Philips GC2800 Series User manual

GC2800 Series

2

3
D E F GA B C
JKLM
H
I
1

4

GC2800 SERIES
ENGLISH 6
INDONESIA 18
한국어 30
ภาษาไทย 42
 51

6
Introduction
Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips.
com/welcome.
General description (Fig. 1)
ASpray nozzle
B Cap of lling opening
CSpray button 8
DSteam control
- b= Calc-Clean function
- 0 = no steam
- l= minimum steam
- ;= maximum steam
ESteam boost button \
FAuto-off light (GC2860 only)
GMains cord
HTemperature light
IAnti-Calc tablet (GC2860/GC2840/GC2830/GC2820 only)
Note:Anti-Calc tablet not visible from the outside.
JType plate
KWater tank
LTemperature dial
MSoleplate
Important
Read this user manual carefully before you use the appliance and save it
for future reference.
Danger
- Never immerse the iron in water.
Warning
- Check if the voltage indicated on the appliance corresponds to the
local mains voltage before you connect the appliance.
ENGLISH

- Do not use the appliance if the plug, the mains cord or the appliance
itself shows visible damage, or if the appliance has been dropped
or leaks.
- If the mains cord is damaged, you must have it replaced by Philips, a
service centre authorised by Philips or similarly qualied persons in
order to avoid a hazard.
- Never leave the appliance unattended when it is connected to the
mains.
- This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.
- Do not let the mains cord come into contact with the hot soleplate
of the iron.
Caution
- Only connect the appliance to an earthed wall socket.
- Check the mains cord regularly for possible damage.
- The soleplate of the iron can become extremely hot and may cause
burns if touched.
- When you have nished ironing, when you clean the appliance, when
you ll or empty the water tank and also when you leave the iron
even for a short while: set the steam control to position O, put the
iron on its heel and remove the mains plug from the wall socket.
- Always place and use the iron on a stable, level and horizontal
surface.
- Do not put perfume, vinegar, starch, descaling agents, ironing aids or
other chemicals in the water tank.
- This appliance is intended for household use only.
Electromagnetic elds (EMF)
This Philips appliance complies with all standards regarding
electromagnetic elds (EMF). If handled properly and according to the
ENGLISH 7

instructions in this user manual, the appliance is safe to use based on
scientic evidence available today.
Before rst use
1 Remove any sticker or protective foil from the soleplate.
2 Let the iron heat up to maximum temperature and pass the iron
over a piece of damp cloth for several minutes to remove any
residues from the soleplate.
Preparing for use
Filling the water tank
Do not put perfume, vinegar, starch, descaling agents, ironing aids,
chemically descaled water or other chemicals in the water tank.
1 Switch off the appliance and unplug it.
2 Set the steam control to position 0 (= no steam) (Fig. 2).
3 Openthecapofthellingopening.
4 Tilttheironandllthewatertankuptomaximumlevelunderthe
tap (Fig. 3).
Note: Do not ll the water tank beyond the MAX indication.
Note: If the tap water in your area is very hard, we advise you to use distilled
water. Do not use chemically descaled water.
5 Closethecapofthellingopening(‘click’).
Selecting the temperature and the steam settings
Fabric type Temperature
setting
Steam
setting
Steam boost
Linen MAX &Yes
Cotton 3&Yes
ENGLISH8

Fabric type Temperature
setting
Steam
setting
Steam boost
Wool 2$N.A.
Silk 10 N.A.
Synthetic fabrics (e.g.
Acrylic, nylon,
polyamide, polyester).
10 N.A.
- Check the laundry care label for the required ironing temperature:
If you do not know what kind or kinds of fabric an article is made of,
determine the right ironing temperature by ironing a part that will not be
visible when you wear or use the article.
Silk, woollen and synthetic materials: iron the reverse side of the fabric to
prevent shiny patches. Avoid using the spray function to prevent stains.
1 To set the appropriate ironing temperature, turn the temperature
dialtotheappropriateposition(see‘Temperatureandsteam
settingstable’)(Fig.4).
2 Settheappropriatesteamsetting(see‘Temperatureandsteam
settingstable’).
Note: Make sure that the steam setting you select is suitable for the set
ironing temperature.
3 Put the iron on its heel.
4 Put the mains plug in an earthed wall socket.
,The temperature light goes on.
5 When the temperature light goes out, wait a while before you start
ironing.
,During ironing, the temperature light goes on from time to time.
This indicates that the iron is heating up to the set temperature.
ENGLISH 9

Using the appliance
Note: The iron may give off some smoke when you use it for the rst time.
This stops after a short while.
Steam ironing
1 Make sure that there is enough water in the water tank.
2 Settherecommendedironingtemperature(seechapter‘Preparing
foruse’,‘Temperatureandsteamsettingtable’).
3 Set the appropriate steam setting. Make sure that the steam setting
is suitable for the ironing temperature selected:
- $for minimum steam (temperature settings 2and 3).
- &for maximum steam (temperature settings 3to MAX).
Note:The iron starts to produce steam as soon as it has reached the set
temperature.
Ironing without steam
1 Set the steam control to position 0 (= no steam) (Fig. 2).
2 Settherecommendedironingtemperature(seechapter‘Preparing
foruse’,‘Temperatureandsteamsettingtable’).
Features
Spray function
You can use the spray function at any temperature to moisten the article
to be ironed.This helps remove stubborn creases.
1 Make sure that there is enough water in the water tank.
2 Press the spray button several times to moisten the article to be
ironed (Fig. 5).
Steam boost function
A powerful boost of steam helps to remove very stubborn creases.
The steam boost function only works at temperature settings between
3and MAX.
ENGLISH10

1 Press and release the steam boost button (Fig. 6).
Vertical shot of steam
You can also use the steam boost function when you hold the iron in
vertical position.This is useful for removing creases from hanging clothes,
curtains etc.
1 Hold the iron in vertical position and press and release the steam
boost button (Fig. 7).
Never direct the steam at people.
Drip stop
This iron is equipped with a drip-stop function: the iron automatically
stops producing steam when the temperature is too low to prevent
water from dripping out of the soleplate.When this happens you hear a
click sound.
Automatic shut-off function (specic types only)
The automatic shut-off function automatically switches off the iron if it
has not been moved for a while.
,Theredauto-offlightashestoindicatethattheironhasbeen
switched off by the automatic shut-off function (Fig. 8).
To let the iron heat up again:
1 Pick up the iron or move it slightly.
,Theautomaticshut-offlightstopsashing.
,If the temperature of the soleplate has dropped below the set
ironing temperature, the temperature light goes on.
2 If the temperature light goes on after you have moved the iron,
wait for it to go out before you start ironing.
Note: If the temperature light does not go on after you move the iron, the
soleplate still has the right temperature and the iron is ready for use.
ENGLISH 11

Cleaning and maintenance
Cleaning
1 Set the steam control to position 0, remove the plug from the wall
socket and let the iron cool down.
2 Wipeakesandanyotherdepositsoffthesoleplatewithadamp
cloth and a non-abrasive (liquid) cleaning agent.
To keep the soleplate smooth, avoid hard contact with metal objects.
Never use a scouring pad, vinegar or other chemicals to clean the
soleplate.
3 Clean the upper part of the iron with a damp cloth.
4 Regularly rinse the water tank with water. Empty the water tank
after you have rinsed it (Fig. 9).
Double-Active Calc System (specic types only)
Note: Refer to chapter ‘General description’ for the specic type numbers.
The Double-Active Calc System consists of an Anti-Calc tablet inside the
water tank combined with the Calc-Clean function.
- The Anti-Calc tablet prevents scale from clogging the steam vents.
The tablet is constantly active and does not need to be
replaced (Fig. 10).
- The Calc-Clean function removes scale particles from the iron.
Calc-Clean function
Use the Calc-Clean function once every two weeks. If the water in your
area is very hard (i.e. when akes come out of the soleplate during
ironing), use the Calc-Clean function more frequently.
1 Make sure the appliance is unplugged.
2 Set the steam control to position 0.
3 Fill the water tank to the maximum level.
Do not pour vinegar or other descaling agents into the water tank.
4 Set the temperature dial to MAX (Fig. 11).
ENGLISH12

5 Put the mains plug in an earthed wall socket.
6 Unplug the iron when the temperature light goes out.
7 Hold the iron over the sink. Push the steam control to the Calc-
Clean position and hold it. Gently shake the iron to and
fro (Fig. 12).
,Steam and boiling water come out of the soleplate. Impurities and
akes(ifany)areushedout.
8 Release the steam control as soon as all the water in the tank has
been used up.
9 Repeat the Calc-Clean process if the iron still contains a lot of
impurities.
After the Calc-Clean process
1 Put the plug back into the wall socket and let the iron heat up to
let the soleplate dry.
2 Unplug the iron when the temperature light goes out.
3 Move the iron gently over a piece of used cloth to remove any
water stains that may have formed on the soleplate.
Storage
1 Set the steam control to position 0, remove the plug from the wall
socket and let the iron cool down.
2 Wind the mains cord round the cord storage facility (Fig. 13).
3 Store the iron on its heel in a safe and dry place.
Environment
- Do not throw away the appliance with the normal household waste
at the end of its life, but hand it in at an ofcial collection point for
recycling. By doing this, you help to preserve the
environment (Fig. 14).
ENGLISH 13

Guarantee & service
If you need service or information or if you have a problem, please visit
the Philips website at www.philips.com or contact the Philips Consumer
Care Centre in your country (you nd its phone number in the
worldwide guarantee leaet). If there is no Consumer Care Centre in
your country, go to your local Philips dealer.
Troubleshooting
This chapter summarises the most common problems you could
encounter with the appliance. If you are unable to solve the problem with
the information below, contact the Consumer Care Centre in your
country.
Problem Cause Solution
The iron is
plugged in, but
the soleplate is
cold.
There is a
connection
problem.
Check the mains cord, the plug
and the wall socket.
The temperature
dial is set to MIN.
Set the temperature dial to the
required position.
The iron does
not produce any
steam.
There is not
enough water in
the water tank.
Fill the water tank (see chapter
‘Preparing for use’, section
‘Filling the water tank’).
The steam control
is set to position 0. Set the steam position to $
or &(see chapter ‘Using the
appliance’, section ‘Steam
ironing’).
ENGLISH14

Problem Cause Solution
The iron is not hot
enough and/or the
drip-stop function
has been activated.
Set an ironing temperature
that is suitable for steam
ironing ( 2to MAX). Put the
iron on its heel and wait until
the temperature light goes out
before you start ironing.
The steam
boost function
does not work
properly.
You have used the
steam boost
function too often
within a very
short period.
Continue ironing in horizontal
position and wait a while
before you use the steam
boost function again.
The iron is not hot
enough.
Set an ironing temperature at
which the steam boost
function can be used ( 3
to MAX). Put the iron on its
heel and wait until the
temperature light goes out
before you use the steam
boost function.
Flakes and
impurities come
out of the
soleplate during
ironing.
Hard water forms
akes inside the
soleplate.
Use the Calc-Clean function
one or more times (see
chapter ‘Cleaning and
maintenance’, section ‘Calc-
Clean function’).
The light on the
handle ashes
(GC2860 only).
The automatic
shut-off function
has been activated
(see chapter
‘Features’, section
‘Automatic shut-
off’).
Pick the iron up or move it
slightly to deactivate the
automatic shut-off function.
The automatic shut-off light
goes out.
ENGLISH 15

Problem Cause Solution
Water droplets
drip on the
fabric during
ironing.
You have not
closed the cap of
the lling opening
properly.
Press the cap until you hear a
click.
The set
temperature is too
low for steam
ironing.
Set an ironing temperature
that is suitable for steam
ironing ( 2to MAX). Put the
iron on its heel and wait until
the temperature light goes out
before you start ironing.
You have put an
additive in the
water tank.
Rinse the water tank and do
not put any additive in the
water tank.
You have used the
steam boost
function at a
setting below
3.
Set the temperature dial to a
setting between 3and
MAX.
You have used the
steam boost
function too often
within a short
period.
Continue ironing in horizontal
position and wait a while
before you use the steam
boost function again.
Water drips
from the
soleplate after
the iron has
cooled down or
has been stored.
You have put the
iron in horizontal
position while
there was still
water in the water
tank.
Empty the water tank and set
the steam control to position
0 after use. Store the iron on
its heel.
ENGLISH16

Problem Cause Solution
Water spots
appear on the
garment during
ironing.
These wet spots
may be caused by
steam that has
condensed onto
the ironing board.
Iron wet spots without steam
from time to time to dry them.
If the underside of
the ironing board
is wet, wipe it dry
with a piece of dry
cloth.
To prevent steam from
condensing onto the ironing
board, use an ironing board
with wire mesh top.
ENGLISH 17

18
Pendahuluan
Selamat atas pembelian Anda dan selamat datang di Philips! Untuk
memanfaatkan sepenuhnya dukungan yang ditawarkan Philips, daftarkan
produk Anda di www.philips.com/welcome.
Gambaran umum (Gbr. 1)
ANozel semprotan
BTutup lubang pengisian
CTombol semprotan 8
DKontrol uap
- b= fungsi Calc-Clean
- 0 = tanpa uap
- l= uap minimum
- ;= uap maksimum
ETombol semburan uap \
FLampu mati-otomatis (hanya GC2860)
GKabel listrik
HLampu suhu
ITablet Anti-Calc (hanya GC2860/GC2840/GC2830/GC2820)
Catatan: Tablet Anti-Calc tidak terlihat dari luar.
JPelat jenis
KTangki air
LPutaran suhu
MTapak setrika
Penting
Bacalah petunjuk pengguna ini secara saksama sebelum Anda
menggunakan alat dan simpan untuk referensi di kemudian hari.
Bahaya
- Jangan sekali-kali merendam setrika di dalam air.
Peringatan
- Periksalah apakah voltase pada alat sesuai dengan voltase listrik di
rumah Anda, sebelum menghubungkan alat.
INDONESIA

- Jangan menggunakan alat jika steker, kabel listrik atau alat itu sendiri
menunjukkan kerusakan, atau jika alat pernah terjatuh atau bocor.
- Jika kabel listrik rusak, maka harus diganti oleh Philips, pusat servis
resmi Philips atau orang yang mempunyai keahlian sejenis agar
terhindar dari bahaya.
- Jangan sekali-kali meninggalkan alat tanpa pengawasan saat masih
tersambung ke arus listrik.
- Alat ini tidak dimaksudkan untuk digunakan oleh orang (termasuk
anak-anak) dengan cacat sik, indera atau kecakapan mental yang
kurang, atau kurang pengalaman dan pengetahuan, kecuali jika mereka
diberikan pengawasan atau petunjuk mengenai penggunaan alat oleh
orang yang bertanggung jawab bagi keselamatan mereka.
- Anak kecil harus diawasi untuk memastikan mereka tidak bermain-
main dengan alat ini.
- Jangan sampai kabel listrik mengenai tapak setrika saat sedang panas.
Perhatian
- Alat hanya boleh dihubungkan ke stopkontak dinding yang telah
dibumikan.
- Periksa kabel listrik secara teratur kalau-kalau ada kerusakan.
- Tapak setrika dapat menjadi sangat panas dan menyebabkan luka
bakar jika tersentuh.
- Apabila Anda sudah selesai menyetrika, ketika membersihkan alat,
mengisi atau mengosongkan tangki airnya dan juga saat Anda
meninggalkan setrika meskipun hanya sebentar: setel kontrol uap ke
posisi O, letakkan setrika pada tumitnya dan cabut steker listrik dari
stopkontak dinding.
- Selalu simpan dan gunakan setrika pada permukaan yang stabil, rata
dan pada posisi horizontal.
- Jangan memasukkan parfum, cuka, kanji, zat pembersih kerak, bahan
pelembut penyetrikaan atau bahan kimia lainnya ke dalam tangki air.
- Alat ini hanya untuk keperluan rumah tangga.
Medan elektromagnet (EMF)
Alat Philips ini mematuhi semua standar yang berkenaan dengan medan
elektromagnet (EMF). Jika ditangani dengan benar dan sesuai dengan
INDONESIA 19

instruksi petunjuk pengguna ini, alat tersebut aman digunakan berdasarkan
pada bukti ilmiah yang kini tersedia.
Sebelum menggunakan alat pertama kali.
1 Lepaskan stiker atau foil pelindung dari pelat tapak setrika.
2 Panaskan setrika sampai suhu maksimum dan setrikakan pada
sehelai kain lembab selama beberapa menit untuk menghilangkan
sisa-sisa kotoran dari tapak setrikanya.
Menyiapkan penggunaan
Mengisi tangki air.
Jangan memasukkan parfum, cuka, kanji, zat pembersih kerak, alat bantu
penyetrikaan, bahan kimia pembersih kerak atau bahan kimia lainnya ke
dalam tangki air.
1 Matikan alat dan cabut stekernya.
2 Setel kontrol uap ke posisi 0 (= tanpa uap) (Gbr. 2).
3 Buka tutup lubang pengisian.
4 Miringkan setrika dan isi tangki air hingga batas maksimum (Gbr. 3).
Catatan: Jangan mengisi tangki air melewati tanda batas MAKS.
Catatan: Jika air keran di daerah Anda memiliki kesadahan yang sangat
tinggi, kami sarankan Anda menggunakan air distilasi. Jangan menggunakan
cairan yang mengandung bahan kimia.
5 Pasangtutuplubangpengisian(hinggaberbunyi‘klik’).
Memilih setelan suhu dan uap
Jenis kain Setelan suhu Setelan uap Semburan
uap
Linen MAKS &Ya
Katun 3&Ya
INDONESIA20
