Philips Sonicare DiamondClean Smart User manual

DiamondClean
Smart
mondClean
ar
t

4
3
5
6
8
11
7
13
9
10
1
2
17
12
13
14
1516

empty page before TOC

English 6
Čeština 25
Eesti 45
Hrvatski 64
Latviešu 84
Lietuviškai 103
Magyar 123
Polski 144
Română 166
Slovenščina 187
Slovensky 206
Srpski 226
Български 244
Русский 266
Українська 287
Қазақша 306

English
6English
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that Philips
offers, register your product at
www.philips.com/welcome or via the Philips Sonicare
app.
Important
Read this user manual carefully before you use the
appliance and save it for future reference.
Danger
- Keep the charger away from water.
- Do not place or store the product where it
can fall or be pulled into a tub or sink.
Warning
- The main cord cannot be replaced. If the
main cord is damaged, discard the charger.
- Always have the charger replaced with one
of the original type in order to avoid a
hazard.
- Do not use the charger outdoors or near
heated surfaces.

7
English
- If the appliance is damaged in any way
(brush head, toothbrush handle or charger),
stop using it. This appliance contains no
serviceable parts. If the appliance is
damaged, contact the Consumer Care
Center in your country (see 'Warranty and
support').
- This appliance can be used by children aged
from 8 years and above and by persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and if they
understand the hazards involved. Children
should not play with the appliance. Cleaning
and user maintenance shall not be made by
children unless they are older than 8 and
supervised.
- In order to effectively charge your Philips
Sonicare handle do not place your charger
base on a magnetic metal surface.
Caution
- Do not clean the brush head, the handle or
the charger in the dishwasher.

8English
- If you have had oral or gum surgery in the
previous 2 months, consult your dentist
before you use the toothbrush.
- Consult your dentist if excessive bleeding
occurs after using this toothbrush or if
bleeding continues to occur after 1 week of
use. Also consult your dentist if you
experience discomfort or pain when you use
the Philips Sonicare.
- The Philips Sonicare toothbrush complies
with the safety standards for
electromagnetic devices. If you have a
pacemaker or other implanted device,
contact your physician or the device
manufacturer of the implanted device prior
to use.
- If you have medical concerns, consult your
doctor before you use the Philips Sonicare.
- This appliance has only been designed for
cleaning teeth, gums and tongue. Do not
use it for any other purpose. Stop using the
appliance and contact your doctor if you
experience any discomfort or pain.

9
English
- The Philips Sonicare toothbrush is a
personal care device and is not intended for
use on multiple patients in a dental practice
or institution.
- Stop using a brush head with crushed or
bent bristles. Replace the brush head every
3 months or sooner if signs of wear appear.
Do not use other brush heads than the ones
recommended by the manufacturer.
- If your toothpaste contains peroxide, baking
soda or bicarbonate (common in whitening
toothpastes), thoroughly clean the brush
head with soap and water after each use.
This prevents possible cracking of the
plastic.
- Do not use other brush heads than the ones
recommended by Philips Sonicare.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
Radio Equipment Directive
Hereby, Philips declares that electric toothbrushes
with radio frequency interface (Bluetooth) are in
compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
www.philips.com/support

10 English
The radio frequency interface in this product operates
at 13.56MHz.
The maximum RF power transmitted by the appliance
is 30.16dBm.
Your Philips Sonicare (Fig. 1)
1 Hygienic travel cap
2 Brush heads
3 Handle
4 Power on/off button
5 Intensity light
6 Mode/intensity button
7 Mode light
8 Brush head replacement reminder light
9 Battery indication
10 Light ring
11 Charging base
12 Travel case
13 Cord storage compartment
14 USB cord (integrated)
15 Charging glass
16 Charging base
17 Brush head holder
Note: The content of the box may vary based on
the model purchased.
Brush heads
Your Philips Sonicare comes with a range of brush
heads which are designed to deliver superior results
for your oral care needs.
The number and type of brush heads might change
according to the toothbrush type you purchased.
1Premium Plaque Defense brush head
2Premium Gum Care brush head
3Premium White brush head
4Tongue Care+ brush head (specific types only)
Smart brush head recognition
Premium Plaque Defense, Premium Gum Care,
Premium White and Tongue Care+ brush heads are

11
English
enabled with smart brush head recognition
technology.
A micro-chip inside the brush head communicates
with the toothbrush handle. So when you attach a
brush head, the handle automatically recognizes the
brush head and selects the recommended mode and
intensity level to optimize your brushing performance.
Thanks to this feature the toothbrush also tracks your
usage and gives a personalized reminder when you
need to replace your brush head for the best oral care
results.
Brushing modes
Your power toothbrush is equipped with 5 different
modes to accommodate all your oral care needs
(some models come with 4 brushing modes only). The
following modes are available:
Clean mode
Clean is a 2-minute mode, recommended to be used
with intensity level 3. It gives you a thorough and
complete clean and is recommended to be used with
the Premium Plaque Defense brush head. In order to
reach optimal results, follow the instructions below.
2
13
64
5
1Begin brushing the upper right teeth (segment 1)
and brush for 20 seconds, on both the outer and
inner surfaces, before you move to the upper front
teeth (segment 2). Continue doing this for
segments 3 to 6 to ensure even brushing in all 6
segments of the mouth. You will hear a beep after
each 20-second interval, to indicate that you
should move to the next segment.
White+ mode
White+ is a 2-minute 40-seconds mode,
recommended to be used with intensity level 3 and
the Premium White brush head. In order to reach
optimal results, follow the instructions below.

12 English
2
13
64
5
1Begin brushing the upper right teeth (segment 1)
and brush for 20 seconds before you move to the
upper front teeth (segment 2). Continue doing this
for segments 3 to 6 to ensure even brushing in all 6
sections of the mouth.
2After completing all 6 of these segments, the
toothbrush switches to polishing mode
automatically.
2
5
3To polish your teeth, brush the outer surface of
your upper teeth for 20 seconds (segment 2) and
then brush the outer surface of your lower teeth
for 20 seconds (segment 5). The polishing motion
used in this part of the mode will feel and sound
different from the first two minutes of the mode.
Gum Health mode
Gum Health is a 3-minute 20-seconds mode,
recommended to be used with intensity level 3 and
the Premium Gum Care brush head. In order to reach
optimal results, follow the instructions below:
2
13
64
5
1Begin brushing the upper right teeth (segment 1)
and brush for 20 seconds, on both the outer and
inner surfaces, before you move to the upper front
teeth (segment 2). Continue doing this for section 3
to 6 to ensure even brushing in all 6 segments of
the mouth.
13
64
2Next, to take optimal care for your gums, brush the
outer and inner surfaces of your upper right back
teeth for 20 seconds (segment 1), then brush the
outer and inner surfaces of your upper left back
teeth for 20 seconds (segment 3).
Continue brushing the outer and inner surfaces of
your lower right back teeth for 20 seconds
(segment 4), followed by another 20 seconds on
the outer and inner surfaces of your lower left back
teeth (segment 6). The brushing motion used in
this part of the mode will feel and sound different
from the first two minutes of the mode.
DeepClean+ mode
DeepClean+ mode length depends on whether or not
the handle is connected to the app. In connected

13
English
mode DeepClean+ runs for two minutes and provides
BrushPacer feedback every 20 seconds. In non-
connected mode DeepClean+ runs for three minutes
and provides BrushPacer feedback every 30 seconds.
In order to reach optimal results, follow the
instructions below when brushing non-connected.
2
13
64
5
- Begin brushing in the upper right teeth (segment 1)
and brush for 30 seconds, on both the outer and
inner surfaces, before you move to the upper front
teeth (segment 2). Continue doing this for
segments 3 to 6 to ensure even brushing in all 6
segments of the mouth.
Tongue Care mode (specific types only)
Tongue Care is a 20-second mode, recommended to
be used with intensity level 1 and the Tongue Care+
brush head. In order to reach optimal results, follow
the instructions below:
20 sec.
1Wet the micro bristles and brush your tongue with
a back and forth motion. Clean as far back as
comfortable.
2Rinse your mouth and repeat the procedure two
more times.
Based on the brush head you attach, the mode will be
selected automatically. If you want to adjust the mode
or intensity manually, you can do this by using the
mode/intensity button. Press the mode/intensity
button before brushing to change the mode, and
press it while brushing to adjust the intensity level.
Your selection will be remembered next time you
attached the same brush head. If you want to go back
to the initial recommended settings for your brush
head, manually change it to the recommended setting
described above.
Note: When the Philips Sonicare is used in clinical
studies, it must be used at high intensity in the Clean
mode, in White+ mode, in GumHealth mode, or in
unconnected DeepClean+ mode to achieve the
efficacy in plaque removal, stain removal, gum health
or superiority (respectively).

14 English
Intensity settings
Your power toothbrush gives you the option to
choose between 3 different intensity levels: low,
medium and high. Based on the brush head you
attach, the intensity will be selected automatically. If
you wish to change to a different intensity, you can do
so by pressing the mode/intensity button while
brushing. For optimal results it is recommended to use
the automatically selected intensity. The intensity
cannot be changed as long as the handle is powered
off or paused.
Using your Philips Sonicare
Brushing instructions
1Attach your desired brush head. Align the brush
head so the bristles point in the same direction as
the front of the handle.
2Wet the bristles.
3Apply a small amount of toothpaste on the bristles.
4Place the toothbrush bristles against the teeth at a
slight angle (45 degrees), pressing firmly to make
the bristles reach the gumline or slightly beneath
the gumline. A change in vibration (and a slight
change in sound) and activation of the light ring
alert you when you apply too much pressure while
brushing.

15
English
Note: Keep the center of the brush in contact with
the teeth at all times.
5Press the power on/off button to switch on the
Philips Sonicare.
6Apply light pressure to maximize Philips Sonicare's
effectiveness. Brush your teeth with a small back
and forth motion so the bristles reach between the
teeth. Continue this motion throughout the
brushing cycle.
Note: The bristles should flare slightly. Do not
scrub.
7To clean the inside surfaces of the front teeth, tilt
the brush handle semi-upright and make several
vertical overlapping brushing strokes on each
tooth.
Your Philips Sonicare is safe to use on:
- Braces (brush heads wear out sooner when used
on braces).
- Dental restorations (fillings, crowns, veneers).
Features and accessories
a App
b Pressure sensor
c Brush head replacement reminder
d BrushPacer
e Easy-start
f Travel case (specific types only)
g Brush head holder (specific types only)
a. App
Your Philips Sonicare is Bluetooth enabled and allows
you to achieve superior oral health care with the
Philips Sonicare app.
Using the Philips Sonicare app will help you to
improve your oral health care habits. It gives you real-

16 English
time feedback while brushing, informs you if you
missed any spots when brushing, tracks your brushing
behavior over time and provides useful tips and tricks
for your healthiest mouth ever. In order to fully benefit
from your Philips Sonicare, we advise you to follow
these steps:
Connecting your toothbrush
1Download the Philips Sonicare app from the Apple
App Store or Google Play Store.
2Confirm Bluetooth is switched on on your mobile
device before you open the app. Check the
settings on your mobile device to switch on
Bluetooth.
3Open the Sonicare app.
4To connect the toothbrush to the app, remove the
handle from the charger and press the
mode/intensity button.
5Follow the Sonicare app instructions displayed on
your mobile device. The app automatically
connects with the toothbrush. If the toothbrush
does not connect, follow the troubleshooting steps
provided in the app.
Note: For optimal data capture, keep your mobile
device close during brushing.
b. Pressure sensor
Your Philips Sonicare is equipped with an advanced
sensor that measures the pressure you apply while
brushing. If you apply too much pressure, the
toothbrush will provide immediate feedback to
indicate that you need to reduce the pressure. The
feedback is given in two different ways:
1You experience a change in vibration and therefore
brushing sensation.
2The pressure warning light of the light ring will light
up purple.
If you receive a warning, reduce the pressure. The light
will turn off and the brushing sensation will adjust to
the original sensation.

17
English
Activating or deactivating the pressure sensor
1Place the handle, with a brush head attached, in
the plugged-in charger.
2Pressure sensor is enabled by holding the
mode/intensity button and by pressing the power
button twice while on a charger. The handle will
beep twice to confirm it is enabled.
3Pressure sensor is disabled by holding the
mode/intensity button and by pressing the power
button twice while on a charger. The handle will
beep once to confirm it is disabled.
c. Brush head replacement reminder
Your Philips Sonicare is equipped with a smart feature
that tracks the wear of your brush head. Depending
on the pressure you apply and the amount of time
used, the brush head replacement reminder light
reminds you to change your brush head. It is
important to change your brush head in time in order
to guarantee the best cleaning & care of your teeth.
When the amber brush head replacement light starts
blinking, you should replace your brush head.
Activating or deactivating the brush head
replacement reminder
1Place the handle in the plugged-in charger.
2Brush head replacement reminder is enabled by
holding the mode/intensity button and by pressing
the power button three times while on the charger.
The handle will beep twice to confirm it is enabled.
3Brush head replacement reminder is disabled by
holding the mode/intensity button and by pressing
the power button three times while on the charger.
The handle will beep once to confirm it is disabled.
d. BrushPacer
2
3 1
64
5
The BrushPacer is an interval timer that has a short
beep and pause to remind you to brush the different
sections of your mouth. Depending on the brushing
mode you have selected (see 'Brushing modes'), the
BrushPacer beeps at different intervals during the
brushing cycle.

18 English
e. Easy-start
The Easy-start feature gently increases the power
over the first 14 brushings to help you get used to the
brushing with the Philips Sonicare. The Easy-start
feature works in all modes other than TongueCare+
mode. This Philips Sonicare model comes with the
Easy-start feature deactivated.
Activating or deactivating the Easy-start feature
1Place the handle in the plugged-in charger.
2Easy-start is enabled by holding the
mode/intensity button and by pressing the power
button once while on the charger. The handle will
beep twice to confirm it is enabled.
3Easy start is disabled by holding the
mode/intensity button and by pressing the power
button once while on the charger. The handle will
beep once to confirm it is disabled.
Note: Using the EasyStart feature beyond the initial
ramp-up period is not recommended and reduces
Philips Sonicare effectiveness in removing plaque.
Note: Each of the first 14 brushings must be at least 1
minute in length to properly move through the Easy-
start ramp-up cycle.
Note: To achieve clinical efficacy, Easy-start needs to
be deactivated.
f. Travel case (specific types only)
Your Philips Sonicare comes with a travel case to
make traveling with your power toothbrush more
convenient. It is designed to accommodate the power
toothbrush handle and two brush heads. Some
models come with a USB charging travel case which
connects to your laptop via USB -this allows you to
charge your Philips Sonicare when traveling. For
information about charging your Philips Sonicare with
the travel case, see 'Battery status and charging'.

19
English
g. Brush head holder (specific types only)
The brush head holder is designed to keep and store
your brush heads.
Battery status and charging
Charging on charger base
1Plug the cord of the charging base into an
electrical outlet.
2Place the charging stand or the charging glass on
the charging base.
3Place the handle on the charging stand or in the
charging glass.
4The charger will charge your toothbrush until it is
fully charged.
The handle is charging when the battery indication is
blinking white. When the handle is fully charged, the
battery indication illuminates white for 30 seconds
and then turns off.
Note: Your handle comes pre-charged for first use.
After first use, charge for at least 24 hours.
Charging with travel case (specific types only)
1Place the handle in the charging travel case.
2Connect the charging travel case to a laptop, a
wall-mounted USB socket or a suitable wall
adapter. The USB cord is attached to the travel
case and stored in the cord storage compartment.
3The battery indication flashes white until your
toothbrush is fully charged.

20 English
Important: The wall adapter must be a safe extra low
voltage source, compatible with the electrical ratings
marked on the device.
Important: Only toothbrush handels HX993W,
HX993B, HX993P, HX993S, HX993L, HX993R,
HX992W, HX992B, HX992P, HX992S, HX992R can be
charged in the travel case. Other products and
batteries are not compatible with the travel case.
Note: It takes at least 24 hours to fully charge your
Philips Sonicare. You do not have to fully charge your
handle before first use, as the handle is pre-charged
for first use. However, it is recommended to fully
charge it after first use.
Note: This charger is designed to properly charge only
one handle at a time. This charger is not compatible
with other models of Philips Sonicare.
Note: Do not place metallic objects in the travel case,
as handle charging may be affected and may cause
the charger to overheat.
Cleaning
Note: Do not clean the brush head, handle or travel
case in the dishwasher.
Toothbrush handle
1Remove the brush head and rinse the metal shaft
area with warm water. Make sure you remove any
residual toothpaste.
Caution: Do not push on the rubber seal on the
metal shaft with sharp objects, as this may cause
damage.
2Wipe the entire surface of the handle with a damp
cloth.
Note: Do not use isopropyl rubbing alcohol, vinegar
or bleach to clean handle as this may cause
discoloration.
