Philips FlexCare Platinum HX6972/38 User manual

FlexCare Platinum
4235_020_9773_2_Book_Simp_A6_v5.indd 1 16/03/16 15:12

2
1
3
4
5
6
8
9
10
7
11
12
13
1

English 6
Bahasa Indonesia 18
Bahasa Melayu 31
Français 44
Tiếng Việt 58
ภาษาไทย 69
ﺔﻴﺑﺮﻌﻟﺍ 79
یسرﺍف 90

English
Introduction
Congratulations on your purchase and welcome to Philips! To fully
benefit from the support that Philips offers, register your product at
www.philips.com/welcome.
Important
Read this user manual carefully before you use the appliance and
save it for future reference.
Danger
- Keep the charger away from water. Do not place or store it over or
near water contained in a bathtub, washbasin, sink etc. Do not
immerse the charger in water or any other liquid. After cleaning,
make sure the charger is completely dry before you connect it to
the mains.
Warning
- The mains cord cannot be replaced. If the mains cord is damaged,
discard the charger.
- Always have the charger replaced with one of the original type in
order to avoid a hazard.
- Do not use the charger outdoors or near heated surfaces.
- If the appliance is damaged in any way (brush head, toothbrush
handle or charger), stop using it. This appliance contains no
serviceable parts. If the appliance is damaged, contact the
Consumer Care Centre in your country (see chapter ‘Guarantee
and support').
- This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.
Caution
- Do not clean the brush head, the handle, the charger, the charger
cover and/or the sanitiser in the dishwasher.
6English

- If you have had oral or gum surgery in the previous 2 months,
consult your dentist before you use the toothbrush.
- Consult your dentist if excessive bleeding occurs after using this
toothbrush or if bleeding continues to occur after 1 week of
use.Also consult your dentist if you experience discomfort or pain
when you use the Sonicare.
- The Sonicare toothbrush complies with the safety standards for
electromagnetic devices. If you have a pacemaker or other
implanted device, contact your physician or the device
manufacturer of the implanted device prior to use.
- If you have medical concerns, consult your doctor before you use
the Sonicare.
- This appliance has only been designed for cleaning teeth, gums
and tongue. Do not use it for any other purpose. Stop using the
appliance and contact your doctor if you experience any
discomfort or pain.
- The Sonicare toothbrush is a personal care device and is not
intended for use on multiple patients in a dental practice or
institution.
- Stop using a brush head with crushed or bent bristles. Replace the
brush head every 3 months or sooner if signs of wear appear.
- Do not use other brush heads than the ones recommended by the
manufacturer.
- If your toothpaste contains peroxide, baking soda or bicarbonate
(common in whitening toothpastes), thoroughly clean the brush
head with soap and water after each use.This prevents possible
cracking of the plastic.
- Do not insert objects into the air openings of the sanitiser or block
these air openings by placing it on a soft surface or in a position or
location where objects will block these openings (examples of
objects:
- magazine, tissue paper and hair).
- The UV light bulb is hot during and immediately after the sanitising
cycle. Do not touch the UV light bulb when it is hot.
- Do not operate the sanitiser without the protective screen in place
to avoid contact with a hot bulb.
7
English

- If the sanitiser has been used for 3 consecutive UV clean cycles
(i.e. 3 times in a row), switch it off for at least 30 minutes before
you start another UV clean cycle.
- Discontinue use of the sanitiser if the UV light bulb remains on
when the door is open. UV light can be harmful to the human eye
and skin. Keep the sanitiser out of the reach of children at all times.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.
General description (Fig. 1)
1Hygienic travel cap
2Brush head with unique identifier
3Handle
4Power on/off button
5Intensity level indicator
6Intensity level button (+ and -)
7Brushing modes
8Mode button
9Battery level indicator
10 UV sanitiser base with integrated charger and cord wrap (specific
types only)
- Not shown: UV light bulb
- Not shown: Sanitizer drip tray
- Not shown: Protective screen for UV light bulb
11 Mains cord with plug
12 Charger cover with brush head holders (select models)
13 Travel charger
- Not shown: Travel case
The content of the box may vary based on the model purchased.
8English

Preparing for use
Attaching the brush head
1Align the brush head so the bristles point in the same direction as
the front of the handle. (Fig. )
2Firmly press the brush head down onto the metal shaft until it
stops.
Philips Sonicare brush heads are imprinted with icons to easily
identify your brush head.
Charging the appliance
1Put the plug of the charger or sanitizer in a wall socket.
2Place the handle on the charger.
The flashing light of the battery level indicator indicates that the
toothbrush is charging. (Fig. )
Note: It takes at least 24 hours to fully charge the battery.
Using the appliance
Brushing instructions
1Wet the bristles (Fig. 4) and apply a small amount of toothpaste
(Fig. 5). (Fig. 4)
2Place the toothbrush bristles against the teeth at a slight angle (45
degrees), pressing firmly to make the bristles reach the gumline or
slightly beneath the gumline. A change in vibration (and a slight
change in sound) alerts you when you apply too much pressure
while brushing. (Fig. 6)
Note: Keep the center of the brush in contact with the teeth at all
times.
3Press the power on/off button to switch on the Philips Sonicare.
(Fig. 7)
4Apply light pressure to maximize Philips Sonicare’s effectiveness
and let the Philips Sonicare toothbrush do the brushing for you. Do
not scrub.
9
English

5Gently move the brush head slowly across the teeth in a small
back and forth motion so the longer bristles reach between your
teeth (Fig. 8). Continue this motion throughout the brushing cycle.
6To clean the inside surfaces of the front teeth, tilt the brush handle
semi-upright and make several vertical overlapping brushing
strokes on each tooth (Fig. 9).
7Begin brushing in section 1 (outside upper teeth) and brush for 30
seconds (45 seconds in Deep Clean mode) before you move to
section 2 (inside upper teeth). Continue brushing in section 3
(outside lower teeth) and brush for 30 seconds (45 seconds in
Deep Clean mode) before you move to section 4 (inside lower
teeth (Fig. 10)).
Note: To make sure you brush evenly throughout the mouth, divide
your mouth into 4 sections using the Quadpacer feature (see chapter
‘Features’).
Note:After you have completed the brushing cycle, you can spend
additional time brushing the chewing surfaces of your teeth and areas
where staining occurs. (Fig. 11) You can also brush your tongue, with
the toothbrush turned on or off, as you prefer.
Your Philips Sonicare is safe to use on:
- Braces (brush heads wear out sooner when used on braces).
- Dental restorations (fillings, crowns, veneers).
Brushing modes
Clean mode
For an exceptional everyday clean (default mode).
White mode
2 minutes to remove surface stains and 30 seconds to brighten and
polish your front teeth.
Deep Clean
Provides an invigorating 3 minutes of alternating cleaning and
massaging to deliver an exceptionally clean experience.
Your Philips Sonicare comes with the Clean mode activated.
10 English

Note: When the toothbrush is switched on, you cannot toggle
between modes.
1Before you switch on the Philips Sonicare, press the mode button
to toggle between modes.
-The selected brushing mode lights up.
-Once a brushing mode has been selected, it remains active until
another brushing mode is selected.
Note: When the Philips Sonicare is used in clinical studies, it must be
used in the default 2-minute Clean mode at high intensity or in the
Deep Clean mode at high intensity.
Intensity levels per mode
- Low: 1 LED indicator light.
- Medium: 2 LED indicator lights.
- High: 3 LED indicator lights.
Note: to adjust the intensity level to the next higher or lower level,
you can press the + button to increase intensity or the - button to
decrease intensity at any time during the brushing cycle.
Pressure Sensor
A change in vibration (and a slight change in sound) alerts you when
you apply too much pressure while brushing. See chapter ‘Features’.
Battery status (when handle is not on charger)
- 1 yellow LED indicates a low charge.
- 3 green LEDs indicate a full charge.
Note: If you hear a long beep and the yellow LED of the battery level
indicator flashes, your toothbrush is completely empty and switches
off. Place the toothbrush on the charger to recharge it.
Note: To keep the battery fully charged at all times, you may keep
your Philips Sonicare on the charger when not in use.
Features
Pressure Sensor
This Philips Sonicare model comes with the Pressure Sensor feature
activated. The Pressure Sensor works in all 3 modes and at all 3
intensity levels.
11
English

Activating or deactivating the Pressure Sensor feature
1Attach the brush head to the handle.
2Place the handle in the plugged-in charger or sanitizer.
- To deactivate Pressure Sensor:
Press and hold the power on/off and mode button for 2 seconds.
You hear 1 beep to indicate that the Pressure Sensor feature has
been deactivated.
- To activate Pressure Sensor:
Press and hold the power on/off and mode button for 2 seconds.
You hear 2 beeps to indicate that the Pressure Sensor feature has
been activated.
Quadpacer
- The Quadpacer is an interval timer that has a short beep and
pause to remind you to brush the 4 sections of your mouth.
Depending on the brushing mode or brushing routine you have
selected, the Quadpacer beeps at different intervals during the
brushing cycle. The Quadpacer works in all 3 modes and at all 3
intensity levels. (Fig. 10)
The Quadpacer feature on this model has been activated. To
deactivate or reactivate the Quadpacer feature:
1Place the handle in the plugged-in charger. or sanizater.
2Press and hold the mode button until:
a You hear 1 beep to indicate the Quadpacer has been
deactivated.
b You hear 2 beeps to indicate the Quadpacer has been
activated.
Smartimer
The Smartimer indicates that your brushing cycle is complete by
automatically turning off the toothbrush at the end of the brushing
cycle.
Dental professionals recommend brushing no less than 2 minutes
twice a day.
12 English

Easy-start
This Sonicare comes with the Easy-start deactivated.
The Easy-start feature gently increases the power over the first 14
brushings to help you get used to the brushing with the Philips
Sonicare.
Note: Each of the first 14 brushings must be at least 1 minute in length
to properly advance through the Easy-start ramp-up cycle.
Activating or deactivating the Easy-start feature
1Attach the brush head to the handle.
2Place the handle in the plugged-in charger or sanitizer.
- To activate Easy-start:
Press and hold the power on/off and mode button for 2 seconds.
You hear 2 beeps to indicate that the Easy-start feature has been
activated.
- To deactivate Easy-start:
Press and hold the power on/off and mode button for 2 seconds.
You hear 1 beep to indicate that the Easy-start feature has been
deactivated.
Note: Using the Easy-start feature beyond the initial ramp-up period
is not recommended and reduces Philips Sonicare effectiveness in
removing plaque.
Note: Each of the first 14 brushings must be at least 1 minute in length
to properly move through the Easy-start ramp-up cycle.
Sanitizing
- With the UV sanitizer you can clean your brush head after every
use (Fig. 12).
Unplug the sanitizer, discontinue use and call Consumer Care if:
- The UV light bulb remains on when the door is open.
- The window is broken or missing from the sanitizer.
- The sanitizer gives off smoke or a burning smell while it is
operating.
Note: UV light can be harmful to the human eye and skin. This device
should be kept out of reach of children at all times.
1After brushing, rinse the brush head and shake off excess water.
13
English

Warning: Do not place the travel cap on the brush head
during sanitization.
2Place your finger in the door recess on top of the sanitizer and pull
open the door (Fig. 13).
3Place the brush head on one of the 2 pegs in the sanitizer with the
bristles facing the light bulb (Fig. 14).
Note: Only clean Philips Sonicare snap-on brush heads in the
sanitizer.
Note: Do not clean Philips Sonicare for Kids brush heads in the
sanitiser.
4Make sure the sanitizer is plugged into a live outlet of appropriate
voltage.
5Close the door and press the green power on/off button once to
select the UV clean cycle.
Note: You can only turn on the sanitizer if the door is properly
closed.
Note: The sanitizer stops if you open the door during the sanitizing
cycle.
Note: The sanitizer cycle runs for 10 minutes and then
automatically shuts off.
-The sanitizer is in operation when the light glows through the
window.
Cleaning
Warning: Do not clean the brush head, handle, travel
charger or the UV sanitizer in the dishwasher.
Toothbrush handle
1Remove the brush head and rinse the metal shaft area with warm
water. Make sure you remove any residual toothpaste (Fig. 15).
Caution: Do not push on the rubber seal on the metal shaft with
sharp objects, as this may cause damage.
2Wipe the entire surface of the handle with a damp cloth.
14 English

Brush head
1Rinse the brush head and bristles after each use (Fig. 16).
2Remove the brush head from the handle and rinse the brush head
connection with warm water at least once a week.
Sanitizer
Warning: Do not immerse the sanitizer in water or rinse it
under the faucet.
Warning: Do not clean the sanitizer when the UV light bulb
is hot.
For optimal effectiveness, it is recommended to clean your sanitizer
weekly.
1Unplug the sanitizer.
2Pull the drip tray straight out. Rinse the drip tray and wipe it clean
with a damp cloth (Fig. 17).
3Clean all interior surfaces with a damp cloth.
4Remove the protective screen in front of the UV light bulb (Fig. 18).
To remove the screen, grasp the edges next to the snaps, gently
squeeze and pull out the protective screen.
5Remove the UV light bulb.
To remove the light bulb, grasp it and pull it out of the metal clasp.
6Clean the protective screen and the UV light bulb with a damp
cloth.
7Reinsert the UV light bulb.
To reinsert the light bulb, align the bottom of the light bulb with
the metal clasp and push the bulb into the clasp.
8Reinsert the protective screen.
To reinsert the screen, align the pegs on the screen with the slots
on the reflective surface near the UV light bulb. Push the screen
straight into the slots on the sanitizer.
15
English

Storage
If you are not going to use the product for a long time, unplug it, clean
it (see chapter 'Cleaning') and store it in a cool and dry place away
from direct sunlight. You can use the integrated cord wrap to store
excess cord of the UV sanitizer in an organized manner.
Replacement
Brush head
- Replace Philips Sonicare brush heads every 3 months to achieve
optimal results.
- Use only Philips Sonicare replacement brush heads.
Ordering accessories
To buy accessories or spare parts, visit
www.shop.philips.com/service or go to your Philips dealer. You can
also contact the Philips Consumer Care Center in your country (see
the worldwide guarantee leaflet for contact details).
Recycling
- Do not throw away the product with the normal household waste
at the end of its life, but hand it in at an official collection point for
recycling. By doing this, you help to preserve the environment.
Removing the rechargeable battery
Warning: PLEASE NOTE THAT THIS PROCESS IS NOT
REVERSIBLE.
- To remove the rechargeable battery, you need a flat-head
(standard) screwdriver. Observe basic safety precautions when
you follow the procedure outlined below. Be sure to protect your
eyes, hands, fingers, and the surface on which you work.
1To deplete the rechargeable battery of any charge, remove the
handle from the charger, turn on the Philips Sonicare and let it run
until it stops. Repeat this step until you can no longer switch on
the Philips Sonicare.
16 English

2Insert a screwdriver into the slot located at the bottom of the
handle and turn counterclockwise to release the bottom cap (Fig.
19).
3Hold the handle upside down and push down on the shaft to
release the internal components of the handle (Fig. 20).
4Insert the screwdriver under the circuit board, next to the battery
connections, and twist to break the connections. Remove the
circuit board and pry the battery from the plastic carrier (Fig. 21).
The rechargeable battery can now be recycled and the rest of the
product discarded appropriately.
Guarantee and support
If you need information or support, please visit
www.philips.com/support or read the separate worldwide guarantee
leaflet.
Guarantee restrictions
The terms of the international guarantee do not cover the following:
- Brush heads.
- Damage caused by use of unauthorised replacement parts.
- Damage caused by misuse, abuse, neglect, alterations or
unauthorised repair.
- Normal wear and tear, including chips, scratches, abrasions,
discolouration or fading.
17
English

Bahasa Indonesia
Pendahuluan
Selamat atas pembelian Anda dan selamat datang di Philips! Untuk
memanfaatkan sepenuhnya dukungan yang ditawarkan Philips,
daftarkan produk Anda di www.philips.com/welcome.
Penting
Bacalah petunjuk pengguna ini secara saksama sebelum Anda
menggunakan alat dan simpan untuk referensi di kemudian hari.
Bahaya
- Jauhkan pengisi daya dari air. Jangan meletakkan atau
menyimpan pengisi daya di dalam atau di dekat air seperti di bak
mandi, tempat cuci, wastafel, dll. Jangan mencelupkan pengisi
daya ke dalam air atau cairan lain. Setelah dibersihkan, pastikan
pengisi daya benar-benar kering sebelum Anda
menyambungkannya ke stopkontak listrik.
Peringatan
- Kabel tidak dapat diganti. Buang pengisi daya jika kabelnya rusak.
- Selalu ganti pengisi daya dengan produk yang asli untuk
menghindari bahaya.
- Jangan gunakan pengisi daya di luar ruangan atau dekat
permukaan panas.
- Jika alat rusak, apa pun kerusakannya (kepala sikat, gagang sikat
gigi atau pengisi daya), hentikan penggunaan. Alat ini tidak
memiliki komponen yang bisa diperbaiki. Jika alat rusak, hubungi
Pusat Layanan Konsumen di negara Anda (lihat bab 'Garansi dan
dukungan').
- Alat ini tidak dimaksudkan untuk digunakan oleh orang (termasuk
anak-anak) dengan cacat fisik, indera atau kecakapan mental
yang kurang, atau kurang pengalaman dan pengetahuan, kecuali
jika mereka diberikan pengawasan atau petunjuk mengenai
penggunaan alat oleh orang yang bertanggung jawab bagi
keselamatan mereka.
- Anak kecil harus diawasi untuk memastikan mereka tidak bermain-
main dengan alat ini.
18 Bahasa Indonesia

Perhatian
- Jangan membersihkan kepala sikat, gagang, pengisi daya, tutup
pengisi daya dan/atau sanitiser di mesin pencuci piring.
- Jika rongga mulut atau gusi Anda baru dioperasi 2 bulan
sebelumnya, tanyakan dengan dokter gigi Anda sebelum
menggunakan sikat gigi ini.
- Konsultasikan dengan dokter gigi jika terjadi pendarahan
berlebihan setelah menggunakan sikat gigi ini atau jika
pendarahan terus terjadi hingga setelah 1 minggu penggunaan.
Juga konsultasikan dengan dokter gigi jika Anda mengalami rasa
sakit atau tidak nyaman saat menggunakan Sonicare.
- Sikat gigi Sonicare memenuhi standar keselamatan untuk
perangkat elektromagnetik. Jika Anda menggunakan alat pacu
jantung atau perangkat implan lainnya, hubungi dokter atau
produsen perangkat sebelum penggunaan.
- Jika Anda memiliki masalah kesehatan, konsultasikan dengan
dokter Anda sebelum menggunakan Sonicare.
- Alat ini dirancang hanya untuk membersihkan gigi, gusi dan lidah.
Jangan gunakan alat untuk tujuan lain. Hentikan penggunaan alat
dan hubungi dokter Anda jika Anda merasa tidak nyaman atau
mengalami rasa sakit.
- Sikat gigi Sonicare adalah perangkat perawatan pribadi dan tidak
ditujukan untuk digunakan oleh beberapa orang pasien pada
praktik atau institusi perawatan gigi.
- Hentikan penggunaan kepala sikat dengan bulu yang sudah rusak
atau bengkok. Ganti kepala sikat setiap 3 bulan atau lebih sering
jika terlihat tanda-tanda kerusakan.
- Jangan gunakan kepala sikat selain dari yang direkomendasikan
oleh produsen.
- Bila pasta gigi Anda mengandung peroksida, baking soda atau
bikarbonat (sering terdapat pada pasta gigi pemutih), bersihkan
kepala sikat secara menyeluruh dengan sabun dan air setelah
penggunaan. Ini akan mencegah keretakan pada plastik.
19
Bahasa Indonesia

- Jangan memasukkan benda asing ke dalam celah udara sanitiser
atau menutup celah udara ini dengan meletakkannya di
permukaan lembut atau dengan posisi atau lokasi yang
memungkinkan masuknya benda yang dapat menutup celah ini
(misalnya:
- majalah, kertas tisu, dan rambut).
- Lampu sinar UV menjadi panas selama dan sesaat setelah siklus
sanitasi selesai. Jangan menyentuh lampu sinar UV saat masih
panas.
- Jangan gunakan sanitiser tanpa lapisan pelindung untuk
menghindari kontak dengan lampu panas.
- Bila sanitiser telah digunakan selama 3 siklus pembersihan UV
berturut-turut (misalnya dipakai 3 kali berturut-turut), matikan
setidaknya selama 30 menit sebelum mulai menggunakannya lagi.
- Hentikan penggunaan sanitiser jika lampu sinar UV terus menyala
saat pintunya terbuka. Sinar UV dapat membahayakan mata dan
kulit manusia. Jauhkan sanitiser dari jangkauan anak-anak.
Medan elektromagnetik (EMF)
Alat Philips ini mematuhi semua standar dan peraturan yang berlaku
terkait paparan terhadap medan elektromagnet.
Keterangan umum (Gbr. 1)
1Tutup yang higienis
2Kepala sikat dengan penanda unik
3Gagang
4Tombol daya
5Indikator tingkat intensitas
6Tombol tingkat intensitas (+ dan -)
7Mode menyikat
8Tombol mode
9Indikator batas baterai
10 Sanitiser UV dan alas dengan pengisi daya dan penggulung kabel
terintegrasi (tipe tertentu saja)
- Tidak diperlihatkan: Lampu sinar UV
- Tidak diperlihatkan: Wadah penampung sanitiser
20 Bahasa Indonesia
