Philips DiamondClean Series User manual

DiamondClean

2
1
7
9
8
3
4
5
611
10
10
1

English 6
Deutsch 18
Español 32
Français 45
Italiano 59
Nederlands 73
Português 86
Ελληνικά 100

English
Important
Read this user manual carefully before you use the appliance and
save it for future reference.
Danger
-Keep the charger away from water. Do not
place or store it over or near water
contained in a bathtub, washbasin, sink etc.
Do not immerse the charger in water or any
other liquid. After cleaning, make sure the
charger is completely dry before you
connect it to the wall socket.
Warning
-The mains cord cannot be replaced. If the
mains cord is damaged, discard the charger.
-Always have the charger replaced with one
of the original type in order to avoid a
hazard.
-Do not use the charger outdoors or near
heated surfaces.
6English

-If the appliance is damaged in any way
(brush head, toothbrush handle or charger),
stop using it. This appliance contains no
serviceable parts. If the appliance is
damaged, contact the Consumer Care
Center in your country (see chapter
'Warranty and support').
-This appliance can be used by children and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Cleaning and user
maintenance shall not be made by children
without supervision.
-Children shall not play with the appliance.
Caution
-Do not clean the brush head, the handle or
the charger in the dishwasher.
-If you have had oral or gum surgery in the
previous 2 months, consult your dentist
before you use the toothbrush.
7
English

-Consult your dentist if excessive bleeding
occurs after using this toothbrush or if
bleeding continues to occur after 1 week of
use. Also consult your dentist if you
experience discomfort or pain when you use
the Philips Sonicare.
-The Philips Sonicare toothbrush complies
with the safety standards for
electromagnetic devices. If you have a
pacemaker or other implanted device,
contact your physician or the device
manufacturer of the implanted device prior
to use.
-If you have medical concerns, consult your
doctor before you use the Philips Sonicare.
-This appliance has only been designed for
cleaning teeth, gums and tongue. Do not
use it for any other purpose. Stop using the
appliance and contact your doctor if you
experience any discomfort or pain.
8English

-The Philips Sonicare toothbrush is a
personal care device and is not intended for
use on multiple patients in a dental practice
or institution.
-Stop using a brush head with crushed or
bent bristles. Replace the brush head every
3 months or sooner if signs of wear appear.
Do not use other brush heads than the ones
recommended by the manufacturer.
-If your toothpaste contains peroxide, baking
soda or bicarbonate (common in whitening
toothpastes), thoroughly clean the brush
head with soap and water after each use.
This prevents possible cracking of the
plastic.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.
Introduction
Congratulations on your purchase and welcome to Philips! To fully
benefit from the support that Philips offers, register your product at
www.philips.com/welcome.
Your Philips Sonicare (Fig. 1)
1 Hygienic travel cap
2 Brush head
3 Handle with ergonomic shape
9
English

4 Recessed power on/off button
5 Hidden brushing mode display
6 Charge indicator
7 Charging glass
8 Charger stand
9 Charging base
10 Charging travel case
11 USB cord
Note: The content of the box may vary based on the model
purchased.
Preparing for use
Attaching the brush head
1Align the brush head so the bristles point in the same direction as
the front of the handle (Fig. 2).
2Firmly press the brush head down onto the metal shaft until it
stops.
Note: It is normal to see a slight gap between the brush head and the
handle.
Charging the appliance
1Plug the charger into an electrical outlet.
2Place the charging glass on top of the charging base and place the
handle in the glass (Fig. 3) or place the charger stand on top of the
charging base. Place the handle in the stand (Fig. 4).
-The charge indicator flashes green until fully charged.
-Rapid yellow flashing indicates charge is extremely low (fewer
than 3 uses left).
Note: It takes at least 24 hours to fully charge the battery.
This charger is designed to properly charge only one handle at a time.
This charger is not compatible with other models of Sonicare.
Using the appliance
Brushing instructions
1Wet the bristles (Fig. 5).
10 English

2Apply a small amount of toothpaste on the bristles (Fig. 6).
3Place the toothbrush bristles against the teeth at a slight angle (45
degrees), pressing firmly to make the bristles reach the gumline or
slightly beneath the gumline (Fig. 7).
Note: Keep the center of the brush in contact with the teeth at all
times.
4Press the power on/off and mode button to turn on your Philips
Sonicare (Fig. 8).
5Gently keep the bristles placed on the teeth and in the gumline.
Brush your teeth with small back and forth motion so the bristles
reach between the teeth (Fig. 9).
Note: The bristles should slightly flare. Do not scrub.
6To clean the inside surfaces of the front teeth, tilt the brush handle
semi-upright and make several vertical overlapping brushing
strokes on each tooth (Fig. 10).
7Begin brushing in section 1 (outside top teeth) and brush for 30
seconds (45 seconds in Deep Clean mode) before moving to
section 2 (inside top teeth). Continue brushing in section 3 (outside
bottom teeth) and brush for 30 seconds (45 seconds in Deep
Clean mode) before moving to section 4 (inside bottom teeth (Fig.
11)).
Note: To make sure you brush evenly throughout the mouth,
divide your mouth into 4 sections using the Quadpacer feature
(see chapter ‘Features’).
Note: After you have completed the brushing cycle, you can spend
additional time brushing the chewing surfaces of your teeth and
areas where staining occurs. You can also brush your tongue, with
the toothbrush turned on or off, as you prefer (Fig. 12).
Your Philips Sonicare is safe to use on:
- Braces (brush heads wear out sooner when used on braces).
- Dental restorations (fillings, crowns, veneers).
Brushing modes
1To toggle through modes press the on/off button twice in less
than 5 seconds.
11
English

2To turn off your Philips Sonicare press the on/off button again
after 5 seconds.
Your Philips Sonicare comes with the Clean mode activated.
Note: When the Philips Sonicare is used in clinical studies, it must be
used in the default 2-minute Clean mode or in the Deep Clean mode
with Easy Start turned off.
Clean mode
The ultimate in plaque removal (default mode). Clean mode lasts for 2
minutes and includes four 30 second Quadpacer intervals.
White mode
2 minutes to remove surface stains and 30 seconds to brighten and
polish your front teeth.
Sensitive mode
Extra gentle 2 minute mode for sensitive teeth and gums.
Gum Care mode
Complete whole mouth cleaning (2 minutes) plus gentle cleaning for
problem areas and along the gumline (1 minute).
Deep Clean mode (select models)
Provides an invigorating 3 minutes of alternating cleaning and
massaging to deliver an exceptionally clean experience.
Polish mode (select models)
Quick 1-minute mode to brighten and polish your front teeth.
Features
Quadpacer
The Quadpacer is an interval timer that has a short beep and pause
to remind you to brush the 4 sections of your mouth. Depending on
the brushing mode you have selected, the Quadpacer beeps at
different intervals during the brushing cycle. The Quadpacer works in
all 5 modes (Fig. 11).
12 English

Smartimer
The Smartimer indicates that your brushing cycle is complete by
automatically turning off the toothbrush at the end of the brushing
cycle.
Dental professionals recommend brushing no less than 2 minutes
twice a day.
Easy-start
The Easy-start feature gently increases the power over the first 14
brushings to help you get used to the brushing with the Philips
Sonicare. The Easy-start feature works in all modes other than
TongueCare mode. This Philips Sonicare model comes with the Easy-
start feature activated.
Activating or deactivating the Easy-start feature
1Place the handle in the plugged-in charger.
To activate Easy-start:
Press and hold the power on/off for 2 seconds. You hear 2 beeps to
indicate that the Easy-start feature has been activated.
To deactivate Easy-start:
Press and hold the power on/off for 2 seconds. You hear 1 beep to
indicate that the Easy-start feature has been deactivated.
Note: Using the Easy-start feature beyond the initial ramp-up period
is not recommended and reduces Philips Sonicare effectiveness in
removing plaque.
Note: Each of the first 14 brushings must be at least 1 minute in length
to properly move through the Easy-start ramp-up cycle.
Traveling with the appliance
Charging with travel case (specific types only)
1Place the handle in the charging travel case.
2Connect the charging travel case to a UL 60950-1 and IEC 60950-1
Listed computer, laptop, USB hub, USB receptacle, or wall adapter.
13
English

3The wall adapter you use with this product, shall have an output
marked Class 2 or the limited power source (LPS) requirements
and compatible with the electrical ratings marked on the travel
case.
4The battery indication flashes white until your toothbrush is fully
charged.
Important: The wall adapter must be a safe extra low voltage source,
compatible with the electrical ratings marked on the device.
Important: Only toothbrush models HX9330, HX9340, HX9350,
HX9360, HX9370, HX939W, HX939B, HX939P, HX939V, HX939L can
be charged in the travel case. Other products and batteries are not
compatible with the travel case.
Note: It takes at least 24 hours to fully charge your Philips Sonicare.
You do not have to fully charge your handle before first use, as the
handle is pre-charged for first use. However, it is recommended to
fully charge it after first use.
Note: This charger is designed to properly charge only one handle at
a time. The charging base is not compatible with other models of
Philips Sonicare.
Note: Do not place metallic objects in the travel case, as handle
charging may be affected and may cause the charger to overheat.
Cleaning
Note: Do not clean the brush head, handle, charging base or USB
travel case in the dishwasher. The glass is dishwasher safe.
Toothbrush handle
1Remove the brush head and rinse the metal shaft area with warm
water. Make sure you remove any residual toothpaste (Fig. 13).
Note: Do not push on the rubber seal on the metal shaft with
sharp objects, as this may cause damage.
2Wipe the entire surface of the handle with a damp cloth.
Note: Do not use isopropyl rubbing alcohol, vinegar or bleach to
clean handle as this may cause discoloration.
Brush head
1Rinse the brush head and bristles after each use (Fig. 14).
14 English

2Remove the brush head from the handle and rinse the brush head
connection with warm water at least once a week.
Charging base
Use a damp cloth to wipe the surface of the charging base. Make sure
you remove any toothpaste or other residue from the surfaces.
Storage
If you are not going to use your Philips Sonicare for an extended
period of time, charge the handle fully, unplug the charger from the
electrical outlet, clean both devices and store them in a cool and dry
place away from direct sunlight.
Replacement
Brush head
Replace Philips Sonicare brush heads every 3 months to achieve
optimal results. Use only Philips Sonicare replacement brush heads.
Recycling
- This symbol means that this product shall not be disposed of with
normal household waste (2012/19/EU) (Fig. 23).
- This symbol means that this product contains a built-in
rechargeable battery which shall not be disposed of with normal
household waste (Fig. 24) (2006/66/EC). Please take your product
to an official collection point or a Philips service center to have a
professional remove the rechargeable battery.
- Follow your country’s rules for the separate collection of electrical
and electronic products and rechargeable batteries. Correct
disposal helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Warning: Only remove the rechargeable battery when you discard the
appliance. Make sure the battery is completely empty when you
remove it.
To remove the rechargeable battery, you need a towel or cloth, a
hammer and a flat-head (standard) screwdriver. Observe basic safety
15
English

precautions when you follow the procedure outlined below. Be sure
to protect your eyes, hands, fingers, and the surface on which you
work.
1To deplete the rechargeable battery of any charge, remove the
handle from the charger, turn on the Philips Sonicare and let it run
until it stops. Repeat this step until you can no longer turn on the
Philips Sonicare.
2Remove and discard the brush head. Cover the entire handle with
a towel or cloth (Fig. 15).
3Hold the top of the handle with one hand and strike the handle
housing 0.5 inch above the bottom end. Strike firmly with a
hammer on all 4 sides to eject the end cap (Fig. 16).
Note: You may have to hit on the end several times to break the
internal snap connections.
4Remove the end cap from the toothbrush handle. If the end cap
does not release easily from the housing, repeat step 3 until the
end cap is released (Fig. 17).
5Holding the handle upside down, press the shaft down on a hard
surface. If the internal components do not easily release from the
housing, repeat step 3 until the internal components are released
(Fig. 18).
6Remove the rubber battery cover.
7Wedge the screwdriver between the battery and the black frame
at the bottom of the internal components. Then pry the
screwdriver away from the battery to break the bottom of the
black frame (Fig. 19).
8Insert the screwdriver between the bottom of the battery and the
black frame to break the metal tab connecting the battery to the
green printed circuit board. This will release the bottom end of the
battery from the frame (Fig. 20).
9Grab the battery and pull it away from the internal components to
break the second metal battery tab (Fig. 21).
Caution: Be aware of the sharp edges of the battery tabs so as to
avoid injury to your fingers.
16 English

10 Cover the battery contacts with tape to prevent any electrical short
from residual battery charge. The rechargeable battery can now be
recycled and the rest of the product discarded appropriately (Fig.
22).
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the international warranty leaflet.
Warranty restrictions
The terms of the international warranty do not cover the following:
- Brush heads.
- Damage caused by use of unauthorized replacement parts.
- Damage caused by misuse, abuse, neglect, alterations or
unauthorized repair.
- Normal wear and tear, including chips, scratches, abrasions,
discoloration or fading.
17
English

Deutsch
Wichtig
Lesen Sie diese Bedienungsanleitung vor dem Gebrauch des Geräts
aufmerksam durch, und bewahren Sie sie für eine spätere
Verwendung auf.
Gefahr
-Halten Sie das Ladegerät von Wasser fern.
Stellen Sie es nicht über oder direkt bei
einer mit Wasser gefüllten Badewanne bzw.
einem Waschbecken ab. Tauchen Sie das
Ladegerät nicht in Wasser oder andere
Flüssigkeiten. Vergewissern Sie sich nach
der Reinigung, dass das Ladegerät
vollständig trocken ist, bevor Sie es wieder
an das Stromnetz anschließen.
Warnhinweis
-Das Netzkabel kann nicht ersetzt werden. Ist
das Netzkabel beschädigt, müssen Sie das
Ladegerät entsorgen.
-Tauschen Sie das Ladegerät immer durch
ein Original-Ersatzgerät aus, um
Gefährdungen zu vermeiden.
-Benutzen Sie das Ladegerät nicht im Freien
oder in der Nähe von heißen Oberflächen.
18 Deutsch

-Benutzen Sie das Gerät nicht, wenn es
beschädigt ist (Bürstenkopf, Handstück oder
Ladegerät). Dieses Gerät enthält keine Teile,
die vom Benutzer repariert werden können.
Wenn das Gerät beschädigt ist, wenden Sie
sich bitte an das Service‑Center in Ihrem
Land (siehe Kapitel „Garantie und
Kundendienst“).
-Dieses Gerät kann von Kindern und
Personen mit verringerten physischen,
sensorischen oder psychischen Fähigkeiten
oder Mangel an Erfahrung und Kenntnis
verwendet werden, wenn sie bei der
Verwendung beaufsichtigt werden oder
Anleitung zum sicheren Gebrauch des
Geräts erhalten und die Gefahren
verstanden haben. Die Reinigung und Pflege
des Geräts darf von Kindern nicht ohne
Aufsicht durchgeführt werden.
-Kinder dürfen nicht mit dem Gerät spielen.
Achtung
-Reinigen Sie Bürstenkopf, Handstück und
Ladegerät nicht im Geschirrspüler.
19
Deutsch

-Wenn in den vergangenen 2Monaten ein
chirurgischer Eingriff an Ihren Zähnen oder
am Zahnfleisch vorgenommen wurde,
sollten Sie vor Benutzung der Zahnbürste
Ihren Zahnarzt konsultieren.
-Konsultieren Sie Ihren Zahnarzt, wenn nach
Benutzung dieses Geräts übermäßiges
Zahnfleischbluten auftritt oder
Zahnfleischbluten länger als eine Woche
anhält. Konsultieren Sie außerdem Ihren
Zahnarzt, wenn bei Benutzung der Philips
Sonicare Unbehagen oder Schmerzen
auftreten.
-Die Philips Sonicare Zahnbürste erfüllt die
Sicherheitsstandards für
elektromagnetische Geräte. Wenden Sie
sich als Träger eines Herzschrittmachers
oder eines anderen Implantats vor der
Verwendung dieses Geräts an Ihren Arzt
oder den Hersteller des implantierten
Gerätes.
20 Deutsch

-Sollten Sie Bedenken wegen Ihrer
Gesundheit haben, konsultieren Sie vor
Benutzung der Philips Sonicare Ihren Arzt.
-Dieses Gerät ist ausschließlich zum Reinigen
von Zähnen, Zahnfleisch und Zunge
gedacht. Benutzen Sie es nicht für andere
Zwecke. Falls Beschwerden oder Schmerzen
auftreten, verwenden Sie das Gerät nicht
mehr, und wenden Sie sich an Ihren Arzt.
-Die Philips Sonicare Zahnbürste ist ein Gerät
zur individuellen Mundpflege und nicht für
die Verwendung von mehreren Patienten in
einer Zahnarztpraxis oder Zahnklinik
geeignet.
-Unterlassen Sie es, einen Bürstenkopf mit
abgeknickten oder zerdrückten Borsten zu
verwenden. Ersetzen Sie den Bürstenkopf
alle 3Monate oder früher, falls Anzeichen
von Abnutzung auftreten. Benutzen Sie nur
die vom Hersteller für diese Zahnbürste
empfohlenen Bürstenköpfe.
21
Deutsch

-Bei Verwendung peroxid-, natron- oder
bikarbonathaltiger Zahnpasta (üblich in
Weißmacher-Zahnpasta) sollten Sie den
Bürstenkopf nach jedem Gebrauch
gründlich mit einem milden
Reinigungsmittel und Wasser reinigen. Dies
verhindert ein mögliches Brechen des
Plastiks.
Elektromagnetische Felder
Dieses Philips Gerät erfüllt sämtliche Normen und Regelungen
bezüglich der Exposition in elektromagnetischen Feldern.
Einführung
Herzlichen Glückwunsch zu Ihrem Kauf und willkommen bei Philips!
Um die Unterstützung von Philips optimal nutzen zu können, sollten
Sie Ihr Produkt unter www.philips.com/welcome registrieren.
Ihre Philips Sonicare (Abb. 1)
1 Hygienische Schutzkappe
2 Bürstenkopf
3 Ergonomisches Handstück
4 Vertiefter Ein-/Ausschalter
5 Verstecktes Putzmodusdisplay
6 Aufladeanzeige
7 Ladeglas
8 Ladeständer
9 Ladestation
10 Box für Reiseladegerät
11 USB-Kabel
Hinweis: Abhängig vom gekauften Modell kann der Packungsinhalt
variieren.
22 Deutsch
