Philips AJ5305D/05 User manual

www.philips.com/welcome
User manual
Always there to help you
Register your product and get support at
AJ5305D/05
Question?
Contact
Philips

1EN
Content
1 Important 2
Safety 2
2 Your Docking Entertainment System 3
Introduction 3
What's in the box 3
Overview of the main unit 4
3 Get started 5
Connect power 5
Turn on 5
Set time and date 5
4 Play 6
Play from iPod/iPhone 6
Listen to radio 9
Play from an external device 10
Adjust volume 10
5 Other features 11
Set alarm timer 11
Set sleep timer 11
Adjust display brightness 11
6 Product information 12
Specications 12
7 Troubleshooting 13
8 Notice 13

2EN
1 Important
Safety
• Heed all warnings, and follow all
instructions.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or other
devices(includingampliers)thatproduce
heat.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the clock radio.
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Unplug the clock radio during lightning
storms or when unused for long periods
of time.
• Referallservicingtoqualiedservice
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
• The clock radio shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on the
clockradio(e.g.liquidlledobjects,lighted
candles).
• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
Warning
•Never remove the casing of this clock radio.
•Never place this clock radio on other electrical
equipment.
•Keep this clock radio away from direct sunlight, naked
amesorheat.
•Toreducetheriskofreorelectricshock,donot
expose this apparatus to rain or moisture.
•Ensure that you always have easy access to the power
cord, plug or adapter to disconnect this clock radio
from the power.

3EN
2 Your Docking
Entertainment
System
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
If you contact Philips, you will be asked for the
model and serial number of this apparatus.The
model number and serial number are on the
bottom of the apparatus.Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
Introduction
With this clock radio, you can
• listen to FM radio;
• enjoy audio from iPod/iPhone or an
external device;
• set alarms to ring at different time;
• choose buzzer, radio, or audio in iPod/
iPhone as your alarm source;
• experience various features brought by
HomeStudio app.
What's in the box
Check and identify the contents of your
package:
• Main unit
• AC adapter
• User manual

4EN
Overview of the main unit
a Display panel
b SOURCE
• Select source.
c
• Turn on/off the clock radio.
d - VOLUME +
• Adjust volume.
e DOCK
• Dock for iPod/iPhone.
f SNOOZE/BRIGHTNESS
• Snooze alarm.
• Adjust display brightness.
g AL1/AL2
• Set alarm.
• View alarm settings.
• Activate/deactivate alarm timer.
h TUNING
• Tune or scan to an FM radio station.
i TIME SET
• Set the time.
j DC IN
• Power supply socket.
f
g
h
i
j
a
b
c
de
m
l
k
g
k FM ANTENNA
• Improve FM reception.
l AUDIO IN
• Connect an external audio device.
m SLEEP
• Set sleep timer.

5EN
3 Get started
Caution
•Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
Always follow the instructions in this chapter in
sequence.
Connect power
Caution
•Risk of product damage! Make sure that the power
voltage corresponds to the voltage printed on the back
or underside of the unit.
•Risk of electric shock! When you unplug the power
adapter, always pull the plug from the socket. Never
pull the cord.
•Before connecting the power adapter, make sure that
you have completed all other connections.
•Use the supplied power adapter only.
Turn on
Press .
» The clock radio switches to the last
selected source.
Switch to standby mode
Press to switch the clock radio to standby
mode.
» Theclock(ifset)isdisplayed.
Set time and date
1 In standby mode, press and hold TIME SET
on the back of your clock radio for more
than two seconds.
» [12H] or [24H] begins to blink.
2 Press / repeatedly to select 12/24
hour format.
3 Press TIME SETtoconrm.
» The hour digits begin to blink.
4 Repeat steps 2-3 to set hour and minute.
Note
•When iPod/iPhone is connected, the unit synchronizes
time from the iPod/iPhone automatically.
Tip
•The accuracy of the transmitted time depends on the
docked iPod/iPhone that transmits the time signal.

6EN
4 Play
Play from iPod/iPhone
You can enjoy audio from iPod/iPhone through
this clock radio.
Compatible iPod/iPhone
The unit supports the following iPod, iPhone
models:
Made for.
• iPod touch 5th generation
• iPod nano 7th generation
• iPhone 5
Install HomeStudio App
Philips HomeStudio app brings a suite of new
features to your clock radio, including FM radio
programming and a multi-function alarm clock.
To enjoy more features, you are recommended
to install this free HomeStudio app.
Note
•Make sure that your iPod/iPhone is connected to the
Internet.
1 Press SOURCE repeatedly to select
DOCK mode.
2 Insert your iPod/iPhone into the dock.
3 Fortherst-timeuse,youwillbeaskedto
install the HomeStudio app on your iPod/
iPhone.
4 Tap [Yes] to accept the installation request.
5 Follow the on-screen instructions to
complete the installation.
Philips HomeStudio app only can be installed in
the following iPod, iPhone models:
• iPhone 5
• iPod touch 5th generation
Register an account
Fortherst-timeusetheHomeStudioApp,you
must register an account.
SOURCE

7EN
1 Tap HomeStudio icon on your iPod/
iPhone.
2 Followtheon-screeninstructiontonish
the registration.
Play music in the iPod/iPhone
Note
•Make sure that you have installed the HomeStudio app
on your iPod/iPhone.
1 Tap HomeStudio icon on your iPod/
iPhone.
2 Tap to select Music library source.
3 Select a track from the playlist, and then
press .
» Music streams from your iPod/iPhone
to the clock radio.
Use more features with "HomeStudio
App"
Note
•Make sure that your iPod/iPhone is inserted into the
clock radio.
Set alarm clock:
1 Launch the HomeStudio app.

8EN
2 On the screen below, tap the .
3 You can choose to turn the alarm1/alarm2
on or off.
Set sleep timer:
1 Tap and then tap
2 Choose a period of time and tap Start.
Store FM radio stations automatically
1 Tap and then tap the icon on right top
the screen to select FM Radio source.
2 Tap to search the radio station with
strong reception automatically.
» All available stations are stored.
» Therststoredradiostationis
broadcast automatically.
Store FM radio stations manually
1 Select FM Radio source.
2 Tap / to tune to a radio station.
• You can also tap and drag on the
frequency scale to tune to the desired
frequency directly.
3 Tap to add the current station to a
preset list.

9EN
4 Select a preset number, enter the station
title, then Done.
5 Repeat the above step to store more
stations.
Dimmer the screen brightness
1 Tap and then tap to dimmer the
screen the screen brightness.
2 Tap anywhere to restore the screen
brightness.
User more features
Tap (Settings),youcan:
• Set the virtual skin
• Set the location for weather report
• Choose the temperature unit.
• Set the clock
• See the App information
• Register an account
• Upgradermware.
• Share the information to Twitter.
• Send feedback
Charge the iPod/iPhone
When your clock radio is connected to power,
the docked iPod/iPhone begins to charge
automatically.
Remove the iPod/iPhone
Pull the iPod/iPhone out of the dock.
Listen to radio
Note
•Keep the unit away from other electronic devices to
avoid radio interference.
•For better reception, do not place iPod/iPhone into
the dock when you listen to the radio. Fully extend and
adjust the position of the FM antenna.

10 EN
Tune to FM radio stations
You also can tune to radio stations from your
clock radio.
1 Press SOURCE repeatedly to select FM
tuner.
2 Press and hold / on the back
of your clock radio for more than two
seconds.
» The radio tunes to a station with
strong reception automatically.
3 Repeat step 2 to tune to more stations.
To tune to a station manually:
Press / repeatedlyuntilyoundoptimal
reception.
Play from an external device
You can also listen to an external audio device
through this clock radio.
1 Press SOURCE to select the AUX source.
2 Connecttheaudioincable(notsupplied)
to:
• the AUDIO INsocket(3.5mm)atthe
back of your clock radio.
• the headphone socket of an external
device.
3 Start to play the device (see the user
manualofthedevice).
Adjust volume
VOLUME

11EN
5 Other features
Set alarm timer
Set alarm
You can set two alarms to ring at different time.
Buzzer, FM radio, or your last listened audio in
the iPod/iPhone can be selected as alarm sound.
Note
•Make sure that you have set the clock correctly.
1 Press and hold AL1/AL2 for more than
two seconds to activate alarm setting
mode.
» The hour digits and alarm icon begin
to blink.
2 Press / repeatedly set the hour.
3 press AL1/AL2toconrm.
» The minute digits begin to blink.
4 Repeat steps 2-3 to set the minute, select
an alarm source (buzzer, FM radio, or
dock),andadjustvolume.
Tip
•If iPod/iPhone is selected as alarm source, but no iPod/
iPhone is connected, the clock radio switches to buzzer
source instead.
Activate/deactivate alarm timer
1 Press AL1/AL2.
» The alarm settings are displayed.
2 Press AL1/AL2 repeatedly to activate or
deactivate the alarm timer.
» [AL1] or [AL2] is displayed if the alarm
timer is on and disappears if it is off.
• To stop the ringing alarm, press the
corresponding AL1/AL2.
» The alarm repeats ringing for the next
day.
Snooze alarm
When alarm sounds, press SNOOZE.
» The alarm snoozes and repeats ringing
nine minutes later.
Set sleep timer
This clock radio can switch to standby mode
automatically after a preset period.
Press SLEEP repeatedly to select the sleep
timerperiod(inminutes).
» When the sleep timer is activated,
appears.
To deactivate the sleep timer, press SLEEP
repeatedly until OFF appears.
Adjust display brightness
Press BRIGHTNESS repeatedly to select
different brightness levels.
15 30 60 90 120
OFF

12 EN
6 Product
information
Note
•Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output Power 2 X 2 W RMS
Frequency Response 40-20000 Hz
Signal to Noise Ratio >65 dB
Total Harmonic Distortion <1%
AuxInput(MP3link) 0.6 V RMS 10
k ohm
Tuner (FM)
Tuning range 87.5-108
MHz
Tuning grid 50 KHz
Sensitivity
- Mono, 26 dB S/N Ratio
- Stereo, 46 dB S/N Ratio
<22 dBf
<46 dBf
Search Selectivity 30 dBf
Speakers
Speaker Impedance 4 ohm
Sensitivity >82 dB/m/W
General information
AC power (power
adapter)
Brand name: Philips;
Model:Y12FE-059-
2000G;
Input: 100-240 V~, 50-
60 Hz; 0.35 A;
Output: 5.9 V 2000
mA;
Operation Power
Consumption
<10 W
Standby Power
Consumption
<1 W
Dimensions:
Main Unit
(WxHxD)
283 x 118 x 112 mm
Weight:
-Main Unit
-With Packing
0.654 kg
0.812 kg

13EN
7 Troubleshooting
Warning
•Never remove the casing of this device.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.
philips.com/support).WhenyoucontactPhilips,
make sure that the device is nearby and the
model number and serial number are available.
No power
•Ensure that the AC power plug of the unit
is connected properly.
•Ensure that there is power at the AC
outlet.
No sound
•Adjust the volume.
No response from the unit
•Disconnect and reconnect the AC power
plug, then turn on the unit again.
Poor radio reception
•Increase the distance between the unit and
your TV or VCR.
•Fully extend the FM antenna.
Alarm does not work
•Set the clock/alarm correctly.
Clock/alarm setting erased
•Power has been interrupted or the power
plug has been disconnected.
•Reset the clock/alarm.
8 Notice
This product complies with the radio
interference requirements of the European
Community.
Anychangesormodicationsmadetothis
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local
separate collection system for electrical and
electronic products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste.
Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separateintothreematerials:cardboard(box),
polystyrenefoam(buffer)andpolyethylene
(bags,protectivefoamsheet.)
Your system consists of materials which can
be recycled and reused if disassembled by

14 EN
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
“Made for iPod” and “Made for iPhone”
mean that an electronic accessory has been
designedtoconnectspecicallytoiPodor
iPhonerespectively,andhasbeencertiedby
the developer to meet Apple performance
standards. Apple is not responsible for the
operation of this device or its compliance with
safety and regulatory standards. Please note that
the use of this accessory with iPod or iPhone
may affect wireless performance.
iPod and iPhone are trademarks of Apple Inc.,
registered in the U.S. and other countries.
2013 © Koninklijke Philips Electronics N.V. All
rights reserved.
Specicationsaresubjecttochangewithout
notice.Trademarks are the property of
Koninklijke Philips Electronics N.V. or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
Note
•The type plate is located on the bottom of the
apparatus.

15EN

Specifications are subject to change without notice
© 2013 Koninklijke Philips Electronics N.V.
All rights reserved.
AJ5305D_05_UM_V2.0
