Philips DST5010/10 User manual

Published by Philips Consumer Lifestyle Page 1of 14 For internal use only
Document No. : CSW-07-081-20617
Steam Iron
DST5010/10
DST5020/20
DST5020/21
DST5020/30
DST5021/20
DST5030/26
DST5030/30
DST5030/80
DST5031/30
DST5040/80
GC 4541
DST5040/86
DST5041/30
GC 4564

Published by Philips Consumer Lifestyle Page 2of 14 For internal use only
Document No. : CSW-07-081-20617
Contents
Page
1. Important Repair Instructions 3
2. Product Information
- Functions/ Features Information 4
- Product Matrix 5
3. Troubleshooting Guide 7
4. Disassembly and Reassembly Instructions 8
5. Service Lists 12
6. Revision History 14

Published by Philips Consumer Lifestyle Page 3of 14 For internal use only
Document No. : CSW-07-081-20617
Important Repair Instructions
1. Only skilled personnel should carry out the repair.
2. Verification test to carry out as follows, to determine the problem:
a. Ensure product are properly assembled
b. Power on
c. Water Tank to be filled up to Maximum level
3. Refer to Troubleshooting guide for part repair/ replacement
4. After repaired, the appliance must function properly, following test to be carried out:
a. Power-on check
Powered ON with socket equipped with Residual Current Circuit Breaker (RCCB) or Earth Leakage Circuit
Breaker (ELCB) to ensure no electrical hazard risk to end consumer.
b. Soleplate temperature
Check the soleplate temperature is within IEC temperature.
Measure the temperature of the Soleplate after the iron has reached steady state i.e connected to the mains for
at least 15 minutes. The table below shows the temperature requirement.
Soleplate temperature (Deg C)
Minimum
Maximum
160
230
c. Water leakage
Check that there is no water leakage from any part of product during operation.
d. Functionality
Check the functionality of the product:
- Steaming & ASO (for ASO version only) is working properly.
- Buttons/ Knobs: no sluggish, jammed and loose.
- Filling Door: able to open freely and close with “click” sound
- Thermostat Dial: able to turn clockwise & anticlockwise without jammed and loose.
e. Loose part
Check that there are no loose parts such as extra screws in the product that can cause short circuit or product
malfunction.

Published by Philips Consumer Lifestyle Page 4of 14 For internal use only
Document No. : CSW-07-081-20617
Product Information
Functions/ Features information
Easy to use
Water Advice
Drip stop system
In case you live in an area with hard water,
Tap water suitable
(eg: water hardness more than 8dGH), it is
Safety Auto Shut Off (for ASO version only)
Recommended to use a mixture of 50% tap water
Robust heel rest
And 50% demineralized water.
Extra large filling hole
Water Tank Capacity: 320ml
SteamGlide Plus Soleplate
Steam Glide Plus Soleplate with its advanced
Fast crease removal
titanum layer and 6 layer coating delivers ultimate
SteamGlide Plus
gliding performance over any fabric. Non-stick,
Power: 2400W ~ 2600W
scratch resistant and easy to keep clean.
Continuous steam output: 40g ~ 45 g/min
Steam boost: 160g ~ 200g
Vertical Steam
Spray feature
This features a steam boost in vertical position to
Vertical Steam
remove wrinkles in hanging garments
Drip Stop
Steam boost
The Water Tank Bottom has a Valve that is
The steam boost helps to remove stubborn wrinkles.
Controlled by a bimetal disc on the Soleplate.
Water is only released into Steam Chamber via
Product size & weight
the Tank Valve when the Soleplate temperature
Product dimension (W x H x L)
Is high enough. When the Soleplate temperature
147 x 127 x 312 mm
is too low, the Tank Valve is closed. This prevent
Weight of Iron: 1.552Kg
water from dripping onto garment.

Published by Philips Consumer Lifestyle Page 5of 14 For internal use only
Document No. : CSW-07-081-20617
Product Information
Product Matrix
CTN
DST5010/10
DST5020/20
DST5020/21
*DST5020/26
DST5020/30
DST5021/20
DST5030/26
Power (W)
2400
2400
2400
2400
2400
Colour
Grey-white
Blue
Purple-pink
Pastel blue-white
Blue
Steam Output (g/min)
40
40
40
40
45
Steam Boost (g)
160
180
180
180
180
Auto Shut-Off
No
No
No
No
Yes
Ready Light Indicator
Yes
Yes
Yes
Yes
Yes
ECO Setting
Yes
Yes
Yes
Yes
Yes
Calc Solution
Calc Clean
Calc Clean
Calc Clean
Calc Clean
Calc Clean
Cord Length (m)
2.0
2.0
*2.5
2.0
2.0
2.5
Accessory / Gift included
No
No
No
No
No

Published by Philips Consumer Lifestyle Page 6of 14 For internal use only
Document No. : CSW-07-081-20617
Product Information
Product Matrix
CTN
DST5030/30
DST5031/30
DST5030/80
DST5040/80
DST5040/86
DST5041/30
Power (W)
2400
2400
2600
2600
Colour
Purple-pink
Purple-black
Black
Purple-black
Steam Output (g/min)
45
45
45
45
Steam Boost (g)
180
180
200
200
Auto Shut-Off
Yes
Yes
Yes
Yes
Ready Light Indicator
Yes
Yes
Yes
Yes
ECO Setting
Yes
Yes
Yes
Yes
Calc Solution
Calc Clean
Calc Clean
Calc Clean
Calc Clean
Cord Length (m)
2.0
2.0
2.0
2.0
Accessory / Gift
included
No
No
No
No

Published by Philips Consumer Lifestyle Page 7of 14 For internal use only
Document No. : CSW-07-081-20617
Troubleshooting Guide
Problem
Possible root cause
Solution
No heating/ No power
Soleplate
Replace Soleplate Mtd Assy with Cover and
replace Mainscord, apply Heat Sink Paste to Live &
Neutral wire.
Mainscord
Replace Mainscord, apply Heat Sink Paste to Live &
Neutral wire.
ASO (for ASO version)
Replace ASO
Water leaking
Water Tank Assy
Replace Water Tank Assy
Soleplate
Replace Soleplate Mtd Assy with Cover and
replace Mainscord, apply Heat Sink Paste to Live &
Neutral wire.
Filling Door jammed/ can not
close or open/ bounce up
Inlay Assy
Replace Inlay Assy
No Steam
Soleplate
Replace Soleplate Mtd Assy with Cover and
replace Mainscord, apply Heat Sink Paste to Live &
Neutral wire.
No spray
Water Tank Assy
Spray Knob
Replace Water Tank Assy
Replace Spray Knob
No SOS
Soleplate
Water Tank Assy
SOS Knob
Replace Soleplate Mtd Assy with Cover and
replace Mainscord, apply Heat Sink Paste to Live &
Neutral wire.
Replace Water Tank Assy
Replace SOS Knob
Backplate damaged/ cracked
Backplate Assy
Replace Backplate Assy & Mainscord, apply Heat Sink
Paste to Live & Neutral wire.
T’stat Dial tight/ loose
T’stat Dial
Bullet Molded
Bullet Spring
Replace T’stat Dial
Replace Bullet Molded
Replace Bullet Spring
Not lighting up
Lamp Assy
Replace Lamp Assy
Part damaged, broken, short
molding, cosmetic defect &
sharp edges
Tank Top Seal
SOS Knob
Spray Knob
Backplate
Ball Swivel
T’stat Dial
Bullet Molded
Bullet Spring
Replace Tank Top Seal
Replace SOS Knob
Replace Spray Knob
Replace Backplate
Replace Ball Swivel
Replace T’stat Dial
Replace Bullet Molded
Replace Bullet Spring

Published by Philips Consumer Lifestyle Page 8of 14 For internal use only
Document No. : CSW-07-081-20617
Disassembly Instructions
Before dismantling :
Ensure the plug is disconnected from the mains and Soleplate is not hot.
1
Remove Screw A
2
Remove Backplate 10
3
Remove 2x Screw B & Clamping Plate
4
Remove Lamp Assy 2 & disconect all wires
5
Remove SOS Knob 7 & Spray Knob 8
6
Open up Filling Door, remove Screw C
7
Remove Inlay Assy 9
8
Remove Tank Top Seal 3 &
ASO 6 (ASO version)

Published by Philips Consumer Lifestyle Page 9of 14 For internal use only
Document No. : CSW-07-081-20617
9
Remove T’stat Dial Prted 12
10
Remove Bullet Molded 13 & Spring Bullet 14
11
Remove 2x Screw D
12
Remove Water Tank Assy 4
13
Remove T’stat Bush &
Soleplate Mtd Assy with Cover 1
14
Remove Mainscord 15 & Ball Swivel 11

Published by Philips Consumer Lifestyle Page 10 of 14 For internal use only
Document No. : CSW-07-081-20617
Reassembly Instructions
Cautions:
a. Before fastening screw, relocate the screw with first thread. Once done fasten the screw.
b. Do not drop, hit or knock the ASO (for ASO version only).
c. Ensure there is click sound after Connector to Terminal engage. Refer to wiring diagram for detail.
d. Take note of live part (red & blue wire) must apply with Heat Sink Paste after wire dressing on area as shown.
Notes: Heat Sink Paste –Dow Corning 340 Heat Sink Compound to be used.
1
Assemble Backplate 10
2
Assemble Ball Swivel 11
3
Assemble Mainscord 15 & connect all wires
Apply Heat Sink Paste
4
Assemble T’stat Bush to Soleplate Mtd Assy
with Cover 1
5
Assemble Water Tank Assy 4
6
Assemble ASO (ASO version only),
connect wire & assemble Lamp Assy 2

Published by Philips Consumer Lifestyle Page 11 of 14 For internal use only
Document No. : CSW-07-081-20617
7
Assemble & fasten 2x Screw D &
dress all wires
8
Assemble Clamping Plate,
Assemble & fasten 2x Screw B
9
Assemble Inlay Assy 9
10
Assemble & fasten Screw C
Assemble Tank Top Seal 3
11
Assemble Ball Swivel 11 and Backplate 10
Assemble & fasten Screw A
12
Assemble SOS Knob 7 & Spray Knob 8
13
Assemble Spring Bullet 14,
assemble Bullet Moulded 13
14
Assemble T’stat Dial prted 12

Published by Philips Consumer Lifestyle Page 12 of 14 For internal use only
Document No. : CSW-07-081-20617
Service Lists
POS
DESCRIPTION
DST5030/26
889004226150
MALAYSIA
HONG KONG
SINGAPORE
DST5010/10
889003810040
TURKEY
DST5031/30
889004330300
RUSSIA
DST5040/86
889004486150
MALAYSIA
HONG KONG
SINGAPORE
1
S/P MTD ASSY WITH COVER
423902288601
423902288601
423902288601
423902288611
2
LAMP ASSY (ASO)
423902282471
423902282471
423902282471
423902282471
3
TANK TOP SEAL
423902288301
423902282501
423902288431
423902288481
4
WATER TANK ASSY
423902288311
423902288381
423902288441
423902288491
6
ASO
423902283421
-
423902283421
423902283421
7
SOS KNOB
423902288321
423902288391
423902288451
423902288501
8
SPRAY KNOB
423902288331
423902288401
423902288461
423902288511
9
INLAY ASSY
423902288341
423902288411
423902288471
423902288521
10
BACKPLATE
423902288351
423902288421
423902282951
423902282881
11
BALL SWIVEL
423902282971
423902282971
423902282971
423902283651
12
T'STAT DIAL PRTED
423902288371
423902288371
423902288371
423902288541
13
BULLET MOLDED
423902283261
423902283261
423902283261
423902283261
14
SPRING BULLET
423902283271
423902283271
423902283271
423902283271
15
MAINSCORD
423902274331
423902273971
423902273971
423902288551
POS
DESCRIPTION
DST5041/30
889004530300
RUSSIA
1
S/P MTD ASSY WITH COVER
423902288611
2
LAMP ASSY (ASO)
423902282471
3
TANK TOP SEAL
423902288431
4
WATER TANK ASSY
423902288561
6
ASO
423902283421
7
SOS KNOB
423902288571
8
SPRAY KNOB
423902288581
9
INLAY ASSY
423902288591
10
BACKPLATE
423902282881
11
BALL SWIVEL
423902283651
12
T'STAT DIAL PRTED
423902288541
13
BULLET MOLDED
423902283261
14
SPRING BULLET
423902283271
15
MAINSCORD
423902274301

Published by Philips Consumer Lifestyle Page 13 of 14 For internal use only
Document No. : CSW-07-081-20617
Service Lists
- Exploded view
Notes:
Scale: Not to scale

Published by Philips Consumer Lifestyle Page 14 of 14 For internal use only
Document No. : CSW-07-081-20617
Revision History
Version
Records
Author
Date
1
New release
Chong Yoke Lan
24-Dec-2020
