Philips HP3553/01 User manual

HP 405/355

2
English Page 4
• Keep page 3 and pages 44, 45 and 46 open when reading these
operating instructions.
Français Page 9
• Pour le mode d'emploi: dépliez la page 3 et les pages 44, 45 et 46 .
Deutsch Seite 14
• Schlagen Sie beim Lesen der Gebrauchsanweisung Seite 3 und Seiten
44, 45 und 46 auf.
Nederlands Pagina 19
• Sla bij het lezen van de gebruiksaanwijzing pagina 3 en de pagina's 44,
45 en 46 op.
Dansk Side 24
• Hold side 3 og side 44, 45 og 46 opslået mens De læser
brugsanvisningen.
Norsk Side 29
• Slå opp på side 3 og side 44, 45 og 46 før De leser videre.
Svenska Sid 34
• Ha sidan 3 och sidan 44, 45 och 46 utvikt när ni läser bruksanvisningen.
Suomi Sivu 39
• Pidä sivu 3 ja sivut 44, 45 ja 46 auki samalla kun luet käyttöohjetta.

3
5
A
C
E
F
H
B
I
D
HP 405
HP 405
G
HP 405

English
Clean and healthy teeth ... with Philips!
Teeth are essential for a good digestion and also play an important role in
speech. Furthermore, sound teeth are one of the prerequisites for an
attractive appearance.
Unfortunately, teeth are often prematurely lost due to dental decay and
inflammation of the gums. This is mainly caused by dental plaque.
What is dental plaque?
Dental plaque is a soft and sticky film which continually develops on teeth.
It has almost the same colour as teeth and mainly consists of bacteria
which occur normally in the mouth.
As long as plaque is still soft, it can easily be removed.
If not removed timely, plaque will start to calcify. This hard, calcified
plaque is called “tartar”.
New soft plaque will easily adhere to the rough surface of this tartar. As
tartar is usually firmly stuck to the tooth, it must be removed by a dentist or
dental hygienist.
Fig. 1 shows a section of a tooth. The root of the tooth is joined to the
jawbone by strong tissue, called periodontium.
The jawbone is covered by gums or gingiva.
Gums, jawbone and periodontium together form the supporting tissue.
What are the effects of plaque?
The bacteria in the plaque produce an acid which can dissolve the enamel
of the teeth and the dentine beneath it. This will cause dental decay
(caries).
The bacteria also form substances which may cause inflammation of the
gums (gingivitis) or decay of the supporting tissue (periodontitis).
This process is illustrated in fig. 2: the shallow groove around the tooth
has become a deep pocket filled with plaque and tartar.
If the inflammation of the gums is allowed to continue for too long, it may
lead to destruction of the periodontium and gradual loss of the jawbone.
Inflamed gums are generally red and swollen and often bleed when the
teeth are brushed.
Eventually, this may result in the tooth coming loose or falling out (fig. 3).
Thorough and regular removal of plaque will prevent gingivitis from
starting and will help stop the spread of periodontitis.
4

Philips rechargeable toothbrushes HP 405 and HP 355
Clean & Clear brush movement (fig. 4a)
The brush moves in two directions and at two speeds simultaneously:
• Quick short stroke (4200 rpm) longitudinal scrubbing to dislodge the
plaque material;
• Slow long stroke (120 rpm) rolling movement to move the dislodged
plaque away.
New “Soft Pressure Control” (fig. 4b)
Too much pressure may damage both gums and teeth, causes
unneccesary wear of the brush and also reduces the effectiveness of the
brushing operation.
The “Soft Pressure Control” system helps you to control the pressure
when brushing your teeth.
When pushed too hard against the teeth or gums, the brush will
automatically warn you by a sudden change in the position of its neck.
“Contour” brush profile (fig. 4c)
The ergonomic “Contour” bristle profile guarantees optimum cleaning.
The soft white bristles brush the gumline and reach deeply between the
teeth. The blue bristles especially clean the (chewing) surfaces.
5
Important
•First charging: at least 12 hours.
•The mains cord of this appliance cannot be replaced.
If the cord is damaged, the appliance should be discarded.
•For optimum brushing efficiency and for hygiene: replace the
click-on brushes as soon as the hairs begin to stand out or at
least every three months.
•It is advisable to use your electrical toothbrush twice a day for
at least two minutes.
•The built-in rechargeable battery contains substances which
may pollute the environment.
When eventually discarding your appliance please remove the
built-in rechargeable battery (fig. 20-26) and dispose of it at an
officially assigned refuse site or otherwise according to
national regulations.
Please refer to section “Protecting the environment”.

6
General Description (fig. 5) (pag. 3)
AToothbrush
BDrive shaft
C”Soft-Pressure”bending head
DOn/off switch. Press to switch on. Press again to switch off.
EClick-on brushes (colour-coded for personal use)
FCharge unit with mains cord
GHolder for click-on brushes (HP 405 only)
HPilot light (illuminates green during charging) (HP 405 only)
IMounting-plate, screws and rawlplugs for wall mounting
(HP 405 only)
Bathroom use
• Mount to a wall (HP 405 only) or place the charge unit
where it cannot accidentally fall into water.
• As the toothbrush itself is waterproof you may choose to
use it while having a shower or bath.
Wall mounting (fig. 6-7) (HP 405 only)
How to charge (fig. 8-10)
• Ensure that the appliance is switched off when (re)charging.
•Before first use charge for at least 12 hours.
• In normal use, the toothbrush is recharged after each use by just placing
it back into the connected charge unit.
How to use (fig. 11-15)
• Let the toothbrush do the work for you: just guide the bristle carefully
along the teeth. Ensure that the brush touches the entire tooth surface
as well as a small section of the gums.
• If the head clicks into a straight position during brushing, this means that
you have applied too much pressure (fig. 15).
• Also refer to the provided Tooth Brushing Instructions card.

Minimum brushing time: 2 minutes (fig. 16)
Two minutes is regarded to be the minimum time required for effective
plaque removal and gum massage.
For even better results you may decide to brush longer.
Remember that fluoride in toothpaste also needs some time to act.
After brushing your teeth (fig. 17-19)
Cleaning
- The toothbrush may be cleaned in lukewarm (soapy) water.
- The charge unit can be cleaned with a damp cloth. Unplug before
cleaning!
Replacement click-on brushes
Colour-coded click-on brushes are available from your dealer under type
nrs.
HP 5926 (for grown-ups);
HP 5927 (for children);
HP 5928 (for both grown-ups and children).
Protecting the environment
To remove the built-in rechargeable battery when eventually discarding
your appliance: see fig. 20-26.
• Please note: You can also take the appliance to a Philips Service
Centre. The staff will be happy to help you.
• Before removing the battery should be completely empty of charge. Let
the appliance run until the motor stops.
• Please note: Only unscrew the bottom for battery removal.
The toothbrush may not be watertight anymore after the bottom has
been unscrewed.
For that reason the guarantee is void after opening the toothbrush.
7

Fitting a different plug
This appliance is fitted with a BS 1363 13 Amp. plug.
Should you need to replace the plug, connect the wires as follows:
Brown wire to the Live (L) terminal of the new plug.
Blue wire to the Neutral (N) terminal of the new plug.
Always fit the same value of fuse as that originally supplied with your
appliance.
Only use BS 1362 approved fuses.
As a guide only: Appliances under 700 W can have a 3 Amp. fuse (red)
and all others should have a 13 Amp. fuse (brown).
When disposing of an old plug (particularly the moulded type which has
been cut from the mains cord) always remove the fuse as the plug could
be dangerous if ever inserted in a live socket.
8

Propreté et santé des dents ... avec Philips !
Les dents ont plusieurs fonctions importantes.
Elles doivent être en bonne santé, ce qui est primordial pour la digestion.
Les dents ont aussi un rôle important lorsque nous parlons.
Et pour une apparence attrayante, il est également essentiel d'avoir de
belles dents en bonne santé.
Qu'est-ce que la plaque dentaire ?
La plaque dentaire est une couche mince et gluante qui se forme
continuellement sur les dents. Elle a souvent la même couleur que les
dents et les molaires et se compose principalement de bactéries qui sont
normalement présentes dans la bouche.
La plaque s'enlève facilement lorsqu'elle est molle. Si elle n'est pas
enlevée régulièrement ou correctement, la plaque dentaire se calcifie.
Cette plaque dure est appelée "tartre". Une nouvelle plaque peut alors
aisément adhérer à la surface rugueuse du tartre ainsi formé.
Comme le tartre est fortement collé aux dents, il ne reste plus que
l'intervention du dentiste pour l'enlever.
La figure 1 montre la coupe d'une dent. La racine de la dent est attachée
à la mâchoire par des tissus forts, appelés aussi périodonte.
La mâchoire est recouverte par la gencive.
Gencives, mâchoire et périodonte forment les tissus supports de la dent.
Quels sont les effets de la plaque ?
Les bactéries de la plaque produisent un acide qui peut dissoudre l'émail
de la dent et ensuite la dentine se trouvant en-dessous de l'émail. C'est
ainsi que se forme une cavité, appelée carie.
A part l'acide, les bactéries forment d'autres substances nuisibles, qui
peuvent provoquer l'inflammation de la gencive (gingivite), ou altérer les
tissus qui maintiennent les dents (périodontite).
La figure 2 montre ce processus : le petit sillon entre dent et gencive est
devenu une "poche" profonde, remplie de plaque et de tartre.
Si l'inflammation des gencives dure trop longtemps, elle peut conduire à la
destruction du périodonte et dégrader progressivement la mâchoire. En
général, des gencives enflammées sont rouges et gonflées et saignent
Français
9

souvent lorsque vous vous brossez les dents. La poche devenant plus
profonde, la plaque et le tartre commencent à s'y développer. Finalement,
cela mène au déchaussement, voire à la perte d'une ou plusieurs dents
(fig. 3).
En enlevant minutieusement la plaque dentaire, vous pourrez prévenir la
gingivite et stopper le développement de périodontite.
Brosses à dents rechargeables HP 405 et HP 355
Mouvement des brosses "Clean & Clear" (fig. 4a)
Les poils de la brosse ont un mouvement dans deux sens et à deux
vitesses différentes :
• Des petits mouvements rapides de frottement (4200/min) dans le sens
de la longueur pour détacher la plaque de la surface des dents, des
alvéoles et des espaces interdentaires ;
• De longs et lents mouvements de roulement (120/min) autour de l'axe
longitudinal pour évacuer la plaque détachée.
Contrôle de la pression "Soft pressure" (fig. 4b)
Une trop forte pression peut endommager les dents et la gencive,
occasionner une dégradation prématurée de la brosse et réduire
l'efficacité du brossage.
Le système "Soft Pressure" permet de contrôler la pression et d'éviter ce
genre de problèmes.
Si la brosse est appliquée trop fortement sur les dents ou les gencives,
celle-ci vous avertira en changeant brusquement la position de son cou
articulé.
Brosse "Contour" (fig. 4c)
Les brosses "Contour" ont une forme spécialement étudiée pour vous
garantir une efficacité de nettoyage optimale.
Les touffes blanches brossent les gencives et pénètrent entre les dents.
Les touffes bleues brossent l'émail de la dent en surface.
10
