Philips HD9270/96 User manual

User manual
HD927X

2ENGLISH
TABLE OF CONTENTS
Important 3
Introduction 7
General description 7
Before rst use 9
Preparing for use 9
Using the appliance 9
Food table 9
Airfrying 11
Choosing the keep warm mode 14
Cooking with a preset 15
Changing to another preset 17
Making home-made fries 18
Cleaning 18
Cleaning table 20
Storage 20
Recycling 20
Guarantee and support 20
Troubleshooting 20

3ENGLISH
Important
Read this important information carefully before you use the appliance
and save it for future reference.
Danger
- Always put the ingredients to be fried in the
basket, to prevent them from coming into contact
with the heating elements.
- Do not cover the air inlet and the air outlet
openings while the appliance is operating.
- Do not ll the pan with oil as this may cause a re
hazard.
- Never immerse the appliance in water or any other
liquid, nor rinse it under the tap.
- Do not let any water or other liquid enter the
appliance to prevent electric shock.
- Never put any amount of food that exceeds the
maximum level indicated in the basket.
- Never touch the inside of the appliance while it is
operating.
- Always make sure the heater is free and no food is
stuck in heater.
Warning
- Check if the voltage indicated on the appliance
corresponds to the local mains voltage before you
connect the appliance.
- Do not use the appliance if the plug, the mains
cord or the appliance itself is damaged.
- If the mains cord is damaged, you must have it
replaced by Philips, a service centre authorised by
Philips or similarly qualied persons in order to
avoid a hazard.
- This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the

4ENGLISH
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall
not be made by children unless they are older than
8 years and supervised.
- Keep the appliance and its cord out of reach of
children less than 8 years.
- Keep the mains cord away from hot surfaces.
- Only connect the appliance to an earthed wall
socket. Always make sure that the plug is inserted
into the wall socket properly.
- This appliance is not intended to be operated by
means of an external timer or a separate remote-
control system.
- Do not place the appliance against a wall or
against other appliances. Leave at least 10 cm free
space on the back and sides and 10 cm free space
above the appliance. Do not place anything on top
of the appliance.
- Do not use the appliance for any other purpose
than described in the user manual.
- During hot air frying, hot steam is released through
the air outlet openings. Keep your hands and face
at a safe distance from the steam and from the air
outlet openings. Also be careful of hot steam and
air when you remove the pan from the appliance.
- The accessible surfaces may become hot during
use.
- The pan, the basket and accessories inside the
Airfryer become hot during use. Be careful when
you handle them.
- Do not place the appliance on or near a hot gas
stove or all kinds of electric stove and electric
cooking plates, or in a heated oven.
- Never use light ingredients or baking paper in the
appliance.
- Do not place the appliance on or near combustible
materials such as a tablecloth or curtain.

5ENGLISH
- Do not let the appliance operate unattended.
- Immediately unplug the appliance if you see dark
smoke coming out of the appliance. Wait for the
smoke emission to stop before you pull the pan
out of the appliance.
- Storage of potatoes: The temperature shall be
appropriate to the potato variety stored and it shall
be above 6°C to minimize the risk of acrylamide
exposure in the prepared foodstu.
- Do not plug in the appliance or operate the control
panel with wet hands.
- This appliance is designed to be used at ambient
temperatures between 5°C and 40°C.
Caution
- This appliance is intended for normal household
use only. It is not intended for use in environments
such as sta kitchens of shops, oces, farms
or other work environments. Nor is it intended
to be used by clients in hotels, motels, bed and
breakfasts and other residential environments.
- Always return the appliance to a service centre
authorised by Philips for examination or repair.
Do not attempt to repair the appliance yourself,
otherwise the guarantee becomes invalid.
- If the appliance is used improperly or for
professional or semi-professional purposes or if
it is not used according to the instructions in the
user manual, the guarantee becomes invalid and
Philips refuses any liability for damage caused.
- Always place and use the appliance on a dry,
stable, level and horizontal surface.
- Always unplug the appliance after use.
- Let the appliance cool down for approx. 30
minutes before you handle or clean it.
- Make sure the ingredients prepared in this
appliance come out golden-yellow instead of
dark or brown. Remove burnt remnants. Do not fry

6ENGLISH
fresh potatoes at a temperature above 180°C (to
minimise the production of acrylamide).
- Be careful when cleaning the upper area of the
cooking chamber: Hot heating element, edge of
Metal parts.
- Always make sure that the food is fully cooked in
the Airfryer.
- Always make sure that you have the control over
your Airfryer.
- When cooking fatty food, the Airfryer could emit
smoke.
Electromagnetic elds (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding electromagnetic elds.
Automatic shut-o
This appliance is equipped with an automatic shut-o function. If you
do not press a button within 20 minutes, the appliance switches o
automatically. To switch o the appliance manually, press the power On/
o button.

7ENGLISH
Introduction
Congratulations on your purchase and welcome to Philips!
To fully benet from the support that Philips oers, register your product at
www.philips.com/welcome.
Philips Airfryer is the only Airfryer with unique Rapid Air technology to fry
your favorite foods with little or no added oil and up to 90% less fat.
Philips Rapid Air technology cooks food all around as well as our starsh
design for perfect results from your rst bite to your last.
You can now enjoy perfectly cooked fried food—crispy on the outside
tender on the inside—Fry, grill, roast and bake to prepare a variety of tasty
dishes in a healthy, fast and easy way.
For more inspiration, recipes and information about the Airfryer, visit
www.philips.com/kitchen or download the free NutriU App* for IOS® or
Android™.
*The NutriU app may not be available in your country.
In this case please access your local Philips website for inspiration.
General description
1 Control panel
A Temperature up button
B Temperature down button
C Menu button
D Preset menus
E On/O button
F Time down button
G Time up button
H Time indication
I Screen
J Temperature indication
2 MAX indication
3 Basket
4 Basket release button
5 Pan
6 Power cord
7 Air outlets
8 Air inlet

8ENGLISH
1
J HI
B
A
C
G
F
E
D
2
4
3
5
8
7
6

9ENGLISH
Before rst use
1 Remove all packing material.
2 Remove any stickers or labels (if available) from the appliance.
3 Thoroughly clean the appliance before rst use, as indicated in the
cleaning chapter.
Preparing for use
1 Place the appliance on a stable, horizontal, level and heat-resistant
surface.
Note
• Do not put anything on top or on the sides of the appliance. This could disrupt
the airow and aect the frying result.
• Do not place the operating appliance near or underneath objects that could be
damaged by steam, such as walls and cupboard.
• Leave the rubber plug in the pan. Do not remove it before cooking.
Using the appliance
Food table
The table below helps you select the basic settings for the types of food
you want to prepare.
Note
• Keep in mind that these settings are suggestions. As ingredients dier in origin,
size, shape as well as brand, we cannot guarantee the best setting for your
ingredients.
• When preparing larger amount of food (e.g. fries, prawns, drumsticks, frozen
snacks), shake, turn, or stir the ingredients in the basket 2 to 3 times in order to
achieve a consistent result.
Ingredients Min.– max.
amount
Time
(min) Temperature Note
Thin frozen fries (7x7
mm/0.3x0.3 in)
200-800 g /
7-28 oz
14-31 180°C/350°F • Shake, turn or stir 2-3
times in between
Homemade fries (10x10
mm/0.4x0.4 in thick)
200-800 g /
7-28 oz
20-40 180°C/350°F • Shake, turn or stir 2-3
times in between
Frozen chicken nuggets 200-600 g/
7-21 oz
9-20 200°C/400°F • Shake, turn or stir halfway
Frozen spring rolls 200-600 g/
7-21 oz
9-20 200°C/400°F • Shake, turn or stir halfway

10 ENGLISH
Ingredients Min.– max.
amount
Time
(min) Temperature Note
Hamburger (around 150
g/5 oz)
1-5 patties 16-21 200°C/400°F
Meat loaf 1200 g / 42 oz 55-60 150°C/300°F • Use the baking accessory
Meat chops without bone
(around 150 g/5 oz)
1-4 chops 15-20 200°C/400°F • Shake, turn or stir halfway
Thin sausages (around 50
g/1.8 oz)
2-10 pieces 11-15 200°C/400°F • Shake, turn or stir halfway
Chicken drumsticks
(around 125 g/4.5 oz)
2-8 pieces 17-27 180°C/350°F • Shake, turn or stir halfway
Chicken breast (around
160 g/6 oz)
1-5 pieces 15-25 180°C/350°F
Whole chicken 1200 g/42 oz 60-70 180°C/350°F
Whole sh (around 300-
400 g/11-14 oz)
1-2 sh 20-25 200°C/400°F
Fish let (around 200
g/7 oz)
1-5 (1 layer) 25-32 160°C / 325°F
Mixed vegetables
(roughly chopped)
200-800 g/7-
28 oz
9-18 180°C/350°F • Set the cooking time
according to your own
taste
• Shake, turn or stir halfway
Muns (around 50 g/1.8
oz)
1-9 13-15 180°C/350°F • Use the Mun cups
Cake 500 g/18 oz 40-45 160°C/325°F • Use a cake pan
Pre-baked bread/rolls
(around 60 g/ 2 oz)
1-6 pieces 6-8 200°C/400°F
Homemade bread 800 g / 28 oz 55-65 150°C/300°F • Use the baking accessory
• The shape should be as
at as possible to avoid
that the bread touches
the heating element when
rising.

11ENGLISH
Airfrying
Caution
• This is an Airfryer that works on hot air. Do not ll the pan with oil, frying fat
or any other liquid.
• Do not touch hot surfaces. Use handles or knobs. Handle the hot pan with
oven-safe gloves.
• This appliance is for household use only.
• This appliance may produce some smoke when you use it for the rst time.
This is normal.
• Preheating of the appliance is not necessary.
1 Put the plug in the wall outlet.
2 Remove the pan with the basket from the appliance by pulling the
handle.
3 Put the ingredients in the basket.
Note
• The Airfryer can prepare a large range of ingredients. Consult the ‘Food table’
for the right quantities and approximate cooking times.
• Do not exceed the amount indicated in the ‘Food table’ section or overll the
basket beyond the ‘MAX’ indication as this could aect the quality of the end
result.
• If you want to prepare dierent ingredients at the same time, make sure you
check the suggested cooking time required for the dierent ingredients before
you start to cook them simultaneously.

12 ENGLISH
4 Put the pan with the basket back into the Airfryer.
Caution
• Never use the pan without the basket in it.
• Do not touch the pan or the basket during and for some time after use, as
they get very hot.
5 Press the power On/O button to switch on the appliance.
6 Press the temperature up or down button to choose the needed
temperature.
7 Press the time up button to choose the needed time.
8 Press the On/O button to start the cooking process.
Note
• During cooking the temperature and time are shown alternately.
• The last cooking minute counts down in seconds.
• Refer to the food table with basic cooking settings for dierent types of food.

13ENGLISH
Tip
• During cooking, if you want to change the cooking time or temperature, press
the corresponding up or down button at any time to do so.
• To pause the cooking process, press the On/O button. To resume the cooking
process, press the On/O button again to continue the cooking process.
• The device is automatically in pause mode when you pull out the pan and the
basket. The cooking process continues when the pan and the basket are put in
the appliance again.
• To change the temperature unit from Celsius to Fahrenheit or the other way
around on your Airfryer, press the temperature up and down button at the
same time for about 10 seconds.
Note
• If you do not set the required cooking time within 30 minutes, the appliance
automatically shuts o for safety reasons.
•Some ingredients require shaking or turning halfway through the cooking time
(see ‘Food table’). To shake the ingredients, pull out the pan with the basket,
place it on a heat resistant work top, slide the lid and press the basket release
button to remove the basket and shake the basket over the sink. Then put the
basket into the pan, and slide them back into the appliance.
• If you set the timer to the half of the cooking time and you hear the timer bell
it is time to shake or turn the ingredients. Be sure to reset the timer to the
remaining cooking time.
9 When you hear the timer bell, the cooking time has elapsed.
Note
• You can stop the cooking process manually. To do this, press the On/O
button.
10 Pull out the pan and check if the ingredients are ready.
Caution
• The Airfryer pan is hot after the cooking process. Always place it on a heat
resistant work top (eg. trivet, etc.) when you remove the pan from the device.
Note
• If the ingredients are not ready yet, simply slide the pan back into the Airfryer
by the handle and add a few extra minutes to the set time.

14 ENGLISH
11 To remove small ingredients (e.g. fries), lift the basket out of the pan
by sliding the lid rst, and then pressing the basket release button.
Caution
• After the cooking process, the pan, the basket, the interior housing and the
ingredients are hot. Depending on the type of ingredients in the Airfryer,
steam may escape from the pan.
12 Empty the basket contents into a bowl or onto a plate. Always remove
the basket from the pan to empty contents as hot oil may be in the
bottom of the pan.
Note
• To remove large or fragile ingredients, use a pair of tongs to lift out the
ingredients.
• Excess oil or rendered fat from the ingredients is collected on the bottom of
the pan.
• Depending on the type of ingredients cooking, you may want to carefully pour
o any excess oil or rendered fat from the pan after each batch or before
shaking or replacing the basket in the pan. Place the basket on a heat-resistant
surface. Wear oven-safe gloves to pour o excess oil or rendered fat. Return
the basket into the pan.
When a batch of ingredients is ready, the Airfryer is instantly ready for
preparing another batch.
Note
• Repeat steps 3 to 12 if you want to prepare another batch.
Choosing the keep warm mode
1 Press the menu button as often as the keep warm icon is blinking.
2 Press the On/O button to start the keep warm mode.
Note
• The keep warm timer is set to 30 minutes. To change the keep warm time
(1 - 30 minutes), press the time down button. The time will be conrmed
automatically.
• The temperature cannot be changed in keep warm mode.

15ENGLISH
3 To pause the keep warm mode, press the On/O button. To resume
the keep warm mode, press the On/O button again.
4 To exit the keep warm mode, long press the On/O button.
Tip
• If food like French fries loses too much crispness during the keep warm mode,
either shorten the keep warm time by switching o the appliance earlier or
crisp them up for 2-3 minutes at the temperature of 180°C/350°F.
Note
• During the keep warm mode, the fan and heater inside of the appliance turn
on from time to time.
• The keep warm mode is designed to keep your food warm immediately after it
is cooked in the Airfryer. It is not meant for reheating.
Cooking with a preset
1 Follow steps 1 to 5 in chapter "Airfrying".
2 Press the Menu button. The frozen snacks icon is blinking. Press the
Menu button as often as your needed preset is blinking.
3 Start the cooking process by pressing the On/O button.
Note
• In the following table you can nd more information about the presets.
Preset Preset time
(min)
Preset
temperature Weight (Max.) Information
Frozen potato based
snacks
31 180°C/
350°F 800 g/28 oz
• Potato based frozen
snacks like frozen
French fries, potato
wedges, criss-cross fries
etc.
• Shake, turn or stir 2-3
times in between

16 ENGLISH
Preset Preset time
(min)
Preset
temperature Weight (Max.) Information
Fresh fries 38 180°C/
350°F 800 g/28 oz
• Use mealy potatoes
• 10x10mm / 0.4x0.4 in
thick cut
• Soak 30 minutes in
water, dry then add ¼ to
1 tbsp of oil
• Shake, turn or stir 2-3
times in between
Chicken drumsticks
27 180°C/
350°F 1000 g/35 oz
• Up to 8 chicken
drumsticks
• Shake, turn or stir in
between
Whole sh around
300 g/11 oz
20 200°C/
400°F 600 g/21 oz
Cake 45 160°C/
325°F 500 g/18 oz
• Use the XL baking
accessory (199 x 189 x
80 mm)
Meat chops
20 200°C/
400°F 600 g/21 oz • Up to 4 meat chops
without bone
Mixed vegetables
18 180°C/
350°F 800 g/28 oz
• Roughly chopped
• Use the XL baking
accessory
Keep warm
30 80°C/
175°F N/A • Temperature cannot be
adjusted

17ENGLISH
Changing to another preset
1 During the cooking process long press the power On/O button to
stop the cooking process. The device is then in stand-by mode.
2 Press the On/O button again to turn on the device.
3 Press the menu button as often as your needed preset is blinking.
4 Press the On/O button to start the cooking process.

18 ENGLISH
Making home-made fries
To make great home-made fries in the Airfryer:
- Choose a potato variety suitable for making fries, e.g. fresh, (slightly)
oury potatoes.
- It is best to air fry the fries in portions of up to 800 g/28 oz for an even
result. Larger fries tend to be less crispy than smaller fries.
1 Peel the potatoes and cut into sticks (10 x 10 mm/0.4 x 0.4 in thick).
2 Soak the potato sticks in a bowl of water for at least 30 minutes.
3 Empty the bowl and dry the potato sticks with a dish towel or paper
towel.
4 Pour one tablespoon of cooking oil into the bowl, put the sticks in the
bowl and mix until the sticks are coated with oil.
5 Remove the sticks from the bowl with your ngers or a slotted kitchen
utensil so excess oil remains in the bowl.
Note
• Do not tilt the bowl to pour all the sticks in the basket at once to prevent
excess oil from going into the pan.
6 Put the sticks into the basket.
7 Fry the potato sticks and shake the basket 2-3 times during cooking.
Cleaning
Warning
• Let the basket, the pan, and the inside of the appliance cool down
completely before you start cleaning.
• The pan, the basket, and the inside of the appliance have a non-stick
coating. Do not use metal kitchen utensils or abrasive cleaning materials as
this may damage the non-stick coating.
Clean the appliance after every use. Remove oil and fat from the bottom of
the pan after every use.
1 Press the power On/O ( ) button to switch o the appliance,
remove the plug from the wall outlet and let the appliance cool down.
Tip
• Remove the pan and the basket to let the Airfryer cool down more quickly.
2 Dispose of rendered fat or oil from the bottom of the pan.
3 Clean the pan and the basket in a dishwasher. You can also clean
them with hot water, dishwashing liquid and a non-abrasive sponge
(see ‘Cleaning table’).

19ENGLISH
Note
• Put the pan with the rubber plug in the dishwasher. Do not remove the rubber
plug before cleaning.
Tip
• If food residues stuck to the pan or the basket, you can soak them in hot water
and dishwashing liquid for 10–15 minutes. Soaking loosens the food residues
and makes it easier to remove. Make sure you use a dishwashing liquid that
can dissolve oil and grease. If there are grease stains on the pan or the basket
and you have not been able to remove them with hot water and dishwashing
liquid, use a liquid degreaser.
• If necessary, food residues stuck to the heating element can be removed with
a soft to medium bristle brush. Do not use a steel wire brush or a hard bristle
brush, as this might damage the coating on the heating element.
4 Wipe the outside of the appliance with a moist cloth.
Note
• Make sure no moisture remains on the control panel. Dry the control panel with
a cloth after you have cleaned it.
5 Clean the heating element with a cleaning brush to remove any food
residues.
6 Clean the inside of the appliance with hot water and a non-abrasive
sponge.

20 ENGLISH
Cleaning table
Storage
1 Unplug the appliance and let it cool down.
2 Make sure all parts are clean and dry before storing.
Note
• Always hold the Airfryer horizontally when you carry it. Make sure that you also
hold the pan on the front part of the appliance as the pan with the basket can
slide out of the appliance if accidentally tilted downwards. This can lead to
damaging of these parts.
• Always make sure that the removable parts of the Airfryer are xed before you
carry and/or store it.
Recycling
- This symbol means that this product shall not be disposed of with
normal household waste (2012/19/EU).
- Follow your country’s rules for the separate collection of electrical and
electronic products. Correct disposal helps prevent negative
consequences for the environment and human health.
Guarantee and support
If you need information or support, please visit www.philips.com/support
or read the separate worldwide guarantee leaet.
Troubleshooting
This chapter summarizes the most common problems you could encounter
with the appliance. If you are unable to solve the problem with the
