Philips 437 User manual

Model: 437
Model: 438
DVD VIDEO PLAYER
.User Manual
.Manuel D’utilisation
.Manual de Instrucciones
.Manual do Utilizador
.Gebruikershandleiding
01-39_xDV437_438_55_77_eng2.indd1 101-39_xDV437_438_55_77_eng2.indd1 1 2007-01-03 11:20:43 AM2007-01-03 11:20:43 AM

English
2
LASER
Type Semiconductor laser
InGaAlP (DVD)
AIGaAs (CD)
Wave length 658 nm (DVD)
790 nm (CD)
Output Power 7.0 mW (DVD)
10.0 mW (VCD/CD)
Beam divergence 60 degrees
General Information
Environmental Information
All unnecessary packaging has been
omitted. The packaging has been made
easy to separate into two materials;
cardboard (box) and polyethylene (bags,
protective foam sheet).
Your DVD player consists of materials
which can be recycled and reused if
disassembled by a specialised company.
Please observe the local regulations
regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
(only for model 438)
Laser Safety
This unit employs a laser. Due to possible
eye injury, only a qualied service person
should remove the cover or attempt to
service this device.
NOTE:
Pictures shown maybe different
between countries.
CAUTION:
WARNING LOCATION: ON THE
BACKPLATE OF THE SET
NEVER MAKE OR CHANGE
CONNECTIONS WITH THE
POWER SWITCHED ON.
For Customer Use:
Read carefully the information located at
the bottom or rear of your DVD Video
player and enter below the Serial No.
Retain this information for future
reference.
Model No. 437 & 438
Serial No. ___________________
Specications are subject to change without
notice. Trademarks are the property of
Koninklijke Philips Electronics N.V. or their
respective owners.
Manufactured under license from
Dolby Laboratories, “Dolby”
and the double-D symbol are
trademarks of Dolby Laboratories.
logo.indd 1 2006-03-21 10:25:36 AM
logo.indd 1 2006-03-21 10:25:36 AM
DivX Certied products: “DivX ”,
“DivX Certied” and associated logos
are trademarks of DivX , Inc. and
are used under license.
Copyright Notice: The making of
unauthorized copies of copy-protected
material, including computer programs, les,
broadcasts and sound recordings, may be an
infringement of copyrights and constitute a
criminal offence. This device should not be
used for such purposes.
01-39_xDV437_438_55_77_eng2.indd2 201-39_xDV437_438_55_77_eng2.indd2 2 2007-01-03 11:20:47 AM2007-01-03 11:20:47 AM

English
EspañolPortuguês
Index
English ------------------------------------------6
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual property
rights owned by Macrovision Corporation and other
rights owners. Use of this copyright protection
technology must be authorized by Macrovision
Corporation, and is intended for home and other
limited viewing uses only unless otherwise authorized
by Macrovision Corporation. Reverse engineering or
disassembly is prohibited.
Português --------------------------------- 76
Español --------------------------------------- 40
01-39_xDV437_438_55_77_eng2.indd3 301-39_xDV437_438_55_77_eng2.indd3 3 2007-01-03 11:20:48 AM2007-01-03 11:20:48 AM

English
4
Contents
Care and Safety Information
Setup .............................................................................................................................................................6
Cleaning discs .............................................................................................................................................6
General Information
Accessories supplied ................................................................................................................................7
Region codes...............................................................................................................................................7
Connections
Connecting to television..............................................................................................8-9
Using Composite Video jacks (CVBS).................................................................................................8
Using Component Video jacks (YPbPr)..............................................................................................8
Using an accessory RF modulator ........................................................................................................9
Connecting the power cord.......................................................................................... 10
Optional connections
Connecting to an stereo system...................................................................................11
Stereo system has right/left Audio In jacks .....................................................................................11
Connecting to a digital AV receiver.............................................................................11
Receiver has a PCM, Dolby Digital or MPEG decoder.................................................................11
Product Overview
Front and Rear panels ....................................................................................................12
Remote Control ..............................................................................................................13
Getting Started
Step 1: Inserting Batteries.............................................................................................14
Using the remote control to operate the system......................................................................... 14
Step 2: Finding your viewing channel...........................................................................14
Step 3: Setting up Progressive Scan feature.............................................................. 15
Step 4: Selecting the matching color system .............................................................16
Step 5: Setting the language .........................................................................................17
On-screen display (OSD) language.....................................................................................................17
Audio, Subtitle and DVD menu languages........................................................................................17
Playback from Disc
Playable discs.................................................................................................................. 18
Supported formats................................................................................................................................. 18
Playback Features
Starting disc playback ....................................................................................................19
Basic playback controls..................................................................................................19
Pausing playback...................................................................................................................................... 19
Selecting title/chapter/track ................................................................................................................ 19
Stopping playback................................................................................................................................... 19
Operations for video playback..................................................................................... 20
Using the Disc Menu ............................................................................................................................. 20
Zooming in ............................................................................................................................................... 20
Resuming playback from the last stopped point............................................................................20
Slow Motion............................................................................................................................................. 20
Forward / Reverse Searching .............................................................................................................. 20
Selecting various repeat functions.............................................................................. 21
Repeat play mode................................................................................................................................... 21
Repeating a section within a chapter/track.....................................................................................21
01-39_xDV437_438_55_77_eng2.indd4 401-39_xDV437_438_55_77_eng2.indd4 4 2007-01-03 11:20:48 AM2007-01-03 11:20:48 AM

English
5
Contents
Viewing the disc playback information ...............................................................22
Title/Chapter/Track selection ............................................................................................................ 22
Time Search ............................................................................................................................................. 22
Angle .......................................................................................................................................................... 22
Special DVD Features ................................................................................................... 23
Playing a Title........................................................................................................................................... 23
Changing the Audio Language............................................................................................................. 23
Subtitles..................................................................................................................................................... 23
Special VCD and SVCD Feature.................................................................................. 23
Playback Control (PBC)........................................................................................................................ 23
Playing a DivX®disc ....................................................................................................... 24
Playing MP3/WMA/JPEG/Kodak/Fuji Picture CD................................................24-25
General Operation ................................................................................................................................ 24
Playback selection .................................................................................................................................. 25
Zoom picture (JPEG) ............................................................................................................................ 25
Playback with multi-angles (JPEG)..................................................................................................... 25
DVD Menu Options
Using the Language setup menu ................................................................................. 26
OSD Language......................................................................................................................................... 26
Subtitle / Audio / DVD Menu.............................................................................................................. 26
Setting the DivX®Subtitle font........................................................................................................... 26
Using the Video setup menu ................................................................................... 27-29
Setting the Aspect Ratio ...................................................................................................................... 27
View Mode ............................................................................................................................................... 28
TV System ................................................................................................................................................ 28
Video Out................................................................................................................................................. 28
Smart Picture........................................................................................................................................... 29
Using the Audio setup menu...................................................................................30-31
Digital Output ......................................................................................................................................... 30
Night Mode .............................................................................................................................................. 31
Down Sampling ....................................................................................................................................... 31
Using the Rating setup menu.................................................................................. 31-33
Rating level settings ............................................................................................................................... 32
Changing the Password......................................................................................................................... 33
Using the Misc (Miscellaneous) setup menu .........................................................33-34
Restoring to the original settings....................................................................................................... 34
Volume Control...................................................................................................................................... 34
DivX®Registration Code ..................................................................................................................... 34
Others
Software Upgrade ......................................................................................................... 35
Troubleshooting.......................................................................................................36~37
Specications ................................................................................................................. 38
Glossary........................................................................................................................... 39
01-39_xDV437_438_55_77_eng2.indd5 501-39_xDV437_438_55_77_eng2.indd5 5 2007-01-03 11:20:48 AM2007-01-03 11:20:48 AM

English
6
Care and Safety Information
DANGER!
High voltage! Do not open the
device. You run the risk of getting
an electric shock.
The machine does not contain any
user-serviceable parts. Please leave
all maintenance work to qualied
personnel.
Setup
Finding a suitable location
– Place the set on a at, hard and stable
surface. Do not place the set on a
carpet.
– Do not put any equipment or heavy
objects on top of the set.
– Do not position the set on top of
other equipment that might heat it up
(such as receiver or amplier).
– Do not put anything under the set
(such as CDs, magazines).
– Install this unit near the AC outlet and
where the AC power plug can be
reached easily.
Space for ventilation
– Place the apparatus in a location with
adequate ventilation to prevent
internal heat build up. Allow at least
10 cm (4.0”) clearance from the rear
and the top of the set and 5cm (2.0”)
from the left and right to prevent
overheating.
10cm (4.0") 10cm (4.0")
5cm (2.0")
5cm (2.0")
Avoid high temperatures, moisture,
water and dust
– Apparatus shall not be exposed to
dripping or splashing.
– Do not place any sources of danger
on the apparatus (such as liquid lled
objects, lighted candles).
Cleaning discs
Some problems occur because the disc
inside the player is dirty (frozen picture,
sound disruptions, picture distortions).
To avoid these problems, discs should be
cleaned on a regular basis.
To clean a disc, use a micro bre cleaning
cloth and wipe the disc from the center
to the edge in a straight line.
CAUTION!
Do not use solvents such as benzene,
thinner, commercially available cleaners,
or anti-static sprays intended for analog
discs. Since the optical unit (laser) of the
DVD player operates at a higher power
than regular DVD or CD players,
cleaning CDs intended for DVD or CD
players may damage the optical unit
(laser). Therefore, refrain from using a
cleaning CD.
01-39_xDV437_438_55_77_eng2.indd6 601-39_xDV437_438_55_77_eng2.indd6 6 2007-01-03 11:20:48 AM2007-01-03 11:20:48 AM

English
7
General Information
Accessories supplied
ALL
4
Region
U.S.A. and
Canada regions
U.K and
Europe regions
Asia Pacic,
Taiwan, Korea
Australia,
New Zealand,
Latin America
Russia and
India regions
China, Calcos Islands,
Walls and Futuna
Islands
ALL
ALL
5
6
Discs that can
be played
ALL
1
ALL
ALL
2
3
Remote
control and
two AAA
batteries
Region codes
This DVD player is designed to support
the Region Management System. Check
the regional code number on the disc
package. If the number does not match
the player’s region number (see table
below), the player may be unable to
playback the disc.
Tips:
– It may not be possible to play CD-R/RW
or DVD-R/RW in all cases due to the type of
disc or condition of the recording.
– If you are having trouble playing a certain
disc, remove the disc and try a different one.
Improper formatted disc will not played on
this DVD player.
Audio cable
(white, red)
Video cable
(yellow)
01-39_xDV437_438_55_77_eng2.indd7 701-39_xDV437_438_55_77_eng2.indd7 7 2007-01-03 11:20:49 AM2007-01-03 11:20:49 AM

English
8
IMPORTANT!
– The progressive scan video quality
is only possible when using YPbPr
and a progressive scan television is
required.
Using Component Video jacks
(YPbPr)
AUse the component video cables (red/
blue/green) to connect the DVD player’s
YPbPr jacks to the component video
input jacks (or labeled as YPbPr) on the
television (cable not supplied).
BTo hear sound of this DVD player
through your television, use the audio
cables (white/red) to connect AUDIO
OUT (L/R) jacks of the DVD player to
the corresponding AUDIO IN jacks on
the television (cable supplied).
CProceed to page 15 for detailed
progressive scan setup.
Connections
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
Connecting to television
IMPORTANT!
– You only need to make one video
connection from the following
options, depending on the
capabilities of your television.
– Connect the DVD player directly
to the television.
Using Composite Video jacks
(CVBS)
AUse the composite video cable (yellow)
to connect the DVD player’s TV OUT
(CVBS) jack to the video input jack (or
labeled as A/V In, Video In, Composite or
Baseband) on the television (cable
supplied).
BTo hear sound of this DVD player
through your television, use the audio
cables (white/red) to connect AUDIO
OUT (L/R) jacks of the DVD player to
the corresponding AUDIO IN jacks on
the television (cable supplied).
AUDIO OUT
DIGITAL
OUT TV OUT
COAXIAL
AUDIO
IN
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO
OUT
V(Pr/Cr)
U(Pb/Cb)
Y
S-VIDEO
IN
VIDEOIN
COMPONENT
VIDEOIN
2 1
COMPONENT VIDEO OUT
COMPONENT VIDEO OUT
01-39_xDV437_438_55_77_eng2.indd8 801-39_xDV437_438_55_77_eng2.indd8 8 2007-01-03 11:20:49 AM2007-01-03 11:20:49 AM

English
9
AUDIO OUT
DIGITAL
OUT TV OUT
COAXIAL
AUDIO IN
R L
VIDEO
IN
TO TVINT IN
CH3 CH4
1
COMPONENT VIDEO OUT
Connections (continued)
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
IMPORTANT!
– If your television only has a single
Antenna In jack (or labeled as 75
ohm or RF In,) you will need an RF
modulator in order to view the
DVD playback on the television. See
your electronics retailer for details
on RF modulator availability and
operations.
Using an accessory RF modulator
AUse the composite video cable (yellow)
to connect the DVD player’s TV OUT
(CVBS) jack to the video input jack on
the RF modulator.
BUse the RF coaxial cable (not supplied) to
connect ANTENNA OUT or TO TV jack
on the RF modulator to the ANTENNA
IN jack on the television.
RF coaxial cable to TV
Back of RF Modulator
(example only)
CTo hear sound of this DVD player
through your TV, use the audio cables
(white/red) to connect AUDIO OUT (L/
R) jacks of the DVD player to the
corresponding AUDIO IN jacks on the
RF modulator (cable supplied).
DConnect the Antenna or Cable TV
service signal to the ANTENNA IN or RF
IN jack on the RF modulator. (It may
have been connected to your TV
previously. Disconnect it from the TV).
01-39_xDV437_438_55_77_eng2.indd9 901-39_xDV437_438_55_77_eng2.indd9 9 2007-01-03 11:20:50 AM2007-01-03 11:20:50 AM

English
10
Connections (continued)
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
Connecting the power cord
After everything is connected
properly, plug in the AC power cord
to the power outlet.
Never make or change any connections
with the power switched on.
When no disc is loaded, press
STANDBY ON on the DVD player
front panel.
“– – –” may appear on the display
panel.
AUDIO OUT
DIGITAL
OUT TV
O
COAXIAL
~ AC MAINS
AUDIO
OUT
V(Pr/Cr)
U(Pb/Cb)
Y
S-VIDEO
IN
VIDEOIN
COMPONENT
VIDEOIN
01-39_xDV437_438_55_77_eng2.indd10 1001-39_xDV437_438_55_77_eng2.indd10 10 2007-01-03 11:20:50 AM2007-01-03 11:20:50 AM
