Philips 5 User manual

5 Series
gum health
Rechargeable
Sonic Toothbrush

1
2
3
4
5
6
7
8
9
1

English 6
简体中文 16
繁體中文 24

English
Important safety information
Read this important information carefully before you use the
appliance and save it for future reference.
Danger
- Keep the charger away from water. Do not place or store it over or
near water contained in a bathtub, washbasin, sink etc. Do not
immerse the charger in water or any other liquid. After cleaning,
make sure the charger is completely dry before you connect it to
the wall socket.
Warning
- The mains cord cannot be replaced. If the mains cord is damaged,
discard the charger.
- Always have the charger replaced with one of the original type in
order to avoid a hazard.
- Do not use the charger outdoors or near heated surfaces.
- If the appliance is damaged in any way (brush head, toothbrush
handle or charger), stop using it. This appliance contains no
serviceable parts. If the appliance is damaged, contact the
Consumer Care Center in your country (see chapter 'Warranty and
support').
- This appliance can be used by children and persons with reduced
physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the
hazards involved. Cleaning and user maintenance shall not be
made by children without supervision.
- Children shall not play with the appliance.
Caution
- Do not clean the brush head, the handle or the charger in the
dishwasher.
- If you have had oral or gum surgery in the previous 2 months,
consult your dentist before you use the toothbrush.
6English

- Consult your dentist if excessive bleeding occurs after using this
toothbrush or if bleeding continues to occur after 1 week of use.
Also consult your dentist if you experience discomfort or pain
when you use the Philips Sonicare.
- The Philips Sonicare toothbrush complies with the safety
standards for electromagnetic devices. If you have a pacemaker or
other implanted device, contact your physician or the device
manufacturer of the implanted device prior to use.
- If you have medical concerns, consult your doctor before you use
the Philips Sonicare.
- This appliance has only been designed for cleaning teeth, gums
and tongue. Do not use it for any other purpose. Stop using the
appliance and contact your doctor if you experience any
discomfort or pain.
- The Philips Sonicare toothbrush is a personal care device and is
not intended for use on multiple patients in a dental practice or
institution.
- Stop using a brush head with crushed or bent bristles. Replace the
brush head every 3 months or sooner if signs of wear appear. Do
not use other brush heads than the ones recommended by the
manufacturer.
- If your toothpaste contains peroxide, baking soda or bicarbonate
(common in whitening toothpastes), thoroughly clean the brush
head with soap and water after each use. This prevents possible
cracking of the plastic.
- Avoid contact with liquids that contain essential oils (common in
strong mouthwashes) as damage to hard and soft plastic may
occur.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.
Introduction
Congratulations on your purchase and welcome to Philips! To fully
benefit from the support that Philips offers, register your product at
www.philips.com/welcome.
7
English

General description (Fig. 1)
1 Hygienic travel cap
2 Brush head
3 Handle
4 Power on/off and mode button
5 Intensity level indicator
6 Intensity level button (+ and -)
7 Mode indicator
8 Battery level indicator
9 Charger
Note: The content of the box may vary based on the model
purchased.
Preparing for use
Attaching the brush head
1Align the brush head so the bristles point in the same direction as
the front of the handle (Fig. 2).
2Firmly press the brush head down onto the metal shaft until it
stops.
Note: Philips Sonicare brush heads are imprinted with icons to easily
identify your brush head (Fig. 4).
Charging your Philips Sonicare
1Plug the charger into an electrical outlet.
2Place the handle on the charger (Fig. 5).
-The flashing light of the battery level indicator indicates that the
toothbrush is charging.
-When the battery is fully charged, the battery level indicator
lights up solid green for 10 seconds before it turns off.
Note: It can take up to 48 hours to fully charge the battery, but the
Philips Sonicare may be used before it is fully charged.
Using the appliance
Brushing instructions
1Wet the bristles and apply a small amount of toothpaste.
8English

2Place the toothbrush bristles against the teeth at a slight angle (45
degrees), pressing firmly to make the bristles reach the gumline or
slightly beneath the gumline (Fig. 7).
Note: Keep the center of the brush in contact with the teeth at all
times.
3Press the power on/off and mode button to turn on the Philips
Sonicare.
4Apply light pressure to maximize Philips Sonicare’s effectiveness
and let the Philips Sonicare toothbrush do the brushing for you.
Do not scrub.
5Gently move the brush head slowly across the teeth in a small
back and forth motion so the longer bristles reach between your
teeth. Continue this motion throughout the brushing cycle.
6To clean the inside surfaces of the front teeth, tilt the brush handle
semi-upright and make several vertical overlapping brushing
strokes on each tooth (Fig. 8).
Note: To make sure you brush evenly throughout the mouth,
divide your mouth into 4 sections using the Quadpacer feature
(see chapter ‘Features’).
7Begin brushing in section 1 (outside upper teeth) and brush for 30
seconds before you move to section 2 (inside upper teeth).
Continue brushing in section 3 (outside lower teeth) and brush for
30 seconds before you move to section 4 (inside lower teeth (Fig.
9)).
8After you have completed the brushing cycle, you can spend
additional time brushing the chewing surfaces of your teeth and
areas where staining occurs. You can also brush your tongue, with
the toothbrush turned on or off, as you prefer (Fig. 10).
Your Philips Sonicare is safe to use on:
- Braces (brush heads wear out sooner when used on braces).
- Dental restorations (fillings, crowns, veneers).
Note: Ensure that braces or dental restorations are properly adhered
and not compromised. If not, braces or dental restorations may be
damaged when they come into contact with the brush head.
9
English

Note: When the Philips Sonicare is used in clinical studies, the default
2-minute Clean mode with high intensity must be selected. The
handle should be fully charged and the Easy-start feature
deactivated.
Brushing modes
Clean mode
The ultimate in plaque removal (default mode). Clean mode lasts for 2
minutes and includes four 30 second Quadpacer intervals.
Gum Plus mode
To gently stimulate your gums. Gum Plus mode lasts for 2 minutes
and includes four 30 second Quadpacer intervals.
1Press the power on/off and mode button to turn on your Philips
Sonicare.
2Press the power on/off and mode button again within 2.5 seconds
to switch to Gum Plus mode.
3Press the power on/off and mode button after 2.5 seconds to
pause your Philips Sonicare
Intensity levels
-Low: 1 LED indicator light
-Medium: 2 LED indicator lights
-High: 3 LED indicator lights
Note: To adjust the intensity level to the next higher or lower level,
press the + intensity level button to increase intensity or the -
intensity level button to decrease intensity at any time during the
brushing cycle
Battery status (when handle is not on charger)
- A flashing yellow battery level indicator indicates a low charge.
- A flashing green battery level indicator indicates a moderate
charge.
- A solid green battery level indicator indicates a full charge (Fig. 6).
Note: If you hear 5 beeps and the battery level indicator flashes
yellow, this means that you have to recharge the battery. When the
battery is completely empty, the Philips Sonicare turns off. Place the
Philips Sonicare on the charger to charge it.
10 English

To keep the battery fully charged at all times, you may keep your
Sonicare on the charger when not in use.
Features
Smartimer
The Smartimer indicates that your brushing cycle is complete by
automatically turning off the toothbrush at the end of the brushing
cycle.
Dental professionals recommend brushing no less than 2 minutes
twice a day.
Easy-start
The Easy-start feature gently increases the power over the first 14
brushings to help you get used to the brushing with the Philips
Sonicare.This Philips Sonicare comes with the Easy-start feature
deactivated.
Activating or deactivating the Easy-start feature
1Attach the brush head to the handle.
2Place the handle in the plugged-in charger.
To activate Easy-start:
Press and hold the power on/off and mode button for 2 seconds. You
hear 2 beeps and the battery level indicator lights up green to
indicate that the Easy-start feature has been activated.
To deactivate Easy-start:
Press and hold the power on/off and mode button for 2 seconds. You
hear 1 beep and the battery level indicator lights up yellow to indicate
that the Easy-start feature has been deactivated.
Note: Using the Easy-start feature beyond the initial ramp-up period
is not recommended and reduces Philips Sonicare effectiveness in
removing plaque.
11
English

Quadpacer
The Quadpacer is an interval timer that has a short beep and pause
to remind you to brush the 4 sections of your mouth evenly and
thoroughly (Fig. 11).
Depending on the brushing mode you have selected, the Quadpacer
beeps at different intervals during the brushing cycle. See the
"brushing modes" section for more details.
Activating or deactivating the Quadpacer feature:
Place the handle in the plugged-in charger.
- To activate Quadpacer:
Press and hold the intensity level button down (-) for 2 seconds.
You hear 2 beeps and the battery level indicator lights up green to
indicate that the Quadpacer feature has been activated.
- To deactivate Quadpacer:
Press and hold the intensity level button down (-) for 2 seconds.
You hear 1 beep and the battery level indicator lights up yellow to
indicate that the Quadpacer feature has been deactivated.
Charger confirmation
When the charger confirmation feature is activated, the handle beeps
and vibrates briefly when it is placed on the charger base. This Philips
Sonicare model comes with the charger confirmation feature
deactivated.
Activating or deactivating the charger confirmation feature:
Place the handle on the charger.
- To activate charger confirmation:
Press and hold the intensity level button up (+) for 2 seconds. You
hear 2 beeps and the battery level indicator lights up green twice
to indicate that the charger confirmation feature has been
activated.
- To deactivate charger confirmation:
Press and hold the intensity level button up (+) for 2 seconds. You
hear 1 beep and the battery level indicator lights up yellow once to
12 English

indicate that the charger confirmation feature has been
deactivated.
Cleaning
Toothbrush handle
1Remove the brush head and rinse the metal shaft area with warm
water. Make sure you remove any residual toothpaste (Fig. 12).
Caution: Do not push on the rubber seal on the metal shaft with
sharp objects, as this may cause damage.
2Wipe the entire surface of the handle with a damp cloth.
Brush head
1Rinse the brush head and bristles after each use (Fig. 13).
2Remove the brush head from the handle and rinse the brush head
connection with warm water at least once a week.
Charger
1Unplug the charger before you clean it.
2Wipe the surface of the charger with a damp cloth. Make sure you
remove any toothpaste or other residue from the charger surfaces.
Storage
If you are not going to use the Sonicare for an extended period of
time, unplug the charger from the electrical outlet, clean it and store it
in a cool and dry place away from direct sunlight.
Replacement
Brush head
Replace Philips Sonicare brush heads every 3 months to achieve
optimal results. Use only Philips Sonicare replacement brush heads.
Recycling
- Do not throw away the product with the normal household waste
at the end of its life, but hand it in at an official collection point for
recycling. By doing this, you help to preserve the environment.
13
English

- This product contains a built-in rechargeable battery which shall
not be disposed of with normal household waste. Please take your
product to an official collection point or a Philips service center to
have a professional remove the rechargeable battery.
- Follow your country’s rules for the separate collection of electrical
and electronic products and rechargeable batteries. Correct
disposal helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Please note:
This process is not reversible.
Ensure that the battery’s power is completely depleted before
removing the battery from the handle.
To remove the rechargeable battery, you need a towel or cloth, a
hammer and a flat-head (standard) screwdriver. Observe basic safety
precautions when you follow the procedure outlined below. Be sure
to protect your eyes, hands, fingers, and the surface on which you
work.
1To deplete the rechargeable battery of any charge, remove the
handle from the charger, turn on the Philips Sonicare and let it run
until it stops. Repeat this step until you can no longer turn on the
Philips Sonicare.
2Remove and discard the brush head. Cover the entire handle with
a towel or cloth.
3Hold the top of the handle with one hand and strike the handle
housing 0.5 inch above the bottom end. Strike firmly with a
hammer on all 4 sides to eject the end cap.
Note: You may have to hit on the end several times to break the
internal snap connections.
4Remove the end cap from the toothbrush handle. If the end cap
does not release easily from the housing, repeat step 3 until the
end cap is released (Fig. 16).
14 English

5Holding the handle upside down, press the shaft down on a hard
surface. If the internal components do not easily release from the
housing, repeat step 3 until the internal components are released.
6Remove the rubber battery cover.
7Wedge the screwdriver between the battery and the black frame
at the bottom of the internal components. Then pry the
screwdriver away from the battery to break the bottom of the
black frame.
8Insert the screwdriver between the bottom of the battery and the
black frame to break the metal tab connecting the battery to the
green printed circuit board. This will release the bottom end of the
battery from the frame (Fig. 21).
9Grab the battery and pull it away from the internal components to
break the second metal battery tab (Fig. 22).
Caution: Be aware of the sharp edges of the battery tabs so as to
avoid injury to your fingers.
10 Cover the battery contacts with tape to prevent any electrical short
from residual battery charge. The rechargeable battery can now be
recycled and the rest of the product discarded appropriately.
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the international warranty leaflet.
Warranty restrictions
The terms of the international warranty do not cover the following:
- Brush heads.
- Damage caused by use of unauthorized replacement parts.
- Damage caused by misuse, abuse, neglect, alterations or
unauthorized repair.
- Normal wear and tear, including chips, scratches, abrasions,
discoloration or fading.
15
English

重要安全信息
使用产品之前，请仔细阅读本重要信息，并妥善保管以供日后参考。
危险
- 使充电器远离水源。 切勿将它放置或存放在任何有水的容器的上方或附
近，如：浴盆、脸盆、水池等。切勿将充电器浸入水或任何其他液体
中。 清洁后，确保充电器完全干燥，再将其连接至电源。
- 必须安装需要的固定部件，以免它们掉入水中。
警告
- 不得更换电源线。 如果电源线损坏，请丢弃充电器。
- 应始终使用原装型号的充电器进行更换，以免发生危险。
- 切勿在户外或高温表面附近使用充电器。
- 如果本产品受到任何损坏（刷头、牙刷手柄或充电器），请停止使用。
本产品不包含任何可维修零部件。 如果本产品已损坏，请联系您所在国
家/地区的客户服务中心（请参阅“保修和支持”一章）。
- 本产品适合由儿童和肢体不健全、感觉或精神上有障碍或缺乏相关经验
和知识的人士使用，但前提是有人对他们使用本产品进行监督或指导，
以确保他们安全使用，并且让他们明白相关的危害。 不要让儿童在无人
监督的情况下对本产品进行清洁和保养。
- 切勿让儿童玩弄本产品。
警告
- 请勿在洗碗机中清洗牙刷头、牙刷柄或充电器。
- 如果您在前 2 个月中曾做过口腔或牙龈手术，请在使用本产品前先咨询
您的牙医。
- 如果使用本产品后牙龈大量出血或在使用 1 周后仍会出血，请咨询您的
牙医。 如果使用飞利浦 Sonicare 时感觉不适或疼痛，也请咨询您的牙
医。
- 飞利浦 Sonicare 牙刷符合电磁装置的安全标准。 有关任何涉及心脏起
搏器或其他植入装置的问题，请在使用之前咨询医生或相关植入装置的
设备制造商。
- 如果您有医学问题，请在使用飞利浦 Sonicare 前咨询医生。
- 本产品设计仅用于清洁牙齿、牙龈和舌头。 请勿将其用作任何其它用
途。 如果感觉任何不适或疼痛，请停止使用本产品并与医生联系。
- 飞利浦 Sonicare 牙刷为私人用品，不可供牙医诊所或机构对多位患者使
用。
16 简体中文

- 请停止使用变形或刷毛弯曲的牙刷头。 请每 3 个月更换一次牙刷头，如
果出现磨损迹象，应提前更换。 切勿使用非制造商推荐的其他牙刷头。
- 如果您所用的牙膏中含有过氧化物、碳酸氢钠或其它重碳酸盐（增白牙
膏中的常见成份），则请务必在每次使用后用肥皂和水彻底清洗牙刷
头。 这可以预防可能出现的塑料破裂。
- 避免接触含有精油的液体（常见于高浓度漱口水中），否则可能会损坏
硬质或软质塑料。
电磁场 (EMF)
本飞利浦产品符合所有有关暴露于电磁场的适用标准和法规。
简介
感谢您的惠顾，欢迎光临飞利浦！ 为了让您能充分享受飞利浦提供的支
持，请在 www.philips.com/welcome 上注册您的产品。
基本说明（图 1）
1 旅行用卫生保护盖
2 牙刷头
3 牙刷柄
4 电源开/关和模式按钮
5 强度指示灯
6 强度级别按钮（+ 和 -）
7 模式指示灯
8 电池电量指示灯
9 充电器
注意： 包装盒内物品可能会因所购买型号而异。
使用准备
安装刷头
1 对齐牙刷头，使刷毛方向与牙刷柄 (图 2)正面的方向一致。
2 用力将牙刷头向下按到金属轴上，直到按不动 (图 3)为止。
注意： 飞利浦 Sonicare 刷头印有图标，便于识别刷头 (图 4)。
为您的飞利浦 Sonicare 充电
1 将充电器插入电源插座。
2 将牙刷柄放在充电器 (图 5)上。
17
简体中文

-电池电量指示灯闪烁表示牙刷正在充电。
-当电池已完全充满电时，电池电量指示灯将呈绿色持续亮起 10 秒，
然后才会熄灭。
注意： 电池充满电需要 48 小时，但飞利浦 Sonicare 在未充满电时亦可使
用。
使用本产品
刷牙说明
1 浸湿刷毛并挤上少量牙膏。
2 将牙刷的刷毛以小角度（45 度）放在牙齿上，用力按下以使刷毛接触牙
龈或牙龈 (图 7)略下方。
注意： 始终将牙刷中间与牙齿接触。
3 按下电源开/关和模式按钮，打开飞利浦 Sonicare。
4 对飞利浦 Sonicare 轻轻地施加一点压力以使其发挥最佳效果，然后让飞
利浦 Sonicare 为您刷牙。 请勿过度用力。
5 轻柔地将牙刷头在牙齿间来回小幅度缓慢移动，以便长刷毛能清洁牙
缝。 在整个刷牙周期中连续这样移动即可。
6 要清洁门牙内表面，请将牙刷柄呈半直立状倾斜，在每颗牙齿 (图 8)上
反复垂直震动。
注意： 为确保牙刷能均匀清洁整个口腔，可使用 Quadpacer 30 秒时段
计时器功能将口腔分为 4 个区域（参见“功能”一章）。
7 从第 1 个刷牙区域（上牙外侧）开始，刷 30 秒钟，然后移到第 2 个刷
牙区域（上牙内侧）。 继续刷第 3 个刷牙区域（下牙外侧），刷 30 秒
钟，然后移到第 4 个刷牙区域（下牙 (图 9)内侧）。
8 在完成刷牙周期之后，您可以多花一些时间刷洗牙齿的咀嚼面以及污垢
容易出现的区域。 还可以使用该牙刷清洁舌头，这时可以根据自己的喜
好 (图 10)打开或关闭牙刷电源。
您的飞利浦 Sonicare 可安全用于：
- 牙齿矫正器（在牙齿矫正器上使用时，牙刷头磨损较快）。
- 修复牙体（补牙、齿冠、烤瓷牙）。
注意： 确保牙齿矫正器或修复牙体正确固着并且未损坏。 否则，当其与牙
刷头接触时可能会损坏。
注意： 飞利浦 Sonicare 用于临床研究时，必须选择默认的 2 分钟高强度清
洁模式。 应为牙刷柄充满电并禁用 Easy-start 刷牙动力增强功能。
18 简体中文

刷牙模式
清洁模式
有效去除牙菌斑（默认模式）。 清洁模式的持续时间为 2 分钟，包括 4 个
30 秒的 Quadpacer 间隔。
牙龈按摩 模式
轻柔地按摩牙龈。 牙龈按摩 模式的持续时间为 2 分钟，包括 4 个 30 秒的
Quadpacer 间隔。
1 按下电源开/关和模式按钮，打开您的飞利浦 Sonicare。
2 在 2.5 秒之内再次按下电源开/关和模式按钮，可切换至 牙龈按摩 模
式。
3 在 2.5 秒之后按电源开/关和模式按钮，可暂停您的飞利浦 Sonicare 声
波震动牙刷
强度级别
-低： 1 个 LED 指示灯
-中： 2 个 LED 指示灯
-高： 3 个 LED 指示灯
注意： 要将强度级别调节到更高或更低级别，您可以在刷牙期间随时按 +
强度级别按钮增加强度，或按 - 强度级别按钮减小强度
电池状态（牙刷柄未置于充电器上时）
- 电池电量指示灯呈黄色闪烁，表示电量不足。
- 电池电量指示灯呈绿色闪烁，表示中等电量。
- 电池电量指示灯呈绿色持续亮起，表示电量 (图 6)充足。
注意： 如果您听到 5 声蜂鸣音且电池电量指示灯呈黄色闪烁，这表示需为
电池充电。 电池电量完全耗尽时，飞利浦 Sonicare 会关闭。 请将飞利浦
Sonicare 置于充电器上充电。
如需确保电池始终电量充沛，不使用时，可将 Sonicare 声波震动牙刷一直
插在充电器上。
功能
Smartimer 两分钟智能计时器
Smartimer 两分钟智能计时器在刷牙周期结束时会自动关闭牙刷，指示您的
设定刷牙周期已完成。
19
简体中文

牙科专家建议每天刷牙两次，每次不少于 2 分钟。
Easy-start 刷牙动力增强装置
Easy-start 刷牙动力增强功能在最初 14 次刷牙时会缓慢增加动力，以帮助
您适应使用飞利浦 Sonicare 刷牙。该飞利浦 Sonicare 出厂时已禁用 Easy-
start 刷牙动力增强功能。
启用或禁用 Easy-start 刷牙动力增强功能
1 将牙刷头安装到牙刷柄上。
2 将牙刷柄放到连接电源的充电座中。
要启用 Easy-start 刷牙动力增强功能：
按住电源开/关和模式按钮 2 秒钟。 您会听到 2 声蜂鸣音且电池电量指示灯
会呈绿色亮起，表示 Easy-start 刷牙动力增强功能已启用。
要禁用 Easy-start刷牙动力增强功能：
按住电源开/关和模式按钮 2 秒钟。 您会听到 1 声蜂鸣音且电池电量指示灯
会呈黄色亮起，表示 Easy-start 刷牙动力增强功能已禁用。
注意： 不建议在初始动力递增阶段后仍使用 Easy-start 刷牙动力增强功
能，这样做会降低飞利浦 Sonicare 去除牙菌斑的效果。
Quadpacer 30 秒时段计时器
Quadpacer 30 秒时段计时器是一种会发出短暂蜂鸣音并暂停的时段计时
器，提醒您均匀彻底 (图 11)地刷净口腔的四个区域。
根据所选的刷牙模式，Quadpacer 30 秒时段计时器在刷牙期间会以不同的
间隔发出蜂鸣音。 有关详细信息，请参阅“刷牙模式”部分。
启用或禁用 Quadpacer 30 秒时段计时器功能：
将牙刷柄放到连接电源的充电座中。
- 要启用 Quadpacer 30 秒时段计时器功能：
按住强度级别减小按钮 (-) 2 秒钟。 您会听到 2 声蜂鸣音且电池电量指
示灯会呈绿色亮起，表示 Quadpacer 30 秒时段计时器功能已启用。
- 要禁用 Quadpacer 30 秒时段计时器功能：
按住强度级别减小按钮 (-) 2 秒钟。 您会听到 1 声蜂鸣音且电池电量指
示灯会呈黄色亮起，表示 Quadpacer 30 秒时段计时器功能已禁用。
20 简体中文
