
AMBRD1
330RR5
AMBRD2
330RR9
GRND13
330RR13
GRND8
330RR2
AMBRD14
330RR6
AMBRD6
330RR10
GRND11
330RR14
GRND3
330RR3
AMBRD5
330RR7
AMBRD7
330RR11
GRND1 0
VCC5
PIGRN1 PIGRN2 PIGRN3 PIGRN4 PIGRN5 PIGRN6 PIGRN7 PIABR1 PIABR2 PIABR3 PIABR4 PIABR5 PIABR6 PIABR7
SUSPEND NOOC ADOC SP/BP
SP/BP
HP
SUSPEND
ADOC
NOOC
PSW2 PSW1 PSW3 PSW4 PSW7 PSW6 PSW5 OC1 OC2 OC3 OC4 OC5 OC6 OC7
DM1 DP1 DP3 DM3 DM5
DM5 DM7 DP5
DP6
DM0 DM1 DM2 DM3 DM4 DP5
DP6 DM0 DM2 DM4 DM6DM7
DP7
DP4
DP0 DP1 DP2
DP2
DP3 DP4 DM6 DP7
DP0
VCC5(3 1) VAUX(7 0) V3.3(1 3) V3.3(1 7) V3.3(5 0) V3.3(5 2) V3.3(5 6)
V3.3REG
Qrp u N PN
5K6 RVbus
VBU S
J14(By default)
No EEPROM used: J11 & J12 EEPROM used: No J11 & J12

1 1
2 2
3 3
4 4
D D C C B B A A
Ti tl e
Nu mb er Revi sio nSize
A4
Date: 2004-03-24 Sheet of File: C:\My NoteBook Raw\..\1521updatePWR-CCT-A.SchDrawn By:
VCC5
1
4
7 8 5 6
2 3
NDS9 43 5A Q1
10K R21
47K R68
0. 1uF C52
0. 1uF C5 OC1
VBUS1
PSW1
1
4
7 8 5 6
2 3
NDS9 43 5A Q2
10K R22
47K R69
0. 1uF C53
0. 1uF C6 OC2
VBUS2
PSW2
1
4
7 8 5 6
2 3
NDS9 43 5A Q3
10K R23
47K R70
0. 1uF C54
0. 1uF C7 OC3
VBUS3
PSW3
1
4
7 8 5 6
2 3
NDS9 43 5A Q4
10K R24
47K R97
0. 1uF C55
0. 1uF C10 OC4
VBUS4
PSW4
1
4
7 8 5 6
2 3
NDS9 43 5A Q5
10K R25
47K R98
0. 1uF C56
0. 1uF C11 OC5
VBUS5
PSW5
1
4
7 8 5 6
2 3
NDS9 43 5A Q6
10K R26
47K R99
0. 1uF C57
0. 1uF C12 OC6
VBUS6
PSW6
1
4
7 8 5 6
2 3
NDS9 43 5A Q7
10K R27
47K R100
0. 1uF C58
0. 1uF C13 OC7
VBUS7
PSW7
0. 1uF C8
L1
VCC5
0. 1uF C15
L3
V3 .3R EG
0. 1uF C19
L6
V3.3REG
0R
R28
330R R46
0RR16
1uF C33
22uF C61
L5
RED D16
1 2
3 4
5 6
SW1 SW1
J16
VCC5 VBUS
Vin
2
Vss
1
Vout 3
XC6 206 P302 PS1
V3.3REG
1 2 3
DC_ IN PWR_C1
HP
POWE R CI RC UI T
VAUX(3 0)
V3.3(1 1) VCC5(31)
0. 1uF C9
L2
VCC5
VCC5(69)
0. 1uF C32
L4
V3.3REG
VAUX(7 0)
0. 1uF C20
L7
V3.3REG
V3 .3( 13)
0. 1uF C21
L8
V3 .3R EG
V3.3(1 7)
0. 1uF C22
L9
V3.3REG
V3.3(5 0)
0. 1uF C23
L10
V3.3REG
V3.3(5 2)
0. 1uF C24
L12
V3.3REG
V3.3(5 6)
0RR17

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 14 of 20
Component Placement

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 15 of 20
Layer 1: Top Routing

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 16 of 20
Layer 2: Ground Planes

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 17 of 20
Layer3: Power Planes

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 18 of 20
Layer 4: Bottom Routing

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 19 of 20
7. Installing the Board
Assuming that you have already installed the USB host adapter (including drivers) on a computer
running Windows, installing the hub is fairly simple.
1. Plug in power from the power supply to the hub. The power supply must meet the
requirements specified in Section 4.
2. Plug a USB cable in the USB0 port, and connect the other end of the cable to the USB host.
After a while the GoodLink LED (D15) will start to blink. This means that the enumeration
process has successfully completed and the hub is now ready for use.
You can check the driver installation in the Device Manager window. To check whether the
hub is correctly installed in high-speed, choose the View-Devices by connection command
in the Device Manager window.
3. Plug in devices to the downstream facing ports. After these devices are properly
enumerated, the green LEDs will turn ON.

Philips Semiconductors UM10011_4
ISP1521 Hi-Speed USB Hub Demo Board
© Koninklijke Philips Electronics N.V. 2004. All rights reserved.
User manual Rev. 04.00 — 17 June 2004 20 of 20
8. Bill of Materials for the ISP1521 Hub Demo Board
9. References
• Universal Serial Bus Specification Rev. 2.0 (http://www.usb.org/)
• ISP1521 Hi-Speed Universal Serial Bus hub controller data sheet.
Part Type Footprint Quantity Designator
0.01 F 0603C 8 C2, C3, C68, C73, C78, C83, C88, C93
0.1 F 0603C 32 C5, C6, C7, C8, C9, C10, C11, C12, C13, C14, C15, C19,
C20, C21, C22, C23, C24, C25, C30, C32, C34, C35, C36,
C37, C38, C52, C53, C54, C55, C56, C57, C58
0 Ώ0603R 1 R55
0 Ώ0805GR 1 R28
0 Ώ1206G 2 R16, R17
100 F/10 V REC2-25 1 C61
10 kΏ0603R 11
R18, R19, R20, R21, R22, R23, R24, R25, R26, R27, R43, R44
10 F/10 V REC1-2 1 C33
10 F REC1-2 1 C16
12 kΏ, 1% 0603R 1
R53
12 MHz, low profile XTAL7 1 X1
150 F/10 V REC15-3 7 C31, C70, C75, C80, C85, C90, C95
15 kΏ0603R 14 R29, R30, R31, R32, R33, R34, R38, R39, R47, R48, R49, R50,
R51, R54
1.5 kΏ, 1% 0603R 1
R52
1N4148 DIODE0.3 1 D18
1 nF 0603C 8 C1, C4, C69, C74, C79, C84, C89, C94
22 pF 0603C 2 C17, C18
2.2 kΏ0603R 2
R63, R65
330 Ώ0603R 16 R1, R2, R3, R4, R5, R6, R7, R8, R9, R10, R11, R12, R13, R14,
R40, R46
47 kΏ0603R 7
R68, R69, R70, R97, R98, R99, R100
AMBER LED3 7 D1, D2, D5, D6, D7, D12, D14
BLM21AG221SN1 0805G 10 L1, L2, L3, L4, L6, L7, L8, L9, L10, L12
BLM41P600S 1206CUST 8 L5, L11, L21, L31, L41, L51, L61, L71
DC_IN DC-JACK2 1 PWR_C1
GREEN LED3 7 D3, D4, D8, D9, D10, D11, D13
ISP1521 LQFP80-0.5 1 U1
JUMPER 0603 4 J1, J10, J2, J3, J4, J5, J6, J7, J8, J9
JUMPER RAD0.1 6 J11, J12, J13, J14, J15, J16
BA033-3.3 TO-263/D2PAK 1 PS1
USB_UP USB-TYPEB 1 USB0
NDS9435A SO-8 7 Q1, Q2, Q3, Q4, Q5, Q6, Q7
PCF8582 DIP8 1 U2
PSR05 SOT-143 8 ESD0, ESD1, ESD2, ESD3, ESD4, ESD5, ESD6, ESD7
RED LED3 2 D15, D16
SIP_4P PS24254-4 1 CN1
SW1 TOGGSW2 1 SW1
Test Point TP 1 TP1
USB_DOWN USB-TYPEA 7 USB1, USB2, USB3, USB4, USB5, USB6, USB7
