Philips Sonicare DiamondClean 9000 User manual

DiamondClean
9000

4
3
5
6
8
12
14
13
11
10
7
9
1
2
1

English 6
Čeština 31
Eesti 57
Hrvatski 82
Latviešu 108
Lietuviškai 132
Magyar 157
Polski 183
Română 210
Slovenščina 236
Slovensky 261
Srpski 287
Ελληνικά 310
Български 336
Українська 364

English
Introduction
Congratulations on your new Philips Sonicare power toothbrush!
Superior plaque removal, whiter teeth and healthier gums are at your
fingertips. Using Sonicare’s combination of gentle sonic technology
and clinically developed and proven features, you can be confident
that you’re getting the very best clean, every time. Further support
and product registration are available to you at:
http://www.philips.com/welcome.
Welcome to the Philips Sonicare family!
Intended Use
DiamondClean series power toothbrushes are intended to remove
adherent plaque and food debris from the teeth to reduce tooth
decay and improve and maintain oral health. DiamondClean series
power toothbrushes are intended for consumer home use. Use by
children should be with adult supervision.
Important safety information
Read this important information carefully before you use the
appliance and save it for future reference.
Note: The accessories and features of different models vary. For
example, some models come with a sanitizer or are equipped with
Bluetooth.
Danger
- Keep the charger and/or sanitizer away
from water. Do not place or store the
appliance where it can fall or be pulled into
a tub or sink.
- Do not immerse the charger and/or sanitizer
in water or any other liquid.
6English

- After cleaning, make sure the charger
and/or sanitizer is completely dry before
you connect it to the wall socket.
Warning
- This appliance can be used by children and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Cleaning and user
maintenance shall not be made by children
without supervision.
- Children shall not play with the appliance.
- If the appliance is damaged in any way
(brush head, toothbrush handle, charger
and/or sanitizer), stop using it.
- The mains cord cannot be replaced. If the
mains cord is damaged, discard the charger
and/or sanitizer.
- Always replace the charger and/or sanitizer
with one of the original type in order to
avoid a hazard.
7
English

- This appliance contains no user-serviceable
parts. If the appliance is damaged, contact
the Consumer Care Center in your country
(see 'Warranty and support').
- Keep the cord away from heated surfaces.
- Do not use the charger and/or sanitizer
outdoors or near heated surfaces.
Caution
- Do not clean the brush head, handle,
charger, charger cover or sanitizer in the
dishwasher.
- If you have had oral or gum surgery in the
previous 2 months, consult your dentist
before you use this appliance.
- Consult your dentist if excessive bleeding
occurs after using this appliance or if
bleeding continues to occur after 1 week of
use. Also consult your dentist if you
experience discomfort or pain when you use
this appliance.
8English

- This Philips appliance complies with the
safety standards for electromagnetic
devices. If you have a pacemaker or other
implanted device, contact your doctor or the
appliance manufacturer of the implanted
appliance prior to use.
- If you have medical concerns, consult your
doctor before you use this appliance.
- This appliance has only been designed for
cleaning teeth, gums and tongue. Do not
use it for any other purpose. Stop using the
appliance and contact your doctor if you
experience any discomfort or pain.
- This appliance is a personal care device and
is not intended for use on multiple patients
in a dental practice or institution.
- Do not use other brush heads than the ones
recommended by Philips Sonicare.
- Stop using a brush head with crushed or
bent bristles. Replace the brush head every
3 months or sooner if signs of wear appear.
9
English

- If your toothpaste contains peroxide, baking
soda or bicarbonate (common in whitening
toothpastes), thoroughly clean the brush
head with soap and water after each use.
This prevents possible cracking of the
plastic.
- Avoid direct contact with products that
contain essential oils or coconut oil. Contact
may result in bristle tufts dislodging.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.
Radio Equipment Directive
Hereby, Philips declares that electric toothbrushes with radio
frequency interface (Bluetooth) are in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the
following internet address: www.philips.com/support
The radio frequency interface in this product operates at 13.56MHz.
The maximum RF power transmitted by the appliance is 30.16dBm.
Your Philips Sonicare (Fig. 1)
1 Hygienic travel cap
2 Smart brush heads*
3 Handle
4 Power on/off button
5 Intensity light
6 Mode/intensity button
7 Modes
8 Brush head replacement reminder light
10 English

9 Battery indication
10 Charging glass
11 Charging stand
12 Charging base
13 (Charging)Travel case*
14 USB wall adapter*
* Note: The content of the box may vary based on the model
purchased.
Sonicare app – Getting Started
The Sonicare app pairs with your toothbrush to provide you a
connected experience. By connecting your toothbrush to your
Sonicare app account, you will be able to:
- Easily review your progress report for ways to improve your
brushing routine
- Receive personalized tips and recommendations for managing
your oral health
To start using the Sonicare app:
1Download the Sonicare app to your phone
2Open the app and follow the guided steps
3Pair your toothbrush with the app
4Create your account
5Complete firmware update, if prompted, to access the latest
improvements and features.
6Brush regularly
You are ready to start your connected experience. Be sure to brush
regularly. You can receive updates to help improve your oral
healthcare.
Note: Make sure your phone’s Bluetooth is turned on when using the
app. Your toothbrush uses the Bluetooth connection to transfer your
brushing data to the app. If you have questions about why your
brushing data is collected, be sure to review the Sonicare Privacy
Statement, available throughout the app setup process.
11
English

Sonicare app – Track and improve your oral health
care
Your Sonicare power toothbrush is equipped with smart sensors to
provide you with feedback about your brushing habits, including:
- Daily brushing sessions
- Time spent during each brushing session
- Applied brushing pressure
- Brush head replacement reminder (based on actual use)
The Sonicare app collects the data provided by the smart sensors
and tracks your brushing habits over time.
Each of the features available in the app are designed to help you
understand your brushing habits and provide you with simple
recommendations for improving and maintaining your oral health.
You will receive personalized brushing information in the Sonicare
app.
Brush heads
To see what type of brush head you have, check the label at the
bottom of the brush head. The symbol at the bottom of the brush
head indicates that it is a smart brush head, equipped with the
BrushSync technology.
Note: The content of the box may vary based on the model
purchased.
Brush head
name
Premium
Plaque Control Premium White Premium Gum Care
Brush head
label
C3 W3 G3
12 English

Benefit Plaque removal Plaque and
stain removal Healthier gums
To explore our full range of brush heads, go to
www.philips.com/toothbrush-heads for more information.
Using your Philips Sonicare
Brushing instructions
1Push the brush head firmly onto the handle. Wet the bristles and
apply toothpaste.
Note: It is normal to see a slight gap between the brush head and
the handle. This allows the brush head to vibrate properly.
2Place the toothbrush bristles against the teeth at a slight angle (45
degrees), apply light pressure to make the bristles reach the
gumline or slightly beneath the gumline.
Note: Keep the center of the brush head in contact with the teeth
at all times.
3Press the power on/off button to turn on the Philips Sonicare.
45°
13
English

4Apply light pressure to maximize Philips Sonicare’s effectiveness
and let the Philips Sonicare toothbrush do the brushing for you.
Gently move the brush head slowly across the teeth in a small
back and forth motion so the longer bristles reach between your
teeth. Continue this motion throughout the brushing cycle.
Note: Different modes are available (see 'Brushing modes').
5To clean the inside surfaces of the front teeth, tilt the brush handle
semi-upright and make several vertical overlapping brushing
strokes on each tooth.
Note:
- A change in vibration from the handle alerts you when you apply
too much pressure (see 'Pressure sensor').
- Your Philips Sonicare toothbrush is safe to use on braces, dental
modifications and dental restorations (fillings, crowns, veneers)
- Do not use your power toothbrush in the shower.
BrushSync technology
BrushSync technology enables your brush heads to communicate
with your handle using a microchip. The symbol at the bottom of the
14 English

brush head indicates that it is equipped with the BrushSync
technology. This enables the following features:
- Brush head mode pairing
- Brush head replacement reminder
Brushing modes
Your power toothbrush is equipped with 4 different modes: clean,
white+, gum health and deep clean+.
Based on the smart brush head you use, the optimal mode and
intensity will be selected automatically by the BrushSync technology.
To manually change the mode, press the mode/intensity button while
the toothbrush is off with the brush head attached.
* Note:
- All brush heads work with each mode.
- When the Philips Sonicare toothbrush is used in clinical studies, it
must be used at high intensity, with the EasyStart feature turned off.
Brush head mode pairing
Brush heads with BrushSync technology are equipped with a
microchip which communicates to the handle and automatically pairs
it with the recommended mode and intensity.
Note:If you change modes/intensity, the brush head will remember
the last used setting. If you wish to brush with the recommended
setting, you can find the recommended mode/intensity in ‘Brushing
Modes’.
15
English

Brush head mode pairing
Brush heads with BrushSync technology are equipped with a
microchip which communicates to the handle and automatically pairs
it with the recommended mode and intensity.
Note:If you change modes/intensity, the brush head will remember
the last used setting. If you wish to brush with the recommended
setting, you can find the recommended mode/intensity in the
following table.
clean and deep
clean+
white+ gum health
Benefit Plaque removal Plaque and
surface stains
removal
Plaque removal
and gum
massage
Recommended
brush head
Premium
Plaque Control
(C3)
Premium White
(W3) Premium Gum Care (G3)
Recommended
intensity level
3 3 3
Total brushing
time
clean: 2
minutes
deep clean+: 3
minutes*
2 minutes and
40 seconds 3 minutes and 20 seconds
16 English

clean and deep
clean+
white+ gum health
How to brush clean: Brush
each segment
for 20 seconds
1
2
3
4
5
6
deep clean+:
Brush each
segment for 30
seconds*
1
2
3
4
5
6
Brush each
segment for 20
seconds,
1
2
3
4
5
6
then brush
segments 7 and
8 for 20
seconds each.
7
8
Brush each
segment for 20
seconds,
1
2
3
4
5
6
then brush
segments 7, 8,
9 and 10 for 20
seconds each.
7
8
10
9
*Note: When brushing with the Sonicare app in 'deep clean+' mode,
the brushing time will be 2 minutes.
Intensity settings
Your power toothbrush comes with 3 different intensity settings:
- low intensity (one bar)
- medium intensity (two bars)
- high intensity (three bars)
17
English

When attached to the handle, the smart brush head will automatically
select the recommended intensity. To manually change the intensity,
turn on the handle and press the mode/intensity button.
While toothbrush is
ON, press this
button to change
the intensity setting
Features
- BrushPacer
- Pressure sensor
- Brush head replacement reminder
- EasyStart
BrushPacer
The BrushPacer features indicates when you have to move to the
next section of your teeth with a brief change in vibration.
The toothbrush turns off automatically at the end of the brushing
session.
Pressure sensor
Your Philips Sonicare measures the pressure you apply while
brushing to protect your gums and teeth from damage.
If you apply too much pressure, the handle will change its vibration
until you reduce the pressure.
Note: The Pressure Sensor comes activated with your product. To
deactivate this feature, see 'Activating or deactivating features'.
Brush head replacement reminder
Over time, the handle will track the wear of your smart brush head by
measuring:
18 English

- The overall pressure you apply while brushing
- The total time you have brushed with your brush head
Once your brush head is no longer effective, the brush head
replacement reminder will blink amber and the handle will make a
series of beeps and tones.
Note: The brush head replacement reminder comes activated with
your product. To deactivate this feature, see 'Activating or
deactivating features'.
EasyStart
The EasyStart feature gently increases the power of the handle over
the first 14 brushings to help you get used to the brushing power of
the Philips Sonicare.
The EasyStart feature works with all modes.
Note: The EasyStart feature comes deactivated with your product. To
activate EasyStart, see 'Activating or deactivating features'.
Charging and battery status
Charging on charger base
1Plug the cord of the charging base into an electrical outlet.
2Place the charging stand or the charging glass on the charging
base.
19
English

3Place the handle on the charging stand or in the charging glass.
4The charger will charge your toothbrush until it is fully charged.
The handle is charging when the battery indication is blinking white.
When the handle is fully charged, the battery indication illuminates
white for 30 seconds and then turns off.
Note: Your handle comes pre-charged for first use. After first use,
charge for at least 24 hours.
Charging with the travel case*
*Note: The charging travel case may not be included depending on
the model purchased.
1Take the USB cable from the bottom of the charging travel case.
2Connect the charging travel case to 5V DC input power either from:
-The USB adapter provided
-a UL-listed or certified to ANSI/UL 60950-1 personal
computer's standard USB connector or,
-a UL-listed or certified to ANSI/UL 60950-1 LPS power supply
with USB output port or,
20 English
