Philips HD9243 User manual

User manual
HD9243

2ENGLISH
TABLE OF CONTENTS
Important 3
Introduction 6
General description 6
Before rst use 8
Preparing for use 8
Using the appliance 8
Food table 8
Airfrying 10
Choosing the keep warm mode 13
Cooking with a preset 14
Changing to another preset 16
Making home-made fries 17
Cleaning 18
Cleaning table 19
Storage 19
Recycling 19
Warranty and support 20
Troubleshooting 20

3ENGLISH
Important
Read this important information carefully before you use the
appliance and save it for future reference.
Danger
-Do not place the appliance on or near a hot gas stove or all
kinds of electric stove and electric cooking plates, or in a
heated oven.
-Never immerse the appliance in water nor rinse it under the
tap.
-Do not let any water or other liquid enter the appliance to
prevent electric shock.
-Always put the ingredients to be fried in the pan, to prevent
them from coming into contact with the heating elements.
-Do not cover the air inlet and the air outlet openings while
the appliance is operating.
-Do not ll the pan with oil as this may cause a re hazard.
-Do not use the appliance, if the plug, the mains cord or the
appliance itself is damaged.
-Never touch the inside of the appliance while it is operating.
-Never put any amount of food that exceeds the maximum
level indicated in the pan.
-Always make sure heater is free and no food stuck in heater.
Warning
-If the supply cord is damaged, it must be replaced by Philips,
its service agent or similarly qualied persons in order to
avoid a hazard.
-Only connect the appliance to an earthed wall socket. Always
make sure that the plug is inserted into the wall socket
properly.
-This appliance is not intended to be operated by means of an
external timer or a separate remote-control system.
-The accessible surfaces may become hot during use.
-This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they are
older than 8 and supervised.
-Keep the appliance and its cord out of the reach of children
less than 8 years.
-Do not place the appliance against a wall or against other
appliances. Leave at least 10 cm free space at the back, on
both sides and above the appliance. Do not place anything
on top of the appliance.

4ENGLISH
-During hot air frying, hot steam is released through the air
outlet openings. Keep your hands and face at a safe distance
from the steam and from the air outlet openings. Also, be
careful of hot steam and air when you remove the pan from
the appliance.
-Never use light ingredients or packing paper in the appliance.
-Accessible surfaces may become hot during use.
-Storage of potatoes: The temperature shall be appropriate
to the potato variety stored and it shall be above 6 °C to
minimize the risk of acrylamide exposure in the prepared
foodstu.
-Never ll the pan with oil.
-This appliance is designed to be used at ambient
temperatures between 5°C and 40°C.
-Check if the voltage indicated on the appliance corresponds
to the local mains voltage before you connect the appliance.
-Keep the mains cord away from hot surfaces.
-Do not place the appliance on or near combustible materials
such as a tablecloth or curtain.
-Do not use the appliance for any other purpose than
described in this manual and use only original Philips-
accessories.
-Do not let the appliance operate unattended.
-The pan and frying insert becomes hot during and after use
of the appliance, always handle carefully.
-Thoroughly clean the parts that come into contact with food
before you use the appliance for the rst time. Refer to the
instructions in the manual.
Caution
-This appliance is intended for normal household use only. It
is not intended for use in environments such as sta kitchens
of shops, oces, farms or other work environments. Nor is
it intended to be used by clients in hotels, motels, bed and
breakfasts and other residential environments.
-Always disconnect the appliance from the supply if it is left
unattended and before you assemble, disassemble, store or
cleaning.
-Place the appliance on a horizontal, even and stable surface.
-If the appliance is used improperly or for professional or
semi-professional purposes or if it is not used according to
the instructions in the user manual, the guarantee becomes
invalid and Philips refuses any liability for damage caused.
-Always return the appliance to a service center authorised
by Philips for examination or repair. Do not attempt to repair
the appliance yourself, otherwise the guarantee becomes
invalid.
-Always unplug the appliance after use.

5ENGLISH
-Let the appliance cool down for approximately 30 minutes
before you handle or clean it.
-Make sure the ingredients prepared in this appliance come
out golden yellow instead of dark or brown. Remove burnt
remnants. Do not fry fresh potatoes at a temperature above
180°C (to minimise the production of acrylamide).
-Be careful when cleaning the upper area of the cooking
chamber: Hot heating element, edge of Metal parts.
-Always make sure that the food is fully cooked in the Airfryer.
-Always make sure that you have the control over your
Airfryer.
-When cooking fatty food, the Airfryer could emit smoke.
Electromagnetic elds (EMF)
This appliance complies with the applicable standards and
regulations regarding electromagnetic elds.
Automatic shut-o
This appliance is equipped with an automatic shut-o function.
If you do not press a button within 20 minutes, the appliance
switches o automatically. To switch o the appliance manually,
press the power On/o button.

6ENGLISH
Introduction
Congratulations on your purchase and welcome to Philips!
To fully benet from the support that Philips oers, register your
product at www.philips.com/welcome.
Philips Airfryer is the only Airfryer with unique Rapid Air
technology to fry your favorite foods with little or no added oil
and up to 90% less fat.
Philips Rapid Air technology cooks food all around as well as our
starsh design for perfect results from your rst bite to your last.
You can now enjoy perfectly cooked fried food—crispy on the
outside tender on the inside—Fry, grill, roast and bake to prepare
a variety of tasty dishes in a healthy, fast and easy way.
For more inspiration, recipes and information about the Airfryer,
visit www.philips.com/kitchen or download the free NutriU
App* for IOS® or Android™.
*The NutriU app may not be available in your country.
In this case please access your local Philips website for inspiration.
General description
1 Control panel
A Temperature up button
B Temperature down button
C Menu button
D Preset menus
E On/O button
F Time down button
G Time up button
H Display screen
2 Frying insert
3 MAX indication for other food
4 MAX indication for frozen fries
5 Pan
6 Power cord
7 Air outlets
8 Air inlet

7ENGLISH
8
6
1
2
5
3
4
H
B
A
C
F
G
E
D
7

8ENGLISH
Before rst use
1 Remove all packing material.
2 Remove any stickers or labels (if available) from the
appliance.
3 Thoroughly clean the appliance before rst use, as
indicated in the cleaning chapter.
Preparing for use
1 Place the appliance on a stable, horizontal, level and heat-
resistant surface.
Note
• Do not put anything on top or on the sides of the appliance. This
could disrupt the airow and aect the frying result.
• Do not place the operating appliance near or underneath objects that
could be damaged by steam, such as walls and cupboard.
Using the appliance
Food table
The table below helps you select the basic settings for the types of
food you want to prepare.
Note
• Keep in mind that these settings are suggestions. As ingredients dier
in origin, size, shape as well as brand, we cannot guarantee the best
setting for your ingredients.
• When preparing larger amount of food (e.g. fries, prawns, drumsticks,
frozen snacks), turn or stir the ingredients in the pan 2 to 3 times in
order to achieve a consistent result.
Ingredients Min.– max.
amount
Time
(min) Temperature Note
Thin frozen fries (7x7
mm/0.3x0.3 in)
200-500g /
7-18 oz
16-22 180°C/350°F • Shake, turn or stir 2-3
times in between
Homemade fries
(10x10 mm/0.4x0.4 in
thick)
200-500g /
7-18 oz
18-26 180°C/350°F • Shake, turn or stir 2-3
times in between
Frozen chicken
nuggets
200-600g /
7-21 oz
10-15 200°C/400°F • Shake, turn or stir
halfway
Frozen spring rolls 200-600g /
7-21 oz
10-15 200°C/400°F • Shake, turn or stir
halfway

9ENGLISH
Ingredients Min.– max.
amount
Time
(min) Temperature Note
Hamburger (around
150 g/5 oz)
1-3 patties 15-20 200°C/400°F
Meat loaf 800 g / 28 oz 50-55 150°C/300°F • Use the baking
accessory
Meat chops without
bone (around 150 g/5
oz)
1-2 chops 11-15 200°C/400°F • Shake, turn or stir
halfway
Thin sausages
(around 50 g/1.8 oz)
1-6 pieces 9-13 200°C/400°F • Shake, turn or stir
halfway
Chicken drumsticks
(around 125 g/4.5 oz)
2-6 pieces 18-24 180°C/350°F • Shake, turn or stir
halfway
Chicken breast
(around 160 g/6 oz)
1-3 pieces 20-25 180°C/350°F
Whole sh (around
300-400 g/11-14 oz)
1 sh 15-20 200°C/400°F
Fish let
(around 200 g/7 oz)
1-3 (1 layer) 25-27 160°C / 325°F
Mixed vegetables
(roughly chopped)
200-600 g/
7-21 oz
10-20 180°C/350°F • Set the cooking time
according to your own
taste
• Shake, turn or stir
halfway
Muns (around 50 g/
1.8oz)
1-7 12-14 160°C/325°F • Use the Mun cups
Cake 500 g/18 oz 50-60 160°C/325°F • Use a cake pan
Pre-baked bread/rolls
(around 60 g/ 2 oz)
1-4 pieces 6-8 200°C/400°F
Homemade bread 500 g / 18 oz 50-60 150°C/300°F • Use the baking
accessory
• The shape should be as
at as possible to avoid
that the bread touches
the heating element
when rising.

10 ENGLISH
Airfrying
Caution
• This is an Airfryer that works on hot air. Do not ll the pan with
oil, frying fat or any other liquid.
• Do not touch hot surfaces. Use handles or knobs. Handle the hot
pan with oven-safe gloves.
• This appliance is for household use only.
• This appliance may produce some smoke when you use it for the
rst time. This is normal.
• Preheating of the appliance is not necessary.
1 Put the plug in the wall outlet.
2 Remove the pan from the appliance by pulling the handle.
3 Put the ingredients in the pan.
Note
• The Airfryer can prepare a large range of ingredients. Consult the
‘Food table’ for the right quantities and approximate cooking times.
• Do not exceed the amount indicated in the ‘Food table’ section or
overll the pan beyond the ‘MAX’ indication as this could aect the
quality of the end result.
• If you want to prepare dierent ingredients at the same time, make
sure you check the suggested cooking time required for the dierent
ingredients before you start to cook them simultaneously.
4 Put the pan back into the Airfryer.
Caution
• Never use the pan without the frying insert in it.
• Do not touch the pan or the frying insert during and for some
time after use, as they get very hot.

11ENGLISH
5 Press the power On/O button to switch on the appliance.
6 Press the temperature up or down button to choose the
needed temperature.
7 Press the time up button to choose the needed time.
8 Press the On/O button to start the cooking process.
Note
• During cooking the temperature and time are shown alternately.
• The last cooking minute counts down in seconds.
• Refer to the food table with basic cooking settings for dierent types
of food.
Tip
• During cooking, if you want to change the cooking time or
temperature, press the corresponding up or down button at any time
to do so.
• To pause the cooking process, press the On/O button. To resume
the cooking process, press the On/O button again to continue the
cooking process.
• The device is automatically in pause mode when you pull out the pan.
The cooking process continues when the pan is put in the appliance
again.
• To change the temperature unit from Celsius to Fahrenheit or the
other way around on your Airfryer, press the temperature up and
down button at the same time for about 10 seconds.

12 ENGLISH
Note
• If you do not set the required cooking time within 30 minutes, the
appliance automatically shuts o for safety reasons.
•Some ingredients require stirring turning halfway through the
cooking time (see ‘Food table’). To stir the ingredients, pull out the
pan and place it on a heat resistant worktop. Use a tongue or another
kitchen utensial to stir or turn the ingredients. Then slide the pan back
into the appliance.
• If you set the timer to the half of the cooking time and you hear the
timer bell it is time to stir or turn the ingredients. Be sure to reset the
timer to the remaining cooking time.
9 When you hear the timer bell, the cooking time has
elapsed.
Note
• You can stop the cooking process manually. To do this, press the On/
O button.
10 Pull out the pan and check if the ingredients are ready.
Caution
• The Airfryer pan is hot after the cooking process. Always place it
on a heat resistant work top (eg. trivet, etc.) when you remove
the pan from the device.
Note
• If the ingredients are not ready yet, simply slide the pan back into the
Airfryer by the handle and add a few extra minutes to the set time.
11 To remove small ingredients (e.g. fries), use a tongue or
another kitchen utensil to get them out of the pan.
Caution
• After the cooking process, the pan, the frying insert, the interior
housing and the ingredients are hot. Depending on the type of
ingredients in the Airfryer, steam may escape from the pan.
12 Empty the pan contents into a bowl or onto a plate. Always
remove food with a kitchen utensil as hot oil may be
collected at the bottom of the pan.

13ENGLISH
Note
• To remove large or fragile ingredients, use a pair of tongs to lift out
the ingredients.
• Excess oil or rendered fat from the ingredients is collected on the
bottom of the pan.
• Depending on the type of ingredients cooking, you may want to
carefully pour o any excess oil or rendered fat from the pan after
each batch. Take out the frying insert and place it on a heat-resistant
surface. Wear oven-safe gloves to pour o excess oil or rendered fat.
Return the frying insert into the pan.
When a batch of ingredients is ready, the Airfryer is instantly ready
for preparing another batch.
Note
• Repeat steps 3 to 12 if you want to prepare another batch.
Choosing the keep warm mode
1 Press the On/O button to turn on the Airfryer.
2 Press the menu button as often as the keep warm icon is
blinking.
3 Press the On/O button to start the keep warm mode.
Note
• The keep warm timer is set to 30 minutes. To change the keep warm
time (1 - 30 minutes), press the time down button. The time will be
conrmed automatically.
• The temperature cannot be changed in keep warm mode.

14 ENGLISH
4 To pause the keep warm mode, press the On/O button.
To resume the keep warm mode, press the On/O button
again.
5 To exit the keep warm mode, long press the On/O button.
Tip
• If food like French fries loses too much crispness during the keep
warm mode, either shorten the keep warm time by switching o the
appliance earlier or crisp them up for 2-3 minutes at the temperature
of 180°C/350°F.
Note
• During the keep warm mode, the fan and heater inside of the
appliance turn on from time to time.
• The keep warm mode is designed to keep your food warm
immediately after it is cooked in the Airfryer. It is not meant for
reheating.
Cooking with a preset
1 Follow steps 1 to 5 in chapter "Airfrying".
2 Press the Menu button. The frozen snacks icon is blinking.
Press the Menu button as often as your needed preset is
blinking.
3 Start the cooking process by pressing the On/O button.
Note
• In the following table you can nd more information about the
presets.

15ENGLISH
Preset Preset time
(min)
Preset
temperature Weight (Max.) Information
Frozenpotato
based snacks
22 180°C/
350°F 500 g/18 oz
• Potato based frozen
snacks like frozen
French fries, potato
wedges, criss-cross
fries etc.
• Shake, turn or stir 2-3
times in between
Fresh fries 26 180°C/
350°F 500 g/18 oz
• Use mealy potatoes
• 10x10mm / 0.4x0.4 in
thick cut
• Soak 30 minutes in
water, dry then add
¼ to 1 tbsp of oil
• Shake, turn or stir 2-3
times in between
Chicken drumsticks
24 180°C/
350°F 750 g/26 oz
• Up to 6 chicken
drumsticks
• Shake, turn or stir in
between
Fish let around
200 g/7 oz
27 160°C /
325°F 600 g/21 oz
Mun
13 160°C /
325°F
50 g/1.8 oz per
mun • 7 muns in one go
Meat chops
13 200°C/
400°F 300 g/11 oz • Up to 2 meat chops
without bone
Mixed vegetables
20 180°C/
350°F 600 g/21 oz
• Roughly chopped
• Use the XL baking
accessory
Keep warm 30 80°C/
175°F N/A • Temperature cannot be adjusted

16 ENGLISH
Changing to another preset
1 During the cooking process, long press the power On/O
button to stop the cooking process. The device is then in
stand-by mode.
2 Press the On/O button again to turn on the device.
3 Press the menu button as often as your needed preset is
blinking.
4 Press the On/O button to start the cooking process.

17ENGLISH
Making home-made fries
To make great home-made fries in the Airfryer:
- Choose a potato variety suitable for making fries, e.g. fresh,
(slightly) oury potatoes.
-It is best to air fry the fries in portions of up to 500g/18oz for
an even result. Larger fries tend to be less crispy than smaller
fries.
1 Peel the potatoes and cut into sticks
(10 x 10 mm/0.4 x 0.4 in thick).
2 Soak the potato sticks in a bowl of water for at least
30minutes.
3 Empty the bowl and dry the potato sticks with a dish towel
or paper towel.
4 Pour one tablespoon of cooking oil into the bowl, put the
sticks in the bowl and mix until the sticks are coated with
oil.
5 Remove the sticks from the bowl with your ngers or a
slotted kitchen utensil so excess oil remains in the bowl.
Note
• Do not tilt the bowl to pour all the sticks in the pan at once to prevent
excess oil from going into the pan.
6 Put the sticks into the pan.
7 Fry the potato sticks and shake the pan 2-3 times during
cooking.

18 ENGLISH
Cleaning
Warning
•Let the frying insert, the pan, and the inside of the appliance cool
down completely before you start cleaning.
• The pan, the frying insert, and the inside of the appliance have a
non-stick coating. Do not use metal kitchen utensils or abrasive
cleaning materials as this may damage the non-stick coating.
Clean the appliance after every use. Remove oil and fat from the
bottom of the pan after every use.
1 Press the power On/O ( ) button to switch o the
appliance, remove the plug from the wall outlet and let the
appliance cool down.
Tip
• Remove the pan and the frying insert to let the Airfryer cool down
more quickly.
2 Dispose of rendered fat or oil from the bottom of the pan.
3 Clean the pan and the frying insert in a dishwasher. You
can also clean them with hot water, dishwashing liquid and
a non-abrasive sponge (see ‘Cleaning table’).
Tip
• If food residues stuck to the pan or the frying insert, you can soak
them in hot water and dishwashing liquid for 10–15 minutes. Soaking
loosens the food residues and makes it easier to remove. Make sure
you use a dishwashing liquid that can dissolve oil and grease. If there
are grease stains on the pan or the frying insert and you have not
been able to remove them with hot water and dishwashing liquid,
use a liquid degreaser.
• If necessary, food residues stuck to the heating element can be
removed with a soft to medium bristle brush. Do not use a steel wire
brush or a hard bristle brush, as this might damage the coating on the
heating element.
4 Wipe the outside of the appliance with a moist cloth.
Note
• Make sure no moisture remains on the control panel. Dry the control
panel with a cloth after you have cleaned it.
5 Clean the heating element with a cleaning brush to remove
any food residues.

19ENGLISH
6 Clean the inside of the appliance with hot water and a
non-abrasive sponge.
Cleaning table
Storage
1 Unplug the appliance and let it cool down.
2 Make sure all parts are clean and dry before storing.
Note
• Always hold the Airfryer horizontally when you carry it. Make sure that
you also hold the pan on the front part of the appliance as the pan
can slide out of the appliance if accidentally tilted downwards. This
can lead to damaging of these parts.
• Always make sure that the removable parts of the Airfryer are xed
before you carry and/or store it.
Recycling
- This symbol means that this product shall not be disposed of
with normal household waste (2012/19/EU).
- Follow your country’s rules for the separate collection of
electrical and electronic products. Correct disposal helps
prevent negative consequences for the environment and
human health.

20 ENGLISH
Warranty and support
Versuni oers a two-year warranty after purchase on this product.
This warranty is not valid if a defect is due to incorrect use or poor
maintenance. Our warranty does not aect your rights under law
as a consumer. For more information or for invoking the warranty,
please visit our website www.philips.com/support.
Troubleshooting
This chapter summarizes the most common problems you
could encounter with the appliance. If you are unable
to solve the problem with the information below, visit
www.philips.com/support for a list of frequently asked
questions or contact the Consumer Care Center in your country.
Problem Possible cause Solution
The outside of the
appliance becomes
hot during use.
The heat inside radiates
to the outside walls.
This is normal. All handles and knobs that
you need to touch during use stay cool
enough to touch.
The pan, the frying insert, and the inside
of the appliance always become hot when
the appliance is switched on to ensure the
food is properly cooked. These parts are
always too hot to touch.
If you leave the appliance switched on
for a longer time, some areas get too hot
to touch. These areas are marked on the
appliance with the following icon:
As long as you are aware of the hot areas
and avoid touching them, the appliance is
completely safe to use.
My home-made
fries do not turn
out as I expected.
You did not use the right
potato type.
To get the best results, use fresh oury
potatoes. If you need to store the
potatoes, do not store them in a cold
environment like in a fridge. Choose
potatoes whose package states that they
are suitable for frying.
The amount of
ingredients in the pan is
too big.
Follow the instructions on page 17 in
this user manual to prepare home-made
fries.
Certain types of
ingredients need to be
shaken halfway through
the cooking time.
Follow the instructions on page 17 in
this user manual to prepare home-made
fries.
