Philips HX2740/02 User manual

ENGLISH 4
FRANÇAIS 17
DEUTSCH 31
NEDERLANDS 45
ITALIANO 59
ESPAÑOL 73
PORTUGUÊS 86
TÜRKÇE 101
HX2740,1720

Mounting the appliance on the wall
C1Mount the charging unit on the wall by means of the mounting
plate.Choose a place where the appliance cannot fall into the
water accidentally.
◗The toothbrush itself is waterproof,so you may use it while having a
shower or bath.
C2Push excess mains cord into the storage space in the back of the
charging unit.
4ENGLISH

Important
◗Charge the toothbrush for at least 16 hours before you use it for the first
time.
◗The mains cord of the charging unit cannot be replaced.If the cord is
damaged,the unit should be discarded.Turn to your Philips dealer or to
the Philips organisation in your country for help or advice (refer to the
WorldWide Guarantee leaflet).
◗The mains plug of the charging unit meets the latest European standards.
The plug is safe, although the standard UK shaver socket holes may be
slightly too wide for the pins of the plug.Make sure a proper connection
is made.
◗Use a suitable adapter if you have to connect the appliance to a standard
UK 3-pin socket,
◗If your toothbrush is marked with the following text applies:
To protect the environment,this toothbrush has been equipped with a
nickel-hydride (NiMH) battery which contains less than 0.01% cadmium.
Nevertheless we advise you to make sure that,when you discard the
toothbrush,you keep the battery separate from normal household refuse
and dispose of it at an officially assigned collection point.Please refer to
the section "Environmental aspects".
◗If your toothbrush is marked with the following text applies:
The built-in rechargeable (NiCd) battery contains substances which may
pollute the environment.
When you discard your toothbrush in due course,please make sure that
the battery is kept separate from normal household refuse and dispose
of it at an officially assigned collection point.Please refer to the section
"Environmental aspects".
◗When you use the OralWater Jet for the first time or when you have
not been using it for a long time, it is necessary to set the volume control
to its maximum setting (5) and the jet tip nozzle to position • (for single-
jet operation) to start the water flowing to the jet tip.If the water
doesn’t flow out after 10 seconds,put the jet tip nozzle in your mouth
and suck it shortly.
ENGLISH 5

Healthy teeth are to be
treasured, which is
logical, for we want
them to last a lifetime.
As plaque is the major
cause of tooth decay,
proper dental care is
essential. By brushing
carefully every day you
will remove plaque and
keep your teeth and
gums healthy longer
What is plaque?
Plaque is a soft, sticky layer on our teeth. It forms
mainly on hard-to-reach areas such as interdental
spaces and along the gum line. Plaque mainly
consists of bacteria that turn the sugars in our food
into harmful acids. Due to its yellowy white colour,
plaque is hard to detect on the teeth. Fortunately, as
long as the plaque is still soft, it can easily be
removed by means of careful and correct brushing.
What are the consequences
of plaque?
The acids in plaque dissolve the enamel on our
teeth and molars, which may lead to the
development of cavities.The bacteria produce
toxins which may cause the gums to become
inflamed (gingivitis). Inflamed gums are often red
and swollen and may start bleeding during brushing
or eating. Moreover, the inflammation may spread
from the gum line to the jaw bone beneath, which
may eventually cause the teeth and molars to fall
out. If plaque is not removed daily, it may calcify
into tartar adhering strongly to the teeth.Tartar, in
its turn, provides an excellent platform for new
plaque growth, thus further increasing the risk of
caries and inflammation.
6ENGLISH
Taking optimal care of your teeth

What is the best toothbrushing method?
Toothbrushing is an activity that needs to be carried
out with care.Therefore, take your time to reach all
areas. Electric toothbrushes have been proven to be
more effective than manual toothbrushes when it
comes to removing plaque. With the Philips Jordan
Sensiflex, brushing each side of the tooth for a few
seconds is enough to clean both the tooth and the
surrounding gums. In this way, you can clean all
your teeth in a few minutes (see also the brushing
instructions). If you like, you can ask your dentist
or dental hygienist for a personal brushing advice.
Correct positioning of the toothbrush
The Philips Jordan Sensiflex has been designed to
make the type of movement that best removes
plaque. As there is no need for you to move the
brush to and fro, you can focus on placing the
brush on your teeth correctly.The quickly
oscillating bristles of the brush first detach and then
wipe away the plaque.The extra long and soft
bristles of the ActiveTip ensure thorough and
effective cleaning between the teeth and at the back
of the mouth.
Enough time
By guiding the brush slowly along the insides,
outsides and chewing surfaces of all teeth and
molars, you will clean all areas in which plaque is
likely to develop. Hard-to-reach areas such as
behind the molars, along the gum line and behind
the front teeth, require extra attention. It is
therefore important that you take enough time for
your daily oral hygiene.
Optimal pressure
Brushing too hard may cause damage to your teeth
and gums. And, contrary to what you might expect,
it removes plaque less effectively than gentle
brushing. The unique Controlled Pressure system
will help you keep a check on your brushing
pressure. If too much pressure is applied to the
brush, the toothbrush will warn you immediately
by means of a click that you will both hear and feel.
Then the brush head will flex back. Clinical tests
have shown that, thanks to this Controlled Pressure
system, brushing with the Philips Jordan Sensiflex
results in a better and safer brushing technique.
Oral Water Jet
The Oral Water Jet is an additional device to assist
you in the daily care for your teeth. It gives your
mouth a delightfully fresh feeling, particularly when
mouthwash has been added to the water.
ENGLISH 7
www.homeandbody.philips.com

Directions for use: toothbrush
Charging the toothbrush
C1Leave the toothbrush to charge for at least 16 hours before you
use it for the first time.
◗The toothbrush can be put back in the charging unit after use.
◗If the battery in the toothbrush is being charged,the pilot light is green
(only type HX2740).
◗If the battery is almost empty,the pilot light is red and blinks for 10
seconds after the toothbrush has been switched off (only type HX2740).
Tip:The toothbrush can be left to charge continuously.However,to
extend the life of the battery,it is recommended to let the toothbrush
run until it is completely empty and then fully recharge it every six
months.
How to use the toothbrush
C1Mount the brush head onto the toothbrush by inserting it into the
bayonet catch and turning it.This will make it impossible for the
brush head to become detached due to vibration.
C2Place the brush in your mouth.
C3Press the on/off button to switch the toothbrush on.
12
8ENGLISH

C4The toothbrush will start oscillating at the highest speed.To switch
to a lower speed,press the 2-speed button (only type HX2740).
Brushing
C1Place the brush against the tooth at an angle,in such a way that it
covers the surface of the tooth as well as the gum line.Hold the
brush in that position for a few seconds and then move on to the
next tooth.
◗The round brush head removes plaque from the teeth and beneath the
gum line.
◗The individually moving ActiveTip cleans between the teeth.
C2The brush will do the work for you.All you have to do is guide the
brush carefully along the teeth and molars.
◗Make sure that you reach all surfaces of the teeth (inside,outside and
chewing surface) as well as the gums properly.A fixed brushing pattern
will prevent you from skipping certain areas.
◗See also the brushing instructions coming with the appliance and the
section‘taking optimal care of your teeth’.
Safe brushing
C1The Controlled Pressure system will keep a check on the pressure
you exert on the brush.
ENGLISH 9

C2If you press the brush too hard against your gums,you will feel and
hear a click when the brush head flexes backwards.As soon as you
reduce the pressure,the brush will return to its normal position.
◗This will probably happen regularly when you first start using the brush,
but after some time you will have discovered the optimal brushing
pressure,and the brush will flex backwards less often.
Tip: If plaque is removed properly, the gums will have a pink colour
and firmly surround the teeth. Healthy gums do not bleed when you
eat or brush your teeth (see also the section‘taking optimal care of
your teeth’).
If,nevertheless,your gums bleed slightly the first few times you use the
brush,this bleeding will generally stop after a few days.If it does not,
consult your dentist or dental hygienist.
Minimum brushing time: 2 minutes
◗In general,2 minutes will be enough to clean your teeth properly.
◗Therefore the brush is equipped with a red pilot light that will blink for
40 seconds when you have been brushing for 2 minutes (only type
HX2740).
◗Naturally,you can also brush longer than 2 minutes.
After using the toothbrush
C1Let the toothbrush run while you rinse the brush head under the
tap.Use lukewarm water (max.60°C).
C2Also rinse the inside of the brush head.
10 ENGLISH

C3Switch the toothbrush on again to rinse toothpaste residues from
the drive shaft.
C4Store the brush head upside down in the storage compartment,
with the coloured ring on top.
◗You can clean the charging unit with a moist cloth.
◗First unplug the charging unit!
Brush head replacement
C1Replace the brush head every three months for the best brushing
results.
◗The brush head should also be replaced when the bristles start to splay.
◗New brush heads are available from the shop in which you have
purchased your Philips Jordan toothbrush.
Tip:Worn bristles will move plaque around rather than remove it.
They may also damage the gums.It is therefore important that you
replace the brush head every three months.
Environmental aspects
When you discard the toothbrush in due course,remove the battery
and dispose of it in an environmentally safe way.
◗NB:You can also hand the toothbrush in at a Philips Service Centre,
which will dispose of the battery for you.
◗Before you remove the battery,it must be completely empty. Let the
toothbrush run until is stops before removing the battery.
2
1
CLICK
ENGLISH 11

◗NB:Only unscrew the bottom of the toothbrush if you want to remove
the battery.
After the bottom has been unscrewed,the toothbrush may not be
watertight anymore.Therefore the guarantee will become invalid if the
bottom of the toothbrush has been unscrewed.If undamaged,the
sticker on the bottom of the toothbrush will prove that the toothbrush
has not been opened.
Directions for use: Oral Water Jet
When you use the OralWater Jet for the first time or when you have
not been using it for a couple of days:
C1Click the jet tip onto the appliance.
C2Remove the water reservoir from its base.
12 ENGLISH
