TABLE OF CONTENTS
Page
Version 1.0
Service Manual
. Technical Specifications…………....………………………..............1-2
. Safety Instruction, Warning & Notes….……………………....….....1-3
. Mechanical and Dismantling Instructions…………........................3-1
. Software Version & Upgrades, Region Code Change..……..........4-1
. Trouble Shooting Chart…………………..……………………………
.5-1
. Wiring Diagram………………………………………..………..….….6-1
. Electrical Diagrams and Print-layouts..….…………………....….…7-1
. Set Mechanical Exploded view & Part list.…………………..….….8-1
©Copyright 2009 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in aretrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
CLASS 1
LASER PRODUCT
PHILIPS
GB
. DFU Instruction..............................................................................2-1
. Revision List..................................................................................9-1
Published by FK-0912 BU AVM Printed in The Netherlands Subject to modification
DVP3320
DVP3320/55
3141 785 33870

Great user manuals database on UserManuals.info
Audio performance
DAconverter:24bits,192kHz
Frequency response:
DVD:4Hz-22kHz(48kHz);4Hz
-44kHz(96kHz)
SVCD:4Hz-20kHz(44.1kHz);4
Hz-22kHz(48kHz)
CD/VCD:4Hz-20kHz(44.1kHz)
Signal-Noise(1kHz):>90dB(A-
weighted)
Dynamicrange(1kHz):>80dB(A-
weighted)
Crosstalk(1kHz):>90dB
Distortion/noise(1kHz):>65dB
MPEG MP3: MPEG Audio L3
Audio format
Digital:
MPEG/AC-3/PCM: Compressed
digital(16,20,24bitsfs,44.1,48,96
kHz)
MP3(ISO9660):96,112,128,256
kbps&variablebitratefs,32,44.1,
48 kHz
Analog sound stereo
Dolby surround compatible downmix
from Dolby Digital multi-channel sound
Connections
YPbProutput:Cinch3x
Video output: Cinch (yellow)
Audiooutput(L+R):Cinch(white/red)
Digital output:
1coaxial:IEC60958forCDDA/
LPCM;IEC61937forMPEG1/2,
Dolby Digital
Main unit
Dimensions(wxhxd):360x37x209
(mm)
Net Weight: approximately 1.3 kg
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Specification
Note
6SHFLÀFDWLRQDQGGHVLJQDUHVXEMHFWWRFKDQJH
without notice.
•
Accessories supplied
Remote control and batteries
Audio/video cables
Power cable
Playback media
DVD-Video, Video CD/SVCD, Audio CD,
CD-R/CD-RW, DVD+R/+RW, DVD-R/-
RW,PictureCD,MP3-CD,WMA-CD,
86%ÁDVKGULYH
USB
Compatibility: USB
Class support: UMS (USB Mass Storage
Class)
TV standard
Number of lines:
625(PAL/50Hz);525(NTSC/60Hz)
Playback: Multi-standard (PAL/NTSC)
Video performance
VideoDAC:14bits,108MHz
YPbPr:0.7Vpp~75ohm
Videooutput:1Vpp~75ohm
Video format
Digital compression:
MPEG 2: DVD/SVCD
MPEG 1: VCD
Horizontal resolution:
DVD:720pixels(50Hz);720pixels
(60 Hz)
VCD:352pixels(50Hz);352pixels
(60 Hz)
Vertical resolution:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
DVD:576pixels(50Hz);480pixels
(60 Hz)
VCD:288lines(50Hz);240lines
(60 Hz)
•
•
Power
Powersupplyrating:110V-240V;50/60
Hz
Powerconsumption:<10W
Power consumption in standby mode: <
1W
/DVHUVSHFLÀFDWLRQ
Type: Semiconductor laser InGaAIP
(DVD), AIGaAs (CD)
Wavelength:655nm(DVD),790nm
(CD)
Output Power: 10 mW (DVD), 5 mW
(VCD/CD)
Beam divergence: 60 degrees
•
•
•
•
•
•
•
1-2

Great user manuals database on UserManuals.info
Safety instruction
1. General safety
Safety regulations require that during a repair:
. Connect the unit to the mains via an isolation transformer.
. Replace safety components indicated by the symbol ,
only by components identical to the original ones. Any
other component substitution (other than original type)
may increase risk of fire or electrical shock hazard.
Safety regulations require that after a repair, you must
return the unit in its original condition. Pay, in particular,
attention to the following points:
. Route the wires/cables correctly, and fix them with the
mounted cable clamps.
. Check the insulation of the mains lead for external
damage.
. Check the electrical DC resistance between the mains
plug and the secondary side:
1) Unplug the mains cord, and connect a wire between
the two pins of the mains plug.
2) Set the mains switch the “on” position (keep the
mains cord unplug).
3) Measure the resistance value between the mains
plug and the front panel, controls, and chassis
bottom.
4) Repair or correct unit when the resistance
measurement is less than 1M
¡
.
5) Verify this, before you return the unit to the
customer/user (ref. UL-standard no. 1492).
6) Switch the unit “off”, and remove the wire between
the two pins of the mains plug.
2.Laser safety
This unit employs a laser. Only qualified service personnel
may remove the cover, or attempt to service this device
(due to possible eye injury).
Laser device unit
Type :SemiconductorlaserGaAlAs
Wavelength : 650nm (DVD)
: 780nm (VCD/CD)
Output power : 7mW (DVD)
:10mW(DVD/CD)
Beam divergence: 60 degree
Note: Use of controls or adjustments or performance of
procedure other than those specified herein, may result in
hazardous radiation exposure. Avoid direct exposure to
beam.
Safet
y
instruction, Warnin
g
& Notes
1-3

Great user manuals database on UserManuals.info
Warning
1.General
. All ICs and many other semiconductors are susceptible to
electrostatic discharges (ESD). Careless handing during
repair can reduce life drastically. Make sure that, during
repair, you are at the same potential as the mass of the
set by a wristband with resistance. Keep components and
tools at this same potential. Available ESD protection
equipment:
1) Complete kit ESD3 (small tablemat, wristband,
connection box, extension cable and earth cable)
4822 310 10671.
2) Wristband tester 4822 344 13999.
. Be careful during measurements in the live voltage
section. The primary side of the power supply , including
the heat sink, carries live mains voltage when you
connect the player to the mains (even when the player is
“off”!). It is possible to touch copper tracks and/or
components in this unshielded primary area, when you
service the player. Service personnel must take
precautions to prevent touching this area or components
in this area. A “lighting stroke” and a stripe-marked
printing on the printed wiring board, indicate the primary
side of the power supply.
. Never replace modules, or components, while the unit is
“on”.
2. Laser
. The use of optical instruments with this product, will
increase eye hazard.
. Only qualified service personnel may remove the cover
or attempt to service this device, due to possible eye
injury.
. Repair handing should take place as much as possible
with a disc loaded inside the player.
. Text below is placed inside the unit, on the laser cover
shield:
Notes: Manufactured under licence from Dolby
Laboratories. The double-D symbol is trademarks of Dolby
Laboratories, Inc. All rights reserved.
CAUTION: VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN, AVOID EXPOSURE
TO BEAM.
1-4

Great user manuals database on UserManuals.info
Lead-Free requirement for service
INDENTIFICATION:
Regardless of special logo (not always indicated)
One must treat all sets from 1.1.2005 onwards, according
next rules.
Important note: In fact also products a little older can also
be treated in this way as long as you avoid mixing
solder-alloys (leaded/ lead-free). So best to always use
SAC305 and the higher temperatures belong to this.
Due to lead-free technology some rules have to be
respected by the workshop during a repair:
xUse only lead-free solder alloy Philips SAC305 with
order code 0622 149 00106. If lead-free solder-paste is
required, please contact the manufacturer of your
solder-equipment. In general use of solder-paste within
workshops should be avoided because paste is not easy
to store and to handle.
xUse only adequate solder tools applicable for lead-free
solder alloy. The solder tool must be able
oTo reach at least a solder-temperature of 400°C,
oTo stabilize the adjusted temperature at the
solder-tip
oTo exchange solder-tips for different applications.
xAdjust your solder tool so that a temperature around
360°C – 380°C is reached and stabilized at the solder
joint. Heating-time of the solder-joint should not exceed
~ 4 sec. Avoid temperatures above 400°C otherwise
wear-out of tips will rise drastically and flux-fluid will be
destroyed. To avoid wear-out of tips switch off un-used
equipment, or reduce heat.
xMix of lead-free solder alloy / parts with leaded solder
alloy / parts is possible but PHILIPS recommends
strongly to avoid mixed
solder alloy types (leaded and lead-free). If one cannot
avoid, clean carefully the
solder-joint from old solder alloy and re-solder with new
solder alloy (SAC305).
xUse only original spare-parts listed in the
Service-Manuals. Not listed standard-material
(commodities) has to be purchased at external
companies.
xSpecial information for BGA-ICs:
- always use the 12nc-recognizable soldering
temperature profile of the specific BGA (for
de-soldering always use highest lead-free
temperature profile, in case of doubt)
- lead free BGA-ICs will be delivered in so-called
‘dry-packaging’ (sealed pack including a silica gel
pack) to protect the IC against moisture. After
opening, dependent of MSL-level seen on
indicator-label in the bag, the BGA-IC possibly
still has to be baked dry. This will be
communicated via AYS-website.
Do not re-use BGAs at all.
xFor sets produced before 1.1.2005, containing
leaded soldering-tin and components, all needed
spare-parts will be available till the end of the
service-period. For repair of such sets nothing
changes.
xOn our website:
www.atyourservice.ce.Philips.com
You find more information to:
BGA-de-/soldering (+ baking instructions)
Heating-profiles of BGAs and other ICs used in
Philips-sets
You will find this and more technical information
within the “magazine”, chapter “workshop news”.
For additional questions please contact your local
repair-helpdesk.
Notes
1-5

Great user manuals database on UserManuals.info
Product overview
Main unit
a(Standby-On)
TurnsontheDVDplayerorswitches
to standby mode.
bDisc compartment
cDisplay panel
d(Open/Close)
Opens or closes the disc
compartment.
e(Play/Pause)
Starts, pauses or resumes disc play.
f(USB) jack
&RQQHFWD86%ÁDVKGULYH
Remote control
a(Standby-On)
TurnsontheDVDplayerorswitches
to standby mode.
b(Open/Close)
•
•
•
•
•
66
4
3
6
7
9
8
1
5
2
16
17
12
15
13
14
10
11
18
4
3
6
7
9
8
1
5
2
16
17
12
15
13
14
10
11
18
Opensorclosesthedisc
compartment.
cDISC MENU
Accesses or exits the disc menu.
Switches to disc mode.
ForVCDandSVCD,turnsPBC
(playbackcontrol)onoroffinPBC
mode.
d(Navigation buttons)
Navigates through the menus.
Searchesfast-forward(right)orfast-
backward (left). Press repeatedly to
change the search speed.
Searches slow-forward (up) or slow-
backward (down). Press repeatedly
to change the search speed.
eBACK
Returns to the previous menu.
ForDVD,navigatestotitlemenu.
ForVCDversion2.0orSVCDwith
PBCturnedon,returnstothemenu.
f/ (Previous/Next)
Skips to the previous or next title,
chapter, or track.
Press and hold for fast-backward or
fast-forward search.
g(USB)
Switches to USB mode and displays
the content.
hNumeric buttons
Selectsanitemtoplay.
iSUBTITLE
Selects the subtitle language on a
disc.
jZOOM
Fits the picture format to the TV
screen.
Zoomsinoroutofthepicture.
kREPEAT
Toggles between various repeat
modes.
lREPEAT A-B
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2-1

Great user manuals database on UserManuals.info
Marks the section for repeat play, or
turnsoffrepeatmode.
mAUDIO
Selects an audio language or channel
onadisc.
n(Stop)
Stops disc play.
o(Play/Pause)
Starts, pauses or resumes disc play.
pINFO
For discs, displays information about
the current status or the disc.
For slideshows, displays a thumbnail
YLHZRISKRWRÀOHV
qOK
&RQÀUPVDQHQWU\RUVHOHFWLRQ
rSETUP
Accesses or exits the setup menu.
•
•
•
•
•
•
•
•
2-2

Great user manuals database on UserManuals.info
Mechanical and Dismantling Instructions
Dismantling Instruction
The following guidelines show how to dismantle the player.
Step1: Remove 5 screws around the Top Cover, and then remove the Top Cover (Figure 1).
Figure 1
Step2: If it is necessary to dismantle Loader or Front Panel, the Front door should be removed first. (Figure 2)
Note: Make sure to operate gently otherwise the guider would be damaged.
Figure 2
3-1
Please kindly note that dismantle the front door
assembly carefully to avoid damage tray and the front door.
Detailed information please refer to the model set.

Great user manuals database on UserManuals.info
Mechanical and Dismantling Instructions
Dismantling Instruction
Step3: If the tray can’t open in normal way, you can make it through the instruction as below (Figure 3).
Note: Make sure to operate gently otherwise the guider would be damaged.
Figure 3
Step4: Dismantling Front Panel, disconnect the connectors (XP1), need release 4 snaps of Front Panel
and 2 snaps of bottom cabinet , then gently pull the Panel out from the set. (Figure 4 - Figure 6)
Figure 4
3-2
Detailed information please refer to the model set.
XP7
XP8
XP9
XP1
XP2
XP10
XP5
XP6

Great user manuals database on UserManuals.info
3-3
Mechanical and Dismantling Instructions
Dismantling Instruction
Figure 5
Step5: Dismantling Loader, disconnect the 3 connectors (XP7, XP8, XP9) aiming in the below figure, and remove 1 screw that
connects the loader and the bottom cabinet. (Figure 5 & 6)
Figure 6
Detailed information please refer to the model set.
