Philips HX3292/28 User manual

CleanCare+ series toothbrush
EN: User manual
RU: Руководство пользователя
KZ: Пайдаланушы нұсқаулығы
UK: Посібник користувача
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 1 17/02/17 10:19

4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 2 17/02/17 10:19

1
2
3
4
5
6
1
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 3 17/02/17 10:19

1
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 4 17/02/17 10:19

CleanCare+
English 6
Русский 18
Қазақша 30
Українська 40
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 5 17/02/17 10:19

English
6
Introduction
Congratulations on your purchase and welcome to Philips! To fully
benet from the support that Philips oers, register your product at
www.philips.com/welcome.
Important
Read this user manual carefully before you
use the appliance and save it for future
reference.
Danger
-Keep the charger away from water.
Do not place or store it over or near water
contained in a bathtub, washbasin, sink
etc. Do not immerse the charger in water
or any other liquid. After cleaning, make
sure the charger is completely dry before
you connect it to the mains.
Warning
-The mains cord cannot be replaced.
If the mains cord is damaged, discard the
charger.
-Always have the charger replaced with
one of the original type in order to avoid
a hazard.
-Do not use the charger outdoors or near
heated surfaces.
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 6 17/02/17 10:19

English 7
-If the appliance is damaged in any
way (brush head, toothbrush handle or
charger), stop using it. This appliance
contains no serviceable parts. If the
appliance is damaged, contact the
Consumer Care Centre in your country
(see chapter ‘Guarantee and support‘).
-This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not
be made by children unless they are older
than 8 and supervised.
Caution
-Do not clean the brush head, the handle
or the charger in the dishwasher.
-If you have had oral or gum surgery in the
previous 2 months, consult your dentist
before you use the toothbrush.
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 7 17/02/17 10:19

-Consult your dentist if excessive bleeding
occurs after using this toothbrush or if
bleeding continues to occur after 1 week
of use. Also consult your dentist if you
experience discomfort or pain when you
use the Philips Sonicare.
-The Philips Sonicare toothbrush
complies with the safety standards for
electromagnetic devices. If you have a
pacemaker or other implanted device,
contact your physician or the device
manufacturer of the implanted device
prior to use.
-If you have medical concerns, consult
your doctor before you use the Philips
Sonicare.
-This appliance has only been designed for
cleaning teeth, gums and tongue. Do not
use it for any other purpose. Stop using
the appliance and contact your doctor if
you experience any discomfort or pain.
-The Philips Sonicare toothbrush is a
personal care device and is not intended
for use on multiple patients in a dental
practice or institution.
English
8
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 8 17/02/17 10:19

-Stop using a brush head with crushed
or bent bristles. Replace the brush head
every 3 months or sooner if signs of wear
appear. Do not use other brush heads
than the ones recommended by the
manufacturer.
-If your toothpaste contains peroxide,
baking soda or bicarbonate (common in
whitening toothpastes), thoroughly clean
the brush head with soap and water after
each use. This prevents possible cracking
of the plastic.
Electromagnetic elds (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic elds.
General description (Fig. 1)
1 Hygienic travel cap
2 Brush head
3 Handle
4 Power on/o button
5 Battery level indicator
6 Charger
Note: The content of the box may vary based on the model
purchased.
See the Addendum of the DFU for the content of the toothbrushes.
English 9
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 9 17/02/17 10:19

Preparing for use
Attaching the brush head
1 Align the brush head so the bristles point in the same direction as
the front of the handle (Fig. 2).
2 Firmly press the brush head down onto the metal shaft until it stops.
Note: Philips Sonicare brush heads are imprinted with icons to easily
identify your brush head (Fig. 3).
Charging your Philips Sonicare
1 Plug the charger into a live electrical outlet.
2 Place the handle on the charger.
-The light of the battery level indicator ashes and the appliance
beeps twice. This indicates that the toothbrush is charging.
Note: It can take up to 24 hours to fully charge the battery, but you
can use the Philips Sonicare toothbrush before it is fully charged.
Using your Philips Sonicare toothbrush
Brushing instructions
1 Wet the bristles and apply a small amount of toothpaste.
2 Place the toothbrush bristles against the teeth at a slight angle
(45 degrees), pressing rmly to make the bristles reach the gumline
or slightly beneath the gumline (Fig. 4).
Note: Keep the center of the brush in contact with the teeth at all
times.
3 Press the power on/o and mode button to turn on the Philips
Sonicare.
English
10
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 10 17/02/17 10:19

4 Gently keep the bristles placed on the teeth and in the gumline.
Brush your teeth with small back and forth motion so the bristles
reach between the teeth. Continue this motion throughout your
brushing cycle.
Note: The bristles should slightly are. Do not scrub.
5 To clean the inside surfaces of the front teeth, tilt the brush handle
semi-upright and make several vertical overlapping brushing
strokes on each tooth (Fig. 5).
Note: To make sure you brush evenly throughout the mouth,
divide your mouth into 4 sections using the Quadpacer feature
(see chapter ‘Features’).
6 Begin brushing in section 1 (outside upper teeth) and brush for
30 seconds before you move to section 2 (inside upper teeth).
Continue brushing in section 3 (outside lower teeth) and brush for
30 seconds before you move to section 4 (inside lower teeth (Fig. 6)).
7 After you have completed the brushing cycle, you can spend
additional time brushing the chewing surfaces of your teeth and
areas where staining occurs. You can also brush your tongue,
with the toothbrush turned on or o, as you prefer (Fig. 7).
Your Philips Sonicare toothbrush is safe to use on:
-Braces (brush heads wear out sooner when used on braces)
-Dental restorations (llings, crowns, veneers)
Note: Ensure that braces or dental restorations are properly adhered
and not compromised. If not, braces or dental restorations may be
damaged when they come into contact with the brush head.
Note: When the Philips Sonicare toothbrush is used in clinical studies,
the handle should be fully charged and the Easy-start feature
deactivated.
English 11
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 11 17/02/17 10:19

Battery status (when handle is not on charger)
This Philips Sonicare toothbrush is designed to provide at least
20 brushing sessions, each session lasting 2 minutes. The battery
level indicator shows the battery status when you complete the
2-minute brushing session, or when you pause the Philips Sonicare
toothbrush for 30 seconds while brushing by pressing the power
on/o button.
Brushing
sessions
Battery
status color
Light Beeps
20-6 Green Solid -
5-2 Orange Flashing 3 beeps
1 Orange Flashing 2 sets of
3 beeps
Note: When the battery is completely empty, the Philips Sonicare
toothbrush turns o. Place the Philips Sonicare toothbrush on the
charger to charge it.
Note: To keep the battery fully charged at all times, you may keep
your Philips Sonicare toothbrush on the charger when not in use.
English
12
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 12 17/02/17 10:19

Features
Smartimer
The Smartimer indicates that your brushing cycle is complete by
automatically turning o the toothbrush at the end of the brushing cycle.
Dental professionals recommend brushing no less than 2 minutes
twice a day.
Note: If you press the power on/o button after you started the
brushing cycle, the toothbrush will pause. After a pause of
30 seconds, the Smartimer resets.
Easy-start
The Easy-start feature gently increases power over the rst 14 brushings
t o help you get used to brushing with the Philips Sonicare toothbrush.
This Philips Sonicare toothbrush comes with the Easy-start feature
activated.
Activating or deactivating the Easy-start feature:
Place the handle in the plugged-in charger.
-To activate Easy-start:
Press and hold the power on/o button for 2 seconds. You hear
2 beeps and the battery level indicator lights up green to indicate
that the Easy-start feature has been activated.
-To deactivate Easy-start:
Press and hold the power on/o button for 2 seconds. You hear
1 beep and the battery level indicator lights up yellow to indicate
that the Easy-start feature has been deactivated.
Note: Each of the rst 14 brushings must last at least 1 minute to
move through the Easy-start ramp-up cycle properly.
English 13
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 13 17/02/17 10:19

Note: Use of the Easy-start feature beyond the initial ramp-up period
is not recommended and reduces the eectiveness of the Philips
Sonicare toothbrush in removing plaque.
Quadpacer
-The Quadpacer is an interval timer that has a short beep and
pause to remind you to brush the 4 sections of your mouth evenly
and thoroughly. This Philips Sonicare toothbrush comes with the
Quadpacer feature activated (Fig. 8).
Charger conrmation
The handle beeps and vibrates briey when it is placed on the
charger base. This Philips Sonicare toothbrush comes with the
charger conrmation feature activated.
Cleaning
You should clean your Philips Sonicare toothbrush regularly to
remove toothpaste and other residue. Failure to clean your Philips
Sonicare toothbrush may result in an unhygienic product and damage
to it may occur.
Warning: Do not clean brush heads, the handle or the charger in the
dishwasher.
Toothbrush handle
1 Remove the brush head and rinse the metal shaft area with warm
water. Make sure you remove any residual toothpaste (Fig. 9).
Caution: Do not push on the rubber seal on the metal shaft
with sharp objects, as this may cause damage.
2 Wipe the entire surface of the handle with a damp cloth.
English
14
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 14 17/02/17 10:19

Brush head
1 Rinse the brush head and bristles after each use (Fig. 10).
2 Remove the brush head from the handle and rinse the brush head
connection with warm water at least once a week. Rinse the travel
cap as often as needed.
Charger
1 Unplug the charger before you clean it.
2 Wipe the surface of the charger with a damp cloth.
Storage
If you are not going to use the product for a long time, unplug it, clean
it (see chapter ‚Cleaning‘) and store it in a cool and dry place away
from direct sunlight.
Replacement
Brush head
Replace Philips Sonicare brush heads every 3 months to achieve
optimal results. Use only Philips Sonicare replacement brush heads.
Recycling
-This symbol on a product means that the product is covered by
European Directive 2012/19/EU (Fig. 18).
-This symbol means that the product contains a built-in rechargeable
battery covered by European Directive 2006/66/EC which cannot
be disposed of with normal household waste. Follow the
instructions in section ‘Removing the rechargeable battery’
to remove the battery (Fig. 19).
English 15
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 15 17/02/17 10:19

-Inform yourself about the local separate collection system for
electrical and electronic products and rechargeable batteries.
Follow local rules and never dispose of the product and rechargeable
batteries with normal household waste. Correct disposal of old
products and rechargeable batteries helps prevent negative
consequences for the environment and human health.
Removing the rechargeable battery
Warning: Only remove the rechargeable battery when you
discard the appliance. Make sure the battery is completely
empty when you remove it.
Warning: Please note that this process is not reversible.
To remove the rechargeable battery, you need a towel or cloth, a
hammer and a at-head (standard) screwdriver. Observe basic safety
precautions when you follow the procedure outlined below. Be sure
to protect your eyes, hands, ngers, and the surface on which you work.
1 To deplete the rechargeable battery of any charge, remove the
handle from the charger, turn on the Philips Sonicare toothbrush
and let it run until it stops. Repeat this step until you can no longer
turn on the Philips Sonicare toothbrush.
2 Remove and discard the brush head. Cover the entire handle with
a towel or cloth (Fig. 11).
3 Hold the top of the handle with one hand and strike the handle
housing 0.5 inch above the bottom end. Strike rmly with a
hammer on all 4 sides to eject the end cap (Fig. 12).
Note: You may have to hit on the end several times to break the
internal snap connections.
English
16
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 16 17/02/17 10:19

4 Remove the end cap from the toothbrush handle. If the end cap
does not release easily from the housing, repeat step 3 until the
end cap is released (Fig. 13).
5 Holding the handle upside down, press the shaft down on a hard
surface. If the internal components do not easily release from the
housing, repeat step 3 until the internal components are released
(Fig. 14).
6 Remove the inner assembly from the housing by fully inserting a
small at-head screwdriver into the slot opposite the circuit board
and pry until it comes apart (Fig. 15).
7 Grab the battery and pull it out of the internal assembly (Fig. 16).
Caution: Be aware of the sharp edges of the battery tabs so as
to avoid injury to your ngers.
8 Cut the battery wires from the circuit board close to the battery
(Fig. 17).
9 Cover the battery contacts with tape to prevent any electrical short
from residual battery charge. The rechargeable battery can now be
recycled and the rest of the product discarded appropriately.
Guarantee and support
If you need information or support, please visit www.philips.com/
support or read the separate worldwide guarantee leaet.
Guarantee restrictions
The terms of the international guarantee do not cover the following:
-Brush heads.
-Damage caused by use of unauthorised replacement parts.
-Damage caused by misuse, abuse, neglect, alterations or
unauthorised repair.
-Normal wear and tear, including chips, scratches, abrasions,
discolouration or fading.
English 17
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 17 17/02/17 10:19

Введение
Поздравляем с покупкой продукции Philips! Чтобы воспользоваться всеми
преимуществами поддержки Philips, зарегистрируйте изделие на веб-сайте
www.philips.com/welcome.
Важная информация
Перед использованием прибора внимательно
ознакомьтесь с руководством пользователя и
сохраните его для дальнейшего использования
в качестве справочного материала.
Опасно!
-Храните зарядное устройство вдали от воды!
Не помещайте и не оставляйте зарядное
устройство над или поблизости от воды,
налитой в ванну, раковину и т. д. Не опускайте
зарядное устройство в воду или другие
жидкости. После чистки проверяйте, что
зарядное устройство полностью высохло,
прежде чем подключать его к сетевой розетке.
Предупреждение
-Сетевой шнур заменить нельзя. Если он
поврежден, зарядное устройство необходимо
заменить полностью.
-Всегда заменяйте зарядное устройство только
оригинальным устройством, чтобы обеспечить
безопасную эксплуатацию прибора.
Русский
18
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 18 17/02/17 10:19

-Не используйте зарядное устройство вне
помещений или рядом с нагреваемыми
поверхностями.
-При повреждении любой части прибора
(Чистящая насадка-щетка (далее - насадки),
электрическая зубная щетка (далее - щётка или
ручка) или зарядное устройство) не пользуйтесь
им. Данное устройство не содержит деталей,
замена и ремонт которых может выполняться
пользователем.
Если прибор поврежден, обратитесь в центр
поддержки потребителей в вашей стране
(см. главу «Гарантия и поддержка»).
-Данным прибором могут пользоваться
дети старше 8 лет и лица с ограниченными
возможностями сенсорной системы или
ограниченными умственными или физическими
способностями, а также лица с недостаточным
опытом и знаниями, но только под присмотром
других лиц или после инструктирования
о безопасном использовании прибора и
потенциальных опасностях. Не позволяйте
детям играть с прибором. Дети старше 8 лет
могут осуществлять очистку прибора и уход
за ним только под присмотром взрослых.
Русский 19
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 19 17/02/17 10:19

Внимание!
-Чистящие насадки, ручку и зарядное устройство
нельзя мыть в посудомоечной машине.
-Если за последние 2 месяца вы перенесли
операцию ротовой полости или десен,
перед использованием зубной щетки
проконсультируйтесь со стоматологом.
-Если после использования зубной щетки
появляется обильное кровотечение или если
кровоточивость десен не прекращается через
1 неделю, проконсультируйтесь со стоматологом.
Также обратитесь к стоматологу при появлении
неприятных или болевых ощущений во время
использования щетки Philips Sonicare.
-Зубная щетка Philips Sonicare соответствует
стандартам безопасности для электромагнитных
приборов. Если у вас есть кардиостимулятор
или другой имплантированный прибор,
проконсультируйтесь с врачом или
производителем имплантированного прибора
перед использованием.
-При необходимости, перед использованием
Philips Sonicare проконсультируйтесь у врача.
-Данное устройство предназначено для чистки
зубов, десен и языка. Не используйте его
для других целей. При появлении ощущения
дискомфорта или боли прекратите пользоваться
прибором и обратитесь к врачу.
Русский
20
4235_021_0743_4_Booklet_Simple_A6_3mm_v1.indd 20 17/02/17 10:19
