Philips HI 980 User manual

Supervapor Professional
HI 980
HI 984
Philips Domestic Appliances and Personal Care
PRODUCT INFORMATION
HI 980 HI 984
soleplate linished linished
manometer - x
steam control knob - x
pilot light for refilling boiler - x
steam output > 45 gr / min > 45 gr / min
Voltage : 220 - 240 V
Power consumption : Boiler 1200 Watts
Iron 800 Watts
Soleplate temperature : Dial at max. position : 205 ± 25 ºC
Features : contents boiler 0.9 litre
: length steam hose 1.7 m
: length cordset 2.0 m.
Product meets the requirements regarding interference
suppression on radio and TV.
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands ©Copyright reserved Subject to modification
4822 729 21713
96/11
PCS 88 245

pos description service code HI 980 HI 984
1
2
3
4
insert dial
dial ring
microswitch
lever microswitch
4822 410 11017
4822 532 12772
4822 282 30239
4822 402 10688
x
x
x
x
x
x
x
x
5
6+7
8
9
cover microswitch
handle right + left prt
swivel, colour black
steam hose/elect. cable
4822 442 00787
4822 310 10944
4822 325 10193
4822 530 10377
x
x
x
x
x
x
x
x
10
11
12
13
pilot light
cork grip
clamping ring
clamping ring
4822 134 10076
4822 498 10638
4822 492 71001
4822 532 12742
x
x
x
x
x
x
x
x
14
15
16
17
sleeve
connect. bracket therm.
metal cover
insulating bracket
4822 325 10194
4822 402 10689
4822 442 00788
4822 466 11473
x
x
x
x
x
x
x
x
18
19
20
21
sole plate + pos. 19
thermostat
insulating plate
bracket + item 22 and 23
4822 259 10234
4822 282 30238
4822 466 11474
4822 310 10945
x
x
x
x
x
x
x
x
24 hose joint 4822 526 10669 x x
DIAL 1
RING 2
MICROSWITCH 3
LEVER
MICROSWITCH 4
remove SCREW A
remove COVER
MICROSWITCH 5
lift MICROSWITCH 3
unsolder WIRING
rem
rem
rem
rem
disas
rem
rem
rem
disas
rem
rem
PARTS LIST IRON DISASSEMBLY ADVICE IRON

5
3
REPLACE
HANDLE 6 + 7
remove SCREW B
remove SCREW C
remove SCREW D
remove SCREW E
REPLACE SWIVEL 8
REPLACE HOSE 9
REPLACE
PILOT LAMIP 10
disassemble HANDLE
PARTS 6+7
remove SCREW F 2 x
remove CONNECTING
WIRES
remove CLAMP( S )
REPLACE
CORK GRIP 11
disassemble HANDLE
PARTS 6+7
remove SCREW G
remove SCREW H
REPLACE COVER 16
REPLACE
SOLE PLATE 18
REPLACE
THERMOSTAT 19
REPLACE
INSULATING PLATE 20
remove DIAL 1
remove RING 2
remove HANDLE
PARTS 6+7
remove HOSE
remove SLEEVE
remove CORK GRIP
remove SCREW I
remove BRACKET 21
turn conductor B through
180 degrees
remove PLATE 17
THERMOSTAT 19 ONLY
cut CONDUCTOR A
at location P
remove SCREW J
ASSEMBLY
REQUIREMENTS
THERMOSTAT 19
Instead of metal conductor A,
the new thermostat has a wire
with AMP clamp.
After fixing screw J, connect the
AMP clamp to tag Q.
After assembling cover 16
ALWAYS turn conductor B
through 180 degrees.
ADVICE IRON
ADJUSTMENT AND CONTROLS
Thermostat 19
Thermostat ( 19 ) supplied as a spare part or fitted to the sole plate
( 18 ) has already been adjusted by the supplier and secured by glue.
To avoid disfunction of the iron, NEVER readjust the
thermostat.
PCS 88 247

Parts list stand
pos description service code HI980 HI984
30
30.1
31
32
cap + safety valve
Sealing
tray
cover stand
4822 462 10895
4822 466 11489
4822 418 10243
4822 442 00789
x
x
x
x
x
x
x
x
33
34
35
36
rubber distance piece
rubber buffer
housing stand
boiler complete HI980
4822 325 71999
4822 466 11398
4822 441 11914
4822 218 11596
x
x
x
x
x
x
x
-
37
38
39
boiler complete HI984
steam hose ( black ) HI984 “Y - Y”
steam hose ( red ) HI980 “Z - Y”
cordset Euro, colour black
4822 218 11597
4822 530 10378
4822 530 10379
4822 321 11291
-
-
x
x
x
x
-
x
40
41
cordset Italy, colour black
cordset UK, colour black
switch(es) boiler
manometer
4822 321 11292
4822 321 11293
4822 276 13848
4822 349 11023
x
x
x
-
x
x
x
x
42
43
44
45
steam control valve
sealing of filling opening
clamping bracket hose
rubber foot
4822 360 10278
4822 532 12773
4822 401 11686
4822 462 10896
-
x
x
x
x
x
x
x
46 pilot light 4822 134 10077 x x
PARTS LIST + DISASSEMBLY ADVICE STAND
ADJUSTMENT AND CONTROLS
Pressostat 101
The pressostat ( 101 ) fixed to the boiler has already been adjusted.
The adjustment has been secured by glue.
To avoid dangerous situations, NEVER try to adjust or
readjust the pressostat.
IMPORTANT
− When the thermal fuse ( 104 ) is open, the boiler has been
subjected to too high temperatures.
In that case, the complete boiler must be replaced for
safety reasons.
− To avoid leakage of the sealings and damage to the components in
and on the boiler :
Never clean the boiler with vinegar, a descaling agent or
other chemicals.
−When the safety valve, located in the cap ( 30 ), has been
activated, the COMPLETE PRODUCT has to be replaced.
−THE COMPLETE BOILER HAS TO BE REPLACED WHEN:
*the pressostat ( 101 ) doesn’t function properly.
*the electrovalve ( 103 ) fails or the sieve is soiled with
scale.
*the thermal fuse ( 104 ), boiler thermostat ( 105 ) or hand
- resettable thermostat ( 106 ) are open, because the
boiler has been subjected to too high temperatures.
−When replacing the sealing of filling opening of the boiler
( 43 ), always add silicone pasta suitable for general
purposes.
−When the water hardness is higher than 17° DH / 21°
Clarke, it’s advised to use distilled water.
−Due to standardisation, only tube 37 “Y - Y” has been
incorporated into the service manual.
Components with numbers from 100 and higher cannot be ordered separarely
BOILER COMPLETE
The boiler complete
consists of:
boiler body
pressostat 101
sieve + electro valve 103
boiler thermostat 105
hand-resettable thermostat 106
fuse 104
sealing of the filling opening 43
pilot light( s ) boiler 46
cap + safety valve 30
electrical wiring
DISASSEMBLY ADVICE
STAND
to open the STAND
remove CAP 30
remove INLAY 31
remove SCREW K 6x
remove COVER 32
