Compact Fluorescent Energy Saver Reflector Floods & Dimmable Reflector Floods
Ordering, Electrical and Technical Data
Approx.
Color Approx. Rated Min. Max.
Product Nom.
Incand.
T
emp. Initial MOL Diam. Avg.Life Starting Ambient
Number Description olts Watts Equiv. Base (Kelvin) CRI Lumens1(In.) (In.) (Hrs.)2T
emp. Temp.
15701-6 Reflector Flood EL/A R20 120 14 50R20 ed. 2700 82 500 4 3⁄82.5 8000 -4°F/-20°C 122°F/50°C
15703-2 Reflector Flood EL/A R30 120 15 65BR30 ed. 2700 82 750 5 3⁄43.7 8000 -4°F/-20°C 122°F/50°C
13707-5 Reflector Flood EL/A R30 Dimmable 120 16 65BR30 ed. 2700 82 630 5 13⁄32 3.7 8000 -4°F/-20°C 122°F/50°C
15702-4 Reflector Flood EL/A R40 120 23 85BR40 ed. 2700 82 1250 6 1⁄24.7 8000 -4°F/-20°C 122°F/50°C
13708-3 Reflector Flood EL/A R40 Dimmable 120 20 85BR40 ed. 2700 82 900 6 3⁄32 4.7 8000 -4°F/-20°C 122°F/50°C
15715-6 Reflector Flood EL/A PAR38 120 23 85PAR38 ed. 2700 82 1250 6 1⁄24.7 8000 -4°F/-20°C 122°F/50°C
14644-9 Reflector Flood EL/A PAR38 Dimmable 120 20 75PAR38 ed. 2700 82 850 6 3⁄324.7 8000 -4°F/-20°C 122°F/50°C
15716-4 Reflector Flood EL/A PAR38 Outdoor 120 23 85PAR38 ed. 2700 82 1300 4 1⁄24.7 8000 -4°F/-20°C 122°F/50°C
Shipping Data
Outer Case Case SKUs
Product SKU UPC Bar Code Case Weight Cube Pallet Per Layers SKU Dimensions Case Dimensions Pallet Dimensions
Number (0-46677) (5-00-46677) Qty. (lbs.) (cu. ft.) Qty. Layer High (W x D x H)(In.) (W x D x H)(In.) (W x D x H)(In.)
15701-6 15701-2 15701-7 6 6.0 0.178 1554 222 7 2.6 x 2.6 x 5.4 5.9 x 8.5 x 6.1 40.0 x 46.9 x 43.0
15703-2 15703-6 15703-1 6 1.95 0.487 450 90 5 4.2 x 4.2 x 5.9 9.0 x 13.3 x 7.1 39.8 x 45.0 x 35.3
13707-5 13707-6 13707-1 6 1.5 0.400 840 120 7 3.8 x 3.8 x 6.2 8.1 x 12.1 x 7.0 40.3 x 48.5 x 49.0
15702-4 15702-9 15702-4 6 2.60 0.889 216 54 4 5.4 x 5.4 x 7.0 11.4 x 16.8 x 8.1 39.5 x 44.9 x 32.2
13708-3 13708-3 13708-8 6 2.14 0.551 546 78 7 4.8 x 4.8 x 6.0 9.9 x 14.7 x 6.6 39.3 x 49.8 x 45.9
15715-6 15715-9 15715-4 6 3.20 0.889 216 54 4 5.4 x 5.4 x 7.0 11.4 x 16.8 x 8.1 39.5 x 44.9 x 32.2
14644-9 14644-3 14644-8 6 2.52 0.551 504 72 7 4.8 x 4.8 x 6.0 9.9 x 14.7 x 6.6 39.5 x 44.1 x 45.9
15716-4 15716-6 15716-1 6 3.20 0.560 432 72 6 4.5 x 4.5 x 5.9 9.9 x 14.6 x 6.7 39.8 x 43.7 x 40.1
1) Approximate initial lumens.The lamp lumen output is based upon lamp performance after 100 hours of operating life under standard laboratory conditions.
2) Average life under specified test conditions with lamps turned off and restarted no more frequently than once every 3 operating hours. Use in recessed cans or enclosed
indoor fixtures could result in reduced lamp life.
AmalgamTechnology provides stable light output from -4˚F to 122˚F.
ENERGY STAR®Bulb:As an ENERGY STAR®Partner, Philips has determined that this product meets the ENERGY STAR®guidelines for energy efficiency.
Do not use with dimmers.
Above specifications subject to change without notice.
WARNINGS & CAUTIONS: Some electronic timer and photosensor switches contain dimming circuitry, so before using such a switch, check with its manufacturer to ensure
compatibility with electronic CFL bulbs. Do not use with emergency exit fixtures or lights. Outdoor use requires a weather-protected fixture.Turn off power before changing bulb.
This device complies with Part 18 of the FCC Rules.
Reliable operating temperature range –4F/-20C to 122F/50C.
Note: This product may cause interference with radios, televisions, telephones, or remote controls. If interference occurs, move this product away from device or plug into another outlet.
© 2008 Philips Lighting Company. All rights reserved.
Printed in USA 1/08
P-8516-C
www. philips.com
Philips Lighting Company
200 Franklin Square Drive
P.O. Box 6800
Somerset, NJ 08875-6800
1-800-555-0050
A Division of Philips Electronics North America Corporation
Philips Lighting
281 Hillmount Road
arkham, Ontario
Canada L6C 2S3
1-800-555-0050
A Division of Philips Electronics Ltd.
Printed on chlorine free paper from Sappi Fine Paper mills, who are accredited with E AS environmental certification.
Sappi claims that the pulp used in the manufacture of agno Dull paper is derived from environmentally certified forests.
Bulb Type Table/Floor Outdoor Wall Surface Reading Border Recessed Open Vanity Ceiling
Lamp Postlight Sconce ount Lamp Lights Fixture Hanging Strip Fan
Decorative Twister ●●● ●
Universal ●● ● ●● ● ● ●
3-Way ●
Reflector Flood ●●
Dimmable Reflector Flood ●●
Candle ●● ● ●
Vanity & Decor Globe ●●●
Soft White Plus ●● ● ● ● ● ●
Outdoor ●●
Bug-A-Way ●
Circline ●
Genie ●● ● ●● ● ● ●●●
◆
◆
◆
◆
◆
◆
