Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
ServiceManual
Philips Consumer Lifestyle
Hair clipper
HC3410
14/12
PRODUCT INFORMATION
General:
• Corded use only
• World wide automatic voltage selection 100 - 240 Volt
• Dry use only
• Only the cutter is washable
Safety information
• This product meets the requirements regarding
interference suppression on radio and TV.
• After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
Place of production date
YYWW
TECHNICAL INFORMATION
• Voltage : 100 - 240 Volt
• Cutter needs no oil
• Cutter with : 41 mm
• Number of length settings : 13
• Length setting : 1 - 23 mm
• Precision (size of steps) : 2 mm
• Celecting by : Push button
• Without comb : 0,5 mm
• Self-shapening stainless steel blades
REPAIR INSTRUCTION
• No specific issues
OPTIONAL (accessories)
• No specific issues

HC3410
DISASSEMBLY- AND RE-ASSEMBLY ADVICE
To remove the Cutter assy:
1. Remove comb from the clipper
2. Push button for opening cutter
1
2
3. Clean the cutter/chamber with a brush
To place the Cutter assy:
1. Place nocks in front off clipper
2. Push on back to replace the cutter correctly

HC3410
1
3
5
7
9
11
13
15
17
19
21
23
5
1 2
3
4
EXPLODED VIEW & PARTS LIST
Pos Service code Description
1 4222 036 23991 Cutter assy
24222 036 24011 Beard comb
34222 036 24001 Adjustable comb
4 4222 036 30171 Power plug GB
4 4222 036 30181 Power plug EU
Pos Service code Description
4 4222 036 24051 Power plug BR
4 4222 036 24061 Power plug ARG
4 4222 036 24071 Power plug JP/MEX/PAN
5 4222 036 02770 Brush
= changed
